Ubiquiti's USW-48P is a managed Layer 2 switch with 48x Gigabit Ports. It includes 32x 802.3at PoE+ ports, 4x 1.25Gbps SFP uplink ports and a PoE budget of 195W. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rackmount
Operating System: UniFi
Operating Temperature: -5 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~32
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 285 x 43.7mm
Weight: 4.61kg

Ubiquiti's USW-24 is a managed, Layer 2, UniFi switch. It has 24x Gigabit Ethernet ports and 2x 1.25Gbps SFP uplink ports. The unit features a fan less design with a 1.3" touchscreen that displays the current switch state and other information for quick and easy reference.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 200 x 43.7 mm
Weight: 2.79kg

Ubiquiti's USW-24P is a managed Layer 2 switch with 24x Gigabit Ethernet ports. It consists of 16x auto-sensing 802.3at PoE+ ports, 2x 1.25Gbps SFP uplink ports and a PoE budget of 95W. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 200 x 43.7mm
Weight: 3.09kg

Ubiquiti's USW-16P is a configurable Layer 2 switch. It has 16x Gigabit Ethernet ports that are made up of 8x auto-sensing 802.3at PoE+ ports, 2x 1.25Gbps SFP uplink ports and a PoE budget of 42W. It features a 1.3" touch LCM to provide status information and with a depth of 7.9", the compact fan less design can be easily installed in a SOHO network cabinet.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Rackmount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100-240VAC; 50/60Hz
Dimensions: 442.4 x 200 x 43.7 mm
Weight: 2.8kg

Ubiquiti's UK-ULTRA is an indoor and outdoor, IPX6 WiFi 5 dual band access point with versatile mounting options and external antenna support via two RP SMA connectors. It is capable of reaching up to 1167Mbps aggregate over both 2.4GHz and 5GHz 2x2 MIMO radios.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Antenna Gain: 2.4GHz: 6dBi ; 5.8GHz: 6dBi (2x RP-SMA for optional external antennas)

Specifications

Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Wall, Ceiling or Pole Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 802.3af/at PoE (44-57V)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44-57V
USB Ports: None
Dimensions: 137 x 84 x 34 mm
Weight: 173g

Ubiquiti's UXG-MAX is a compact, Multi-WAN, independent gateway featuring a 1.5GHz quad-core processor, 1x 2.5Gbps WAN and 4x 2.5Gbps LAN ports, with one of the LAN ports remappable to WAN. It also features intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter. It can be configured and managed with a Cloud key, Official UniFi Hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000/2500 (WAN): 3x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (LAN/WAN)
Hardware Button: Reset
Max. Power Consumption: 9.6W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V 3A USB-C Power Supply (Included)
Processor: Quad-core 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A
System Memory: 2 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 520g

Ubiquiti's UXG-LITE features a compact design, a 1GHz dual-core processor, 1x Gigabit Ethernet WAN and 1x Gigabit Ethernet LAN port. It also features next-generation security with intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter.

It can be configured and managed with a Cloud key, Official UniFi hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000 (WAN): 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 3.83W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V USB-C Power Supply (Included)
Processor: Dual core 1GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V
System Memory: 1 GB DDR3L
USB Ports: None
Dimensions: 98 x 98 x 30 mm
Weight: 320g

Ubiquiti's UVC-VIEWPORT is a PoE-powered device that makes provision for viewing up to 16 UniFi Protect cameras on an HDMI display. It uses Power over Ethernet (PoE) and connects to the local network to host your cameras. It enables UniFi Protect systems to be viewed in custom high-density camera matrix configurations.

*Note: PoE Injector not Included. The UniFi Protect Application is required to run this product with full functionality.

Specifications

Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.5W
Operating Temperature: 0°C to 40°C
PoE Input: 802.3af
PoE Output: None
Supported Voltage Range: 802.3af PoE
Dimensions: 156.9 x 52 x 37.35mm
Weight: 252g

Ubiquiti's UVC-G5PRO features an 8MP image with a built-in microphone, 3x optical zoom and AI event detection. It is also IP65 rated with a versatile 3-axis mount for both indoor and outdoor installations. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 25 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 10W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 50°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 3840 x 2160 (16:9)
Sensor: 1/2" 8MP
Video Compression: H.264; MJPEG
Dimensions: Ø86 x 153.8 mm
Weight: 670g

Ubiquiti's UVC-G5F features a 4MP image with a wide-angle (102.4°) lens in a weatherproof IPX4-rated enclosure. It features various mounting options for both indoor and outdoor installation and has infrared LEDs with an automatic IR cut filter.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed focal length
Max Frame Rate: 30 FPS
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Desktop, wall, pole or hard-ceiling
Night Mode: IR LEDs with Mechanical IR Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 802.3af PoE (Not Included)
Resolution: 2688 x 1512
Sensor: 5MP CMOS sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø48 x 107.5 mm
Weight: 170g

Ubiquiti's UVC-G5DU features an ultra-compact and tamper-resistant enclosure, a 4MP image with an ultra-wide-angle lens, 20m IR night vision as well as AI Detections.

It can be configured and managed using the UniFi Protect Application.

*Note: The G5 Dome Ultra is for indoor use only. PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: No
Max. Power Consumption: 4.2W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: Ø63.6 x 68.2 mm
Weight: 175g

Ubiquiti's UVC-G5D features a 4MP image with a wide-angle lens, enhanced dynamic range and low-light performance. It is IK08 vandal-resistant with a built-in microphone and speaker. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependant)
Microphone: Yes
Max. Power Consumption: 5W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø109.2 x 64.5 mm
Weight: 390g

Ubiquiti's UVC-G5B features a 4MP image with a built-in microphone and a versatile 3-axis mount that enables quick and easy adjustment for both indoor and outdoor mounting. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 10 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: : Ø75.5 x 150 mm
Weight: 315g

Ubiquiti's UVC-G4INS is a compact, wide-angle, 5MP image, weather-resistant Wi-Fi IP Camera with two-way audio. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance.

It can be configured and managed using the UniFi Protect Application.

Specifications

Ethernet Ports: None
Hardware Button: Reset
Lens: Fixed focal length EFL 2.8 mm, f/1.6
Max Frame Rate: 30 FPS (Resolution Dependant)
Microphone: Yes
Max. Power Consumption: 6W
Mounting: Wall Mount
Night Mode: Built-in IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: None
Power Input: 5V, 2A USB Adapter (Included)
Resolution: 2688 x 1512 (16:9)
Sensor: 5 MP CMOS Sensor
Video Compression: H.264/MJPEG
Dimensions: 81.6 x 50 x 47.2 mm
Weight: 163g

Ubiquiti's UVC-AITH is a remote processing hub compatible with any AI Theta Lens. The unit includes a 1-metre proprietary Theta cable for connecting the lens.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12.5W
Mounting: Wall or Ceiling Mount
Operating Temperature: -20°C to 40°C
PoE Input: 37-57V Passive PoE
Power Input: 37-57V PoE
Video Compression: H.264
Dimensions: Hub: 140 x 70 x 38 mm
Weight: 365g

Ubiquiti’s UVC-AIT offers the choice between an 8MP wide-angle wall-mounted lens or a 12MP 360° fisheye lens for ceiling-mounted applications. The chosen lens module connects to the hub via the included 1-metre proprietary Theta cable. A second Theta hub can be purchased if the user wishes to install both lenses.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included & Theta lenses do no support IR night Vision.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: AI-Theta: 24 FPS; AI-Theta-360°: 20 FPS
Microphone: Yes
Max. Power Consumption: 12.25W
Mounting: Wall or Ceiling Mount
Night Mode: None
Operating Temperature: -20°C to 40°C
PoE Input: 37-57V Passive PoE
Power Input: 37-57V PoE
Resolution: AI-Theta: 3264 x 2448 (4:3); AI-Theta-360°: 2560 x 2560 (1:1)
Sensor: AI-Theta: 8MP; AI-Theta-360°: 12MP
Video Compression: H.264; MJPG
Dimensions: Hub: 140 x 70 x 38 mm; Lens/360°: Ø22.8. x 43.5 mm
Weight: 392g

Ubiquiti's UVC-AI360 is a pan-tilt-zoom (PTZ) IP camera providing panoramic, overhead surveillance of heavily populated areas. Equipped with a 5 MP CMOS sensor and an ultra-wide 360° fisheye lens, it streams sharp 1920x1920 video at 30 frames per second (FPS). It also features built-in IR LEDs for night mode. The IPx4 weather-resistant housing and IK08-rated tamper resistance allow it to be mounted both indoors and outdoors.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: 360° Fisheye lens
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 8.64W
Mounting: Ceiling or Wall-Mount (Included)
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20° to 40° C
PoE Input: 802.3af
Power Input: 802.3af
Resolution: 1920 x 1920
Sensor: 5 MP CMOS sensor
Video Compression: H.264, MJPG
Dimensions: Ø147 x 49 mm
Weight: 0.68Kg

The Ubiquiti UniFi UNVR Pro is a 7‑bay, diskless Network Video Recorder and UniFi OS console running the preinstalled UniFi Protect application. Designed for professional and SMB deployments, it accepts up to seven 2.5" or 3.5" drives (not included) and offers a 10 Gbps SFP+ uplink plus a Gigabit Ethernet port for flexible high‑throughput architectures. A built‑in 1.3" touchscreen provides quick status and local control, while a quad‑core ARM Cortex‑A57 1.7 GHz CPU and 4 GB DDR4 memory deliver responsive multi‑stream recording and playback. With enterprise features like RAID support, rack‑mountable 1U design, and robust power (max 160 W), the UNVR Pro is ideal where high local storage capacity, UniFi Protect management, and secure high‑bandwidth connectivity are required.

Technical Details:

Operating system: UniFi Protect (preinstalled)
Drive bays: 7 × 2.5"/3.5" HDD/SSD (drives not included)
Ethernet: 1 × 10/100/1000 RJ45
SFP+: 1 × 10 Gbps SFP+ port
Processor: Quad‑core ARM Cortex‑A57 @ 1.7 GHz
Memory: 4 GB DDR4
Power: 1 × IEC power input; max power consumption 160 W
PoE: No PoE input or output
I/O: Reset hardware button; 1.3" touchscreen display; no USB; no serial
Supported voltage: 100–240 V
Operating temp: -5 to 40 °C
Form factor: 1U rack mount (rack ears may be required)
Dimensions: 442 × 325 × 87 mm
Model / SKU: UVC‑NVR‑PRO (UNVR Pro)
Notes: HDDs not included use Ubiquiti‑approved drives per compatibility guidelines

Weights
Net weight (unit only): 9.45 kg
Gross weight (boxed, estimated): ~11.8–12.5 kg

Quick deployment tips
Install Ubiquiti‑approved surveillance/NAS drives and configure RAID per retention and redundancy needs.
Use the 10G SFP+ uplink for aggregation or uplink to high‑capacity storage when many high‑resolution streams are active.
Place drives into the unit before rack mounting to simplify cabling and airflow.

The Ubiquiti UniFi UNVR is a 4‑bay, diskless Network Video Recorder and UniFi OS console running the preinstalled UniFi Protect application. Designed for SMBs and pro installs, it accepts up to four 2.5" or 3.5" HDDs (not included), offers a 10G SFP+ uplink for high‑throughput camera deployments, and delivers efficient local management of UniFi Protect camera fleets. With a quad‑core ARM Cortex‑A57 1.7 GHz CPU and 4 GB DDR4 memory, the UNVR provides smooth multi‑stream recording and playback while fitting neatly in a 1U rack footprint.

Technical Details:

Operating system: UniFi Protect (preinstalled)
Drive bays: 4 × 2.5"/3.5" HDD/SSD (drives not included)
Ethernet: 1 × 10/100/1000 RJ45
SFP+: 1 × 10 Gbps SFP+ port
Processor: Quad‑core ARM Cortex‑A57 @ 1.7 GHz
Memory: 4 GB DDR4
Power: 1 × IEC power input; max power consumption 100 W
PoE: No PoE input or output
I/O: Reset hardware button; no USB; no serial
Supported voltage: 100–240 V
Operating temp: -5 to 40 °C
Form factor: 1U rack mount
Dimensions: 442.4 × 325 × 43.7 mm
Model / SKU: UNVR (UVC‑NVR)

Ubiquiti's USW-MAX48P is a 48 port, fully managed, Layer 3 Etherlighting™ switch. The unit features a 720W PoE budget with 32 Gigabit PoE Ports (24x PoE+ and 8x PoE++), 16x 2.5Gbps PoE ports (8x PoE+ and 8x PoE++) and 4x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps PoE links to your WiFi 6 devices as well as 10Gbps fibre uplinks to your network.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 32x 10/100/1000; 16x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps Ports: 8x 802.3af/at/bt ; 8x 802.3af/at ; Gigabit Ports: 24x 802.3af/at ; 8x 802.3af/at/bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442 x 325 x 44mm
Weight: 5.2kg
