Three 2 MP cameras face different directions to cover larger areas
One 2 MP camera for close-up view with 4x zoom ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to DWDR technology
Good night-time performance with up to 10 m IR
Lens
FOVHorizontal field of view: 120° to 56.6° (wide - tele),Vertical field of view: 61.8° to
31.7° (wide - tele),Diagonal field of view: 149° to 65° (wide - tele)
Focal Length2.8 mm to 12 mm, 4× optical zoom
Zoom SpeedApprox.5.4 s (optical, wide - tele)
Working Distance10 mm to 1500 mm (wide - tele)
Aperture RangeF2.0 to F2.4
Smart Features
Basic Event Detection Motion Detection, Video Tampering Detection, Exception
Smart Detection Audio Exception Detection, Intrusion Detection, Line Crossing
Detection
Smart Record ANR (Automatic Network Replenishment)
ROIMain stream supports eight fixed areas.
Smart Image Enhancement HLC/BLC/3D DNR/Regional Exposure/Regional Focus
MaterialPC + ABS & Aluminum alloy
DimensionsΦ 183 mm × 133 mm (Φ 7.20" × 5.24")
WeightApprox. 0.9 kg (1.98 lb)
Protection LevelTVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power 12 VDC, 2.0 A & PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class 4
Max.24 W (Max. 6 W for IR)
Working Temperature-10°C to 50°C (14°F to 122°F)
Working Humidity≤ 90%

High quality imaging with 4 MP resolution
Support Human and Vehicle Detection
Smart Dual-Light: advanced technology with long range
Built-in microphone for real-time audio security
Water and dust resistant (IP67) and vandal resistant (IK08)
Efficient H.265+ compression technology
Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle AdjustmentPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93°
Lens MountM12
Iris Type Fixed
ApertureF1.6
Power 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W
Material Metal & Plastic
DimensionØ121.4 mm × 97.7 mm (Ø4.8" × 3.8")
Package Dimension150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
WeightApprox. 550 g (1.2 lb.)
With Package WeightApprox. 800 g (1.8 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

High quality imaging with 4 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67)
Motorized varifocal lens for easy installation and monitoring
Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. IlluminationColor: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR Cut Filter
Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360°
Lens
Lens TypeVarifocal lens, motor-driven lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm: horizontal FOV 102° to 31°, vertical FOV 55° to
18°, diagonal FOV 122° to 36°
Lens MountØ14
Iris TypeFixed
ApertureF1.6
General
Power 12 VDC ± 25%, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
Dimension Ø105 mm × 244.4 mm (Ø4.1" × 9.6")
Package Dimension 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
Weight Approx. 1035 g (2.3 lb.)
With Package Weight Approx. 1550 g (3.4 lb.)
Storage Conditions-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing)

Port Fast Ethernet Unmanaged POE Switch

Unmanaged switch with 4 x 100 Mbps PoE ports and 1 x 100 Mbps uplink port
All ports support 6 kV lighting protection
35 W PoE power budget
Maximum transmission distance is 250 meters
MAC address auto learning and auto aging

General
ShellMetal material, fan-free design
Operating temperature-10 °C to 55 °C (14 °F to 131 °F)
Storage temperature-40 °C to 85 °C (-40 °F to 185 °F)
Power supply48 VDC, 0.8 A
Storage humidity5% to 95% (no condensation)
Net weight 0.2 kg (0.4 lb)
Gross weight 0.48 kg (1.06 lb)
Dimension (L × H × D)105 mm × 27.6 mm × 83.1 mm (4.1” × 1.1” × 3.3”)
Operating humidity5% to 95% (no condensation)
Power consumption in idle3 W
PoE power supply
PoE standard IEEE 802.3af, IEEE 802.3at
PoE power pin Supports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply
PoE port Ports 1 to 4
Max. port power30 W
PoE power budget35 W
Max. power consumption38 W

MikroTik's RB-WAPAX is a WiFi 6 AX3000 outdoor router featuring a dual core processor, 2x Gigabit Ethernet Ports, PoE and DC powering options and can be wall, ceiling or pole mounted. It allows for an Ethernet cable to be run directly from the back of the case and is secured with an anti-vandal screw for added security.

WI-FI 6 TECHNOLOGY Features advanced 802.11ax wireless technology for higher speeds and improved network efficiency in high-density environments
DUAL CHAIN MIMO: Equipped with 2x2 MIMO technology for higher signal strength, better coverage and reliable wireless connections
WEATHER RESISTANT DESIGN Built to withstand various weather conditions, making it suitable for both indoor and outdoor installations
VERSATILE MOUNTING Compact form factor allows flexible placement options on walls, posts or other surfaces
Performance Features: Supports dual-band operation with advanced wireless protocols for optimal network performance

Antenna Gain: 2.4GHz: 7dBi ; 5.8GHz: 7dBi
Beam-width: 180°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop, Ceiling, Pole & Wall-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18-57V Passive PoE ; 802.3af/at
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V (PoE) 12-57V (DC Jack Input)
USB Ports: None

Dimensions: 185 x 85 x 30 mm

Reyee's RG-RAP1206X is a WiFi 6 (802.3ax) Dual Band, In-Wall Access Point featuring 5x Gigabit Ethernet Ports with PoE-Input and smart AI roaming. The unit supports up to 2976Mbps with 574Mbps on 2.4GHz and 2402Mbps on 5.8GHz and includes a mounting plate for quick and easy installation. It supports Ruijie’s smart networking feature, which with Ruijie's free cloud service allows users to quickly and easily auto-provision, deploy and manage devices remotely. Use the Reyee auto-discovery feature or scan the QR code using the mobile application to easily add devices to new or existing projects via the cloud.

Specifications

Antenna Gain: 2.4GHz: 3dBi; 5.8GHz: 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps; 5.8GHz: 2402Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Wall-Mount (Mounting Bracket Included)
Operating System: Reyee
Operating Temperature: 0°C to 40°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 802.3af/at
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 37-57V
USB Ports: None
Dimensions: 124 × 86 × 24 mm
Weight: 500g

Reyee's RG-RAP72-IW In-Wall Dual Band WiFi 7 Access Point features a WiFi 7 radio providing data rates of up to 3600Mbps, 4x Gigabit Ethernet Ports, 1x 2.5G Ethernet uplink Port, PoE output for IP Phones or IoT devices, all powered by 802.3af/at PoE.

It supports Ruijie’s smart networking feature, which, with Ruijie's free cloud service, allows users to quickly and easily auto-provision, deploy and manage devices remotely. Use the Reyee auto-discovery feature or scan the QR code using the mobile application to easily add devices to new or existing projects via the cloud.

*Note: PoE Injector not included.

Specifications

Antenna Gain: 2.4GHz: 2.84dBi; 5GHz: 4.56dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 2882Mbps
Ethernet Ports: 4x 10/100/1000; 1x 10/100/1000/2500
Hardware Button: Reset
Max Power Consumption: 15W
Mounting: Wall-Mount
Operating System: Reyee
Operating Temperature: 0°C to 40°C
PoE Input: 802.3af/at
PoE Output: PoE passthrough on port 4
Power Input: 802.3af/at
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 37-57V
USB Ports: None
Dimensions: 124 x 86 x 24 mm
Weight: 270g

305m box of CAT5e Economy CCA Ethernet cable suitable for home installations or shorter cable runs. This Economy cable is a very cost-effective option when doing cable installations with short runs (we do not recommend exceeding cable runs longer then 50m).

The Economy cable is great for installations on a budget where only data connectivity is required and is not recommended for any Power over Ethernet (PoE) applications. Comes in a generic easy-pull box, and the CAT5e cable features a 0.50mm CCA conductor core.

Please take note: For applications where PoE is used, it is recommended to use UltraLAN Premium Series cable.


General Specifications

Packaging: 305m Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey
Product Dimensions ‏ : ‎ 4.05 x 2.1 x 2.1 cm; 4.05 kg

305m Economy CAT6 CCA Solid UTP Cable


305m box of CAT6 Economy CCA Ethernet cable suitable for home installations or shorter cable runs. This Economy cable is a very cost effective option when doing cable installations with short runs (we do not recommend exceeding cable runs longer then 50m).

The Economy cable is great for installations on a budget where only data connectivity is required, and is not recommended for any Power over Ethernet (PoE) applications. Comes in a generic easy-pull box, and the CAT6 cable features a 0.50mm CCA conductor core.

Please take note: For applications where PoE is used, it is recommend to use UltraLAN Bare Copper cable.


General Specifications

Packaging: 305m Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Product Dimensions ‏ : ‎ 4.05 x 2.1 x 2.1 cm; 4.05 kg

Cudy's CD-FS1010P is a 10 Port Fast Ethernet switch with 8x 802.3af/at PoE ports and 2x Fast Ethernet Uplink ports. The switch offers a 115W PoE budget, up to 32W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-8 while Extender mode increases the transmission distance on ports 1-8 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 10x 10/100
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 5W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100-240V
Dimensions: 220 x 150 x 40mm
Weight: 800g

Cudy's CD-GS1010P is a 10-Port Gigabit switch with 8x 802.3af/at PoE ports and 2x Gigabit Uplink ports. The switch offers a 100W PoE budge with up to 30W per port. Both VLAN and Extender modes are supported with the integrated toggle switch. VLAN mode enables port isolation on ports 1-8 while Extender mode increases the transmission distance on ports 7-8 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 10x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 20W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100-240V
Dimensions: 220 x 150 x 44 mm
Weight: 1kg

Cudy's CD-FS1018PS is a 16-Port Fast Ethernet switch with 16x 802.3af/at PoE ports, 2x Gigabit, and 1x SFP Uplink ports. The switch offers a 190W PoE budget, up to 30W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-16 while Extender mode increases the transmission distance on ports 1-16 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 16x 10/100; 2x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 10W
Mounting: Rack-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 210 x 50mm
Weight: 1.8kg

Cudy's CD-GS1018PS is a 16 Port Gigabit switch with 16x 802.3af/at PoE ports, 2x Gigabit and 2x SFP Uplink ports. The switch offers a 180W PoE budget and up to 30W per PoE port. Extender Mode increases the transmission distance on ports 9-16 to 250m at 10Mbps. The Watchdog function continuously monitors PoE connections when in Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 18x 10/100/1000
Hardware Button: Extender; Default
Max. Power Consumption: 10W
Mounting: Rack-Mount
Operating System: None
Operating Temperature: -10~50°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 207 x 44 mm
Weight: 2.28kg

Cudy's CD-GS1016 is a 16 Port Gigabit Switch that supports both Desktop and Rack-Mount options. It features a toggle switch with VLAN, Extender and Default Modes. In Default mode, all ports operate freely. VLAN mode enables port isolation on ports 1-14 while Extender mode increases the transmission distance on ports 1-14 to 250m at 10Mbps.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: None
Max. Power Consumption: 15W
Mounting: Desktop or Rackmount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100V-240V
Dimensions: 200 x 118 x 44mm

Cudy's CD-GS1016 is a 16 Port Gigabit Switch that supports both Desktop and Rack-Mount options. It features a toggle switch with VLAN, Extender and Default Modes. In Default mode, all ports operate freely. VLAN mode enables port isolation on ports 1-14 while Extender mode increases the transmission distance on ports 1-14 to 250m at 10Mbps.
Specifications Ethernet Ports: 16x 10/100/1000
Hardware Button: None
Max. Power Consumption: 15W
Mounting: Desktop or Rack-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100V-240V

Dimensions: 200 x 118 x 44mm

Cudy's CD-FS1026PS is a 26-Port Fast Ethernet switch with 24x 802.3af/at PoE ports, 2x Gigabit, and 1x SFP Uplink ports. The switch offers a 290W PoE budget, up to 30W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-24 while Extender mode increases the transmission distance on ports 1-24 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 24x 10/100; 2x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 10W
Mounting: Rackmount
Operating System: None
Operating Temperature: -20°C to 50°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~24
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 210 x 50mm
Weight: 1.9kg

Cudy's CD-GS1026PS is a 24 Port Gigabit switch with 24x 802.3af/at PoE ports, 2x Gigabit and 2x SFP Uplink ports. The switch offers a 280W PoE budget and up to 30W per PoE port. In Extended Mode, the transmission range on ports 17-24 is extended to 250 meters at 10Mbps. The Watchdog function continuously monitors PoE connections when in Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 26x 10/100/1000
Hardware Button: Extended; Default
Max. Power Consumption: 20W
Mounting: Rack-Mount
Operating System: None
Operating Temperature: -10~50°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~24
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 207 x 44 mm
Weight: 2.5kg

Cudy's CD-GS1024 is a 24 Port Gigabit Switch that supports both desktop and rack-mount options. It features a toggle switch with VLAN, Extender and Default modes. In Default mode all ports operate freely. VLAN mode enables port isolation on ports 1-22 while Extender mode increases the transmission distance on ports 1-22 to 250m at 10Mbps.
Ethernet Ports: 24x 10/100/1000
Hardware Button: None
Max. Power Consumption: 15W
Mounting: Desktop or Rack-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100V-240V

Dimensions: 270 x 180 x 44mm

Provide a variety of installation methods for easy deployment in any environment
● Support 11-inch Rack-mount Steel Case
● Support Desktop installation

High Performance
Auto-negotiation RJ-45 ports can provide large file transferring and also be compatible with any 10/100/1000Mbps Ethernet devices. IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode offer increased bandwidth to alleviate network congestion, making the switch work reliably.

Power Saving
Save power up to 40% - The GS1024 uses green Ethernet technology to make your network compatible without compromising performance. The switch automatically powers down the ports that are idle and budgets power output for different Ethernet cable lengths. It helps you save power up to 40%.


Features
Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards
24 10/100/1000Mbps Auto-Negotiation, Auto-MDI/MDIX ports provide smart switching between 10Mbps, 100Mbps and 1000Mbps hardware
Non-blocking switching architecture enables full wire-speed packets forwarding and filtering
Store-and-Forward switching method
Supports 16K MAC address auto-learning and auto-agin

Cudy’s CD-GSPOE40 is a 4-Port Gigabit PoE switch with an 802.3af/at/bt Gigabit PoE input port. The switch can only be powered via PoE input on port 5. The switch has a maximum PoE budget of 60W when powered by 802.3bt and can supply up to 30W per port. It can be either desktop or wall mounted.

Specifications

Ethernet Ports: 5x 10/100/1000
Hardware Button: None
Max. Power Consumption: 5W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 45°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at PoE on Ports 1~4
Power Input: 802.3af/at/bt on Port 5
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 44-57V (802.3af/at/bt)
Dimensions: 119 x 85 x 28 mm

Cudy's CD-LT500O is an IP65 outdoor, dual band WiFi 5 (802.11ac) Fast Ethernet router. With an integrated CAT4 LTE modem, it reaches speeds of up to 50Mbps uplink and 150Mbps downlink. It features 1x Fast Ethernet port, 2x Internal WiFi antennas, 2x detachable LTE antennas, and an aggregate wireless data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system (only as the main router) as well as multiple VPN options including PPTP, L2TP, OpenVPN, Wire Guard, IPSec and Zero tier.

Specifications

Antenna Gain: LTE: 2x 5dBi; Wireless: 2.4GHz: 3.5 dBi ; 5GHz: 5dBi
Beam-width: 360°
Data Rate: LTE: 150Mbps Downlink; 50Mbps Uplink; Wireless: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset; WPS
Max. Power Consumption: 10W
Mounting: Pole-mount or Wall-mount
Operating System: Cudy
Operating Temperature: -20° to 60°
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE (Included)
Serial Interface: None
SIM Slots: 1 (Nano SIM)
Supported Voltage Range: 24V
USB Ports: None
Dimensions: 200 x 130 x 40mm
Weight: 299g
