UltraLAN CAT5e EZ Shielded RJ45 Connector (50x Packet)

The UltraLAN EZ RJ45 CAT5e Shielded Connector simplifies twisted pair terminations by allowing the wires to be inserted through the connector and out the front. This allows the technician or installer to easily verify the proper wiring order. Crimping is recommended by using the UltraLAN EZ Crimping tool, which crimps the RJ45 connector and trims the excess cable in one simple cycle.

Electrical performance of the termination is optimized by pulling the connector down over the cable jacket and seating it tightly in the rear of the connector. By reducing the distance between the wire twists and contacts, performance is also optimized!

This RJ45 connector is enclosed in a metal frame to provide shielding and grounding when used with suitable networking cable.

Please note, only sold in packets of 50 connectors.

UltraLAN CAT5e EZ RJ45 Connector


The UltraLAN EZ RJ45 CAT5e Connector simplifies twisted pair terminations by allowing the wires to be inserted through the connector and out the front. This allows the technician or installer to easily verify the proper wiring order. Crimping is recommended by using the UltraLAN EZ Crimping tool, which crimps the RJ45 connector and trims the excess cable in one simple cycle.

Electrical performance of the termination is optimized by pulling the connector down over the cable jacket and seating it tightly in the rear of the connector. By reducing the distance between the wire twists and contacts, performance is also optimized!

Please note, only sold in packets of 50 connectors.

UltraLAN CAT5e/6/6A/7 Crimping Tool

This professional crimp tool is compact and rugged, while fitting comfortably in your hand or in your pocket. The straight action termination delivers even pressure on each of the modular plug’s pins, ensuring precise termination with minimal hand force.

The crimp tool also stays securely closed with a gun-style lock. Its superior fit and function consistently meets performance requirements.

Product Features:

Able to crimp CAT5/6/6A/7 RJ45 connectors
Straight action crimp with minimal hand force
Compact and rugged
Terminates to industry specified crimp heights

Brand: UltraLAN
SKU/Product Code: CAB‑C‑6609WMSA
Description: 9U swing frame wall mount cabinet with 600mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑6609WMSA is a swing frame wall mount cabinet designed for smaller networking installations where space is limited, such as retail shops, small offices, or schools. Its hinged back section allows the cabinet to swing out from the wall, providing easy access to the rear of equipment — especially useful for cable management.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features removable side panels for quick access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
9U swing frame wall mount cabinet – compact and space‑saving

Hinged back section – easy rear access for cabling

Enclosure depth: 600mm – accommodates deeper equipment

Strengthened safety glass front door – with lock and keys

Removable side panels – quick access for installers

Venting slots with 2 fan mountings (fans not included)

Adjustable rail depth – flexible equipment installation

Powder‑coated finish – scratch resistant and durable

Pre‑assembled – saves time and effort

Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑6609WMSA
Manufacturer UltraLAN
Rack Units 9U
Rack Width 19"
Depth 600mm
Dimensions (H × W × D) 515 × 615 × 615 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~24–26 kg (typical for 9U swing frame steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 28 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64509OD
Description: 9U outdoor wall mount cabinet with 450mm depth, 2 cooling fans, weatherproof steel construction, and 3‑point locking system.

Product Overview
The UltraLAN CAB‑C‑64509OD is a rugged outdoor wall mount cabinet designed to protect sensitive networking equipment from harsh environments. Built from electro‑galvanized cold rolled steel with a powder‑coated finish, it resists corrosion and ensures long‑term durability.

For weatherproofing, the cabinet features a polyurethane door joint strip for water and dust protection, plus a roof awning to prevent rain ingress. Security is enhanced with a 3‑point swing handle locking system, while ventilation is managed through side panel vents with replaceable mesh filters and 2 ceiling‑mounted fans for efficient heat dissipation. Cable entry is provided via rubber‑sealed glands at the base, and four hooks on top simplify installation.

Key Features
9U outdoor wall mount cabinet – 450mm body depth (500mm including rooftop)
Powder‑coated electro‑galvanized cold rolled steel – corrosion resistant
Supplied fully assembled – saves installation time
Polyurethane door joint strip – water & dust protection
Roof awning – prevents rain ingress
3‑point swing handle locking system – enhanced security
2 ceiling‑mounted fans – improved airflow and cooling
Side vents with replaceable mesh filters – dust resistance
Adjustable 19" mounting rails – numbered U markings for easy alignment
Cable entry via round glands with removable rubber covers
4 hooks on top – easier installation

Technical Specifications
Specification Details
Product Code CAB‑C‑64509OD
Manufacturer UltraLAN
Rack Units 9U
Rack Width 19"
Depth 450mm body / 500mm including rooftop
Dimensions (W × D) 600mm wide × 450mm deep
Material Electro‑galvanized cold rolled steel
Finish Powder‑coated
Front Door 3‑point swing handle lock, polyurethane seal
Cooling 2 ceiling‑mounted fans
Side Panels Vented with replaceable mesh filters
Cable Entry Round glands with rubber covers (base)
Mounting Wall mount (hooks included)
Assembly Supplied fully assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~28–30 kg (typical for 9U outdoor steel cabinets with fans)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 32 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64509WMFA
Description: 9U fixed wall mount cabinet with 450mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑64509WMFA is a cost‑effective wall mount cabinet designed for smaller networking installations in retail shops, small offices, and school environments. Its compact size and wall‑mount design save valuable floor space while providing secure housing for networking equipment.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features toolless removable side panels for easy access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with keylock provides both visibility and security.

Key Features
9U fixed wall mount cabinet – compact and space‑saving
Enclosure depth: 450mm – suitable for networking gear
Strengthened safety glass front door – with lock and keys
Toolless removable side panels – easy access for installers
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑64509WMFA
Manufacturer UltraLAN
Rack Units 9U
Rack Width 19"
Depth 450mm
Dimensions (H × W × D) 515 × 615 × 465 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Toolless removable
Fan Mountings 2 slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~22–24 kg (typical for 9U steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 26 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑CPDU‑09SAIEC14
Description: 9‑socket vertical rack‑mount PDU with IEC plug, designed to provide 3pin SA power points for cabinet hardware.

Product Overview
The UltraLAN CAB‑CPDU‑09SAIEC14 is a 9‑socket vertical rack PDU designed for efficient power distribution inside server and network cabinets. It provides nine 3pin SA outlets for hardware and mounts vertically against cabinet railings for neat integration.

Equipped with an IEC power cord, this PDU connects directly to a UPS, making it ideal for professional server environments. For added flexibility, an IEC female to SA 3pin power cord (1.8m) can be purchased separately, allowing connection to a standard SA 220V socket.

Key Features
Vertical rack‑mount design – fits standard server/network cabinets
9 × 3pin SA power sockets – reliable distribution for cabinet hardware
IEC power cord – direct connection to UPS or mains supply
Optional IEC female to SA 3pin cord (1.8m) – for SA 220V socket use
Durable construction – long‑lasting performance
Ideal for powering servers, switches, and networking gear

Technical Specifications
Specification Details
Product Code CAB‑CPDU‑09SAIEC14
Manufacturer UltraLAN
Type Rack Mount PDU
Rack Size 19" standard width (vertical mount)
Sockets 9 × 3pin SA
Plug Type IEC
Cord Option IEC female to SA 3pin (1.8m, sold separately)
Mounting Vertical, against cabinet railings
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~1.5–2 kg (aluminium + sockets + cord)
Packaging (protective box + padding): ~0.5–0.7 kg
Gross shipping weight: ± 2.5 kg

Brand: UltraLAN
SKU/Product Code: CAB‑C‑6606WMSA
Description: 6U swing frame wall mount cabinet with 600mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑6606WMSA is a swing frame wall mount cabinet designed for smaller networking installations where space is limited, such as retail shops, small offices, or schools. Its hinged back section allows the cabinet to swing out from the wall, providing easy access to the rear of equipment — especially useful for cable management.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features toolless removable side panels for quick access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
6U swing frame wall mount cabinet – compact and space‑saving
Hinged back section – easy rear access for cabling
Enclosure depth: 600mm – accommodates deeper equipment
Strengthened safety glass front door – with lock and keys
Toolless removable side panels – quick access for installers
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑6606WMSA
Manufacturer UltraLAN
Rack Units 6U
Rack Width 19"
Depth 600mm
Dimensions (H × W × D) 385 × 615 × 615 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Toolless removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~20–22 kg (typical for 6U swing frame steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 24 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64506OD
Description: 6U outdoor wall mount cabinet with 450mm depth, 2 cooling fans, weatherproof steel construction, and 3‑point locking system.

Product Overview
The UltraLAN CAB‑C‑64506OD is a rugged outdoor wall mount cabinet designed to protect sensitive networking equipment from harsh environments. Built from electro‑galvanized cold rolled steel with a powder‑coated finish, it resists corrosion and ensures long‑term durability.

For weatherproofing, the cabinet features a polyurethane door joint strip for water and dust protection, plus a roof awning to prevent rain ingress. Security is enhanced with a 3‑point swing handle locking system, while ventilation is managed through side panel vents with replaceable mesh filters and 2 ceiling‑mounted fans for efficient heat dissipation. Cable entry is provided via rubber‑sealed glands at the base, and four hooks on top simplify installation.

Key Features
6U outdoor wall mount cabinet – 450mm body depth (500mm including rooftop)
Powder‑coated electro‑galvanized cold rolled steel – corrosion resistant
Supplied fully assembled – saves installation time
Polyurethane door joint strip – water & dust protection
Roof awning – prevents rain ingress
3‑point swing handle locking system – enhanced security
2 ceiling‑mounted fans – improved airflow and cooling
Side vents with replaceable mesh filters – dust resistance
Adjustable 19" mounting rails – numbered U markings for easy alignment
Cable entry via round glands with removable rubber covers
4 hooks on top – easier installation

Technical Specifications
Specification Details
Product Code CAB‑C‑64506OD
Manufacturer UltraLAN
Rack Units 6U
Rack Width 19"
Depth 450mm body / 500mm including rooftop
Dimensions (W × D) 600mm wide × 450mm deep
Material Electro‑galvanized cold rolled steel
Finish Powder‑coated
Front Door 3‑point swing handle lock, polyurethane seal
Cooling 2 ceiling‑mounted fans
Side Panels Vented with replaceable mesh filters
Cable Entry Round glands with rubber covers (base)
Mounting Wall mount (hooks included)
Assembly Supplied fully assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~24–26 kg (typical for 6U outdoor steel cabinets with fans)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 28 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64506WMFA
Description: 6U fixed wall mount cabinet with 450mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑64506WMFA is a cost‑effective fixed wall mount cabinet designed for smaller networking installations in retail shops, small offices, and school environments. Its compact size and wall‑mount design save valuable floor space while providing secure housing for networking equipment.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features removable side panels for easy access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
6U fixed wall mount cabinet – compact and space‑saving

Enclosure depth: 450mm – suitable for networking gear

Strengthened safety glass front door – with lock and keys

Removable side panels – quick access for installers

Venting slots with 2 fan mountings (fans not included)

Adjustable rail depth – flexible equipment installation

Powder‑coated finish – scratch resistant and durable

Pre‑assembled – saves time and effort

Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑64506WMFA
Manufacturer UltraLAN
Rack Units 6U
Rack Width 19"
Depth 450mm
Dimensions (H × W × D) 385 × 615 × 465 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~20–22 kg (typical for 6U fixed steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 24 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

UltraLAN 5-in-1 Fiber Tester & Tracker

The UltraLAN all-in-one Optical Fiber Cable Tester is an essential tool for cable installers, fiber technicians or anyone working in networking environments. The tool features a combination of a fiber power meter, visual fault locator, cable tester, and cable tracker all built into one device. This allows you to test fiber optic cables for breaks, insertion loss and optical power loss, locate network cable and test its physical conditions.

The power meter supports 850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm and 1625nm wavelengths. The visual fault locator features multiple frequency settings for continuous and flashing modes. With the compact adaptor, it can be used to test RJ45 Cable's continuity, but also track cable among unknown bundles of wires (line hunt). The easy-to-read LCD interface displays power loss measurement data, wavelength, frequency, battery capacity and battery charge status.

Brand: UltraLAN
SKU/Product Code: CAB‑C‑6604WMSA
Description: 4U swing frame wall mount cabinet with 600mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑6604WMSA is a compact swing frame wall mount cabinet designed for smaller networking installations in retail shops, small offices, and school environments. Its hinged back section allows the cabinet to swing out from the wall, providing easy access to the rear of equipment especially useful for cable management.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features removable side panels with locks for added security, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and protection.

Key Features
4U swing frame wall mount cabinet – space‑saving design
Hinged back section – easy rear access for cabling
Enclosure depth: 600mm – accommodates deeper equipment
Strengthened safety glass front door – with lock and keys
Removable side panels with locks – secure and accessible
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑6604WMSA
Manufacturer UltraLAN
Rack Units 4U
Rack Width 19"
Depth 600mm
Dimensions (H × W × D) 315 × 615 × 615 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Removable, lockable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~18–20 kg (typical for 4U swing frame steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 22 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

Brand: UltraLAN
SKU/Product Code: CAB‑C‑64504WMFA
Description: 4U fixed wall mount cabinet with 450mm depth, strengthened glass door, removable side panels, and 60kg load capacity.

Product Overview
The UltraLAN CAB‑C‑64504WMFA is a compact fixed wall mount cabinet designed for smaller networking installations in retail shops, small offices, and school environments. Its wall‑mount design saves valuable floor space while providing secure housing for networking equipment.

Constructed from powder‑coated steel, the cabinet offers durability and scratch resistance. It features removable side panels for easy access, venting slots with space for two fans to improve airflow, and rack‑numbered mounting rails for simplified equipment alignment. The strengthened safety glass front door with lock provides both visibility and security.

Key Features
4U fixed wall mount cabinet – compact and space‑saving
Enclosure depth: 450mm – suitable for networking gear
Strengthened safety glass front door – with lock and keys
Removable side panels – quick access for installers
Venting slots with 2 fan mountings (fans not included)
Adjustable rail depth – flexible equipment installation
Powder‑coated finish – scratch resistant and durable
Pre‑assembled – saves time and effort
Maximum static load: 60kg

Technical Specifications
Specification Details
Product Code CAB‑C‑64504WMFA
Manufacturer UltraLAN
Rack Units 4U
Rack Width 19"
Depth 450mm
Dimensions (H × W × D) 295 × 615 × 465 mm
Material Powder‑coated steel
Front Door Strengthened safety glass, lockable
Side Panels Removable
Cooling 2 fan slots (fans not included)
Load Capacity 60kg
Assembly Supplied pre‑assembled
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~16–18 kg (typical for 4U fixed steel cabinets)
Packaging (protective box + padding): ~2–3 kg
Gross shipping weight: ± 20 kg

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

UltraLAN 45mm Fiber Splicing Sleeve

The UltraLAN fiber splice sleeves are specifically designed for the mechanical and environmental protection of fused fiber splices. The splice protectors consist of clear heat shrinkable tubing to allow for visual location of the splice prior to heat shrinking with a pre-installed stainless steel (1.5mm) reinforcing rod.

*Sold in a pack of 100.

Brand: UltraLAN
Product Code: FIB‑T‑FS2
Description: UltraLAN 4.3″ Touch Screen Fiber Fusion Splicer

Product Overview
The UltraLAN FIB‑T‑FS2 Fiber Optic Fusion Splicer is a precision tool engineered for fast, efficient, and reliable fiber optic cable splicing. With advanced features such as rapid heating technology, a high‑resolution 180° flip‑up LCD touch screen, and a six‑motor drive system, it ensures superior accuracy and reduced positioning errors. Built‑in testing tools, extended battery life, and versatile splicing capabilities make it ideal for professional network installations and maintenance tasks.

Key Features
Rapid heating technology: 8‑second fusion time, 18‑second heating cycle
High‑resolution 180° flip‑up LCD touch screen with intuitive GUI
Six‑motor drive system for enhanced precision and reduced errors
Built‑in red light source (VFL) and optical power meter (OPM) with self‑calibration
Large storage capacity for tens of thousands of splice records
5200mAh battery with extended operational life and power‑saving modes
Three‑in‑one universal clamp for patch cords, bare fibers, and leather cables
LED lighting for low‑light environments, plus status and heating indicators
Intelligent fault detection and prompt notifications
Supports external charging, USB upgrades, and splice data export
Comprehensive accessory package including toolbox and fiber optic cleaver
Estimated gross shipping weight: 4.5–5.0 kg (device + accessories + packaging)

Technical Specifications
Feature Details
Product Code FIB‑T‑FS2
Display 4.3″ LCD touch screen, 180° flip‑up
Fusion Time 8 seconds
Heating Cycle 18 seconds
Motors Six‑motor drive system
Testing Tools Built‑in VFL and OPM (six wavelengths)
Battery 5200mAh, pop‑up compartment, extended life
Clamp Three‑in‑one universal clamp
Storage Large capacity for splice records
Connectivity USB upgrades, external charging, data export
Dimensions Standard portable splicer size (toolbox included)
Gross Shipping Weight 4.5–5.0 kg
Warranty As per manufacturer

What’s Included
1 × UltraLAN FIB‑T‑FS2 Fiber Fusion Splicer
1 × Toolbox
1 × Fiber optic cleaver
1 × Power adapter and charging accessories
1 × User manual

Brand: UltraLAN
SKU/Product Code: CAB‑C‑61027FSUA
Description: 27U free‑standing server cabinet with 1m depth, tempered glass door, 4 cooling fans, 3 shelves, and 800kg load capacity.

Product Overview
The UltraLAN CAB‑C‑61027FSUA is a 27U free‑standing server cabinet designed for professional IT, telecom, and data environments. With a depth of 1 meter (1000mm), it accommodates larger equipment while ensuring durability and stability.

This cabinet includes a tempered glass front door, lockable doors, and cable entry points at the top and bottom for flexible installation. It comes with 3 full‑depth shelves, a complete four‑way fan unit, and adjustable feet with lockable castors for mobility and stability. Built from high‑strength steel with powder coating, it supports up to 800kg static load capacity.

Key Features
27U free‑standing server cabinet – 1m deep
Tempered glass front door – secure and stylish
Lockable doors – enhanced security
Cable entry spacing – top & bottom
Numbered 19" punch profiles – front & rear for easy alignment
Adjustable feet & lockable castors – stability and mobility
Complete four‑way fan unit – efficient cooling
3 full‑depth shelves included – flexible mounting options
Earthing and grounding strips – safety compliance
Supplied flat‑packed (3 boxes) – easier transport
Static load capacity: 800kg

Technical Specifications
Specification Details
Product Code CAB‑C‑61027FSUA
Manufacturer UltraLAN
Rack Units 27U
Rack Width 19"
Depth 1000mm (1m)
Dimensions (H × W × D) 1200 × 600 × 1000 mm
Material Powder‑coated steel
Front Door Tempered glass, lockable
Cooling 4 fans (included)
Shelves 3 full‑depth shelves
Load Capacity 800kg
Assembly Supplied flat‑packed (3 boxes)
Warranty 1 Year Limited

📦 Gross Shipping Weight
Actual product weight: ~95–100 kg (steel cabinet + shelves + fans)
Packaging (3 flat‑packed boxes + padding): ~8–10 kg
Gross shipping weight: ± 108 kg
Volumetric weight: ~85–90 kg (couriers may charge on volumetric weight)

🚚 Bulky Item Shipping Disclaimer
Note: Price includes shipping for bulky items in urban areas only. Deliveries to remote or outlying regions may incur additional surcharges, calculated on a case‑by‑case basis. Delivery timelines begin after surcharge confirmation (if applicable).

UltraLAN 25G SFP28 BiDi Module Pair - SM 20KM 1270/1330nm


UltraLAN's SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 25Gbps and 20km transmission distance with SMF.


The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8402.


Product Features:

Up to 25.78Gb/s data links
Bi-Directional LC connector
Hot pluggable SFP28 footprint
1270nm/1330nm DFB transmitter
Applicable for 20KM SMF connection
Low power consumption, <1.5W
Compliant to SFF-8402 for SFP28 solution
RoHS Compliant


Please note, as these are BiDi SFP Modules they are only sold in a pair.

UltraLAN 24 Fiber Splice Tray


The UltraLAN fiber splice tray is designed to provide a place to store fiber cables and splices and prevent them from becoming damaged or being misplaced. These trays are commonly used individually/stand-alone, inside of fiber patch panels, or in large termination boxes.

The fiber splice tray has 4 access ports for fiber cable to either enter/exit the tray, allowing for cables to be easily fed into the tray from various angles. The tray is made from high strength injection mold plastic, is flame retardant, and offers a long anti-aging lifespan.


The UltraLAN fiber splice tray features 12 splice holder slots, but can also support a max of 24 splices when two sleeves are placed inside each slot. The cover and base section is securely joined with a metal pin, and the trays are stackable as well. The inner splice tray offers further cable management, with a fiber bend radius over 30mm.

UltraLAN 1x8 SC/APC 900μm PLC Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x8 LC/APC 900μm PLC Splitter
Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85
