Ubiquiti's AIR-S521AC is a 5GHz 21dBi, 60° airMAX ac, sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.

Specifications

Antenna Gain: 21dBi
Beam-width: 60°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 391N @ 200km/h
Dimensions: 750 x 173 x 78mm
Weight: 4.8Kg

Ubiquiti's AIR-D534 is a 5GHz 34dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D534 features robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 34dBi
Beam-width: 3°
Connector: 2x RP SMA Female
Frequency Range: 4.9 – 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 1;779N @ 200km/h

Dimensions: Ø 1050 x 421mm
Weight: 13.5kg

Ubiquiti's AIR-D530LW is a 5GHz 30dBi lightweight dish antenna designed to seamlessly integrate with the Ubiquiti Radios.
*Note: Radio not included.

Specifications

Antenna Gain: 30dBi
Beam-width: 5.8°
Connector: 2x RP SMA Female
Frequency Range: 5.1GHz - 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 790N @ 200km/h

Dimensions: Ø 650 x 386mm
Weight: 7.4kg

Ubiquiti's UISP-DISH is a 5GHz 30dBi dish antenna designed to seamlessly integrate with Ubiquiti radios. The antenna provides extended coverage by utilising a wide frequency range. The unit comes with a precision mounting bracket for easy installation and alignment.

*Note: Radio not Included.

Specifications

Antenna Gain: 30dBi
Beam-width: 5 to 6° (3 dB) / 6.5 to 8° (6 dB)
Connector: WaveGuide Adapter (Included)
Frequency Range: 5.15 - 6.875GHz
Polarization: Vertical & Horizontal
Wind Loading: 860 N at 200 km/h
Dimensions: Ø 650 x 200 mm
Weight: 7.64Kg

Ubiquiti's AIR-D530 is a 5GHz 30dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D530 features a robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 30dBi
Beam-width: 5°
Connector: 2x RP SMA Female
Frequency Range: 4.9GHz - 5.8GHz
Polarization: Vertical & Horizontal
Wind Loading: 787N @ 200km/h

Dimensions: Ø 650 x 304mm
Weight: 9.8kg

Ubiquiti's AIR-S520 is a 5GHz 20dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 20dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 182N @ 200km/h
Dimensions: 700 x 135 x 70mm
Weight: 5.9kg

Ubiquiti's AIR-S519 is a 5GHz 19dBi, 120° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 19dBi
Beam-width: 120°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 137.9N @ 200km/h

Dimensions: 700 x 135 x 73mm
Weight: 5.9kg

Ubiquiti's AIR-S517 is a 5GHz 17dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 17dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 4.90GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 41.7N @ 200km/h

Dimensions: 367 x 63 x 41mm
Weight: 1.1kg

UltraLAN Fiber Flylead LC-SC APC SM (1Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack.

These flyleads feature a LC connector on one side, and a SC connector on the other , making them practical flyleads to also connect PON ONU equipment to fiber termination boxes with an LC connector.

This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.


Connector Type LC to SC Polish Type APC to APC

Fiber Count Duplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥60dB

UltraLAN Fiber Flylead LC-LC UPC SM Simplex (5Meter)

The UltraLAN high-quality LC to LC Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and simplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead LC-LC UPC SM Simplex (3Meter)

The UltraLAN high-quality LC to LC Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and simplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead LC-LC UPC SM Simplex (20Meter)

The UltraLAN high-quality LC to LC Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and simplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead LC-LC UPC SM (3Meter)

The UltraLAN high-quality LC to LC Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and duplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Duplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead LC-LC UPC SM (1Meter)

The UltraLAN high-quality LC to LC Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and duplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Duplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead LC-LC UPC MM OM3 (1Meter)

UltraLAN's high Quality and cost-effective 50/125μm OM3 Multimode Fiber Optic Cable is ideal for connecting 10G SR, 10G LRM, SFP+ transceivers etc. for 10G/40G/100G Ethernet connections and is the preferred fiber specification for 10G Ethernet connections.

The UltraLAN OM3 Multi Mode fiber optic cables meets RoHS compliance, and is optically tested for insertion loss to ensure high quality and excellent performance. It is very cost-effective for network cabling applications in data centers, enterprise networks, telecom rooms, server racks, cloud storage networks, and any other place fiber patch cables are needed with high bandwidth demands.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Duplex Fiber Mode OM3 50/125μm
Wavelength 850/1300nm 10G Ethernet Distance 300m at 850nm
Insertion Loss ≤0.3dB Return Loss ≥30dB

UltraLAN Fiber Flylead LC-LC UPC MM OM2 (1Meter)

UltraLAN's 50/125μm OM2 multimode fiber optic cable is ideal for connecting SFP and SFP+ transceivers together for 1G Ethernet connections. Ideal for short distance equipment interconnects, such as linking data switches together in a network rack.

The UltraLAN OM2 Multi Mode fiber optic cables has less attenuation when bent or twisted compared with traditional optical fiber cables which makes installation and maintenance of the fiber optic cables more efficient.

This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.

Connector Type LC to LC Polish Type UPC to UPC
Fiber Count Duplex Fiber Mode OM2 50/125μm
Wavelength 850/1300nm 1G Ethernet Distance 550m at 850nm
Insertion Loss ≤0.3dB Return Loss ≥30dB

UltraLAN Fiber Flylead LC-LC APC SM Simplex (1Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack.

This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.

Connector Type LC to LC Polish Type APC to APC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥60dB

UltraLAN Fiber Flylead LC-LC APC SM Duplex (3Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack.

This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.

Connector Type LC to LC Polish Type APC to APC

Fiber Count Duplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥60dB

UltraLAN Fiber Flylead LC-LC APC SM Duplex (1Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack.
This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.

Connector Type LC to LC Polish Type APC to APC

Fiber Count Duplex Fiber Mode OS2 9/125μm

Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)

Insertion Loss ≤0.3dB Return Loss ≥60dB

UltraLAN Fiber Flylead LC UPC-SC APC SM Simplex (3Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack.
This fiber flylead features a LSZH (Low Smoke Zero Halogen) outer jacket.

Connector Type LC to SC Polish Type UPC to APC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥60dB
