Ubiquiti's USW-PRO8P is a fully managed 8-Port Gigabit Layer 3 UniFi switch. It has 6x 802.3at PoE+ Ports, 2x 802.3bt PoE++ Ports, 2x 10Gbps SFP+ and a PoE budget of 120W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -5°C to 45°C
PoE Input: None
PoE Output: 6x 802.3af/at ; 2x 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 200 x 248 x 44mm
Weight: 2.1kg

Ubiquiti's USW-PRO48 is a fully managed Layer 3 switch with 48x Gigabit Ethernet Ports and 4x 10Gbps SFP+ Uplink Ports. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: UniFi
Operating temperature: -5°C to 45°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 285.4 x 43.7 mm
Weight: 4.09kg

Ubiquiti’s USW-PRO48P is a fully managed 48-Port Gigabit Layer 3 UniFi Switch. It has 40x 802.3at PoE+ Ports, 8x 802.3bt PoE++ Ports, 4x 10Gbps SFP+ and a PoE budget of 600W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: Ports 1~40 802.3af/at ; Ports 41~48 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 399.6 x 43.7mm
Weight: 6.34kg

Ubiquiti's USW-PRO24 is a fully managed, Layer 3, UniFi switch with 24x Gigabit Ports and 2x 10G SFP+ uplink ports. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information. It offers a rich set of layer 2 capabilities with integrated layer 3 functionality.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max Power Consumption: 30W
Mounting: Rackmount
Operating System: UniFi
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100 to 240VAC

Ubiquiti's USW-PRO24P is a fully managed 24-Port Gigabit Layer 3 UniFi switch. It has 16x 802.3at PoE+ Ports, 8x 802.3bt PoE++ Ports, 2x 10Gbps SFP+ and a PoE budget of 400W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 16x 802.3af/at ; 8x 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442.4 x 285.4 x 43.7mm
Weight: 4.39kg

Ubiquiti's USW-LITE8P is a fully managed, Layer 2, UniFi switch with 8x Gigabit Ethernet ports, 4x auto-sensing 802.3at PoE+ ports and a PoE budget of 52W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fan less, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktop or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 4
Power Input: 54V 1A Power Supply (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 50-57V
Dimensions: 99.6 x 163.7 x 31.7 mm
Weight: 450g

Ubiquiti's USW-LITE16P is a fully managed layer 2 switch with 16x Gigabit Ethernet ports, 8x 802.3af/at PoE+ ports and a PoE budget of 45W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fanless, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100 to 240VAC
Dimensions: 99.6 x 163.7 x 31.7mm
Weight: 450g

Ubiquiti's USW-48 is a managed, Layer 2, UniFi switch. It features 48x Gigabit Ethernet ports and 4x 1.25Gbps SFP uplink ports. The unit features a fan-less design and a 1.3" touchscreen with AR switch management which displays the current switch state and other information for quick, easy reference.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 40W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -15°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 285 x 43.7 mm
Weight: 4kg

Ubiquiti's USW-48P is a managed Layer 2 switch with 48x Gigabit Ports. It includes 32x 802.3at PoE+ ports, 4x 1.25Gbps SFP uplink ports and a PoE budget of 195W. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rackmount
Operating System: UniFi
Operating Temperature: -5 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~32
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 285 x 43.7mm
Weight: 4.61kg

Ubiquiti's USW-24 is a managed, Layer 2, UniFi switch. It has 24x Gigabit Ethernet ports and 2x 1.25Gbps SFP uplink ports. The unit features a fan less design with a 1.3" touchscreen that displays the current switch state and other information for quick and easy reference.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 200 x 43.7 mm
Weight: 2.79kg

Ubiquiti's USW-24P is a managed Layer 2 switch with 24x Gigabit Ethernet ports. It consists of 16x auto-sensing 802.3at PoE+ ports, 2x 1.25Gbps SFP uplink ports and a PoE budget of 95W. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~16
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100 to 240VAC
Dimensions: 442.4 x 200 x 43.7mm
Weight: 3.09kg

Ubiquiti's USW-16P is a configurable Layer 2 switch. It has 16x Gigabit Ethernet ports that are made up of 8x auto-sensing 802.3at PoE+ ports, 2x 1.25Gbps SFP uplink ports and a PoE budget of 42W. It features a 1.3" touch LCM to provide status information and with a depth of 7.9", the compact fan less design can be easily installed in a SOHO network cabinet.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Rackmount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100-240VAC; 50/60Hz
Dimensions: 442.4 x 200 x 43.7 mm
Weight: 2.8kg

UltraLAN RG59 BNC Crimp Connector (Male)


BNC Connectors are commonly used for video transmission applications such as broadcast and CCTV as well as in radio and test equipment. These UltraLAN connectors are 75 Ohm rated and suitable for all RG59 Coaxial cables.

This connector requires a crimping tool for proper termination. View the UltraLAN RG59/Coaxial crimping tool

UltraLAN QSFP+ 40G DAC Cable - 1meter
RoHS Compliant 40Gb/s QSFP+ TO QSFP+ Copper Cable Assembly
The UltraLAN QSFP+ to QSFP+ Passive cable assemblies are high performance and cost effective QSFP+ equipment interconnect cables . The hybrid cables are compliant with SFF-8436 and SFF-8431 specifications.
These DAC cables are ideal for short distance interconnect applications, such as linking high speed core switches or telecom routers together in a rack/cabinet. While still having a low power consumption, these cables provide an aggregated data rate of 40Gb/s.
Product Applications:
High capacity I/O in SAN (Storage Area Networks), NAS (Network Attached Storage), and Storage Servers
Switched fabric I/O such as ultra high bandwidth switches and routers
Data center cabling infrastructure
High density connections between networking equipment
Product Features:
Support for multi-gigabit data rates up to 40Gbps
Hot-pluggable QSFP+ footprint
Available in lengths of 0.5,1, 2, 3, 5 m
Metal with lower EMI
Low Power Consumption < 0.5W
Power Supply :+3.3V
Compatible to QSFP+ MSA standards
Temperature Range: 0~ 70 ° C
UltraLAN Part Code Matrix:

UltraLAN QSFP Module - 40G MM 150m 850nm


UltraLAN's FIB-SFP-ULSQ854XM-CDS1 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Transceiver for 40 Gigabit Ethernet Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications.


It integrates four data lanes in each direction with 40 Gbps bandwidth.one version is Each lane can operate at 10.5Gbps up to100m using OM3 or 150m using OM4 Multimode fiber,another version is Each lane can operate at 10.5Gbps up to300m using OM3 or 400m using OM4 Multimode fiber. These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm.


The electrical interface uses a 38 contact edge type connector. The optical interface uses an 12 fiber MTP (MPO) connector. This module incorporates proven circuit and VCSEL technology to provide reliable longlife, high performance, and consistent service.


Product Applications:

40GBASE-SR4 40G Ethernet
Data communication/Telecoms switches & router connections
Data Aggregation and Backplane Applications
Proprietary Protocol and High Density Applications
Infiniband transmission at 4CH SDR, DDR and QDR
Other optical links


Product Features:

Supports 1.06 to 10.5Gb/s bit rates per Channel
Four-Channel ,1x12 MPO receptacle
Hot pluggable QSFP+ form factor
VCSEL 850nm array Technology
Applicable for 100m on OM3 MMF, 150m on OM4 MMF.
Built-in digital diagnostic functions
Low power consumption, < 1.5W
Unretimed XLPPI electrical interface
Operating case temperature: -5°C to 80 °C

UltraLAN Punch Down / Krone Tool


Multi-purpose punch down / Krone tool for the construction of Ethernet RJ45, RJ11 and RJ12 cables.


Features:

Universal scissors cut a variety of cable types, including 20 AWG through to 26AWG, and Type 1 foam-insulated conductors.
A blade helps to easily remove the blocks from back mount frames.
Insertion Sensor ensures the conductor is fully inserted into the block contacts before allowing any excess wire to be cut off.
Suitable for connecting cables, modules and distribution frames
Multi-purpose cutter and stripper for data, telephone and network installations
Works with Cat3, Cat5, Cat5e, Cat6 shielded and non-shielded cable.
Wire Hook removes terminated conductors.
Made from high quality steel
Easy to use, portable, and cost effective

UltraLAN Premium RJ45/RJ11 Cable Tester

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 90m White

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 90m

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 60m White

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.
