Three 2 MP cameras face different directions to cover larger areas
One 2 MP camera for close-up view with 4x zoom ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to DWDR technology
Good night-time performance with up to 10 m IR
Lens
FOVHorizontal field of view: 120° to 56.6° (wide - tele),Vertical field of view: 61.8° to
31.7° (wide - tele),Diagonal field of view: 149° to 65° (wide - tele)
Focal Length2.8 mm to 12 mm, 4× optical zoom
Zoom SpeedApprox.5.4 s (optical, wide - tele)
Working Distance10 mm to 1500 mm (wide - tele)
Aperture RangeF2.0 to F2.4
Smart Features
Basic Event Detection Motion Detection, Video Tampering Detection, Exception
Smart Detection Audio Exception Detection, Intrusion Detection, Line Crossing
Detection
Smart Record ANR (Automatic Network Replenishment)
ROIMain stream supports eight fixed areas.
Smart Image Enhancement HLC/BLC/3D DNR/Regional Exposure/Regional Focus
MaterialPC + ABS & Aluminum alloy
DimensionsΦ 183 mm × 133 mm (Φ 7.20" × 5.24")
WeightApprox. 0.9 kg (1.98 lb)
Protection LevelTVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power 12 VDC, 2.0 A & PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class 4
Max.24 W (Max. 6 W for IR)
Working Temperature-10°C to 50°C (14°F to 122°F)
Working Humidity≤ 90%

Four-inch 2 MP camera with pan, tilt and zoom (25x) ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Excellent night-time performance with up to 100 m enhanced IR
Water and dust resistant (IP66)

Camera
Image Sensor1/2.8" progressive scan CMOS
Max. Resolution1920 × 1080
Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC
ON),
0 Lux with IR
Shutter Speed1/1 s to 1/30,000 s
Day & NightIR Cut Filter
Zoom25x optical, 16x digital
Lens
Focal Length4.8 mm to 120 mm, 25× optical
FOV
Horizontal field of view: 57.6° to 2.5° (Wide-Tele),
Vertical field of view: 34.4° to 1.4° (Wide-Tele),
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
FocusAuto, semi-auto, manual
ApertureF1.6 to F3.5
Zoom SpeedApprox. 3.2 s (optical lens, wide-tele)
Illuminator
Supplement Light Type IR
Supplement Light Range Up to 100 m
Smart Supplement Light Yes
PTZ
Movement Range (Pan)360° endless
Movement Range (Tilt)From -15° to 90° (Auto-flip)
Pan Speed Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s
Tilt Speed Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s
Proportional Pan Yes Presets300 Preset Freezing Yes
Patrol Scan8 patrols, up to 32 presets for each patrol
Pattern Scan4 pattern scans, record time over 10 minutes for each scan
Park Action Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan PTZ Status DisplayYes Scheduled TaskPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust Power-off MemoryYes

General
Power
12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4
Max.:18 W (IR Max.6 W)
DimensionØ 165.9 mm × 290 mm (Ø 6.53" × 11.42")
WeightApprox. 2.5 kg (5.51 lb)
MaterialADC 12, PC+10% GF
Operating Condition-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)

HiLook 4-ch Mini 1U 4 PoE 4K NVR
Up to 8 channel IP cameras can be connected
Plug & Play with 8 Power-over-Ethernet (PoE) interfaces
Supports decoding H.264+/H.264 multiple video formats
Up to 4-ch @ 1080p decoding capacity
1 HDD for continuous video recording
Video and Audio
IP video input8-ch
Two-way audio input1-ch, RCA (2.0 Vp-p, 1kΩ)
Video/Audio output
HDMI/VGA output1-ch, resolution:1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output1-ch, RCA (Linear, 1kΩ)
Recording resolution4 MP/3 MP/1080p/1.3 MP/UXGA/720p/VGA/4CIF /DCIF/2CIF/CIF/QCIF
General
Power supply48 VDC
Working temperature-10 °C to +55 °C (14 °F to 131 °F)
Working humidity10 % to 90 %
Consumption (without hard disk and PoE)≤ 10 W
Chassis1U chassis
Dimensions(W × D × H)285 × 215 × 48 mm(11.2" × 8.5" × 1.9")
Weight(without hard disk)≤ 1 kg (2.2 lb)

MikroTik's RB-WAPAX is a WiFi 6 AX3000 outdoor router featuring a dual core processor, 2x Gigabit Ethernet Ports, PoE and DC powering options and can be wall, ceiling or pole mounted. It allows for an Ethernet cable to be run directly from the back of the case and is secured with an anti-vandal screw for added security.

WI-FI 6 TECHNOLOGY Features advanced 802.11ax wireless technology for higher speeds and improved network efficiency in high-density environments
DUAL CHAIN MIMO: Equipped with 2x2 MIMO technology for higher signal strength, better coverage and reliable wireless connections
WEATHER RESISTANT DESIGN Built to withstand various weather conditions, making it suitable for both indoor and outdoor installations
VERSATILE MOUNTING Compact form factor allows flexible placement options on walls, posts or other surfaces
Performance Features: Supports dual-band operation with advanced wireless protocols for optimal network performance

Antenna Gain: 2.4GHz: 7dBi ; 5.8GHz: 7dBi
Beam-width: 180°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop, Ceiling, Pole & Wall-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18-57V Passive PoE ; 802.3af/at
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V (PoE) 12-57V (DC Jack Input)
USB Ports: None

Dimensions: 185 x 85 x 30 mm

High quality imaging with 4 MP resolution
Support Human and Vehicle Detection
Smart Dual-Light: advanced technology with long range
Built-in microphone for real-time audio security
Water and dust resistant (IP67) and vandal resistant (IK08)
Efficient H.265+ compression technology
Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle AdjustmentPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93°
Lens MountM12
Iris Type Fixed
ApertureF1.6
Power 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W
Material Metal & Plastic
DimensionØ121.4 mm × 97.7 mm (Ø4.8" × 3.8")
Package Dimension150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
WeightApprox. 550 g (1.2 lb.)
With Package WeightApprox. 800 g (1.8 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

High quality imaging with 2 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to DWDR technology
Water and dust resistant (IP67) and vandal proof (IK10)
Easy installation with power over Ethernet (PoE) technology
Camera
Image Sensor1/2.7" Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100, 000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°
Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
Lens MountM12
Iris TypeFixed
ApertureF2.0
DimensionØ111 mm × 82.4 mm (Ø4.4" × 3.2")
Package Dimension134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Weight Approx. 410 g (0.9 lb.)
With Package Weight Approx. 610 g (1.3 lb.)

High quality imaging with 6 MP resolution Support Human and Vehicle Detection
Smart Hybrid Light: advanced technology with long range Clear imaging even with strong back lighting due to 120 dB WDR technology Efficient H.265+ compression technology Support on-board storage up to 512 GB (SD card slot) Provide real-time security via built-in two-way audio
2.8 to 12 mm motorized varifocal lens for easy installation and monitoring Water and dust resistant (IP67)
Camera
Image Sensor1/2.4" Progressive Scan CMOS
Max. Resolution3200 × 1800
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
Lens Type Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to
20°, diagonal FOV 127.4° to 40.8°
Lens MountØ14
Iris TypeFixed
ApertureF1.6
DORI
DORID: 68 to 200 m, O: 27 to 79 m, R: 13.6 to 40 m, I: 6.8 to 20 m
General
Power 12 VDC ± 25%, 0.9 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 12.9 W
Material Metal
Dimension Ø105 mm × 285.8 mm (Ø4.13 × 11.25\")"
Package Dimension 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
Weight Approx. 805 g (1.8 lb.)
With Package Weight Approx. 1405 g (3.1 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

High quality imaging with 4 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67)
Motorized varifocal lens for easy installation and monitoring
Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. IlluminationColor: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR Cut Filter
Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360°
Lens
Lens TypeVarifocal lens, motor-driven lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm: horizontal FOV 102° to 31°, vertical FOV 55° to
18°, diagonal FOV 122° to 36°
Lens MountØ14
Iris TypeFixed
ApertureF1.6
General
Power 12 VDC ± 25%, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
Dimension Ø105 mm × 244.4 mm (Ø4.1" × 9.6")
Package Dimension 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
Weight Approx. 1035 g (2.3 lb.)
With Package Weight Approx. 1550 g (3.4 lb.)
Storage Conditions-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing)

Cudy's CD-FS1026PS is a 26-Port Fast Ethernet switch with 24x 802.3af/at PoE ports, 2x Gigabit, and 1x SFP Uplink ports. The switch offers a 290W PoE budget, up to 30W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-24 while Extender mode increases the transmission distance on ports 1-24 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 24x 10/100; 2x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 10W
Mounting: Rackmount
Operating System: None
Operating Temperature: -20°C to 50°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~24
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 210 x 50mm
Weight: 1.9kg

Cudy's CD-GS1016 is a 16 Port Gigabit Switch that supports both Desktop and Rack-Mount options. It features a toggle switch with VLAN, Extender and Default Modes. In Default mode, all ports operate freely. VLAN mode enables port isolation on ports 1-14 while Extender mode increases the transmission distance on ports 1-14 to 250m at 10Mbps.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: None
Max. Power Consumption: 15W
Mounting: Desktop or Rackmount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100V-240V
Dimensions: 200 x 118 x 44mm

Cudy's CD-GS1018PS is a 16 Port Gigabit switch with 16x 802.3af/at PoE ports, 2x Gigabit and 2x SFP Uplink ports. The switch offers a 180W PoE budget and up to 30W per PoE port. Extender Mode increases the transmission distance on ports 9-16 to 250m at 10Mbps. The Watchdog function continuously monitors PoE connections when in Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 18x 10/100/1000
Hardware Button: Extender; Default
Max. Power Consumption: 10W
Mounting: Rack-Mount
Operating System: None
Operating Temperature: -10~50°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 207 x 44 mm
Weight: 2.28kg

Cudy's CD-FS1018PS is a 16-Port Fast Ethernet switch with 16x 802.3af/at PoE ports, 2x Gigabit, and 1x SFP Uplink ports. The switch offers a 190W PoE budget, up to 30W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-16 while Extender mode increases the transmission distance on ports 1-16 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 16x 10/100; 2x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 10W
Mounting: Rack-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 100-240V
Dimensions: 320 x 210 x 50mm
Weight: 1.8kg

Cudy's CD-GS1010P is a 10-Port Gigabit switch with 8x 802.3af/at PoE ports and 2x Gigabit Uplink ports. The switch offers a 100W PoE budge with up to 30W per port. Both VLAN and Extender modes are supported with the integrated toggle switch. VLAN mode enables port isolation on ports 1-8 while Extender mode increases the transmission distance on ports 7-8 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 10x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 20W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100-240V
Dimensions: 220 x 150 x 44 mm
Weight: 1kg

Cudy's CD-FS1010P is a 10 Port Fast Ethernet switch with 8x 802.3af/at PoE ports and 2x Fast Ethernet Uplink ports. The switch offers a 115W PoE budget, up to 32W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-8 while Extender mode increases the transmission distance on ports 1-8 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 10x 10/100
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 5W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100-240V
Dimensions: 220 x 150 x 40mm
Weight: 800g

🏢 Professional Wi-Fi 5 for Business & High-Density Areas

✅ AC1200 Dual-Band Wi-Fi – 867Mbps @5GHz + 300Mbps @2.4GHz
✅ 802.3af PoE Support – Single-cable power & data
✅ Nuclias Connect Cloud Management – Centralized control for multi-AP setups
✅ High-Capacity Design – Supports 200+ concurrent clients

📊 Technical Specifications

Category Specification
Model DAP-2662
Wi-Fi Standard 802.11ac Wave 2
Antennas 4× internal (3dBi each)
Ethernet 1× Gigabit (PoE)
Mounting Ceiling/wall (hardware included)
Dimensions 7.1 × 7.1 × 1.5 in (180 × 180 × 38 mm)
Warranty 3-year limited

**🏢 Ideal For:

✔ Office Wi-Fi networks
✔ Hotel guest room coverage
✔ Retail store connectivity
✔ School/classroom deployments

**📦 What's Included?

DAP-2662 Access Point
Ceiling/wall mount kit
Quick start guide

"Enterprise-grade Wi-Fi made simple—ideal for businesses needing reliable cloud-managed coverage!"

**⚙️ Pro Tips:

Enable band steering to auto-shift devices to 5GHz
Use VLAN tagging for separate guest/employee networks
Deploy in clusters for seamless roaming

**🔍 Why Choose DAP-2662?

✔ Easy cloud management via Nuclias Connect
✔ MU-MIMO technology for multi-device efficiency
✔ Compact, low-profile design blends into ceilings
*(For Wi-Fi 6, see DAP-2680 model)*

🎮 Ultra-Fast Networking for Gamers & Power Users

✅ 5× 2.5GbE Ports – 4× faster than standard Gigabit
✅ 2× 10G SFP+ Uplinks – Future-proof fiber/copper backbone
✅ Plug-and-Play – Zero configuration needed
✅ Fanless Silent Design – Ideal for desktop use

📊 Technical Specifications

Category Specification
Model DMS-106XT
Ports 5× 2.5GbE RJ45 + 2× 10G SFP+
Switching 40Gbps capacity
Latency <3μs (cut-through)
Power 12V DC adapter
Dimensions 7.1 × 4.3 × 1.0 in (180 × 110 × 25 mm)
Warranty 5-year limited

**💻 Perfect For:

✔ Multi-PC gaming rigs
✔ NAS/workstation setups
✔ 10G backbone for home labs
✔ Esports tournament setups

**📦 What's Included?

DMS-106XT switch
Power adapter
Rubber feet
Quick install guide

"Dominate your network—eliminate bottlenecks with pro-grade multi-gig speeds!"

**⚙️ Pro Tips:

Use SFP+ DAC cables for cheapest 10G server connections
Prioritize gaming PC on lowest-numbered port (auto-QoS)
Pair with 2.5GbE NICs for full speed

**🔍 Why Choose DMS-106XT?

✔ Longer warranty than competitors (5 years)
✔ No fan noise during intense sessions
✔ SFP+ flexibility for fiber/copper uplinks

*(For PoE version, see DMS-106XTP model)*

🏢 Professional-Grade Wi-Fi in a Discreet Wall Plate Design

✅ AC1200 Dual-Band Wi-Fi – 867Mbps @5GHz + 300Mbps @2.4GHz
✅ 3x Gigabit Ports (2x PoE+) – Powers IP phones/cameras while uplinking
✅ Sleek Wall-Plate Design – Replaces standard Ethernet wall jack
✅ Nuclias Connect Cloud Management – Centralized control for multi-AP deployments

📊 Technical Specifications

Category Specification
Model DAP-2622
Wi-Fi Standard 802.11ac Wave 2
PoE Support 802.3at (Ports 1-2)
Antennas Internal (4× 3dBi)
Mounting Standard wall plate (included)
Dimensions 4.7 × 2.6 × 1.1 in (120 × 66 × 28 mm)
Warranty 3-year limited

**🏢 Ideal For:

✔ Hotel rooms & dormitories
✔ Office workstations
✔ Retail POS systems
✔ Smart home installations

**📦 What's Included?

DAP-2622 Access Point
Wall plate & mounting hardware
Quick install guide

"The invisible enterprise AP—perfect for clean, professional installations!"

**⚙️ Pro Tips:

Use Port 3 for wired backhaul to avoid bandwidth sharing
Enable band steering to optimize 5GHz device connections
Pair with Nuclias Cloud for multi-site management

**🔍 Why Choose DAP-2622?

✔ Saves space – No bulky ceiling/wall mounts
✔ Simplifies cabling – Combines Wi-Fi + Ethernet in one outlet
✔ Enterprise features – VLAN, QoS, captive portal
*(For Wi-Fi 6, see DAP-2682 model)*

Cudy's CD-TR1200 is a compact, dual band, Wi-Fi 5 mini-VPN travel router with 2x 10/100 Ports, 2x fixed antennas and an aggregate data rate of 1167Mbps. The router supports easy VPN activation via the configurable dip switch and allows users to host their own NAS via the USB-A 2.0 port. The router supports Cudy's whole home mesh system, DNS over TLS (DoT), and various VPN server or client protocols.

*Note: Type C power adapter not included. Easily manage this device on site or remotely using the mobile app.

Specifications

Antenna Gain: 2.4GHz: 3.9dBi: 5.8GHz: 3.8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset; Configurable DIP Switch
Max. Power Consumption: 8W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 5V 2A USB C Power Adapter (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 5V 2A
USB Ports: 1x USB-A 2.0
Dimensions: 118 × 80 × 27.5 mm
Weight: 99

Cudy's CD-M13003 is a 3 pack, dual band WiFi 5 (802.11ac) mesh system featuring 2x Gigabit Ethernet Ports, integrated antennas and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, seamless roaming and multiple VPN Client options including PPTP, L2TP, OpenVPN, WireGuard, IPSec and ZeroTier.

*Note: Easily manage this device on-site or remotely using the mobile app.

Specifications

Antenna Gain: 2x 4dBi Internal Antennas
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000 (Per Mesh Point)
Hardware Button: Reset ; Pair
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None

Dimensions: 150 x 150 x 110 mm
Weight: 405g

Cudy's CD-M13002 is a 2 pack, dual band WiFi 5 (802.11ac) mesh system featuring 2x Gigabit Ethernet Ports, integrated antennas and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, seamless roaming and multiple VPN Client options including PPTP, L2TP, OpenVPN, WireGuard, IPSec and ZeroTier.

*Note: Easily manage this device on-site or remotely using the mobile app.

Specifications Antenna Gain: 2x 4dBi Internal Antennas

Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000 (Per Mesh Point)
Hardware Button: Reset ; Pair
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None

Dimensions: 150 x 150 x 110 mm
Weight: 405g
