The POE-802O adapter transforms almost any Ubiquiti PoE device into a fully compliant 48V, PoE-compatible product.

The Instant PoE Adapter works seamlessly with a variety of PoE switches for remote power control applications. You can conveniently power or power cycle your remote devices using your PoE switch.
Specifications
Interface In: (1) Gigabit RJ45 Port
Interface Out: (1) Gigabit Ethernet Cable
Power Input : 48V; 802.3af
Max Power Output: 24V; 0.5A
Ethernet ESD/Surge Protection: ±15kV
Dimensions: Ø 30.2 x 166 mm
Dimensions with RJ45 Cable: Ø 30.2 x 366.6 mm
Weight: 90g
Operating Temperature: -30 to 70° C

Ubiquiti's U6-EXT is a plug and play, dual band, Wi-Fi 6 (802.11ax) Range Extender. It delivers an aggregate data rate of up to 5.3Gbps over 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: Shuko (EUR-SCH) adapter sold separately.

Specifications
Antenna Gain: 2.4GHz: 5dBi ; 5.8GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 573.5Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: None
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Plug Point
Operating System: UniFi
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: None
Power Input: 2-Pin Schuko
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 100-240V
USB Ports: None
Dimensions: 169.7 x 112.2 x 77.6 mm
Weight: 340g

Ubiquiti's U6-IW is a dual band, WiFi 6 (802.11ax) in-wall access point. It delivers an aggregate data rate of up to 5.3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It offers PoE passthrough as an integrated 4-port Gigabit switch when the device is powered by an 802.3af/at PoE switch.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 5dBi ; 5.8GHz: 5.9dBi
Beam-width: 360°
Data Rate: 2.4GHz : 573.5Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13.5W
Mounting: 1 Gang Electrical Wall Box (Not Included)
Operating System: UniFi
Operating Temperature: -30°C to 60°C
Power Input: 802.3at
PoE Output: 48V Pass-Through
Power Input: 802.3at or UniFi Switch
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57VDC
USB Ports: None
Dimensions: 139.66 x 96 x 31.19 mm
Weight: 460g

Ubiquiti's U6-LR is an indoor or outdoor, dual band, WiFi 6 (802.11ax) long range access point. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (4x4 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5.5dBi
Beam-width: 360
Data Rate: 2.4GHz: 600Mbps; 5.8GHz: 2400Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16.5W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø220 x 48mm
Weight: 930g

Ubiquiti's U6-PRO is a high-performance, dual band WiFi 6 (802.11ax) access point. It delivers an aggregate data rate of up to 5.3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi
Beam-width: 360
Data Rate: 2.4GHz: 573Mbps; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø197 x 35 mm
Weight: 600g

Ubiquiti's U7-IW is a Dual-Band WiFi 7, wall-mounted AP with 4 spatial streams and 3x 2.5Gbps ports, with one supporting PoE input and one supporting PoE output. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi: ; 5GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps
Ethernet Ports: 3x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Wall-Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3af/at (PoE+ required for PoE output)
PoE Output: 802.3af
Power Input: 802.3at/at
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: 137 x 98.7 x 30.2 mm
Weight: 400g

Ubiquiti's U7-LITE is a Dual-Band WiFi 7 access point featuring high gain integrated antennas and 1x 2.5Gbps Ethernet port. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps 5.8GHz: 4.3Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3af or Passive PoE (Not Included)
PoE Output: None
Power Input: 802.3af or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø171.5 x 33 mm
Weight: 313 g

Ubiquiti's U7-PRO-XG-W is a white, Tri-Band, 6-stream, WiFi 7 access point featuring 1x 10Gbps Ethernet port and 6GHz support for interference-free WiFi in demanding, large-scale environments. It delivers an aggregate data rate of up to 10.78Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands and is powered by PoE+ (802.3at).

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications

Antenna Gain: 2.4GHz: 4dBi; 5GHz: 5dBi; 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps ; 6GHz: 5.8Gbps
Ethernet Ports: 1x 10/100/1000/2500/10000
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3at (PoE+)
PoE Output: None
Power Input: 802.3at (PoE+) (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø206 x 32.5 mm
Weight: 750g

Ubiquiti's U7-PRO-XGS-W is a white, Tri-Band, 8-stream, WiFi 7 access point featuring 1x 10Gbps Ethernet port and 6GHz support for interference-free WiFi in demanding, large-scale environments. It delivers an aggregate data rate of up to 15Gbps over its 6GHz (2x2 MU-MIMO), 5GHz (4x4 MU-MIMO), and 2.4GHz (2x2 MU-MIMO) bands and is powered by PoE++ (802.3bt).

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi; 5GHz: 6dBi; 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 8.6Gbbps ; 6GHz: 5.8Gbps
Ethernet Ports: 1x 10/100/1000/2500/10000
Hardware Button: Reset
Max. Power Consumption: 29W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3bt (PoE++)
PoE Output: None
Power Input: 802.3bt (PoE++) (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø215 x 32.5 mm
Weight: 800g

Ubiquiti's UA-G3-W is an IP55 tamper resistant access reader with speaker for single door access control indoors and outdoors. PoE powers the unit, which connects to a UniFi Access Hub via PoE and can be unlocked using an NFC card or UniFi Identity Mobile App.

Note: This device needs to be paired with UA-HUB-DM

Specifications
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: In-wall, Gang Box
Operating Temperature: -30 to 45° C
Max Power Consumption: 5W
Power Input: PoE (Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Dimensions: 93 x 40 x 36.5 mm
Weight: 82g

The Ubiquiti UA-G3FLEX-W is an IP55-rated NFC card reader featuring a keypad and Touch Pass support, for which users will receive 10 free Touch Passes in the first year, thereafter, passes are billed annually per user. Powered via PoE, it's designed for seamless integration with UniFi Access Hubs.

Note: This device needs to be paired with UA-HUB-DM

Specifications
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: Wall-Mount (Included) ; Gang-box, junction box (Optional)
Operating Temperature: -30 to 60° C
Max Power Consumption: 5W
Power Input: PoE (Not Included), UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
Dimensions: 84 x 84 x 40.8 mm
Weight: 165g

Ubiquiti's UA-G3SK-PRO starter kit includes a Door Hub, an IP55 G3 Reader Pro with integrated camera, an IP55 G3 Reader, and 2x Pocket Key fobs. This starter kit provides complete entry and exits control for a single door and includes Touch Pass support, for which users will receive 10 free Touch Passes in the first year; thereafter, passes are billed annually per user. The kit can be configured and managed with the UniFi Access Application.

Specifications
Door Hub
Button: Reset
Terminal Input: 2x Door exit request; 1x Door position; 1x Emergency
Ethernet Ports: 5x 10/100/1000
Lock Terminals: 1x 12V 1A
Mounting: DIN-rail (Included)
Operating Temperature: 0°C to 40°C
Max Power Consumption: 30W
PoE Input: PoE++ (50V DC, 1A)
PoE Output: 4x 802.3af
Power Input: PoE++ ; UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
Supported Doors: 1

Dimensions: 174.9 x 126 x 32.9 mm
Weight: 363g

G3 Reader Pro
Button: Reset
Connectivity: BLE 4.2 or NFC
Ethernet Ports: 1x 10/100/1000
Mounting: Wall, gang-box mount (Included)
Operating Temperature: Device: -30°C to 45°C; Display: -10°C to 45°C
Max Power Consumption: 6W
Power Input: PoE (802.3af, Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Supported Voltage: 48V

Dimensions: 160 x 40.4 x 40.55 mm
Weight: 136g

G3 Reader
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: Wall, gang-box mount (Included)
Operating Temperature: Device: -30°C to 45°C
Max Power Consumption: 5W
Power Input: PoE (802.3af, Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Supported Voltage: 48V

Dimensions: 93 x 40 x 36.5 mm
Weight: 82g

Ubiquiti's UA-HUB-DM is a compact, indoor, access control hub which when paired with a UniFi Access Reader provides access control for a single door. It features 3x Gigabit Ethernet Ports, one of which accepts PoE++ (802.3bt) input and 2x PoE+ output ports with a total of 31W. The hub also has 2x input terminals for 1x door exit request and 1x door position and can be unlocked using an NFC card or UniFi Identity Mobile App.

Specifications
Button: Reset; Dry/Wet Switch
Bluetooth: None
Input Terminals: 1x Door Exit Request ; 1x Door Position
Ethernet Ports: 3x 10/100/1000
Dry Output Relay: 30V DC 1A
Wet Output Relay: 12V DC 1A
Mounting: DIN-rail (Included)
Operating Temperature: -30 to 40° C
Max Power Consumption: 19W
Power Input: 802.3at (PoE++)(Not Included)
Dimensions: 113 x 66 x 27.6mm
Weight: 190g

Ubiquiti's UA-Ultra is an IP55 tamper resistant access reader with an integrated hub for complete single door access control. The unit is powered by PoE+ and features 1x Lock terminal (12V/1A), 1x Exit request input and can be unlocked using an NFC card or UniFi Identity Mobile App.

Specifications

Button: Reset
Bluetooth: BLE 4.2
Digital Input: 1x Exit Request
Ethernet Ports: 1x 10/100
Lock Terminals: 1x 12V 1A
Mounting: Wall-Mount or Gang Box Mount
Operating Tempreture: -30 to 40° C
Max Power Consumption: 18W
Power Input: 802.3af/at PoE (Not Included)
Dimensions: 126 x 45 x 37.45mm
Weight: 140g

Ubiquiti's UACC-INS-4.5M is a 4.5 metre USB-C cable that connects the UVC-G4INS and UVC-G6INS to a POE-USBC adapter.

Specifications

Cable length: 4.5m
Cable Color: White
Operating Temperature: -20°C to 60°C
Shielding: Shielded twisted pair (STP)
Weight: 117g

Ubiquiti's UACC-LRE is an outdoor Gigabit Ethernet adapter which establishes long-range connections between PoE switches and devices. The unit features 2x Gigabit Ethernet ports. Port one receives 802.3af/at PoE input while port two provides PoE passthrough for distances up to 1km when making use of multiple adapters. The unit also offers 10kA+ surge protection and works reliably in extreme temperatures to protect your deployment from weather and electrical damage.

*Note: This device does not support MTU's larger than 1500. If making use of jumbo frames across the device, it will not work.

Specifications
Ethernet Ports: 2x 10/100/1000
Hardware Button: None
Max. Power Consumption: 1.5W
Mounting: Pole-Mount
Operating System: None
Operating Temperature: -40°C to 80°C
PoE Input: 802.3af/at
PoE Output: 802.3af PoE Passthrough
Power Input: 802.3af/at
SFP Ports: None
Supported Voltage Range: 37-57V
Dimensions: 196.5 x 93.5 x 39 mm
Weight: 350g

Ubiquiti's UACC-PSU-210W is a wall mountable AC power adapter which delivers 210W at 54V DC, ideal for powering PoE Switches.

Specifications
Compatibility: USW-ULTRA, USW-U60, USW-PRO-MAX16P, USW-U210
Connector: IEC
DC plug: 5.5 x 2.1 x 11.5 mm
DC cable: UL11353 16AWG 1.5 m
Voltage: 54V
Wattage: 210W
Dimensions: 190 x 86 x 26 mm
Weight: 2kg

Ubiquiti's UB-ETHSP is a Gigabit Ethernet surge protector designed to protect outdoor, PoE or non-PoE Ethernet devices from electrostatic discharge and surges.

Specifications

Data Line Protection: RJ45 10/100/1000
DC Spark-Over Voltage: 90V 100V/s
Discharge Current: 10kA+
Ethernet Ports: 2x 10/100/1000
Maximum Impulse Spark-Over Voltage: 700V 1kV/µs
Operating Temperature: -30°C to 65°C
PoE Support: 802.3af & Passive PoE
Dimensions: 91 x 61 x 32.5mm

Ubiquiti's UCG-FIBER is a desktop 10Gbps dual WAN, UniFi cloud gateway with selectable NVR storage via SSD up to 2TB. The unit runs the complete UniFi application suite for full stack network management and features 1x 10Gbps WAN port, 4x 2.5Gbps LAN Ports, one with 802.3at (PoE+) PoE output, as well as 2 x SFP+ ports.

It can be configured and managed with the UniFi Network Application.

Note: NVMe SSD not included. Third-party SSD installation requires tray accessory.

Specifications
Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/10000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 29.4W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3at (PoE+) on Port 4
Power Input: 54V 1.1A Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
Serial Interface: None
SFP Ports: 2 x SFP+ (1x WAN ; 1 x LAN)
Supported Voltage Range: 50-57V
System Memory: 3GB
USB Ports: None
Dimensions: 212.8 x 127.6 x 30 mm
Weight: 675g

Ubiquiti's UCK-G2-SSD is a compact UniFi console running the complete UniFi application suite for full stack network management and features a pre-installed 1TB SSD. The unit can be powered by PoE or a USB-C quick charge adapter.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.6W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 35°C
PoE Input: 802.3af/at (PoE)
PoE Output: None
Power Input: 802.03af/at (PoE) or 9V 2A USB-C Power Supply (Not Included)
Processor: Octa-core Arm® Cortex®-A53 based chip
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 9V 2A (USB-C)
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 131.2 x 27.1 x 134.2 mm
Weight: 560g
