Ubiquiti's UVC-G5DU features an ultra-compact and tamper-resistant enclosure, a 4MP image with an ultra-wide-angle lens, 20m IR night vision as well as AI Detections.

It can be configured and managed using the UniFi Protect Application.

*Note: The G5 Dome Ultra is for indoor use only. PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: No
Max. Power Consumption: 4.2W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: Ø63.6 x 68.2 mm
Weight: 175g

Ubiquiti's UVC-G5D features a 4MP image with a wide-angle lens, enhanced dynamic range and low-light performance. It is IK08 vandal-resistant with a built-in microphone and speaker. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependant)
Microphone: Yes
Max. Power Consumption: 5W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø109.2 x 64.5 mm
Weight: 390g

Ubiquiti's UVC-G5B features a 4MP image with a built-in microphone and a versatile 3-axis mount that enables quick and easy adjustment for both indoor and outdoor mounting. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 10 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: : Ø75.5 x 150 mm
Weight: 315g

Ubiquiti's UVC-G4INS is a compact, wide-angle, 5MP image, weather-resistant Wi-Fi IP Camera with two-way audio. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance.

It can be configured and managed using the UniFi Protect Application.

Specifications

Ethernet Ports: None
Hardware Button: Reset
Lens: Fixed focal length EFL 2.8 mm, f/1.6
Max Frame Rate: 30 FPS (Resolution Dependant)
Microphone: Yes
Max. Power Consumption: 6W
Mounting: Wall Mount
Night Mode: Built-in IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: None
Power Input: 5V, 2A USB Adapter (Included)
Resolution: 2688 x 1512 (16:9)
Sensor: 5 MP CMOS Sensor
Video Compression: H.264/MJPEG
Dimensions: 81.6 x 50 x 47.2 mm
Weight: 163g

Ubiquiti's UVC-G3FLEX-CM3 is a recessed ceiling mount accessory for the UVC-G3FLEX or UVC-G5F cameras. Mount your camera inside the ceiling or a ceiling tile for a clean, low-profile installation. Includes mounting hardware for drywall, solid surface, or ceiling tile installation. An optional screw locks the camera to the mount from above for added security.

The UVC-G3FLEX-CM3 is packaged to include 3 units per pack.
SKU UVC-FLEX-CM3
Manufacturer Ubiquiti
Manufacturer Product Code UVC-G3-F-C-3
Specifications N/A

Ubiquiti's UVC-AITH is a remote processing hub compatible with any AI Theta Lens. The unit includes a 1-metre proprietary Theta cable for connecting the lens.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12.5W
Mounting: Wall or Ceiling Mount
Operating Temperature: -20°C to 40°C
PoE Input: 37-57V Passive PoE
Power Input: 37-57V PoE
Video Compression: H.264
Dimensions: Hub: 140 x 70 x 38 mm
Weight: 365g

Ubiquiti’s UVC-AIT offers the choice between an 8MP wide-angle wall-mounted lens or a 12MP 360° fisheye lens for ceiling-mounted applications. The chosen lens module connects to the hub via the included 1-metre proprietary Theta cable. A second Theta hub can be purchased if the user wishes to install both lenses.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included & Theta lenses do no support IR night Vision.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: AI-Theta: 24 FPS; AI-Theta-360°: 20 FPS
Microphone: Yes
Max. Power Consumption: 12.25W
Mounting: Wall or Ceiling Mount
Night Mode: None
Operating Temperature: -20°C to 40°C
PoE Input: 37-57V Passive PoE
Power Input: 37-57V PoE
Resolution: AI-Theta: 3264 x 2448 (4:3); AI-Theta-360°: 2560 x 2560 (1:1)
Sensor: AI-Theta: 8MP; AI-Theta-360°: 12MP
Video Compression: H.264; MJPG
Dimensions: Hub: 140 x 70 x 38 mm; Lens/360°: Ø22.8. x 43.5 mm
Weight: 392g

Ubiquiti's UVC-AI360 is a pan-tilt-zoom (PTZ) IP camera providing panoramic, overhead surveillance of heavily populated areas. Equipped with a 5 MP CMOS sensor and an ultra-wide 360° fisheye lens, it streams sharp 1920x1920 video at 30 frames per second (FPS). It also features built-in IR LEDs for night mode. The IPx4 weather-resistant housing and IK08-rated tamper resistance allow it to be mounted both indoors and outdoors.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: 360° Fisheye lens
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 8.64W
Mounting: Ceiling or Wall-Mount (Included)
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20° to 40° C
PoE Input: 802.3af
Power Input: 802.3af
Resolution: 1920 x 1920
Sensor: 5 MP CMOS sensor
Video Compression: H.264, MJPG
Dimensions: Ø147 x 49 mm
Weight: 0.68Kg

The Ubiquiti UniFi UNVR Pro is a 7‑bay, diskless Network Video Recorder and UniFi OS console running the preinstalled UniFi Protect application. Designed for professional and SMB deployments, it accepts up to seven 2.5" or 3.5" drives (not included) and offers a 10 Gbps SFP+ uplink plus a Gigabit Ethernet port for flexible high‑throughput architectures. A built‑in 1.3" touchscreen provides quick status and local control, while a quad‑core ARM Cortex‑A57 1.7 GHz CPU and 4 GB DDR4 memory deliver responsive multi‑stream recording and playback. With enterprise features like RAID support, rack‑mountable 1U design, and robust power (max 160 W), the UNVR Pro is ideal where high local storage capacity, UniFi Protect management, and secure high‑bandwidth connectivity are required.

Technical Details:

Operating system: UniFi Protect (preinstalled)
Drive bays: 7 × 2.5"/3.5" HDD/SSD (drives not included)
Ethernet: 1 × 10/100/1000 RJ45
SFP+: 1 × 10 Gbps SFP+ port
Processor: Quad‑core ARM Cortex‑A57 @ 1.7 GHz
Memory: 4 GB DDR4
Power: 1 × IEC power input; max power consumption 160 W
PoE: No PoE input or output
I/O: Reset hardware button; 1.3" touchscreen display; no USB; no serial
Supported voltage: 100–240 V
Operating temp: -5 to 40 °C
Form factor: 1U rack mount (rack ears may be required)
Dimensions: 442 × 325 × 87 mm
Model / SKU: UVC‑NVR‑PRO (UNVR Pro)
Notes: HDDs not included use Ubiquiti‑approved drives per compatibility guidelines

Weights
Net weight (unit only): 9.45 kg
Gross weight (boxed, estimated): ~11.8–12.5 kg

Quick deployment tips
Install Ubiquiti‑approved surveillance/NAS drives and configure RAID per retention and redundancy needs.
Use the 10G SFP+ uplink for aggregation or uplink to high‑capacity storage when many high‑resolution streams are active.
Place drives into the unit before rack mounting to simplify cabling and airflow.

The Ubiquiti UniFi UNVR is a 4‑bay, diskless Network Video Recorder and UniFi OS console running the preinstalled UniFi Protect application. Designed for SMBs and pro installs, it accepts up to four 2.5" or 3.5" HDDs (not included), offers a 10G SFP+ uplink for high‑throughput camera deployments, and delivers efficient local management of UniFi Protect camera fleets. With a quad‑core ARM Cortex‑A57 1.7 GHz CPU and 4 GB DDR4 memory, the UNVR provides smooth multi‑stream recording and playback while fitting neatly in a 1U rack footprint.

Technical Details:

Operating system: UniFi Protect (preinstalled)
Drive bays: 4 × 2.5"/3.5" HDD/SSD (drives not included)
Ethernet: 1 × 10/100/1000 RJ45
SFP+: 1 × 10 Gbps SFP+ port
Processor: Quad‑core ARM Cortex‑A57 @ 1.7 GHz
Memory: 4 GB DDR4
Power: 1 × IEC power input; max power consumption 100 W
PoE: No PoE input or output
I/O: Reset hardware button; no USB; no serial
Supported voltage: 100–240 V
Operating temp: -5 to 40 °C
Form factor: 1U rack mount
Dimensions: 442.4 × 325 × 43.7 mm
Model / SKU: UNVR (UVC‑NVR)

Ubiquiti's USW-MAX48P is a 48 port, fully managed, Layer 3 Etherlighting™ switch. The unit features a 720W PoE budget with 32 Gigabit PoE Ports (24x PoE+ and 8x PoE++), 16x 2.5Gbps PoE ports (8x PoE+ and 8x PoE++) and 4x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps PoE links to your WiFi 6 devices as well as 10Gbps fibre uplinks to your network.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 32x 10/100/1000; 16x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps Ports: 8x 802.3af/at/bt ; 8x 802.3af/at ; Gigabit Ports: 24x 802.3af/at ; 8x 802.3af/at/bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442 x 325 x 44mm
Weight: 5.2kg

Ubiquiti's USW-MAX48 is a 48 port, fully managed, Layer 3, Ether lighting™ switch. The unit features 32x Gigabit Ports, 16x 2.5Gbps ports and 4x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fiber uplinks to your network.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 32x 10/100/1000; 16x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rackmount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442 x 325 x 44mm
Weight: 5.2kg

Ubiquiti's USW-MAX24P is a 24 port, fully managed, Layer 3 Etherlighting™ switch. The unit features a 400W PoE budget with 16 Gigabit PoE Ports (8x PoE++ and 8x PoE+), 8x 2.5Gbps PoE++ ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps PoE links to your WiFi 6 devices as well as 10Gbps fibre uplinks to your network.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000; 8x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps: 8x 802.3af/at/bt ; Gigabit: 8x 802.3af/at ; 8x 802.3af/at/bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442 x 325 x 44mm
Weight: 5.2kg

Ubiquiti's USW-MAX24 is a 24 port, fully managed, Layer 3, Etherlighting™ switch. The unit features 16x Gigabit Ports, 8x 2.5Gbps ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fibre uplinks to your network.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000; 8x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 442 x 325 x 44 mm
Weight: 5.2kg

Ubiquiti's USW-MAX16P is a 16 port, fully managed, Layer 3 Etherlighting™ switch. The switch includes a rack-mount kit for 10-inch racks and wall mounting. The UACC-MAX16P-RM accessory makes provision for 19 inch rack-mount deployments. The unit features a 180W PoE budget with 12x Gigabit PoE+ (802.3af/at) Ports, 4x 2.5Gbps PoE++ (802.3af/at/bt) ports and 2x SFP+ Uplink Ports. It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps: 4x 802.3af/at/bt ; Gigabit: 12x 802.3af/at
Power Input: 1x 54V, 3.9A, 210W DC adapter (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 54V
Dimensions: 325.1 x 160 x 43.7 mm
Weight: 2.1kg

Ubiquiti's USW-MAX16 is a 16 port, fully managed, Layer 3, Etherlighting™ switch. The unit features 12x Gigabit Ports, 4x 2.5Gbps ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fibre uplinks to your network.

Note: It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 325.1 x 160 x 43.7 mm
Weight: 1.95kg

Ubiquiti's UACC-UKPA is an IPx6, clip-on external antenna for the Swiss Army Knife (UK-ULTRA) that provides extended 90-degree directional coverage.
SKU UACC-UKPA
Manufacturer Ubiquiti
Manufacturer Product Code UACC-UK-Ultra-Panel-Antenna

Specifications

Antenna Gain: 2.4GHz: 10dBi ; 5.8GHz: 15dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Wind Loading: 75 N at 200 km/h
Dimensions: 138 x 207 x 43 mm
Weight: 450g

Ubiquiti's UXG-PRO features a 1.7GHz quad-core processor, 1x Gigabit Ethernet and 1x SFP+ WAN ports with failover support. It also features 1x Gigabit and 1x SFP+ LAN Ports to support the most bandwidth-intensive applications. It offers a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and a layered firewall configuration.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 1x 10/100/1000 (WAN) : 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: IEC Power Cord (Included)
Processor: Quad-core 1.7GHz
Serial Interface: None
SFP Ports: 1x 10Gbps SFP+ (WAN) : 1x 10Gbps (LAN)
Supported Voltage Range: 200V–240V
System Memory: 2GB DDR4 RAM
USB Ports: None
Other: 1x IEC SmartPower outlet (200~240VAC/1.25A)
Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 3.42kg

Ubiquiti's USW-FLEXU is an outdoor, weatherproof enclosure designed for use with the USW-5FLEX. Included with the unit are an Ethernet patch lead and a 60W PoE Injector providing a maximum PoE budget of 46W. The unit can be pole mounted and is easy to secure using the screw lock.

*Note: USW-5FLEX not Included.

Specifications

US-FLEXU Specifications
Compatibility: US5-FLEX

Dimensions: 249 x 218 x 60mm
Weight: 740g

60W PoE Adapter Specifications
Ethernet Ports: 1x 10/100/1000
Operating Temperature: -20°C to 60°C
PoE Output: 54V 1.11A Passive PoE
Power Input: Terminal Block
Supported Voltage Range: 100V-240V
Dimensions: 118.5 x 63 x 34.7mm
Weight: 206g

Ubiquiti's USW-5FLEX is a managed, Layer 2, UniFi switch with 5x Gigabit Ethernet Ports. It includes 4x 802.3af PoE+ Ports and 1x 802.3af/at/bt PoE input. It is designed for indoor or outdoor use with its weatherproof housing and versatile mounting options. The USW-Flex provides both flexibility and durability for environments with extreme temperature variations.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
We recommend using the UPOE-48G60W or a Ubiquiti UniFi Switch to power these devices. When making use of the UPOE-48G60W, be sure to set the power source on the UniFi Network Application to injector.

Specifications

Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 5W
Mounting: Desktop, Wall and Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 55°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af on Ports 2~5
Power Input: 802.3af/at/bt on Port 1
Serial Interface: 1x RJ45 Ethernet In-Band
SFP Ports: None
Supported Voltage Range: 44–57V (802.3af) 50-57V (802.3bt)
Dimensions: 122.5 x 107.1 x 28.0mm
Weight: 230g
