UltraLAN 1x8 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x4 SC/APC 900μm PLC Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

Specifications:
Port Configuration
1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x4 LC/APC 900μm PLC Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

Specifications:

Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x32 SC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x32 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x2 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x16 SC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x16 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

Brand: UltraLAN
SKU/Product Code: CAB‑CS‑F1000
Description: 19" 700mm flat cabinet shelf designed for 1000mm depth cabinets, vented for airflow, supports up to 50kg.

Product Overview
The UltraLAN CAB‑CS‑F1000 is a flat 19" cabinet shelf designed for use in 1000mm depth server and network cabinets. With a depth of 700mm, it provides a large surface area to support non‑rackmount equipment such as routers, PBX systems, and other devices.

Constructed from durable steel and featuring a vented design, the shelf improves airflow and heat dissipation inside the cabinet. It mounts securely to the upright struts with 4‑post mounting, ensuring stability even under heavier loads.

Key Features
19" flat cabinet shelf – 700mm depth
Suitable for 1000mm depth cabinets
4‑post mounting – secure and stable installation
Vented design – improved airflow and heat dissipation
Supports non‑rackmount equipment – routers, PBX, etc.
Load capacity: up to 50kg
Shelf dimensions: 465 × 700 mm
Cage nuts & screws not included (available separately or with UltraLAN cabinets)

Technical Specifications
Specification Details
Product Code CAB‑CS‑F1000
Manufacturer UltraLAN
Type Flat Cabinet Shelf
Rack Width 19"
Depth 700mm
Suitable Cabinet Depth 1000mm
Dimensions (W × D) 465 × 700 mm
Mounting 4‑post mounting
Design Vented
Load Capacity 50kg
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~6–7 kg (steel shelf)
Packaging (protective box + padding): ~1–1.5 kg
Gross shipping weight: ± 8 kg

Brand: UltraLAN
SKU/Product Code: CAB‑C‑6612WMSA
Description: 12U swing frame wall mount cabinet with 600mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑6612WMSA is a swing frame wall mount cabinet designed for medium‑sized networking installations where space is limited, such as retail shops, small offices, or schools. Its hinged back section allows the cabinet to swing out from the wall, providing easy access to the rear of equipment — especially useful for cable management and maintenance.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features removable side panels for quick access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
12U swing frame wall mount cabinet – space‑saving design
Hinged back section – easy rear access for cabling
Enclosure depth: 600mm – accommodates deeper equipment
Strengthened safety glass front door – with lock and keys
Removable side panels – quick access for installers
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑6612WMSA
Manufacturer UltraLAN
Rack Units 12U
Rack Width 19"
Depth 600mm
Dimensions (H × W × D) 645 × 615 × 615 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~26–28 kg (typical for 12U swing frame steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 30 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64512OD
Description: 12U outdoor wall mount cabinet with 450mm depth, 2 cooling fans, weatherproof steel construction, and 3‑point locking system.

Product Overview
The UltraLAN CAB‑C‑64512OD is a rugged outdoor wall mount cabinet designed to protect sensitive networking equipment from harsh environments. Built from electro‑galvanized cold rolled steel with a powder‑coated finish, it resists corrosion and ensures long‑term durability.

For weatherproofing, the cabinet features a polyurethane door joint strip for water and dust protection, plus a roof awning to prevent rain ingress. Security is enhanced with a 3‑point swing handle locking system, while ventilation is managed through side panel vents with replaceable mesh filters and 2 ceiling‑mounted fans for efficient heat dissipation. Cable entry is provided via rubber‑sealed glands at the base, and four hooks on top simplify installation.

Key Features
12U outdoor wall mount cabinet – 450mm body depth (500mm including rooftop)
Powder‑coated electro‑galvanized cold rolled steel – corrosion resistant
Supplied fully assembled – saves installation time
Polyurethane door joint strip – water & dust protection
Roof awning – prevents rain ingress
3‑point swing handle locking system – enhanced security
2 ceiling‑mounted fans – improved airflow and cooling
Side vents with replaceable mesh filters – dust resistance
Adjustable 19" mounting rails – numbered U markings for easy alignment
Cable entry via round glands with removable rubber covers
4 hooks on top – easier installation

Technical Specifications
Specification Details
Product Code CAB‑C‑64512OD
Manufacturer UltraLAN
Rack Units 12U
Rack Width 19"
Depth 450mm body / 500mm including rooftop
Dimensions (W × D) 600mm wide × 450mm deep
Material Electro‑galvanized cold rolled steel
Finish Powder‑coated
Front Door 3‑point swing handle lock, polyurethane seal
Cooling 2 ceiling‑mounted fans
Side Panels Vented with replaceable mesh filters
Cable Entry Round glands with rubber covers (base)
Mounting Wall mount (hooks included)
Assembly Supplied fully assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~30–32 kg (typical for 12U outdoor steel cabinets with fans)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 34 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64512WMFA
Description: 12U fixed wall mount cabinet with 450mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑64512WMFA is a cost‑effective fixed wall mount cabinet designed for medium‑sized networking installations in retail shops, small offices, and school environments. Its compact size and wall‑mount design save valuable floor space while providing secure housing for networking equipment.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features toolless removable side panels for easy access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
12U fixed wall mount cabinet – compact and space‑saving
Enclosure depth: 450mm – suitable for networking gear
Strengthened safety glass front door – with lock and keys
Toolless removable side panels – quick access for installers
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑64512WMFA
Manufacturer UltraLAN
Rack Units 12U
Rack Width 19"
Depth 450mm
Dimensions (H × W × D) 645 × 615 × 465 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Toolless removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~24–26 kg (typical for 12U fixed steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 28 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑DR010U
Description: 10U desktop open frame rack with adjustable tilt angle, steel construction, and 30kg load capacity.

Product Overview
The UltraLAN CAB‑C‑DR010U is a professional desktop open frame rack designed for studios, processing environments, and test setups where compact and flexible equipment housing is required. Compliant with ANSI/EIA RS‑310D, DIN41491, and IEC60297 standards, it ensures maximum compatibility and ease of installation.

Its 0°–15° adjustable slanted front profiles provide optimal stability and ergonomic viewing angles for installed equipment. Constructed from 2.0mm thick cold‑rolled steel with a fine‑structured black powder coating (RAL9004), the rack combines durability with a sleek finish. Perforated sides allow cable guiding and accessory mounting, while the simple flat‑down package design enables easy 5‑minute assembly by a single person.

Key Features
10U desktop open frame rack – compact and versatile
Adjustable tilt angle: 0°–15° for ergonomic viewing
Stores up to 10 units of 19" equipment
2.0mm thick cold‑rolled steel frame – durable and stable
Black powder coating (RAL9004) – fine structure finish
Punched square holes – compatible with snap‑in cage nuts
Perforated sides – cable guiding and accessory mounting
Easy assembly – flat‑down package, 5 minutes setup
Desktop standing use – ideal for studios and test environments
Max load capacity: 30kg

Technical Specifications
Specification Details
Product Code CAB‑C‑DR010U
Manufacturer UltraLAN
Rack Units 10U (9 HE height)
Rack Width 19"
Tilt Angle 0°–15° adjustable
Dimensions (W × H × D) 509 × 446.2 × 301.3 mm (incl. rubber feet)
Material 2.0mm cold‑rolled steel
Finish Black powder coating (RAL9004)
Load Capacity 30kg
Assembly Flat‑down package, 5 minutes assembly
Accessories Assembly hardware + 20 cage nuts & screws
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~8–9 kg (steel frame)
Packaging (flat‑down box + padding): ~2–3 kg
Gross shipping weight: ± 11 kg

UltraLAN 10G SFP BiDi Module Pair - SM 10KM 1270/1330nm


UltraLAN's SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 10Gbps and 10km transmission distance with SMF.


The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.


Product Features:

Supports 10G rates
Bi-Directional LC connector
Hot pluggable SFP footprint
Applicable for 10KM SMF connection
Low power consumption, < 0.8W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection


Please note, as these are BiDi SFP Modules they are only sold in a pair.

Ubiquiti's U6+ is a dual band, WiFi 6 (802.11ax) access point. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included. The U6+ has replaced the UAP-AC-LR and U6-LITE. Read more about that here.
Specifications
Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5.4dBi
Beam-width: 360
Data Rate: 2.4GHz: 573.5Mbps ; 5.8GHz: 2402Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af or 48V Passive PoE
PoE Output: None
Power Input: 802.3af/at or 48V Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø160 x 33 mm
Weight: 413g

Ubiquiti’s U6-MESH-PRO is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point featuring 2x Gigabit Ethernet ports, 4 spacial streams and integrated high power 8dBi antennas. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

Note: It can be configured and managed with the UniFi Network Application.

Specifications
Antenna Gain: 2.4GHz: 8dBi ; 5.8GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop ; Wall-Mount ; Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af/at PoE
PoE Output: None
Power Input: 48V; 0.5A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5V-57V
USB Ports: None
Dimensions: 343.2 x 181.2 x 60.2 mm
Weight: 819g

Ubiquiti’s U6-MESH is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point with a compact IPX5 indoor/outdoor enclosure. It delivers an aggregate data rate of up to 5.3 Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

Specifications
Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11.4W
Mounting: Desktop ; Wall-Mount ; Pole Mount ; Ceiling Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af PoE
PoE Output: None
Power Input: 48V; 0.32A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44V-57V
USB Ports: None
Dimensions: Ø 48.50 x 159.49mm
Weight: 400g

Ubiquiti's U7-PRO-IW is a Tri-Band, Wi-Fi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6GHz support for interference-free Wi-Fi in demanding, large-scale environments. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications

Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi: 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 4.3Gbps; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: 1 Gang Electrical Wall Box (Not Included)
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: 150 x 103 x 36 mm
Weight: 580g

Ubiquiti's U7-PRO is a Tri-Band WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding environments. It delivers an aggregate data rate of up to 9.3Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.8dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 2.8Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø206 x 46 mm
Weight: 680g

Brand: Ubiquiti
Product Code: U7‑PRO‑5
Description: Ubiquiti UniFi WiFi 7 Pro Tri‑Band AP 5‑Pack

Product Overview
The Ubiquiti UniFi U7‑Pro‑5 delivers five WiFi 7 Pro Tri‑Band access points in a single package, designed for high‑performance wireless networking in demanding environments. Each unit supports 2.4GHz, 5GHz, and 6GHz bands with MU‑MIMO technology, providing an aggregate data rate of up to 9.3Gbps. Equipped with a 2.5Gbps Ethernet port, these APs ensure fast wired backhaul. Managed via the UniFi Network Application, they offer seamless configuration and monitoring.

Key Features
Tri‑Band WiFi 7 access points (2.4GHz, 5GHz, 6GHz)
Aggregate throughput up to 9.3Gbps
2.4GHz: 688Mbps, 5GHz: 2.8Gbps, 6GHz: 5.7Gbps
Antenna gain: 2.4GHz 4dBi, 5GHz 6dBi, 6GHz 5.8dBi
1 × 2.5Gbps Ethernet port
Ceiling or wall mount options
Managed via UniFi Network Application
Max power consumption: 21W per unit
Operating temperature: –30°C to 60°C
Dimensions: Ø206 × 46 mm
Net weight per unit: 680g
Gross shipping weight (5‑pack): ~5.0–5.5 kg (including packaging)
Note: PoE injector not included

Technical Specifications
Feature Details
Product Code U7‑PRO‑5
Antenna Gain 2.4GHz: 4dBi; 5GHz: 6dBi; 6GHz: 5.8dBi
Beamwidth 360°
Data Rate 2.4GHz: 688Mbps; 5GHz: 2.8Gbps; 6GHz: 5.7Gbps
Ethernet Ports 1 × 10/100/1000/2500
Hardware Button Reset
Max Power Consumption 21W
Mounting Ceiling or Wall
Operating System UniFi
Operating Temp –30°C to 60°C
PoE Input 802.3at or Passive PoE
PoE Output None
Supported Voltage 44–57V
Dimensions Ø206 × 46 mm
Net Weight 680g per unit
Gross Shipping Weight 5.0–5.5 kg (5‑pack)

What’s Included
5 × Ubiquiti UniFi WiFi 7 Pro Tri‑Band AP units
Mounting accessories (ceiling/wall)
User documentation
