MikroTik's RB-L009UGSRM features a powerful dual-core ARM CPU, 8x Gigabit Ethernet Ports, 1x SFP port supporting both 1.25Gbps and 2.5Gbps as well as a full-sized USB 3.0 port. The unit can be powered by either the included power supply or 24-56V PoE on Port 1. It also features PoE out on port 8 when powered by the DC Jack and ships with an RB-5009RMKIT rack-mount kit.

SKU RB-L009UGSRM
Manufacturer MikroTik
Manufacturer Product Code L009UiGS-RM

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Rackmount (with included RB-5009RMKIT)
Operating System: Router OS (Level 5 License)
Operating Temperature: -40°C to 70°C
PoE Input: 24V-56V (Passive or 802.3af/at PoE)
PoE Output: Passive PoE on Port 8 (Only when powered via DC Jack)
Power Input: 24V 1.5A Power Supply (Included)
Processor: 2 Core 800MHz IPQ-5018 ARM 64bit
Serial Interface: RJ45
SFP Ports: 1x 1.25Gbps / 2.5Gbps
Supported Voltage Range: 24V-56V
System Memory: 512MB
USB Ports: 1x USB 3.0
Dimensions: 220 x 125 x 22 mm

MikroTik's RB-L009UGSAX is a 2.4GHz 600Mbps Wi-Fi 6 router featuring a powerful dual-core ARM CPU, 8x Gigabit Ethernet Ports, 1x SFP port supporting both 1.25Gbps and 2.5Gbps as well as a full-sized USB 3.0 port. The unit can be powered by either the included power supply or 24-56V PoE on Port 1. It also features PoE out on port 8 when powered by the DC Jack.

SKU RB-L009UGSAX
Manufacturer MikroTik
Manufacturer Product Code L009UiGS-2HaxD-IN

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Desktop (Can be rack-mounted with the RB-5009RMKIT)
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 24V-56V (Passive or 802.3af/at PoE)
PoE Output: Passive PoE on Port 8 (Only when powered via DC Jack)
Power Input: 24V 1.5A Power Supply (Included)
Processor: 2 Core 800MHz IIPQ-5018 ARM 64bit
Serial Interface: RJ45
SFP Ports: 1x 1.25Gbps/ 2.5Gbps
Supported Voltage Range: 24V-56V
System Memory: 512MB
USB Ports: 1x USB 3.0
Other: 2.4GHz: 4dBi 600Mbps
Dimensions: 220 x 125 x 22 mm

MikroTik 8port PoE Smart Switch (RBCRS112-8P-4S-IN)

The MikroTik CRS112-8P-4S-IN is an eight Gigabit RJ45 ports PoE switch, that offers different power output options: autosensing 802.3af/at PoE/PoE+ and Passive PoE, and four SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.

CRS112-8P-4S-IN is equipped with 12 independent switching ports. 28 V 3.4 A power supply is already included in the box. There is secondary DC jack on the back of the enclosure that supports 48-57 V power supply (not included). CRS112-8P-4S-IN can power 802.3af/at devices if 48-57 V DC input is used (unit will automatically detect and provide correct power to devices). Max current is 1 A per port if input voltage is 18-28 V, 450 mA if 48-57 V. Total limit is 2.8A@24V and 1.4A@48-57V

The MikroTik CRS series combines a fully functional router and a managable switch with L3 features, it’s powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes. It gives you all the basic functionality for a managed switch, plus more: allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields. IGMP snooping is also supported.

Switching Features:

Non-blocking Layer 2 switching capacity
16K host table
IEEE 802.1Q VLAN
Supports up to 4K simultaneous VLANs
Port isolation
Port security
Broadcast storm control
Port mirroring of ingress/egress traffic
Rapid Spanning Tree Protocol
Access Control List
MikroTik neighbor discovery
SNMP
9204-byte jumbo frames support
IGMP snooping
static link aggregation

Quick Specifications:

8 Gigabit RJ45 Ports
4 SFP Ports
Non-Blocking Throughput: 12 Gbps
Switching Capacity: 24 Gbps
Forwarding Rate: 17.8 Mpps
Maximum Power Consumption: 10 W (without PoE devices connected)
Supports PoE+ IEEE 802.3at/af and 24 V Passive PoE
Quiet, Fanless Operation
Desktop-Rackmount

Weight & Dimensions
W : 24cm
L : 31cm
H : 20cm
Weight : 550g

MikroTik's RB-GPS is an active GPS antenna for the 1575.4 MHz GPS frequency. The antenna is waterproof with IP67 rating and includes a 5m cable which allows you to bring the antenna outside and mount it with the included magnet, or double-sided tape. When paired with the RB-LTAP, it provides accurate geographical coordinates of your router, even when it is mounted indoors.
SKU RB-GPS
Manufacturer MikroTik
Manufacturer Product Code ACGPSA

Specifications

Antenna Gain: 26dBi
Beam-width: 360°
Connector: SMA Male
Frequency Range: 1575.42Mhz (Center Frequency)
Polarization: Vertical & Horizontal
Dimensions: 46.5 x 46.5 x 12.5mm
Weight: 120g

MikroTik RB-SXTSQM is a simple, durable alignment mounting for the RB-SXTSQ range of products. The pole-mount bracket enables fine adjustments up to 45° in both directions and included U-Bolt supports 20-50mm diameter masts.

SKU RB-SXTSQM
Manufacturer MikroTik
Manufacturer Product Code SXTsq-mount

Specifications

Compatibility: SXT sq series
Mast Size: 20-50 mm

MikroTik's RB-BASEBOX5 is an outdoor enclosure, fit with two SMA connectors for antennas, and a cable hood for protection against moisture.

Also available are three additional places for antenna connectors, in case you wish to use the RB912 miniPCIe slot for one more wireless interface to make a dual-band device.

Compatible with ANT-D530PA, a 5GHz, 30dBi dish antenna, also by MikroTik

The case can be opened with one hand, and is protected against the elements. USB, Ethernet, and a Grounding wire exits are provided on the bottom, behind a protective door. It comes with a mounting loop for tower/pole mounting, and a separate DIN rail mount is also provided.

Package also includes a PoE injector and power supply unit.

Specifications

Antenna Gain: Antenna Dependent (2x SMA RP Female)
Beam-width: Antenna Dependent
Data Rate: 5GHz 300Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 14W
Mounting: Pole Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 8V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: 1 (Mini SIM) Requires 3G miniPCI-e card
Supported Voltage Range: 8V-30V
USB Ports: 1x USB 2.0
Other: 1x Mini PCI-e Slot
Dimensions: 246 x 135 x 50mm

Like the other models in CCR2004 series, this CCR also features the Amazon Annapurna Labs Alpine v2 CPU with 4x 64-bit ARMv8-A Cortex-A57 cores. While this CPU is running at 1.2 GHz, the router can be 3x as fast than the previous generation CCR’s. This is the silent powerhouse. Enjoy all the power of a real CCR in peace and quiet. Get rid of all the hum and buzz in your office, studio, server room or homelab without sacrificing the performance!


The new router has 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages. It also has a RJ-45 console port on the front panel.


Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch-chip. Each switch chip has a 10 Gbps full-duplex line connected to the CPU. The same goes for each SFP+ cage - a separate 10 Gbps full-duplex line. Boards come with 4GB of DDR4 RAM and 128MB of NAND storage.


So as you can see - no bottlenecks. As long as the CPU can handle the processing, all ports can reach wire speed. And this CPU is a beast that can handle a lot. If we look at the performance, you can see that it is trading blows with our CCR1009.


The best part? This brand new CCR is among the most affordable options out there - not only within the CCR series, but on the market in general. One of the most common ways to use this device would be: Gigabit Ethernet ports for the internal network; SFP+ ports for downlink and uplink. The perfect all-in-one solution for small and medium-sized businesses. Easy and efficient.


With the new CCR2004, you can take your office network to the next level. Without breaking the bank.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 36V-57V DC Jack or 2 Pin Terminal
Processor: 4 core 1.2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 36V-57V
System Memory: 4GB
USB Ports: None
Weight & Dimensions
W : 21cm
L : 39cm
H : 6cm
Weight : 1460g

MikroTik's RB-CHAT5G is a high power, indoor, dual-band 802.11ac, 5 Port Gigabit router with LTE20/5G support. The dual-band wireless offers speeds up to 1200Mbps, and with carrier aggregation, the 5G modem delivers up to 4.2Gbps.

Note: The SMA Female connectors on the back of the device are for connecting external LTE antennas. Should you wish to add external Wi-Fi antennas, UFL to RP SMA Female pigtails will need to be installed.

Specifications

Antenna Gain: LTE/5G: 2x External Antenna Wireless; 2.4GHz: 3 dBi; 5GHz: 5.5 dBi
Beam-width: 360°
Data Rate: LTE/5G: 4.2Gbps Downlink; 900Mbps Uplink; LTE20: 2Gbps Downlink; 200Mbps Uplink; Wireless: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Mounting: Desktop
Operating System: RouterOS v7 only (Level 4 License)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Serial Interface: None
SIM Slots: 1x Micro SIM
Supported Voltage Range: 12V-28V
USB Ports: 1x Type A
Dimensions: 240 x 156 x 44 mm

MikroTik's RB-CHATLTE6 is an indoor, dual band WiFi 5 router with 5x Gigabit Ethernet Ports and LTE6 support. The wireless router offers speeds of up to 1200Mbps. With carrier aggregation, which uses multiple bands simultaneously, the CAT6 modem delivers up to 300Mbps.

Note: The SMA Female connectors on the back of the device are for connecting external LTE antennas. Should you wish to add external Wi-Fi antennas, UFL to RP SMA Female pigtails will need to be installed.

Specifications

Antenna Gain: LTE: 4dBi Wireless: 2.4GHz: 2dBi; 5GHz: 4dBi
Beam-width: 360°
Data Rate: LTE: 300Mbps Downlink 50Mbps Uplink Wireless: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop
Operating System: RouterOS v7 (Level 4 License)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Serial Interface: None
SIM Slots: 1x Micro SIM
Supported Voltage Range: 12V-28V
USB Ports: 1x Type A
Dimensions: 240 x 156 x 44 mm

MikroTik's RB-CHATAX is an indoor Wi-Fi 6 Router featuring a quad core ARM 64bit 2.2GHz CPU, 5x Gigabit Ethernet Ports, 1x PoE output, 4x4 Mu-MIMO and an aggregate data rate of up to 3600Mbps.

Specifications

Antenna Gain: 2.4GHz: 5dBi; 5.8GHz: 6Bi
Beam-width: 360°
Data Rate: 2.4GHz: 1148Mbps; 5.8GHz: 2400Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Desktop
Operating System: RouterOS, License level 6
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: Passive PoE Passthrough
Power Input: 48V 1.35A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: 1x USB 3.0
Dimensions: 240 x 156 x 44 mm

MikroTik's RB-CCR2116P features 16 cores, each with 2GHz processing power, 12 Gigabit Ethernet Ports, 4 x 10Gbps SFP+ uplink ports and a dual redundant power supply. The router supports Layer 3 Hardware Offloading and each group of 4 Ethernet ports has a separate full-duplex connection to the switch chip to prevent bottlenecks.

Specifications

Ethernet Ports: 12x 10/100/1000; 1x 10/100/1000 Management Interface
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 1x M.2 slot
Dimensions: 443 x 199 x 44mm

MikroTik's RB-CCR2004 is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed Router OS L6 and 4GB of onboard RAM. It features 12x 10Gbps SFP+ ports, 2x 25Gbps SFP28 ports and dual power supplies for integrated redundancy.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 32W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 10Gbps ; 2x 25Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None
Dimensions: 443 x 224 x 44mm

MikroTik RB-CCR2216SP features 16 cores, 12x SFP28 25Gbps ports, 2x QSFP28 100Gbps ports, and a Gigabit Ethernet port. The device includes 2x M.2 SATA slots for additional storage as well as 4x hot-swappable fans and dual-redundant hot-swap power supplies.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 80W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 2x M.2 slots
Dimensions: 443 x 367 x 44mm

MikroTik's RB-CCR2004P is a carrier-grade cloud core router powered by a 4 core ARM CPU. The unit comes equipped with installed Router OS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and dual power supplies for integrated redundancy. Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch chip. Each switch chip has a 10Gbps full-duplex line connected to the CPU. Each SFP+ cage also has a separate
10Gbps full-duplex line.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 35W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None
Dimensions: 443 x 210 x 44mm

MikroTik's RB-CCR2004PC is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and can be powered by either the DC Jack or a 2-pin terminal connection. Each group of 8x Gigabit Ethernet ports is connected to a separate switch chip which has a 10Gbps full-duplex line connected to the CPU. The SFP+ Ports also have a separate 10Gbps full-duplex line to prevent bottlenecks.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 36V-57V DC Jack or 2 Pin Terminal
Processor: 4 core 1.2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 36V-57V
System Memory: 4GB
USB Ports: None
Dimensions: 272 x 195 x 44mm

MikroTik's RB-CCR2004PCIE is a 4-core ARM64 CPU, smart PCIe network interface card (NIC) that adds fully-fledged router capabilities to your Linux servers or PCs. It features 2x SFP28 25Gbps SFP ports and 1x Gigabit Ethernet Port for management.

Note: The device is supported in Linux (minimum kernel 5.15.25) and Router OS (minimum version 7.x), but it will not be recognized in Windows.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: Low Profile & High Bracket (Included)
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: PCI-e
Processor: 4 core 2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 25Gbps
System Memory: 4GB
USB Ports: None
Dimensions: 170 x 69 x 18mm

MikroTik's RB-CRS320P is a Cloud Router Switch with 16x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 600W. PoE ports 1 to 8 support PoE+ (802.3af/at) and ports 9 to 16 support PoE++ (802.3af/at/bt). The unit includes a hot-swappable PSU as well as an expansion slot for an additional PSU, which can raise the PoE budget to 1150W.

Specifications

Ethernet Ports: 17x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 36W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8 : 802.3af/at/bt on Ports 9 to 16
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX226S
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 256MB
USB Ports: None
Other: None
Dimensions: 444 x 235 x 44 mm

MikroTik's RB-CRS520 is an enterprise 4 core Cloud Router Switch with 16x 100Gbps QSFP28, 4x 25Gbps SFP28 ports and 2x 10Gbps Ethernet ports. The unit is powered by dual hot-swappable power supplies and can run OSPF/BGP, out-of-band/management VPNs, ACLs, Jumbo frames, and L3HW Offloaded routing.

Specifications

Ethernet Ports: 2x10/100/1000/2500/10000
Hardware Button: Reset; Mode
Max. Power Consumption: 123W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 50°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 4 Core 2GHz 98CX8410
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 16x 100Gbps ; 4x 25Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB DDR4
USB Ports: None
Other: None
Dimensions: 443 x 367 x 44 mm

MikroTik's RB-CRS317 is a Cloud Router Switch featuring 16x SFP+ ports and 1x Gigabit Ethernet Port for management. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or Router OS with a Level 6 License.

Specifications

Ethernet Ports: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 44W
Mounting: Rackmount
Operating System: Dual Boot - SwOS or Router OS (Level 6 License)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX8216
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 16x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 1GB
USB Ports: None
Other: None
Dimensions: 443 x 224 x 44mm

MikroTik's RB-CRS518S is a Cloud Router Switch featuring 16x 25Gbps SFP28 ports, 2x 100Gbps QSFP28 ports with a total of 1.2Tbps switching capacity. The router has dual power supplies for power redundancy. The 25Gbps SFP28 ports are backwards compatible with 10Gbps and 1.25Gbps SFP modules while the 100Gbps QSFP28 ports are also compatible with the 40Gbps QSFP modules.

Specifications

Ethernet Ports: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 16x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: 1x USB
Other: None
Dimensions: 443 x 265 x 44.5 mm
