Fanvil's FAN-X301 features dual Fast Ethernet ports, 2 SIP lines, HD Voice, IPv4/IPv6, Opus support, a 3-way conference function and an easy-to-read lattice display. The FAN-X301 is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: This IP phone is not compatible with PoE. A 5V 0.6A power supply is included.
Bluetooth Support: None
Ethernet Ports: 2x 10/100
Max Power Consumption: 1.86W
Headset Port: 1x RJ9
Mounting: Desktop or Wall-Mount when used with FAN-WB108
Operating Temperature: 0°C to 45°C
PoE Input: None
Power Input: 5V 0.6A Power Supply (Included)
SIP Lines: 2
WiFi Support: None

Dimensions: 169 x 201.1 x 177.4 mm

Fanvil's FAN-X301G features dual Gigabit Ethernet ports, 2 SIP lines, HD Voice, IPv4/IPv6, Opus support, a 3-way conference function and an easy-to-read lattice display. The FAN-X301G is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: Designed for use with a PoE switch or injector (not included). Alternatively, use with PSU-5V10W DC power supply, sold separately.
Bluetooth Support: None
Ethernet Ports: 2x 10/100/1000
Max Power Consumption: 1.86W
Headset Port: 1x RJ9
Mounting: Desktop or Wall-Mount when used with FAN-WB108
Operating Temperature: 0°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 5V 0.6A (Not included) or 802.3af/at PoE
SIP Lines: 2
WiFi Support: None

Dimensions: 169 x 201.1 x 177.4 mm

Fanvil's FAN-X303P features dual Fast Ethernet ports, 4 SIP lines, HD Voice, IPv4/IPv6, Opus support, a 3-way conference function and an easy-to-read lattice display. The FAN-X303P is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: Designed for use with a PoE switch or injector (not included). Alternatively, use with PSU-5V10W DC power supply, sold separately.
Bluetooth Support: None
Ethernet Ports: 2x 10/100

Max Power Consumption: 2.09W
Headset Port: 1x RJ9
Mounting: Desktop or Wall-Mount when used with FAN-WB108
Operating Temperature: 0°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 5V 0.6A (Not included) or 802.3af/at PoE
SIP Lines: 4
WiFi Support: None

Dimensions: 169 x 201.1 x 177.4 mm

Fanvil's FAN-V61W is a WiFi 6 desktop phone featuring dual Gigabit Ethernet ports, 4 SIP lines, Bluetooth & Opus support, integrated hall switch and a 2.4' colour LCD display. The FAN-V61W is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: Designed for use with a PoE switch or injector (not included). Alternatively, use with PSU-5V10W DC power supply, sold separately.
Bluetooth Support: Bluetooth 5.4
Ethernet Ports: 2x 10/100/1000
Max Power Consumption: 6.7W
Headset Port: 1x RJ9
Mounting: Desktop
Operating Temperature: 0°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 5V 1A (Not included) or 802.3af/at PoE
SIP Lines: 4
WiFi Support: Dual Band WiFi 6

Dimensions: 295 x 222 x 56 mm

Fanvil's FAN-X303 features dual Fast Ethernet ports, 4 SIP lines, HD Voice, IPv4/IPv6, Opus support, a 3-way conference function and a 2.4' colour LCD display. The FAN-X303 is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: This IP Phone is not compatible with PoE. A 5V 0.6A Power Supply is included.
Bluetooth Support: None
Ethernet Ports: 2x 10/100

Max Power Consumption: 2.09W
Headset Port: 1x RJ9
Mounting: Desktop or Wall-Mount when used with FAN-WB108
Operating Temperature: 0°C to 45°C
PoE Input: None
Power Input: 5V 0.6A Power Supply (Included)
SIP Lines: 4
WiFi Support: None

Dimensions: 169 x 201.1 x 177.4 mm

Fanvil's FAN-V61G features dual Gigabit Ethernet ports, 4 SIP lines, HD Voice, Opus support, a 6-way conference function, integrated hall switch and a 2.4' colour LCD display. The FAN-V61G is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.

*Note: Designed for use with a PoE switch or injector (not included). Alternatively, use with PSU-5V10W DC power supply, sold separately.
Bluetooth Support: None
Ethernet Ports: 2x 10/100/1000
Max Power Consumption: 6.7W
Headset Port: 1x RJ9
Mounting: Desktop
Operating Temperature: 0°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 5V 1A (Not included) or 802.3af/at PoE
SIP Lines: 4
WiFi Support: None

Dimensions: 295 x 222 x 56 mm

Fanvil's FAN-W610W features a 2.0” colour screen, IEEE802.11k/v/r roaming, built in Bluetooth and dual band WiFi with up to 9 hours of talk time. The FAN-W610W is compatible with major platforms such as 3CX, Broadsoft, Elastix, Asterisk, Xorcom and others.
Bluetooth Support: Integrated Bluetooth 5.0
Ethernet Ports: None
Battery Capacity: 1900mAH Rechargable
Headset Port: Compatible with Bluetooth 5.0
Mounting: Desktop
Operating Temperature: 0°C to 45°C
PoE Input: None
Power Input: 5V 2A Power Supply (Included)
SIP Lines: 4
WiFi Support: Dual Band WiFi 4

Dimensions: 156 x 53 x 17.7 mm
Weight: 147g

HiLook 8CH Hybrid DVR High Definition Stand Alone DVR - Support H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression, 8 Channel Analog and HD-TVI video input, BNC interface (1.0Vp-p, 75 Ω),supporting coaxitron connection, Audio Input: 1-ch RCA and 8-ch via coaxial cable Audio via coaxial cable, SATA Interface Support up to 4TB Hard disk drive, 10/100 self-adaptive Ethernet interface 2x USB 2.0 Ports on Rear panel, Supports real-time 1080p lite when enabled the image effect is similar to 1080p, HDMI/VGA output at up to 1920 × 1080 resolution, IP 2ch Up to 10-ch IP camera input (up to 5 MP), Signal Input HDTVI/AHD/CVI/CVBS/IP, Deep learning based human and vehicle targets classification of Motion Detection 2.0, 1U Mini White Unit, Smart search for efficient playback, Remote viewing from anywhere on pc and cellphone, Retail Box , 1 year warranty

Product Overview
HiLook 8CH Hybrid DVR High Definition Stand Alone DVR

Features

•H.265 Pro+/H.265 Pro/H.265 video compression
•HDTVI/AHD/CVI/CVBS/IP video input
•Up to 10-ch IP camera input (up to 5 MP)

Specifications

•Product code: DVR-108G-M1
•Description: HiLook 8CH Hybrid DVR High Definition Stand Alone DVR
•Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
•Encoding Resolution: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
•For 720p stream access: 720p/WD1/4CIF/VGA/CIF
•For SD stream access: WD1/4CIF/VGA/CIF
•Main stream:For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
•For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
•For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
•For 1080p and 720p stream access CIF/QVGA@15 fps
•For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
•Support H.265+/H.265/H.264+/H.264 IP cameras
•BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
•HDTVI Input:1080p25, 1080p30, 720p25, 720p30
•AHD Input: 1080p25, 1080p30, 720p25, 720p30
•HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
•HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
•VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
•Video Output Mode: HDMI/VGA simultaneous output
•Audio Input: 1-ch RCA (2.0 Vp-p, 1 KΩ)
•Audio Output: 1-ch, RCA (Linear, 1 KΩ)
•TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS
•1, RJ45 10/100 Mbps self-adaptive Ethernet interface
•Power Supply: 12 VDC, 1.5 A
•200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
•≤ 1 kg (without HDD, 2.2 lb.)

HiLook 16-ch 5 MP 1U H.265 DVR
Deep learning based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video inputs
Audio via coaxial cable
Up to 24-ch IP camera inputs (up to 8 MP)
Up to 8 MP@8 fps encoding capability

Motion Detection 2.0
Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported.

Video and Audio
IP Video Input 8-ch (up to 24-ch)
Enhanced IP mode on:
16-ch (up to 32-ch), each up to 4 Mbps Up to 8 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras

Analog Video Input 16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI Input 8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 3 MP@18 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps

AHD Input 5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps,
4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps

HDCVI Input8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 5 MP(2592 × 1944)@20
fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps,
720p@30 fps, 720p@25 fps

CVBS Input PAL/NTSC
HDMI Output 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz

VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Audio Input 1-ch, RCA (2.0 Vp-p, 1 KΩ) 16-ch via coaxial cable

Video Output Mode HDMI/VGA simultaneous output

Audio Output1-ch, RCA (Linear, 1 KΩ) Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the
audio input) Synchronous playback16-ch

Network
Total Bandwidth128 Mbps Remote Connection128 Network ProtocolTCP/IP, PPPoE, DHCP,
HiLookVision, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
Wi-FiConnectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary Interface
SATA2 SATA interfaces
Capacity Up to 10 TB capacity for each disk
USB Interface Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0
General
Power Supply12 VDC, 5 A
Consumption≤ 25 W (without HDD)

High quality imaging with 2 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to DWDR technology
Water and dust resistant (IP67) and vandal proof (IK10)
Easy installation with power over Ethernet (PoE) technology
Camera
Image Sensor1/2.7" Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100, 000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°
Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
Lens MountM12
Iris TypeFixed
ApertureF2.0
DimensionØ111 mm × 82.4 mm (Ø4.4" × 3.2")
Package Dimension134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Weight Approx. 410 g (0.9 lb.)
With Package Weight Approx. 610 g (1.3 lb.)

HiLook 24-Port 100 Mbps Long-Range Unmanaged PoE Switch
Unmanaged switch with 24 x 100 Mbps PoE ports, 1 x 1000 Mbps RJ45 port, and 1 x 1000 Mbps SFP port
All ports support 6 kV lighting protection
230 W PoE power budget
Maximum transmission distance is 250 meters for port 17 to 24 in "extend" mode
MAC address auto learning and auto aging

Port number24 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
Port typeRJ45 port, full duplex, MDI/MDI-X adaptive
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding mode Store-and-forward switching
Working mode Standard mode (default); Extend mode
High priority ports Ports 1 to 8
Ports for long-distance transmission Ports 17 to 24
MAC address table4 K
Switching capacity8.8 Gbps
Packet forwarding rate6.547 Mpps
Internal cache2.75 Mbits
PoE standard IEEE 802.3af, IEEE 802.3at
PoE power pin
Ports for long-distance transmission (17-24) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.
Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.
PoE port Ports 1 to 24
Max. port power30 W
PoE power budget230 W
Max. power consumption250 W
Shell Metal material
Gross weight3.33 kg (7.34 lb)
Net weight2.55 kg (5.6 lb)
Dimension (L × H × D)335 mm × 44.5 mm × 226 mm (13.2” × 1.8” × 8.9”)
Operating temperature-10 °C to 55 °C (14 °F to 131 °F)
Storage temperature-40 °C to 85 °C (-40 °F to 185 °F)
Operating humidity5% to 95% (no condensation)
Storage humidity5% to 95% (no condensation)
Power supply100 to 240 VAC, 50/60 Hz, Max. 4 A
Power consumption in idle20 W

4 MP Smart Hybrid Light MD 2.0 Fixed Bullet Network Camera
High quality imaging with 4 MP resolution
Support Human and Vehicle Detection
Smart Dual-Light: advanced technology with long range
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
Lens Type Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93°
Lens MountM12
Iris Type Fixed
ApertureF1.6
DORI
2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m
Illuminator
Supplement Light Type IR,White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength850 nm
General
Power
12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6.5 W
MaterialMetal & Plastic
Dimension184.1 mm × 66 mm × 69.1 mm (7.3" × 2.6" × 2.7")
Package Dimension216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight Approx. 270 g (0.6 lb.)
With Package Weight Approx. 481 g (1.1 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

High quality imaging with 4 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67) and vandal proof (IK10)
Motorized varifocal lens for easy installation and monitoring
Power
12 VDC ± 25%, 0.8 A, max. 10 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.32 A to 0.2 A, max. 11.5 W
DimensionØ141 mm × 99.9 mm (Ø5.6″ × 3.9″)
Package Dimension140 mm × 140 mm × 154 mm (5.5″ × 5.5″ × 6.1″)
WeightApprox. 820 g (1.8 lb.)
With Package WeightApprox. 1200 g (2.6 lb.)
Storage Conditions-30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing)
General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

HiLook 4-ch Mini 1U 4 PoE 4K NVR
Up to 8 channel IP cameras can be connected
Plug & Play with 8 Power-over-Ethernet (PoE) interfaces
Supports decoding H.264+/H.264 multiple video formats
Up to 4-ch @ 1080p decoding capacity
1 HDD for continuous video recording
Video and Audio
IP video input8-ch
Two-way audio input1-ch, RCA (2.0 Vp-p, 1kΩ)
Video/Audio output
HDMI/VGA output1-ch, resolution:1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output1-ch, RCA (Linear, 1kΩ)
Recording resolution4 MP/3 MP/1080p/1.3 MP/UXGA/720p/VGA/4CIF /DCIF/2CIF/CIF/QCIF
General
Power supply48 VDC
Working temperature-10 °C to +55 °C (14 °F to 131 °F)
Working humidity10 % to 90 %
Consumption (without hard disk and PoE)≤ 10 W
Chassis1U chassis
Dimensions(W × D × H)285 × 215 × 48 mm(11.2" × 8.5" × 1.9")
Weight(without hard disk)≤ 1 kg (2.2 lb)

High quality imaging with 6 MP resolution Support Human and Vehicle Detection
Smart Hybrid Light: advanced technology with long range Clear imaging even with strong back lighting due to 120 dB WDR technology Efficient H.265+ compression technology Support on-board storage up to 512 GB (SD card slot) Provide real-time security via built-in two-way audio
2.8 to 12 mm motorized varifocal lens for easy installation and monitoring Water and dust resistant (IP67)
Camera
Image Sensor1/2.4" Progressive Scan CMOS
Max. Resolution3200 × 1800
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
Lens Type Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to
20°, diagonal FOV 127.4° to 40.8°
Lens MountØ14
Iris TypeFixed
ApertureF1.6
DORI
DORID: 68 to 200 m, O: 27 to 79 m, R: 13.6 to 40 m, I: 6.8 to 20 m
General
Power 12 VDC ± 25%, 0.9 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 12.9 W
Material Metal
Dimension Ø105 mm × 285.8 mm (Ø4.13 × 11.25\")"
Package Dimension 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
Weight Approx. 805 g (1.8 lb.)
With Package Weight Approx. 1405 g (3.1 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

8 Port Gigabit Unmanaged Desktop Switch

8 x 10/100/1000 Mbps ethernet ports
Supports MDI/MIDX
Store-and-forward switching
Supports MAC address auto-learning and aging
Simple, compact body design
Supports desktop and wall-mounting
Plug & play, easy to use.
General
ShellABS
Net Weight0.093 kg (0.205 lb)
Gross Weight124.00 mm × 25.00 mm × 61.00 mm (4.88'' × 0.98'' × 2.40'')
Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity5% to 95% (no condensation)
Relative Humidity5% to 95% (no condensation)
Power Supply5 VDC, 1 A
Installation ModeDesk-Mounted
Network Parameters
Ports8 × Gigabit RJ45 port
MAC Address Table4 K
Switching Capacity16 Gbps
Packet Forwarding Rate11.90 Mpps
Internal Cache1.5 Mbits

8 Port Fast Ethernet Unmanaged POE Switch

Unmanaged switch with 8 x 100 Mbps PoE ports, 1 x 100 Mbps RJ45 port
All ports support 6 kV lighting protection
60 W PoE power budget
Maximum transmission distance is 250 meters for port 1 to 8 in "extend" mode
MAC address auto learning and auto aging
General
Shell Metal material, fan-free design
Operating temperature-10 °C to 55 °C (14 °F to 131 °F)
Storage temperature-40 °C to 85 °C (-40 °F to 185 °F)
Power supply48 VDC, 1.35 A
Storage humidity5% to 95% (no condensation)
Net weight0.35 kg (0.77 lb)
Gross weight0.89 kg (1.96 lb)
Dimension (L × H × D)170 mm × 27.6 mm × 93.1 mm (6.7” × 1.1” × 3.7”)
Operating humidity5% to 95% (no condensation)
Power consumption in idle5 W
Network parameters
Port number8 × 100 Mbps PoE ports, 1 × 100 Mbps Ethernet port
Port typeRJ45 port, full duplex, MDI/MDI-X adaptive
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding mode Store-and-forward switching
Working mode Standard mode (default); Extend mode
MAC address table2 K
Switching capacity1.8 Gbps
Packet forwarding rate1.339 Mpps
Internal cache1 Mbits
High priority ports Ports 1 to 2
Ports for long-distance transmission Ports 1 to 8

Four-inch 2 MP camera with pan, tilt and zoom (25x) ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Excellent night-time performance with up to 100 m enhanced IR
Water and dust resistant (IP66)

Camera
Image Sensor1/2.8" progressive scan CMOS
Max. Resolution1920 × 1080
Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC
ON),
0 Lux with IR
Shutter Speed1/1 s to 1/30,000 s
Day & NightIR Cut Filter
Zoom25x optical, 16x digital
Lens
Focal Length4.8 mm to 120 mm, 25× optical
FOV
Horizontal field of view: 57.6° to 2.5° (Wide-Tele),
Vertical field of view: 34.4° to 1.4° (Wide-Tele),
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
FocusAuto, semi-auto, manual
ApertureF1.6 to F3.5
Zoom SpeedApprox. 3.2 s (optical lens, wide-tele)
Illuminator
Supplement Light Type IR
Supplement Light Range Up to 100 m
Smart Supplement Light Yes
PTZ
Movement Range (Pan)360° endless
Movement Range (Tilt)From -15° to 90° (Auto-flip)
Pan Speed Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s
Tilt Speed Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s
Proportional Pan Yes Presets300 Preset Freezing Yes
Patrol Scan8 patrols, up to 32 presets for each patrol
Pattern Scan4 pattern scans, record time over 10 minutes for each scan
Park Action Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan PTZ Status DisplayYes Scheduled TaskPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust Power-off MemoryYes

General
Power
12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4
Max.:18 W (IR Max.6 W)
DimensionØ 165.9 mm × 290 mm (Ø 6.53" × 11.42")
WeightApprox. 2.5 kg (5.51 lb)
MaterialADC 12, PC+10% GF
Operating Condition-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)

8 Independent 100MPS POE ports; Video Content Analytics; 1-Ch Audio input; HDMI and VGA output at up to 1920×1080P; 1x SATA interface(Up to 6TB); Mini 1U case; 12VDC
Description
NVR-108-B
8-ch Mini 1U 4 PoE 4K NVR
Connectable to the third-party network cameras
Up to 8 network cameras can be connected
H.264+ compression effectively reduces the storage space and costs by up to 50%
Full channel recording at up to 4 MP resolution
HDMI/VGA output at 1080p resolution
2-ch playback at 4 MP resolution or 4-ch at 1080p resolution
1 SATA hard disk can be connected with 6TB capacity
HDD quota management: different capacity can be assigned to different channel
Supports line crossing detection and intrusion detection
Smart search for the selected area in the video; and smart playback to improve the
playback efficiency
One-key operation: automatically search, modify and add IP cameras after device is
activated
Hik-Connect and DyDDNS for easy network management
100 Mbps Ethernet network interface

General
Power supply48 VDC
Working temperature-10 °C to +55 °C (14 °F to 131 °F)
Working humidity10 % to 90 %
Consumption (without hard disk and PoE)≤ 10 W
Chassis1U chassis
Dimensions(W × D × H)285 × 215 × 48 mm(11.2" × 8.5" × 1.9")
Weight(without hard disk)≤ 1 kg (2.2 lb)

16 Port Fast Ethernet Unmanaged POE Switch
Unmanaged switch with 16 x 100 Mbps PoE ports, 1 x 1000 Mbps RJ45 port, and 1 x 1000 Mbps SFP port
All ports support 6 kV lighting protection
130 W PoE power budget
Maximum transmission distance is 250 meters for port 9 to 16 in "extend" mode
MAC address auto learning and auto aging
General
Shell Metal material
Operating temperature-10 °C to 55 °C (14 °F to 131 °F)
Storage temperature-40 °C to 85 °C (-40 °F to 185 °F)
Power supply100 to 240 VAC, 50/60 Hz, Max. 2.5 A
Storage humidity5% to 95% (no condensation)
Net weight1.8 kg (4.0 lb)
Gross weight2.58 kg (5.69 lb)
Dimension (L × H × D)266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)
Operating humidity5% to 95% (no condensation)
Power consumption in idle20 W

Network parameters
Port number16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
Port typeRJ45 port, full duplex, MDI/MDI-X adaptive
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding mode Store-and-forward switching
Working mode Standard mode (default); Extend mode
MAC address table4 K
Switching capacity7.2 Gbps
Packet forwarding rate5.356 Mpps
Internal cache2.75 Mbits
High priority ports Ports 1 to 8
Ports for long-distance transmission Ports 9 to 16
PoE power supply
PoE standard IEEE 802.3af, IEEE 802.3at
PoE power pin
Ports for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.
Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.
PoE portPorts 1 to 16
Max. port power30 W
PoE power budget130 W
Max. power consumption150 W
