MikroTik's RB-CRS328 is a Cloud Router Switch featuring 24x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 450W. The 24 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 24x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 44W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3af/at or 26V Passive PoE on Ports 1~24
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None
Dimensions: 443 x 305 x 44mm

MikroTik's RB-CRS326Q is a Cloud Router Switch featuring 24x 10Gbps SFP+ Ports and 2x 40Gbps QSFP+ ports. The Router has dual power supplies for power redundancy and a full-sized USB port for configuration. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 42W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 650MHz QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 24x 10Gbps ; 2x 40Gbps QSFP
Supported Voltage Range: 100-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None
Dimensions: 443 x 200 x 44mm

MikroTik's RB-CRS304XG is a Cloud Router Switch featuring 4x 10Gbps Ethernet Ports and 1x Gigabit Management Port. This switch includes a convenient DIN rail mount on the side and standard screw attachment points on the back. It also offers 4 different power inputs, 2x DC jacks, a 2-pin terminal, and PoE-input. The switch automatically selects the power source with the highest voltage, ensuring uninterrupted operation.

Specifications

Ethernet Ports: 4x 10Gbps: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or DIN Rail Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 48V 0.95A Power Supply
Processor: Dual Core 1200MHz 98DX2528
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 36-57V (PoE) 12-57V (DC Input)
System Memory: 512MB
USB Ports: None
Other: Terminal DC Input
Dimensions: 176 x 128 x 35 mm

MikroTik's RB-CRS305S is a Cloud Router Switch featuring 4x 10Gbps SFP+ Ports, 1x Gigabit Ethernet port for management and dual DC Jacks for power redundancy. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.

*Note: In order to achieve the best compatibility, MikroTik recommends not using grounding when powering this device with 802.3af/at.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Desktop
Operating System: Dual Boot - SwOS or Router OS (Level 5 License)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 12-57V Passive PoE
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included) (Dual DC input for power redundancy)
Processor: 1 Core 800 MHz 98DX3236
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 12-57V
System Memory: 512MB
USB Ports: None
Dimensions: 141 x 115 x 28mm

MikroTik's RB-CRS354Q is a Cloud Router Switch featuring 48x Gigabit Ethernet ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 48x 10/100/1000: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rackmount
Operating System: Dual Boot - SwOS or Router OS (Level 5 License)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: None
Other: None
Dimensions: 297 x 443 x 44mm

MikroTik's RB-CRS354QP is a Cloud Router Switch featuring 48x Gigabit PoE Ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports, 1x Fast Ethernet Management port and a PoE budget of 700W. The 48 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 48x 10/100/1000: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 85W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3at/af ; 26V or 53V Passive PoE
Power Input: 1x IEC Power Cord (Included)
Processor: QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64 MB
USB Ports: None
Other: None
Dimensions: 443 x 382 x 44mm

MikroTik's RB-CRS106 is a Cloud Router Switch featuring 5x 1.25Gbps SFP ports, 1x 1.25Gbps SFP or PoE Input Combo Port and is powered by Router OS with a Level 5 license.

Specifications

Ethernet Ports: 1x 10/100/1000 (Combo Port)
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: Router OS (Level 5 License)
Operating Temperature: -20°C to 70°C
PoE Input: 11V-30V (Passive PoE Combo Port)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 6x 1.25Gbps (1x Combo Port)
Supported Voltage Range: 11V-30V
System Memory: 128MB
USB Ports: None
Other: None
Dimensions: 114 x 137 x 29mm

MikroTik's RB-CRS310S is a Cloud Router Switch featuring 5x 1.25Gbps SFP Ports, 4x 10Gbps SFP+ Ports and 1x Gigabit Ethernet Port which supports PoE Input.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktop & Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 18V-57V or 802.3af/at
Processor: 1 Core 800MHz 98DX226S
Serial Interface: 1x RJ45 Port
SFP Ports: 5x 1.25Gbps ; 4x 10Gbps
Supported Voltage Range: 18V-57V
System Memory: 256MB
USB Ports: None
Other: None
Dimensions: 200 x 166 x 45 mm

MikroTik's RB-CRS312 is a Cloud Router Switch featuring 8x 10Gbps Ethernet Ports, 4 combo ports for either 10Gbps SFP+ or 10Gbps Ethernet and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 12x 10Gbps (4 Combo Ports) : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -30°C to 70°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 1 Core 650MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps (Combo Ports)
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None

MikroTik's RB-CRS1128P is a Cloud Router Switch featuring 8x Gigabit PoE ports and 4x 1.25Gbps SFP ports. The 8 PoE ports support both passive PoE (with the included Power Supply) and 802.3af/at when powered by a 48-57V power supply. The unit is powered by RouterOS with a Level 5 License.

Note: Both 24V and 52V PSU's can be used simultaneously to make use of both voltages for POE devices.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop & Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 18V-28V (Passive PoE) or 48V-57V (802.3af/at)
Power Input: 28V 3.4A Power Supply (Included) or 48-57V (Not Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 18V-28V or 48V-57V
System Memory: 128MB
USB Ports: None
Other: None
Dimensions: 200 x 143 x 44mm

Mikrotik's RB-CRS309S is a Cloud Router Switch featuring 8x 10Gbps SFP+ ports and 1x Gigabit Ethernet port for either management or PoE Input. The unit supports the dual boot function which supports either SwOS or Router OS with a Level 5 License.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 17W
Mounting: Desktop & Rackmount
Operating System: Dual Boot - SwOS or Router OS (Level 5 License)
Operating Temperature: -40°C to 70°C
PoE Input: 18V-57V (Passive PoE; 802.3af/at)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: 2 Core 800MHz 98DX8208
Serial Interface: 1x RS232 Port
SFP Ports: 8x 10Gbps
Supported Voltage Range: 12V-57V
System Memory: 512MB
USB Ports: None
Other: None
Dimensions: 272 x 191 x 44mm

MikroTik Cloud Smart Switch CSS326-24G-2S+RM

The Cloud Smart Switch 326-24G-2S+RM is powered by a Marvell DX switch chip. The device is running an operating system designed specifically for MikroTik switch products - SwitchOS.

SwOS is configurable from your web browser. It gives you all the basic functionality for a managed switch, plus more: allows you to manage port-to-port forwarding, apply MAC filtering, configure VLANs, mirror traffic, apply bandwidth limitations and even adjust some MAC and IP header fields. The SFP cage supports both 1.25 Gb SFP and 10 Gb SFP+ modules.


Product Features:


Non-blocking Layer 2 switching capacity
16K host table
IEEE 802.1Q VLAN
Supports up to 4K simultaneous VLANs
Port isolation
Port security
Broadcast storm control
Port mirroring of ingress/egress traffic
Rapid Spanning Tree Protocol
Access Control List
MikroTik neighbor discovery
SNMP v1
Web-based GUI

RouterBoard Specs

RouterBoard CPU Powered by a Marvell DX switch chip (98DX3216A1)
Wired Interfaces 24x Gigabit Ethernet Ports, 2x SFP+ Slots
DC Power Yes - 12-30V DC
PoE Yes, PoE input on Eth1 (12-30V DC - Non 802.3af PoE)
Operating System MikroTik SwitchOS

Specifications:
Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 19W
Mounting: Rack-Mount
Operating System: SwOS
Operating Temperature: -20°C to 70°C
PoE Input: 10V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: Switch Chip
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 10V-30V
System Memory: 2MB
USB Ports: None
Other: None
Weight & Dimensions
W : 20 cm
L : 56 cm
H : 7 cm
Weight: 1720 g

MikroTik’s RB-CUBE60P is a 60GHz 802.11ay CPE featuring automatic 5.8GHz 802.11ac failover, 1x Gigabit Ethernet and a durable, unobtrusive enclosure. Establish an ultra-fast, Point-to-Point connection for distances up to 2.4km with Channel 5 enabled.

Specifications

Antenna Gain: 5.8GHz: 11.5dBi: 60GHz: N/A Recommended for up to 2.4km
Beam-width: 5.8GHz: 35°: 60GHz: 11°
Data Rate: 60GHz: up to 1Gbps+: 5.8GHz: 433Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Pole-Mount
Operating System: Router OS (Level 4 License)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 18V-57V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: None
Dimensions: 115 x 95 x 82mm

MikroTik's RB-CUBE60PS is an outdoor, 802.11ay 60GHz 60° Integrated Sector with automatic 5.8GHz 802.11ac failover, 1x Gigabit Ethernet and a durable, unobtrusive enclosure. Pair the unit with up to x8 60GHz CPEs to create a Point-To-Multi-Point Link for distances up to 800m.

Specifications

Antenna Gain: 5.8GHz: 11.5dBi: 60GHz: N/A Recommended for up to 800m
Beam-width: 5.8GHz: 35° : 60GHz: 60°
Data Rate: 60GHz: up to 1Gbps+ : 5.8GHz: 433Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Pole-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 18V-57V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: None
Dimensions: 115 x 211 x 90 mm

MikroTik's ANT-O25 is a dual band, outdoor, RP SMA whip antenna featuring 3.3dBi gain on 2.4GHz and 5.5 - 7.1dBi on 5.8GHz. Pair this antenna with any dual band access point with RP SMA Female connectors to create a dual band outdoor access point.
Antenna Gain: 2.4GHz 3.3dBi ; 5.8GHz 5.5-7dBi
Connectors: RP SMA Male
SKU ANT-O25
Manufacturer MikroTik
Manufacturer Product Code HGO-antenna-OUT

Specifications

Antenna Gain: 2.4GHz 3.3dBi ; 5.8GHz 5.5-7dBi
Connectors: RP SMA Male

MikroTik's RB-FLEX cable offers superior connection quality, is suited for indoor and outdoor use, and provides superior matching and loss values.

The name of this cable comes from combining the words “flexible” and “waveguide”, to denote the high-end features of this product. The inner conductor is silver plated copper, and both connectors are soldered, not crimped, for the best possible signal quality.

Ideally suited for MikroTik's Base Box and other products with RPSMA connectors and works with most antennas. Compatible with ANT-D530PA, a 5GHz, 30dBi dish antenna, also by MikroTik Router BOARD

SKU RB-FLEX
Manufacturer MikroTik
Manufacturer Product Code ACRPSMA
Specifications N/A

MikroTik's RB-GPEN21 is a smart media converter with PoE pass-through running SwOS. It provides a range of useful software features such as Interface management and monitoring, GPEN link fault detection, VLAN support, SNMP reporting and Basic traffic shaping. This unit has 2 Gigabit Ethernet ports as well as an SFP port for fiber connectivity. The RB-GPEN21 can be used either to power a fiber module or to provide PoE to power an Ethernet uplink using RB-GPER.

*Note: Power supply not included.

SKU RB-GPEN21
Manufacturer MikroTik
Manufacturer Product Code GPEN21
GPEN Concept
Label - Redfern 39UP

Specifications

Ethernet Ports: 2x 10/100/1000
Hardware Button: Mode
Mounting: Wall-Mount
Operating System: SwOS
Operating Temperature: -20°C to 70°C
PoE Input: 802.3af/at
PoE Output: 12V-57V Passive PoE
Power Input: Passive PoE
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 12V-57V
Dimensions: 92 x 104 x 24mm

MikroTik's RB-FTC is a Gigabit Fiber to Copper converter. Unlike many other media converters available on market, FTC has an outdoor waterproof case with lock screw.

The device supports 12-57V PoE with 802.3af/at. It is supplied with a PoE injector and power supply. The case has a mounting system that is secured by a screw from inside the lockable case, making the device hard to access by unauthorized individuals.

*Note: SFP module sold separately.

SKU RB-FTC
Manufacturer MikroTik
Manufacturer Product Code RBFTC11

Specifications

Ethernet Ports: 1x 10/100/1000
Max. Power Consumption: 3W
Operating Temperature: -40°C to 70°C
PoE Input: 12V-57V (Passive PoE, 802.3af/at)
PoE Output: None
Power Input: 24V 0.3A Power Supply (Included)
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 12V-57V
Dimensions: 185 x 85 x 30mm

MikroTik's RB-GPER is part of MikroTik's GPEN (Gigabit Passive Ethernet Network) range. This unit allows you to extend an Ethernet cable by up to 150m to network devices and up to 210m to another GPeR unit. The initial connection from the power source to GPeR should not exceed 100m but thereafter can be extended up to 210m to the next GPeR. Using multiple GPeR devices in line can allow up to 1.5km when using PoE.

NOTE: Jumper usage - If the destination device does not support PoE powering, the power passthrough can be disabled manually by removing both jumpers on the "PoE out" side. This will only work if "PoE in" is served by passive PoE source, as 802.3af/at switches will not be able to power the GPeR itself.
SKU RB-GPER
Manufacturer MikroTik
Manufacturer Product Code GPeR

Specifications

Ethernet Ports: 2x 10/100/1000
Hardware Button: None
Mounting: Wall-Mount
Operating System: None
Operating Temperature: -40°C to 70°C
PoE Input: 24V-57V Passive PoE, 802.3af/at
PoE Output: Jumper selectable passive PoE Passthrough
Power Input: 24V-57V Passive PoE, 802.3af/at
SFP Ports: None
Supported Voltage Range: 24V-57V
Dimensions: 114 x 50 x 25mm

MikroTik's RB-FTC21 is a weatherproof IP55 Fibre-to-Copper converter with smart management capabilities featuring 2x Gigabit Ethernet Ports and 1x 2.5Gbps SFP Port. The RB-FTC21 runs a full version of SwOS Lite, offering advanced management features and comes with everything you need for installation, including a 48V power adapter, a PoE injector, and a ceiling mount and fastening set.
SKU RB-FTC21
Manufacturer MikroTik
Manufacturer Product Code FTC21

Specifications

Ethernet Ports: 2x 10/100/1000
MaxPower Consumption: 3W
Operating Temperature: -40°C to 70°C
PoE Input: 24-57V (Passive PoE, 802.3af/at)
PoE Output: None
Power Input: 48V 0.95A Power Supply (Included)
SFP Ports: 1x 2.5Gbps
Supported Voltage Range: 24-57V DC & PoE
Dimensions: 254 x 97 x 35 mm
