Ubiquiti's UACC-HDD8 is an enterprise-grade 3.5" 8TB SATA hard drive, ideal for storage-intensive UniFi camera security and NAS systems.

Specifications

Capacity: 8TB
Hard Disk Form Factor: 3.5-inch
Mean Time Between Failure (MTBF): 2,000,000 h
Management Interface: SATA 6Gb/s
Operating temperature: 5 to 60°C
Power Method: 5V/12V input
Rotation Speed: 7200 RPM
Workload Rating: 550TB/year
Dimensions: 147 x 101.9 x 26.1 mm
Weight: 720g

Ubiquiti's UACC-INS-4.5M is a 4.5 metre USB-C cable that connects the UVC-G4INS and UVC-G6INS to a POE-USBC adapter.

Specifications

Cable length: 4.5m
Cable Color: White
Operating Temperature: -20°C to 60°C
Shielding: Shielded twisted pair (STP)
Weight: 117g

Ubiquiti's UACC-LRE is an outdoor Gigabit Ethernet adapter which establishes long-range connections between PoE switches and devices. The unit features 2x Gigabit Ethernet ports. Port one receives 802.3af/at PoE input while port two provides PoE passthrough for distances up to 1km when making use of multiple adapters. The unit also offers 10kA+ surge protection and works reliably in extreme temperatures to protect your deployment from weather and electrical damage.

*Note: This device does not support MTU's larger than 1500. If making use of jumbo frames across the device, it will not work.

Specifications
Ethernet Ports: 2x 10/100/1000
Hardware Button: None
Max. Power Consumption: 1.5W
Mounting: Pole-Mount
Operating System: None
Operating Temperature: -40°C to 80°C
PoE Input: 802.3af/at
PoE Output: 802.3af PoE Passthrough
Power Input: 802.3af/at
SFP Ports: None
Supported Voltage Range: 37-57V
Dimensions: 196.5 x 93.5 x 39 mm
Weight: 350g

Ubiquiti's UACC-PROMAX16RM is a 19-inch, 1U rack-mount accessory for the USW-PRO-MAX16 and USW-PRO-MAX16P. The unit includes power cable management and adapter storage for a clean installation.

Specifications
Compatibility: USW-PRO-MAX16 & USW-PRO-MAX16P
Enclosure Material: SGCC steel, polycarbonate
Dimensions: 280.9 x 115.1 x 42.8 mm
Weight: 1.1 kg

Ubiquiti's UACC-PSU-210W is a wall mountable AC power adapter which delivers 210W at 54V DC, ideal for powering PoE Switches.

Specifications
Compatibility: USW-ULTRA, USW-U60, USW-PRO-MAX16P, USW-U210
Connector: IEC
DC plug: 5.5 x 2.1 x 11.5 mm
DC cable: UL11353 16AWG 1.5 m
Voltage: 54V
Wattage: 210W
Dimensions: 190 x 86 x 26 mm
Weight: 2kg

Ubiquiti's UACC-TPC-1.5M is a 1.5m UISP Power Transport Cable for use between the UISP-BOX and the included power supply of the UISP-R or UISP-S.

Specifications
Connector: Power TransPort
Flame rating: VW-1
Conductor wire gauge: 12 AWG
Conductor type: Tin stranded copper
Jacket material: Thermoplastic elastomer
Jacket diameter: 11 x 6.5 mm
Operating temperature: -40 to 80°C
Cable Length: 1.5m

Ubiquiti's UACC-TPC-20M is a 20m UISP Power Transport Cable for use between the UISP-BOX and the included power supply of the UISP-R or UISP-S.

Specifications
Connector: Power TransPort
Flame rating: VW-1
Conductor wire gauge: 12 AWG
Conductor type: Tin stranded copper
Jacket material: Thermoplastic elastomer
Jacket diameter: 11 x 6.5 mm
Operating temperature: -40 to 80°C
Cable Length: 20m

Ubiquiti's UACC-TPC-50M is a 50m UISP Power Transport Cable for use between the UISP-BOX and the included power supply of the UISP-R or UISP-S.

Specifications
Connector: Power Transport
Flame rating: VW-1
Conductor wire gauge: 12 AWG
Conductor type: Tin stranded copper
Jacket material: Thermoplastic elastomer
Jacket diameter: 11 x 6.5 mm
Operating temperature: -40 to 80°C
Cable Length: 50m

Ubiquiti's UACC-UKPA is an IPx6, clip-on external antenna for the Swiss Army Knife (UK-ULTRA) that provides extended 90-degree directional coverage.

Specifications
Antenna Gain: 2.4GHz: 10dBi ; 5.8GHz: 15dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Wind Loading: 75 N at 200 km/h
Dimensions: 138 x 207 x 43 mm
Weight: 450g

Ubiquiti's UB-ETHSP is a Gigabit Ethernet surge protector designed to protect outdoor, PoE or non-PoE Ethernet devices from electrostatic discharge and surges.

Specifications

Data Line Protection: RJ45 10/100/1000
DC Spark-Over Voltage: 90V 100V/s
Discharge Current: 10kA+
Ethernet Ports: 2x 10/100/1000
Maximum Impulse Spark-Over Voltage: 700V 1kV/µs
Operating Temperature: -30°C to 65°C
PoE Support: 802.3af & Passive PoE
Dimensions: 91 x 61 x 32.5mm

Ubiquiti's UC-CAST-LITE is a digital signage player designed for media playback on HDMI displays. It is powered by the included USB-C adapter and has a single HDMI output. It features Dual-Band WiFi for seamless integration with UniFi Access points.

This product is managed and configured using the UniFi Connect application.

Specifications
Buttons: Reset
Connectivity: 2.4GHz (20/40 MHz) ; 5GHz (20/40/80 MHz)
Display Output: HDMI
Max. Power Consumption: 5W
Operating Temperature: 0 to 40°C
Power Input: USB-C 5V 1A Power Supply (Included)
Processor: Quad-Core Arm® Cortex®-A55, 1.9 GHz
Dimensions: 92.1 x 56.3 x 40.8 mm
Weight: 180g

Ubiquiti's UCG-FIBER is a desktop 10Gbps dual WAN, UniFi cloud gateway with selectable NVR storage via SSD up to 2TB. The unit runs the complete UniFi application suite for full stack network management and features 1x 10Gbps WAN port, 4x 2.5Gbps LAN Ports, one with 802.3at (PoE+) PoE output, as well as 2 x SFP+ ports.

It can be configured and managed with the UniFi Network Application.

Note: NVMe SSD not included. Third-party SSD installation requires tray accessory.

Specifications
Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/10000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 29.4W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3at (PoE+) on Port 4
Power Input: 54V 1.1A Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
Serial Interface: None
SFP Ports: 2 x SFP+ (1x WAN ; 1 x LAN)
Supported Voltage Range: 50-57V
System Memory: 3GB
USB Ports: None
Dimensions: 212.8 x 127.6 x 30 mm
Weight: 675g

Ubiquiti's UCK-G2-SSD is a compact UniFi console running the complete UniFi application suite for full stack network management and features a pre-installed 1TB SSD. The unit can be powered by PoE or a USB-C quick charge adapter.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.6W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 35°C
PoE Input: 802.3af/at (PoE)
PoE Output: None
Power Input: 802.03af/at (PoE) or 9V 2A USB-C Power Supply (Not Included)
Processor: Octa-core Arm® Cortex®-A53 based chip
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 9V 2A (USB-C)
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 131.2 x 27.1 x 134.2 mm
Weight: 560g

Ubiquiti's UDB-PRO is a UniFi long range outdoor radio with integrated UniFi Wi-Fi Auto-Link. It features 2x Gigabit Ethernet ports, one for PoE input and the other with PoE output. PoE+ (802.3at) input is required for PoE passthrough on port 2. The UDB-PRO is sold as a single unit and can be bridged to any UniFi Access point or used as a pair for PtP connections. It can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 5.8GHz: 19dBi
Beam-width: 12°
Data Rate: 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: 48V PoE Passthrough when powered with PoE+ (802.3at)
Power Input: 48V 0.32 Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5–57V DC
USB Ports: None
Dimensions: Ø189.5 x 64.3 mm
Weight: 515g

Ubiquiti's UDB-PRO-SEC is a UniFi 5GHz, 17dBi point-to-multipoint, 90° integrated sector which can connect up to 40+ UDB-PRO devices at distances of up to 5km. It features an outdoor IPX6 rating, 2 spatial streams, and up to 400Mbps throughput on its 5GHz radio. It can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 5.8GHz: 17dBi
Beam-width: 90°
Data Rate: 5.8GHz: 400Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 802.3af/at PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5–57V DC
USB Ports: None
Dimensions: 360.9 x 129.6 x 71.4 mm
Weight: 835g

Ubiquiti's UDR7 is a desktop, Tri-Band, 10Gbps cloud gateway with integrated Wi-Fi 7, microSD storage, and full UniFi Application Suite support. The unit features 1x 10Gbps SFP+ port, 4x 2.5Gbps Ethernet Ports, and a pre-installed 64GB microSD for UniFi Protect. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2x2 MU-MIMO), 5GHz (2x2 MU-MIMO), and 2.4GHz (2x2 MU-MIMO) bands and can be configured and managed with the UniFi Network Application.

Specifications

Antenna Gain: 2.4GHz: 5dBi; 5.8GHz: 7dBi : 6GHz: 6dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5GHz: 4.3Gbps ; 6GHz: 5.7Gbps
Total aggregate data rate: 10.7Gbps
Ethernet Ports: 3x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 26W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: 802.3af on Port 3
Power Input: 100 - 240VAC, 1.5A Max, 50/60 Hz
Serial Interface: None
SFP Ports: 1x 10Gbps SFP+ (WAN)
SIM Slots: None
Supported Voltage Range: 100V—240V AC
USB Ports: None
Dimensions: Ø110 x 184.1 mm
Weight: 1.1kg

Ubiquiti's UF-OLT is a fibre solution that anyone can deploy. No command lines, manuals or paid support licenses are required. The UISP Fiber UF-OLT features 8x PON ports to connect up to 1024 ONUs (128x ONUs per port), 2x SFP+ ports and 2x Gigabit Ethernet Management ports. The unit also features 2x Hotswap AC/DC PSUs for power redundancy.

It can be managed via the UISP network management platform.

*Note: 1x UF-GP-B+ included.

Specifications

Ethernet Ports: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 40W
Mounting: Rack-Mount
Operating System: UFiber
Operating Temperature: -10°C to 45°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included) ; 24V DC (Not Included)
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 8x 2.5/1.25Gbps GPON Ports; 2x 10Gbps SFP+
Supported Voltage Range: 100V – 240V
USB Ports: 1x USB 2.0
Dimensions: 442.4 x 285.6 x 43.7 mm
Weight: 4.5kg

Ubiquiti's UF-WIFI6 is a dual band, WiFi 6 (802.11ax) GPON CPE. It features an LED display, 4x Gigabit Ethernet Ports, 1xSC APC GPON WAN port and provides powerful Layer 2/3 management features. The unit is capable of distances of up to 20km with speeds of up to 2.4Gbps downstream and 1.2Gbps upstream. The UF-WIFI6 can be powered by either the included 5V 3A USB-C or 24V Passive PoE.

It can be managed via the UISP network management platform.

Specifications
Antenna Gain: 2.4GHz: 1dBi ; 5.8GHz: 3dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 1.2Gbps
Ethernet Ports: 4x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: UFiber
Operating Temperature: -15°C to 45°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 5V 3A USB-C (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 10-30V Passive PoE ; 5VDC USB-C
USB Ports: None
Other: 1x 2.5/1.25Gbps SC APC GPON
Dimensions: 140.8 x 141.5 x 31.65 mm
Weight: 415g

Ubiquiti's UMR-ULTRA is an ultra-compact, Wi-Fi 4 managed LTE4 mobile router with 2x Fast Ethernet Ports for IoT applications. It features detachable LTE antennas, wired WAN, automatic failover, and can be powered by either USB-C (5V 2A) or 4-pin ATX DC power socket (9-30V DC).

*Note: UMR-ULTRA comes with a 180-day mobility cloud free trial and is available for purchase thereafter from UI.

Specifications

Antenna Gain: LTE 2x External Antennas; 2.4GHz: 1x External Antenna
Beam-width: 360°
Data Rate: LTE: 150Mbps Downlink; 50Mbps Uplink 2.4GHz: 300Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset
Max. Power Consumption: 5.7W
Mounting: DIN-rail or Wall-Mount (Included)
Operating System: UniFi
Operating Temperature: -30°C to 70°C
PoE Input: None
PoE Output: None
Power Input: USB-C 5V 2A
Serial Interface: None
SIM Slots: 1 (Nano SIM)
Supported Voltage Range: USB-C: 5V 2A; ATX DC: 9V-30V
USB Ports: None
Dimensions: 193.5 x 82 x 26 mm
Weight: 220g

Ubiquiti UNAS-PRO is a 2U rack-mount NAS with 7x 2.5/3.5" hard drive bays, 1x Gigabit Ethernet Port and 1x 10Gbps SFP+ port designed for large-scale file storage and sharing. The UNAS-PRO also has a 1.3" touchscreen for easy management, data protection with RAID storage technology and a 1.7GHz Quad Core CPU.

*Note: Hard drives are not included. Please ensure your HDDs meet Ubiquiti's general guidelines and aren't included in the list of incompatible models.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 160W
Max. Power Budget for Drives: 135W
Mounting: 2U Rack-Mount
Operating System: UniFi Drive
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: Quad-Core ARM® Cortex®-A57 at 1.7 GHz
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 1x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 8GB
USB Ports: None
Dimensions: 442 x 325 x 87 mm
