MikroTik's RB-CCR2116P features 16 cores, each with 2GHz processing power, 12 Gigabit Ethernet Ports, 4 x 10Gbps SFP+ uplink ports and a dual redundant power supply. The router supports Layer 3 Hardware Offloading and each group of 4 Ethernet ports has a separate full-duplex connection to the switch chip to prevent bottlenecks.

Specifications

Ethernet Ports: 12x 10/100/1000; 1x 10/100/1000 Management Interface
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 1x M.2 slot
Dimensions: 443 x 199 x 44mm

MikroTik's RB-CCR2004 is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed Router OS L6 and 4GB of onboard RAM. It features 12x 10Gbps SFP+ ports, 2x 25Gbps SFP28 ports and dual power supplies for integrated redundancy.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 32W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 10Gbps ; 2x 25Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None
Dimensions: 443 x 224 x 44mm

MikroTik RB-CCR2216SP features 16 cores, 12x SFP28 25Gbps ports, 2x QSFP28 100Gbps ports, and a Gigabit Ethernet port. The device includes 2x M.2 SATA slots for additional storage as well as 4x hot-swappable fans and dual-redundant hot-swap power supplies.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 80W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 2x M.2 slots
Dimensions: 443 x 367 x 44mm

MikroTik's RB-CCR2004P is a carrier-grade cloud core router powered by a 4 core ARM CPU. The unit comes equipped with installed Router OS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and dual power supplies for integrated redundancy. Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch chip. Each switch chip has a 10Gbps full-duplex line connected to the CPU. Each SFP+ cage also has a separate
10Gbps full-duplex line.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 35W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None
Dimensions: 443 x 210 x 44mm

MikroTik's RB-CCR2004PC is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and can be powered by either the DC Jack or a 2-pin terminal connection. Each group of 8x Gigabit Ethernet ports is connected to a separate switch chip which has a 10Gbps full-duplex line connected to the CPU. The SFP+ Ports also have a separate 10Gbps full-duplex line to prevent bottlenecks.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 36V-57V DC Jack or 2 Pin Terminal
Processor: 4 core 1.2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 36V-57V
System Memory: 4GB
USB Ports: None
Dimensions: 272 x 195 x 44mm

MikroTik's RB-CCR2004PCIE is a 4-core ARM64 CPU, smart PCIe network interface card (NIC) that adds fully-fledged router capabilities to your Linux servers or PCs. It features 2x SFP28 25Gbps SFP ports and 1x Gigabit Ethernet Port for management.

Note: The device is supported in Linux (minimum kernel 5.15.25) and Router OS (minimum version 7.x), but it will not be recognized in Windows.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: Low Profile & High Bracket (Included)
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: PCI-e
Processor: 4 core 2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 25Gbps
System Memory: 4GB
USB Ports: None
Dimensions: 170 x 69 x 18mm

MikroTik's RB-CRS320P is a Cloud Router Switch with 16x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 600W. PoE ports 1 to 8 support PoE+ (802.3af/at) and ports 9 to 16 support PoE++ (802.3af/at/bt). The unit includes a hot-swappable PSU as well as an expansion slot for an additional PSU, which can raise the PoE budget to 1150W.

Specifications

Ethernet Ports: 17x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 36W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8 : 802.3af/at/bt on Ports 9 to 16
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX226S
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 256MB
USB Ports: None
Other: None
Dimensions: 444 x 235 x 44 mm

MikroTik's RB-CRS520 is an enterprise 4 core Cloud Router Switch with 16x 100Gbps QSFP28, 4x 25Gbps SFP28 ports and 2x 10Gbps Ethernet ports. The unit is powered by dual hot-swappable power supplies and can run OSPF/BGP, out-of-band/management VPNs, ACLs, Jumbo frames, and L3HW Offloaded routing.

Specifications

Ethernet Ports: 2x10/100/1000/2500/10000
Hardware Button: Reset; Mode
Max. Power Consumption: 123W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 50°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 4 Core 2GHz 98CX8410
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 16x 100Gbps ; 4x 25Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB DDR4
USB Ports: None
Other: None
Dimensions: 443 x 367 x 44 mm

MikroTik's RB-CRS317 is a Cloud Router Switch featuring 16x SFP+ ports and 1x Gigabit Ethernet Port for management. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 6 License.

Specifications

Ethernet Ports: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 44W
Mounting: Rackmount
Operating System: Dual Boot - SwOS or Router OS (Level 6 License)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX8216
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 16x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 1GB
USB Ports: None
Other: None
Dimensions: 443 x 224 x 44mm

MikroTik's RB-CRS518S is a Cloud Router Switch featuring 16x 25Gbps SFP28 ports, 2x 100Gbps QSFP28 ports with a total of 1.2Tbps switching capacity. The router has dual power supplies for power redundancy. The 25Gbps SFP28 ports are backwards compatible with 10Gbps and 1.25Gbps SFP modules while the 100Gbps QSFP28 ports are also compatible with the 40Gbps QSFP modules.

Specifications

Ethernet Ports: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 16x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: 1x USB
Other: None
Dimensions: 443 x 265 x 44.5 mm

MikroTik's RB-CRS328S is a Cloud Router Switch featuring 20x 1.25Gbps SFP ports, 4x 10Gbps SFP+ ports and 4x SFP or Gigabit Ethernet combo ports. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 4x 10/100/1000 (4 Combo Ports)
Hardware Button: Reset; Mode
Max. Power Consumption: 43W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 800MHz 98DX3236
Serial Interface:1x RJ45 Serial Port
SFP Ports: 24x 1.25Gbps (4 Combo Ports); 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None
Dimensions: 443 x 200 x 44mm

MikroTik' s CRS326G is a Cloud Router Switch featuring 24x 2.5Gbps Ethernet Ports, 4x 10Gbps SFP+ Combo Ports (Either 2.5Gbps Ethernet or 10G SFP+), 2x QSFP+ 40Gbps Ports, as well as 1x RJ45 Console Port and 1x Gigabit port for management. The unit is equipped with dual power supplies for power redundancy.

Specifications

Ethernet Ports: 24x 10/100/1000/2500 (4x Combo Ports)
Hardware Button: Reset
Max. Power Consumption: 51W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 650 MHz QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps (Combo Ports) ; 2x 40Gbps QSFP+
Supported Voltage Range: 100V-240V
System Memory: 128MB
USB Ports: None
Other: None
Dimensions: 443 x 258 x 44 mm

MikroTik' s CRS326 is a Cloud Router Switch featuring 24x Gigabit Ethernet Ports, 2x 10Gbps SFP+ ports and 1x Gigabit Ethernet port for either management or PoE Input. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 10V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 10V-30V
System Memory: 512MB
USB Ports: None
Other: None
Dimensions: 440 x 144 x 44mm

MikroTik's RB-CRS328 is a Cloud Router Switch featuring 24x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 450W. The 24 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 24x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 44W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3af/at or 26V Passive PoE on Ports 1~24
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None
Dimensions: 443 x 305 x 44mm

MikroTik's RB-CRS326Q is a Cloud Router Switch featuring 24x 10Gbps SFP+ Ports and 2x 40Gbps QSFP+ ports. The Router has dual power supplies for power redundancy and a full-sized USB port for configuration. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 42W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 650MHz QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 24x 10Gbps ; 2x 40Gbps QSFP
Supported Voltage Range: 100-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None
Dimensions: 443 x 200 x 44mm

MikroTik's RB-CRS304XG is a Cloud Router Switch featuring 4x 10Gbps Ethernet Ports and 1x Gigabit Management Port. This switch includes a convenient DIN rail mount on the side and standard screw attachment points on the back. It also offers 4 different power inputs, 2x DC jacks, a 2-pin terminal, and PoE-input. The switch automatically selects the power source with the highest voltage, ensuring uninterrupted operation.

Specifications

Ethernet Ports: 4x 10Gbps: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or DIN Rail Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 48V 0.95A Power Supply
Processor: Dual Core 1200MHz 98DX2528
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 36-57V (PoE) 12-57V (DC Input)
System Memory: 512MB
USB Ports: None
Other: Terminal DC Input
Dimensions: 176 x 128 x 35 mm

MikroTik's RB-CRS305S is a Cloud Router Switch featuring 4x 10Gbps SFP+ Ports, 1x Gigabit Ethernet port for management and dual DC Jacks for power redundancy. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.

*Note: In order to achieve the best compatibility, MikroTik recommends not using grounding when powering this device with 802.3af/at.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Desktop
Operating System: Dual Boot - SwOS or Router OS (Level 5 License)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 12-57V Passive PoE
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included) (Dual DC input for power redundancy)
Processor: 1 Core 800 MHz 98DX3236
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 12-57V
System Memory: 512MB
USB Ports: None
Dimensions: 141 x 115 x 28mm

MikroTik's RB-CRS354Q is a Cloud Router Switch featuring 48x Gigabit Ethernet ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 48x 10/100/1000: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rackmount
Operating System: Dual Boot - SwOS or Router OS (Level 5 License)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: None
Other: None
Dimensions: 297 x 443 x 44mm

MikroTik's RB-CRS354QP is a Cloud Router Switch featuring 48x Gigabit PoE Ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports, 1x Fast Ethernet Management port and a PoE budget of 700W. The 48 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 48x 10/100/1000: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 85W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3at/af ; 26V or 53V Passive PoE
Power Input: 1x IEC Power Cord (Included)
Processor: QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64 MB
USB Ports: None
Other: None
Dimensions: 443 x 382 x 44mm

MikroTik's RB-CRS106 is a Cloud Router Switch featuring 5x 1.25Gbps SFP ports, 1x 1.25Gbps SFP or PoE Input Combo Port and is powered by Router OS with a Level 5 license.

Specifications

Ethernet Ports: 1x 10/100/1000 (Combo Port)
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: Router OS (Level 5 License)
Operating Temperature: -20°C to 70°C
PoE Input: 11V-30V (Passive PoE Combo Port)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 6x 1.25Gbps (1x Combo Port)
Supported Voltage Range: 11V-30V
System Memory: 128MB
USB Ports: None
Other: None
Dimensions: 114 x 137 x 29mm
