Ubiquiti's AIR-S516 is a 5GHz 16dBi, 120° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 16dBi
Beam-width: 120°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 41.7N @ 200km/h

Dimensions: 367 x 63 x 4mm
Weight: 1.1kg

Ubiquiti's U7-PRO-OUT is a WiFi 7 Tri-Band, IP67 outdoor access point featuring 6 spatial streams, 1x 2.5Gbps Ethernet port, two external antennas and a versatile wall and pole mounting. It delivers an aggregate data rate of up to 10Gbps over its 6GHz (2x2 MU-MIMO), 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: Internal: 8 dBi External: 6 dBi; 5GHz: Internal: 11 dBi External: 8 dBi : 6GHz: Internal: 10 dBi
Beam-width: 2.4GHz: 90° ; 5GHz: 45°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Wall or Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at (PoE+) or Passive PoE
PoE Output: None
Power Input: 802.3at (PoE+) or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: 170 x 208 x 66.5 mm
Weight: 1.2kg

Ubiquiti's NS4 is an unmanaged, outdoor, 4 port Gigabit switch with PoE passthrough. If powered by 24V Passive PoE can provide up to 24W of power on three PoE out ports. The NanoSwitch is designed for outdoor deployment and supports up to 4 Gbps total, non-blocking line rate.

*Note: PoE Injector not Included.

Specifications

Ethernet Ports: 4x 10/100/1000
Max. Power Consumption: 30W
Mounting: Wall or Pole Mount
Operating Temperature: -30C ~ 70C
PoE Input: Passive 24V PoE
PoE Output: 24V Passive PoE Pass-through
Power Input: 24V Passive PoE (Not Included)
Supported Voltage Range: 21.6 - 30V
Dimensions: 196.4 x 93.5 x 32.4mm
Weight: 271g

The POE-802O adapter transforms almost any Ubiquiti PoE device into a fully compliant 48V, PoE-compatible product.

The Instant PoE Adapter works seamlessly with a variety of PoE switches for remote power control applications. You can conveniently power or power cycle your remote devices using your PoE switch.
Specifications
Interface In: (1) Gigabit RJ45 Port
Interface Out: (1) Gigabit Ethernet Cable
Power Input : 48V; 802.3af
Max Power Output: 24V; 0.5A
Ethernet ESD/Surge Protection: ±15kV
Dimensions: Ø 30.2 x 166 mm
Dimensions with RJ45 Cable: Ø 30.2 x 366.6 mm
Weight: 90g
Operating Temperature: -30 to 70° C

Ubiquiti's U6-EXT is a plug and play, dual band, Wi-Fi 6 (802.11ax) Range Extender. It delivers an aggregate data rate of up to 5.3Gbps over 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: Shuko (EUR-SCH) adapter sold separately.

Specifications
Antenna Gain: 2.4GHz: 5dBi ; 5.8GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 573.5Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: None
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Plug Point
Operating System: UniFi
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: None
Power Input: 2-Pin Schuko
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 100-240V
USB Ports: None
Dimensions: 169.7 x 112.2 x 77.6 mm
Weight: 340g

Ubiquiti's U6-IW is a dual band, WiFi 6 (802.11ax) in-wall access point. It delivers an aggregate data rate of up to 5.3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It offers PoE passthrough as an integrated 4-port Gigabit switch when the device is powered by an 802.3af/at PoE switch.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 5dBi ; 5.8GHz: 5.9dBi
Beam-width: 360°
Data Rate: 2.4GHz : 573.5Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13.5W
Mounting: 1 Gang Electrical Wall Box (Not Included)
Operating System: UniFi
Operating Temperature: -30°C to 60°C
Power Input: 802.3at
PoE Output: 48V Pass-Through
Power Input: 802.3at or UniFi Switch
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57VDC
USB Ports: None
Dimensions: 139.66 x 96 x 31.19 mm
Weight: 460g

Ubiquiti's U6-LR is an indoor or outdoor, dual band, WiFi 6 (802.11ax) long range access point. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (4x4 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5.5dBi
Beam-width: 360
Data Rate: 2.4GHz: 600Mbps; 5.8GHz: 2400Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16.5W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø220 x 48mm
Weight: 930g

Ubiquiti's U6-PRO is a high-performance, dual band WiFi 6 (802.11ax) access point. It delivers an aggregate data rate of up to 5.3Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi
Beam-width: 360
Data Rate: 2.4GHz: 573Mbps; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None
Dimensions: Ø197 x 35 mm
Weight: 600g

Ubiquiti's U7-IW is a Dual-Band WiFi 7, wall-mounted AP with 4 spatial streams and 3x 2.5Gbps ports, with one supporting PoE input and one supporting PoE output. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi: ; 5GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps
Ethernet Ports: 3x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Wall-Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3af/at (PoE+ required for PoE output)
PoE Output: 802.3af
Power Input: 802.3at/at
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: 137 x 98.7 x 30.2 mm
Weight: 400g

Ubiquiti's U7-LITE is a Dual-Band WiFi 7 access point featuring high gain integrated antennas and 1x 2.5Gbps Ethernet port. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps 5.8GHz: 4.3Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3af or Passive PoE (Not Included)
PoE Output: None
Power Input: 802.3af or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø171.5 x 33 mm
Weight: 313 g

Ubiquiti's U7-PRO-XG-W is a white, Tri-Band, 6-stream, WiFi 7 access point featuring 1x 10Gbps Ethernet port and 6GHz support for interference-free WiFi in demanding, large-scale environments. It delivers an aggregate data rate of up to 10.78Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands and is powered by PoE+ (802.3at).

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications

Antenna Gain: 2.4GHz: 4dBi; 5GHz: 5dBi; 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps ; 6GHz: 5.8Gbps
Ethernet Ports: 1x 10/100/1000/2500/10000
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3at (PoE+)
PoE Output: None
Power Input: 802.3at (PoE+) (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø206 x 32.5 mm
Weight: 750g

Ubiquiti's U7-PRO-XGS-W is a white, Tri-Band, 8-stream, WiFi 7 access point featuring 1x 10Gbps Ethernet port and 6GHz support for interference-free WiFi in demanding, large-scale environments. It delivers an aggregate data rate of up to 15Gbps over its 6GHz (2x2 MU-MIMO), 5GHz (4x4 MU-MIMO), and 2.4GHz (2x2 MU-MIMO) bands and is powered by PoE++ (802.3bt).

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications
Antenna Gain: 2.4GHz: 4dBi; 5GHz: 6dBi; 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5GHz: 8.6Gbbps ; 6GHz: 5.8Gbps
Ethernet Ports: 1x 10/100/1000/2500/10000
Hardware Button: Reset
Max. Power Consumption: 29W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 40°C
PoE Input: 802.3bt (PoE++)
PoE Output: None
Power Input: 802.3bt (PoE++) (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None
Dimensions: Ø215 x 32.5 mm
Weight: 800g

Ubiquiti's UA-G3-W is an IP55 tamper resistant access reader with speaker for single door access control indoors and outdoors. PoE powers the unit, which connects to a UniFi Access Hub via PoE and can be unlocked using an NFC card or UniFi Identity Mobile App.

Note: This device needs to be paired with UA-HUB-DM

Specifications
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: In-wall, Gang Box
Operating Temperature: -30 to 45° C
Max Power Consumption: 5W
Power Input: PoE (Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Dimensions: 93 x 40 x 36.5 mm
Weight: 82g

The Ubiquiti UA-G3FLEX-W is an IP55-rated NFC card reader featuring a keypad and Touch Pass support, for which users will receive 10 free Touch Passes in the first year, thereafter, passes are billed annually per user. Powered via PoE, it's designed for seamless integration with UniFi Access Hubs.

Note: This device needs to be paired with UA-HUB-DM

Specifications
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: Wall-Mount (Included) ; Gang-box, junction box (Optional)
Operating Temperature: -30 to 60° C
Max Power Consumption: 5W
Power Input: PoE (Not Included), UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
Dimensions: 84 x 84 x 40.8 mm
Weight: 165g

Ubiquiti's UA-G3SK-PRO starter kit includes a Door Hub, an IP55 G3 Reader Pro with integrated camera, an IP55 G3 Reader, and 2x Pocket Key fobs. This starter kit provides complete entry and exits control for a single door and includes Touch Pass support, for which users will receive 10 free Touch Passes in the first year; thereafter, passes are billed annually per user. The kit can be configured and managed with the UniFi Access Application.

Specifications
Door Hub
Button: Reset
Terminal Input: 2x Door exit request; 1x Door position; 1x Emergency
Ethernet Ports: 5x 10/100/1000
Lock Terminals: 1x 12V 1A
Mounting: DIN-rail (Included)
Operating Temperature: 0°C to 40°C
Max Power Consumption: 30W
PoE Input: PoE++ (50V DC, 1A)
PoE Output: 4x 802.3af
Power Input: PoE++ ; UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
Supported Doors: 1

Dimensions: 174.9 x 126 x 32.9 mm
Weight: 363g

G3 Reader Pro
Button: Reset
Connectivity: BLE 4.2 or NFC
Ethernet Ports: 1x 10/100/1000
Mounting: Wall, gang-box mount (Included)
Operating Temperature: Device: -30°C to 45°C; Display: -10°C to 45°C
Max Power Consumption: 6W
Power Input: PoE (802.3af, Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Supported Voltage: 48V

Dimensions: 160 x 40.4 x 40.55 mm
Weight: 136g

G3 Reader
Button: Reset
Connectivity: BLE 4.1 or NFC
Ethernet Ports: 1x 10/100
Mounting: Wall, gang-box mount (Included)
Operating Temperature: Device: -30°C to 45°C
Max Power Consumption: 5W
Power Input: PoE (802.3af, Not Included), UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
Supported Voltage: 48V

Dimensions: 93 x 40 x 36.5 mm
Weight: 82g

Ubiquiti's UA-HUB-DM is a compact, indoor, access control hub which when paired with a UniFi Access Reader provides access control for a single door. It features 3x Gigabit Ethernet Ports, one of which accepts PoE++ (802.3bt) input and 2x PoE+ output ports with a total of 31W. The hub also has 2x input terminals for 1x door exit request and 1x door position and can be unlocked using an NFC card or UniFi Identity Mobile App.

Specifications
Button: Reset; Dry/Wet Switch
Bluetooth: None
Input Terminals: 1x Door Exit Request ; 1x Door Position
Ethernet Ports: 3x 10/100/1000
Dry Output Relay: 30V DC 1A
Wet Output Relay: 12V DC 1A
Mounting: DIN-rail (Included)
Operating Temperature: -30 to 40° C
Max Power Consumption: 19W
Power Input: 802.3at (PoE++)(Not Included)
Dimensions: 113 x 66 x 27.6mm
Weight: 190g

Ubiquiti's UA-RESCUE is a single pole, dual throw, manual Key Switch designed to work with the UniFi Access system. In the event of a system malfunction, the UA-Rescue Key Switch allows a user to manually unlock any door controlled by the UniFi Access Hub. The key is compatible with both Fail Safe and Fail Secure lock systems.

Specifications
Key Switch: Brass internal wave key, 28VDC, 4A
Operating Temperature: -30° to 65° C
Terminal block: COM/NO/NC - 18-24 AWG
Dimensions: Ø60 x 74 mm
Weight: 94g

Ubiquiti's UA-Ultra is an IP55 tamper resistant access reader with an integrated hub for complete single door access control. The unit is powered by PoE+ and features 1x Lock terminal (12V/1A), 1x Exit request input and can be unlocked using an NFC card or UniFi Identity Mobile App.

Specifications

Button: Reset
Bluetooth: BLE 4.2
Digital Input: 1x Exit Request
Ethernet Ports: 1x 10/100
Lock Terminals: 1x 12V 1A
Mounting: Wall-Mount or Gang Box Mount
Operating Tempreture: -30 to 40° C
Max Power Consumption: 18W
Power Input: 802.3af/at PoE (Not Included)
Dimensions: 126 x 45 x 37.45mm
Weight: 140g

Ubiquiti's UACC-AIPORT-RM is a 1U rack-mount accessory that supports up to 6x AI Ports.

Specifications
Enclosure Material: SGCC steel, polycarbonate
Mounting: Mini rack/rack
Ambient Operating Temperature: -20° to 40° C (-4° to 104° F)
Dimensions: 442.4 x 158.5 x 42.8 mm
Weight: 650g

Ubiquiti's UACC-G5TAM is a IP66 weatherproof arm mount, designed for the G5 Turret Ultra for either wall, corner, or pole mounting.

Specifications
Compatibility: UVC-G5TU
IP Rating: IP66
Pole Diameter: 38-50mm on pipe outer diameter
Dimensions: 115 x 252 x 90 mm
Weight: 670g
