Ubiquiti's UDB-PRO is a UniFi long range outdoor radio with integrated UniFi Wi-Fi Auto-Link. It features 2x Gigabit Ethernet ports, one for PoE input and the other with PoE output. PoE+ (802.3at) input is required for PoE passthrough on port 2. The UDB-PRO is sold as a single unit and can be bridged to any UniFi Access point or used as a pair for PtP connections. It can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 5.8GHz: 19dBi
Beam-width: 12°
Data Rate: 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: 48V PoE Passthrough when powered with PoE+ (802.3at)
Power Input: 48V 0.32 Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5–57V DC
USB Ports: None
Dimensions: Ø189.5 x 64.3 mm
Weight: 515g

Ubiquiti's UDB-PRO-SEC is a UniFi 5GHz, 17dBi point-to-multipoint, 90° integrated sector which can connect up to 40+ UDB-PRO devices at distances of up to 5km. It features an outdoor IPX6 rating, 2 spatial streams, and up to 400Mbps throughput on its 5GHz radio. It can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 5.8GHz: 17dBi
Beam-width: 90°
Data Rate: 5.8GHz: 400Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 802.3af/at PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5–57V DC
USB Ports: None
Dimensions: 360.9 x 129.6 x 71.4 mm
Weight: 835g

Ubiquiti's UDR7 is a desktop, Tri-Band, 10Gbps cloud gateway with integrated Wi-Fi 7, microSD storage, and full UniFi Application Suite support. The unit features 1x 10Gbps SFP+ port, 4x 2.5Gbps Ethernet Ports, and a pre-installed 64GB microSD for UniFi Protect. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2x2 MU-MIMO), 5GHz (2x2 MU-MIMO), and 2.4GHz (2x2 MU-MIMO) bands and can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 2.4GHz: 5dBi; 5.8GHz: 7dBi : 6GHz: 6dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps ; 6GHz: 5.7Gbps
Total aggregate data rate: 10.7Gbps
Ethernet Ports: 3x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 26W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: 802.3af on Port 3
Power Input: 100 - 240VAC, 1.5A Max, 50/60 Hz
Serial Interface: None
SFP Ports: 1x 10Gbps SFP+ (WAN)
SIM Slots: None
Supported Voltage Range: 100V—240V AC
USB Ports: None
Dimensions: Ø110 x 184.1 mm
Weight: 1.1kg

Ubiquiti's UF-OLT is a fibre solution that anyone can deploy. No command lines, manuals or paid support licenses are required. The UISP Fiber UF-OLT features 8x PON ports to connect up to 1024 ONUs (128x ONUs per port), 2x SFP+ ports and 2x Gigabit Ethernet Management ports. The unit also features 2x Hotswap AC/DC PSUs for power redundancy.

It can be managed via the UISP network management platform.

*Note: 1x UF-GP-B+ included.

Specifications

Ethernet Ports: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 40W
Mounting: Rack-Mount
Operating System: UFiber
Operating Temperature: -10°C to 45°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included) ; 24V DC (Not Included)
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 8x 2.5/1.25Gbps GPON Ports; 2x 10Gbps SFP+
Supported Voltage Range: 100V – 240V
USB Ports: 1x USB 2.0
Dimensions: 442.4 x 285.6 x 43.7 mm
Weight: 4.5kg

Ubiquiti's UF-WIFI6 is a dual band, WiFi 6 (802.11ax) GPON CPE. It features an LED display, 4x Gigabit Ethernet Ports, 1xSC APC GPON WAN port and provides powerful Layer 2/3 management features. The unit is capable of distances of up to 20km with speeds of up to 2.4Gbps downstream and 1.2Gbps upstream. The UF-WIFI6 can be powered by either the included 5V 3A USB-C or 24V Passive PoE.

It can be managed via the UISP network management platform.

Specifications
Antenna Gain: 2.4GHz: 1dBi ; 5.8GHz: 3dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 1.2Gbps
Ethernet Ports: 4x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: UFiber
Operating Temperature: -15°C to 45°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 5V 3A USB-C (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 10-30V Passive PoE ; 5VDC USB-C
USB Ports: None
Other: 1x 2.5/1.25Gbps SC APC GPON
Dimensions: 140.8 x 141.5 x 31.65 mm
Weight: 415g

Ubiquiti's UMR-ULTRA is an ultra-compact, Wi-Fi 4 managed LTE4 mobile router with 2x Fast Ethernet Ports for IoT applications. It features detachable LTE antennas, wired WAN, automatic failover, and can be powered by either USB-C (5V 2A) or 4-pin ATX DC power socket (9-30V DC).

*Note: UMR-ULTRA comes with a 180-day mobility cloud free trial and is available for purchase thereafter from UI.

Specifications

Antenna Gain: LTE 2x External Antennas; 2.4GHz: 1x External Antenna
Beam-width: 360°
Data Rate: LTE: 150Mbps Downlink; 50Mbps Uplink 2.4GHz: 300Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset
Max. Power Consumption: 5.7W
Mounting: DIN-rail or Wall-Mount (Included)
Operating System: UniFi
Operating Temperature: -30°C to 70°C
PoE Input: None
PoE Output: None
Power Input: USB-C 5V 2A
Serial Interface: None
SIM Slots: 1 (Nano SIM)
Supported Voltage Range: USB-C: 5V 2A; ATX DC: 9V-30V
USB Ports: None
Dimensions: 193.5 x 82 x 26 mm
Weight: 220g

Ubiquiti UNAS-PRO is a 2U rack-mount NAS with 7x 2.5/3.5" hard drive bays, 1x Gigabit Ethernet Port and 1x 10Gbps SFP+ port designed for large-scale file storage and sharing. The UNAS-PRO also has a 1.3" touchscreen for easy management, data protection with RAID storage technology and a 1.7GHz Quad Core CPU.

*Note: Hard drives are not included. Please ensure your HDDs meet Ubiquiti's general guidelines and aren't included in the list of incompatible models.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 160W
Max. Power Budget for Drives: 135W
Mounting: 2U Rack-Mount
Operating System: UniFi Drive
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: Quad-Core ARM® Cortex®-A57 at 1.7 GHz
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 1x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 8GB
USB Ports: None
Dimensions: 442 x 325 x 87 mm

Ubiquiti UP-SL is a long-range, low-latency wireless gateway for UniFi Protect sensors. It supports up to 96 Super Link clients and 7 UP-Sense devices over a range of up to 2 km. Featuring a 10/100 Mbps Ethernet port and Bluetooth/Super Link management, it’s powered via PoE or USB-C (adapter not included). It is configured and managed through the UniFi Protect Application.

*Note: PoE and USB-C Adapter not included.

Specifications

Antenna Gain: Bluetooth: 3dBi; Super Link: 1dBi
Ethernet Ports: x1 10/100
Max. Power Consumption: 3.4W
Mounting: Wall or DIN-rail
Operating Temperature: 0 to 40°C
Power Input: PoE or USB-C
PoE Input: 802.3af
Dimensions: 159.3 x 81.9 x 30.5 mm
Weight: 179g

Ubiquiti's UPOE24-12W is a 24V, 0.5A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.5A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range:100V-240V
Dimensions: 89 x 46 x 33mm
Weight: 75g

Ubiquiti's UPOE24-24W is a 24V, 1A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 1A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 88 x 57 x 33mm
Weight: 158.5g

Ubiquiti's UPOE24-7W is a 24V, 0.3A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.3A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 72 x 45 x 33mm
Weight: 72.1g

Ubiquiti's UPOE48-60W is a 48V, 1.25A, Gigabit, PoE injector, compatible with Ubiquiti's AF-11. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 1.25A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 106 x 63 x 34mm
Weight: 210g

Ubiquiti's UPOE54-60W-10G is a 54V, 1.15A, 10Gbps, PoE injector. The unit is compatible with products that require 802.3bt PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power cable not included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000/2500/10000
PoE Output: 54V 1.15A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's USW-8FLEX-2.5G is an indoor, compact, 8 Port 2.5Gbps switch powered via PoE or the included USB-C adapter. It also features a 10Gbps Ethernet or 10Gbps SFP+ combination uplink port.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000/2500; 1x 10/100/1000/2500/10000 (Combo)
Hardware Button: None
Max. Power Consumption: PoE: 14W; PSU: 14W
Mounting: Desktop, wall-mount, DIN (Not Included)
Operating System: UniFi
Operating temperature: -20°C to 45°C
PoE Input: 802.3at (PoE+) on Port 9
PoE Output: None
Power Input: USB Type-C 5V 3A or PoE+
Serial Interface: None
SFP Ports: 10Gbps SFP+ (Combo)
Supported Voltage Range: 4.8-5.2V DC/USB or 44-57V PoE
Dimensions: 212.9 x 76 x 33.5mm
Weight: 395g

Ubiquiti's USW-8FLEX-2.5GP is an indoor, compact, 8 Port 2.5Gbps 802.3bt PoE switch that can be powered via PoE or the UACC-PSU-210W AC power adapter (Not Included). It also features a 10Gbps Ethernet or 10Gbps SFP+ combination uplink port.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000/2500; 1x 10/100/1000/10000 (Combo)
Hardware Button: None
Max. Power Consumption: PoE: 14W; PSU: 17W
Mounting: Desktop
Operating System: UniFi
Operating temperature: 20 to 45°C
PoE Input: 802.3bt (PoE+++) on Port 8
PoE Output: 802.3at PoE++)
Power Input: 802.3bt (PoE+++) or UACC-PSU-210W (Not Included)
Serial Interface: None
SFP Ports: 10Gbps SFP+ (Combo)
Supported Voltage Range: 50-57V
Dimensions: 212.9 x 99.4 x 33.5 mm
Weight: 567g

Ubiquiti's USW-PRO-HD24 is a professional-grade, high-performance Layer 3 Etherlighting™ switch with 2x 10Gbps Ports, 22x 2.5Gbps Ports and 4x 10G SFP+ ports. It also features a 1.3' touchscreen with AR switch management, layer 3 switching features and can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 22x 10/100/1000/2500; 2x 10/100/100/2500/10000
Hardware Button: Reset
Max Power Consumption: 60W
Mounting: Rack-Mount
Operating System: UniFi
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100 to 240V AC
Dimensions: 442 x 285 x 44 mm

Ubiquiti's UVC-AIDOME-W is an 8MP, 4K PoE camera with long-range IR night vision up to 40m, and enhanced AI detection capabilities such as license plate recognition and smart detections (People, Vehicles, Animals). The IP66 weather-resistant housing and IK10-rated tamper resistance allow it to be mounted indoors or outdoors. It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: Fixed focal length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max Power Consumption: 10W
Mounting: Wall, Ceiling, Pole-Mount (Included)
Night Mode: Up to 40m (Built-in IR LED illumination and IR cut filter)
Operating Temperature: -30°C to 50°C
PoE Input: 802.3af/at
Power Input: 802.3af/at
Resolution: 8MP 3840 x 2160 (16:9)
Sensor: 1/1.8" 8MP
Video Compression: H.264, MJPG
Dimensions: Ø118 x 90.8 mm
Weight: 700g

Ubiquiti's UVC-AILPR-B is a specialized IP66, 4K, 8MP IP camera with 3x optical zoom and long-range IR night vision optimized for recognizing license plates on vehicles moving up to 90 km/h. It can be configured and managed using the UniFi Protect Application.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 25.5W
Mounting: Wall or Ceiling Mount
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -30°C to 50°C
PoE Input: 802.3at (PoE+)
Power Input: 42.5-57V (PoE+)
Resolution: 3840 x 2160 (16:9)
Sensor: 1/1.8"" 8MP
Video Compression: H.264 ; MJPEG
Dimensions: 130 x 151.4 x 302.9 mm
Weight: 1.5Kg

Ubiquiti's UVC-AIPRO-B is an 8MP, 4K PoE camera with 3x optical zoom, long-range IR night vision up to 25m, and enhanced AI detection capabilities such as face recognition, license plate recognition and smart detections (People, Vehicles, Animals). The IP65 weather-resistant housing and IK04-rated tamper resistance allow it to be mounted both indoors and outdoors. It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Two-Way Audio
Max Power Consumption: 11W
Mounting: Wall, Ceiling, Pole-Mount (Included)
Night Mode: Up to 25m
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at
Power Input: 802.3af/at
Resolution: 8MP 3840 x 2160 (16:9)
Sensor: 1/1.8" 8MP
Video Compression: H.264, MJPG
Dimensions: Ø86 x 175.3 mm
Weight: 820g

Ubiquiti's UVC-AIPRO-W is an 8MP, 4K PoE camera with 3x optical zoom, long-range IR night vision up to 25m, and enhanced AI detection capabilities such as face recognition, license plate recognition and smart detections (People, Vehicles, Animals). The IP65 weather-resistant housing and IK04-rated tamper resistance allow it to be mounted both indoors and outdoors. It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Two-Way Audio
Max Power Consumption: 11W
Mounting: Wall, Ceiling, Pole-Mount (Included)
Night Mode: Up to 25m
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at
Power Input: 802.3af/at
Resolution: 8MP 3840 x 2160 (16:9)
Sensor: 1/1.8"" 8MP
Video Compression: H.264, MJPG
Dimensions: Ø86 x 175.3 mm
Weight: 820g
