The TP‑Link VIGI‑NVR1008H‑8MP is an 8‑channel PoE+ 4K NVR offering robust performance for small to medium surveillance installations. With a 113 W PoE power budget it supplies power and network to up to eight PoE+ cameras, supports up to 8MP recording, and provides H.265+ compression to maximise storage efficiency. Local monitoring is via 4K HDMI output; playback supports up to eight channels simultaneously. A single SATA bay supports up to 16 TB for long retention, while ONVIF compatibility and the VIGI app enable flexible integrations and remote management. Compact (294 × 180 × 44 mm) and easy to deploy, it’s ideal for retail, offices, and residential estates.

Technical Details:

Model / SKU: VIGI‑NVR1008H‑8MP
Channels: 8 IP camera inputs
PoE: PoE+ with 113 W total budget (powers up to eight cameras depending on camera draw)
Max recording: Up to 8 MP
Incoming bandwidth: 80 Mbps
Outgoing bandwidth: 60 Mbps
Compression: H.265+, H.265, H.264
Decoding / Playback: Up to 8‑ch simultaneous playback
Video outputs: 1 × 4K HDMI (local monitor)
Storage: 1 × SATA bay, up to 16 TB (single HDD)
Integration: ONVIF compliant; remote management via VIGI app
Form factor / Dimensions: Compact desktop / rackable style; 294 × 180 × 44 mm
Operating environment: Typical commercial ranges (refer to official datasheet for exact specs)

The Hikvision DS‑7616NXI‑K2/16P is a compact 1U 16‑channel AcuSense NVR delivering intelligent, high‑resolution surveillance for medium sites. It includes 16 built‑in PoE ports for streamlined camera power and connectivity, supports up to 12MP recording with H.265+ compression to save storage, and provides a 4K HDMI output for crisp local monitoring. AcuSense AI offers face recognition and perimeter protection to reduce false alarms and prioritise critical events. Dual SATA bays allow flexible storage (up to 20 TB total), while 160 Mbps incoming bandwidth and robust alarm I/O make this NVR suitable for retail, SMB, and campus deployments requiring reliable, feature‑rich video management.

Technical Details:

Model / SKU: DS‑7616NXI‑K2/16P
Channels: 16 IP camera inputs
PoE: 16 × PoE ports (total power budget depends on SKU/PSU)
Max recording: Up to 12 MP
Incoming bandwidth: 160 Mbps
Compression: H.265+, H.265, H.264
Video output: 1 × 4K HDMI (local display)
Decoding / Playback: Multi‑channel playback; smart search/playback features supported
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection (channel limits per firmware)
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Operating environment: Commercial operating ranges (refer to datasheet for specifics)

The Hikvision DS-7608NXI-K2 is a compact 1U 8‑channel AcuSense NVR designed for small-to-medium deployments that need smart analytics and reliable local monitoring. It features eight integrated PoE ports for streamlined camera power and connectivity, supports up to 12MP recording with H.265+ compression, and offers 4K HDMI output for crisp local display. AcuSense AI provides face and perimeter detection to reduce false alerts, while dual SATA bays allow flexible storage (up to 20 TB total). With 80 Mbps incoming bandwidth, robust alarm I/O, and a compact chassis, this NVR balances performance, manageability, and cost-effectiveness.

Technical Details:

Channels: 8 IP camera inputs
PoE: 8 × PoE ports (power budget depends on SKU/PSU)
Max recording: Up to 12 MP
Incoming bandwidth: 80 Mbps
Decoding / Playback: Multi‑channel playback; H.265+/H.265/H.264 support
Video outputs: 1 × 4K HDMI (local monitor)
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Weight: ~3.0 kg (unit)
Operating conditions: Typical commercial operating ranges (refer to datasheet for specifics)
Model / SKU: DS‑7608NXI‑K2 (8‑PoE variant)

The Hikvision DS-7104NI-Q1/4P is a compact 4‑channel 1U Mini NVR with built‑in PoE for simplified installation. Supporting up to 6MP recording and 4‑channel 1080p decoding, it delivers reliable performance for small to medium surveillance setups. With 40 Mbps incoming bandwidth and 60 Mbps outgoing, HDMI/VGA outputs, and H.265+ compression, it ensures efficient storage and smooth playback. A single SATA interface supports up to 6 TB HDD, while the 36 W PoE budget powers up to four IP cameras directly. Compact (200 × 200 × 48 mm), powered by DC 48V, and operating in -10~55°C, this NVR is ideal for cost‑effective, space‑saving deployments.

Technical Details:

Channels: 4‑channel input
Form Factor: 1U Mini NVR
PoE Ports: 4 × PoE, 36 W total budget
Recording: Up to 6MP/4MP resolution
Bandwidth: 40 Mbps incoming, 60 Mbps outgoing
Decoding: 4‑channel 1080p synchronous playback
Video Output: HDMI & VGA
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 6 TB HDD
Power: DC 48V
Operating Temperature: -10°C to +55°C
Dimensions: 200 × 200 × 48 mm
Model / SKU: DS-7104NI-Q1/4P

The TP-Link VIGI-NVR1104H-4P is a 4‑channel PoE+ 4K NVR designed for efficient and intelligent video management. Supporting up to 16 MP decoding, 4K HDMI output, and 4‑channel synchronous playback, it delivers crisp, high‑resolution monitoring. With a 53 W PoE+ power budget, it can directly power and connect up to four IP cameras, simplifying installation. Featuring H.265+ compression for optimized storage, a single SATA interface supporting up to 10 TB HDD, ONVIF compatibility, and a built‑in speaker, this NVR integrates seamlessly with the VIGI app for remote access and management. Compact and reliable, it’s ideal for small to medium surveillance setups.

Technical Details:

Channels: 4‑channel input
PoE+ Budget: 53 W total
Video Output: 4K HDMI
Decoding Capability: Up to 16 MP
Playback: 4‑channel synchronous playback
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 10 TB HDD
Audio: Built‑in speaker
Integration: ONVIF compliant; remote management via VIGI app
Power: PoE+ and 12 VDC support
Model / SKU: VIGI-NVR1104H-4P

The Hikvision DS-2CD2T27G2-L is a 2MP ColorVu fixed bullet IP camera designed for vivid full‑colour imaging day and night. With a 2.8 mm wide‑angle lens (≈126°), ultra‑low‑light sensitivity down to 0.0005 lux, and 40 m white‑light illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 120 dB WDR balances high‑contrast scenes. Built‑in microphone, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 256 GB make this compact bullet camera ideal for perimeter, entrance, and outdoor monitoring.

Technical Details:

Resolution: 2 MP (1920 × 1080)
Lens: 2.8 mm fixed; Field of View ≈ 126°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: 40 m white‑light LED
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 120 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~5–6 W
Model / SKU: DS-2CD2T27G2-L-2.8mm

The TP-Link VIGI-C445 is a 4MP full‑color turret IP camera designed for reliable outdoor surveillance. With a 2.8 mm wide‑angle lens (≈122°), ultra‑low‑light sensitivity down to 0.005 lux, and dual Smart Illumination (30 m white‑light and 30 m IR), it ensures clear detail day and night. On‑device AI for human and vehicle detection reduces false alarms, while 3D DNR and 130 dB WDR deliver sharp, balanced images. Built with IP67 weatherproof housing, PoE/12V power options, H.265+ compression, and microSD storage up to 256 GB, this turret camera is compact (111 × 111 × 83 mm) and ideal for perimeter, entrance, and commercial monitoring.

Technical Details
Resolution: 4 MP (2560 × 1440)
Lens: 2.8 mm fixed; Field of View ≈ 122°
Low‑light: Min. illumination 0.005 lux (colour)
Illumination: 30 m white‑light + 30 m IR night vision
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
Noise Reduction: 3D DNR (Digital Noise Reduction)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) or 12 VDC
Storage: microSD slot up to 256 GB (card not included)
Dimensions: 111 × 111 × 83 mm
Network: ONVIF compliant; remote viewing via VIGI app/NVRs
Model / SKU: VIGI-C445-2.8mm

The Hikvision DS-2CD2347G2H-LISU-SL is a 4MP ColorVu fixed turret IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Equipped with a 4 mm lens (≈117.4° wide view), ultra‑low‑light sensitivity down to 0.0005 lux, and up to 30 m Smart Illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. With built‑in mic and speaker for two‑way audio, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 512 GB, this turret camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 4 mm fixed; Field of View ≈ 117.4°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone & speaker (two‑way audio)
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2347G2H-LISU-SL-4mm

The Hikvision DS-2CD2047G2H-LIU-SL is a 4MP ColorVu fixed mini bullet IP camera in sleek black finish, designed for vivid full‑colour imaging day and night. With a 2.8 mm lens (≈133.6° wide view), Smart Hybrid Light up to 40 m, and ultra‑low‑light sensitivity (0.0005 lux), it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. Built‑in microphone, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 512 GB make this camera ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 133.6°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 40 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Finish: Black
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Mini bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2047G2H-LIU-SL-2.8mm-BLK

The Hikvision DS-2CD2955G0-ISU is a 5MP fixed fisheye IP camera designed for wide‑area monitoring with a 180° panoramic view. Featuring a 1.05 mm lens, 2560×1920 resolution at 25 fps, and IR coverage up to 8 m, it delivers sharp detail across large spaces. With H.265+ compression, PoE support, and microSD storage up to 512 GB, it ensures efficient recording and easy installation. Audio I/O enables two‑way communication, while flexible mounting options (wall, ceiling, or table) and compact Ø119 mm design make it ideal for retail, offices, and public areas requiring full coverage.

Technical Details:

Resolution: 5 MP (2560 × 1920 @ 25 fps)
Lens: 1.05 mm fixed fisheye; 180° panoramic view
IR Night Vision: Up to 8 m
Video Compression: H.265+, H.265, H.264
Audio I/O: Built‑in microphone and external audio interface
Mounting Options: Wall, ceiling, or table mount
Dimensions: Ø119 mm compact design
Weatherproofing: Indoor/outdoor adaptable (check installation environment)
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Model / SKU: DS-2CD2955G0-ISU-1.05mm

The Hikvision DS-2CD2347G2H-LI is a 4MP ColorVu fixed turret IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈138.5°), ultra‑low‑light sensitivity down to 0.0005 lux, and up to 30 m Smart Illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. With IP67 weatherproof housing, built‑in microphone, PoE support, H.265+ compression, and microSD storage up to 512 GB, this turret camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 138.5°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Dimensions: Ø138 × 115 mm
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2347G2H-LI-2.8mm

The Hikvision DS-2CD2041G0-LIU is a compact 4MP fixed bullet IP camera with Smart Hybrid Light for clear imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈114°), low‑light sensitivity down to 0.005 lux, and 30 m Smart Illumination, it delivers sharp detail in challenging conditions. With 120 dB WDR for high‑contrast scenes, built‑in microphone for audio capture, and support for microSD storage up to 256 GB, this camera offers versatile functionality. Rugged IP67 weatherproof housing, PoE support, and H.265+ compression make it efficient, durable, and ideal for outdoor surveillance.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 114°
Low‑light: Min. illumination 0.005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
WDR: 120 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~5–6 W
Model / SKU: DS-2CD2041G0-LIU-2.8mm

The Hikvision DS-2CD2T47G2H-LI is a 4MP ColorVu fixed bullet IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Equipped with a 4 mm lens (≈108° wide view), ultra‑low‑light sensitivity (0.0005 lux), and up to 60 m Smart Hybrid illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR delivers balanced images in high‑contrast scenes. With IP67 weatherproofing, PoE support, H.265+ compression, and microSD storage up to 512 GB, this camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 4 mm fixed; Field of View ≈ 108°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 60 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2T47G2H-LI-4mm

The Hikvision DS-2CD2T47G2H-LI is a 4MP ColorVu fixed bullet camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈126.7°), ultra‑low‑light ColorVu sensitivity (0.0005 lux) and up to 60 m Smart Hybrid illumination, it captures detailed colour footage even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms while 130 dB WDR manages high‑contrast scenes. Built for outdoor reliability with IP67 weatherproofing, PoE for simplified installs, H.265+ compression and microSD support up to 512 GB, it’s ideal for perimeter, entrance and street‑level monitoring.

Technical Details
Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View: ≈ 126.7°
Low‑light: ColorVu; Min. illumination: 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 60 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2T47G2H-LI-2.8mm

The Hikvision DS-2CD2T46G2H-4I is a 4MP AcuSense bullet camera delivering precise perimeter protection with Dark Fighter low-light performance and long-range IR. Featuring a 2.8 mm wide-angle lens (≈113°), up to 80 m IR, and AcuSense human/vehicle classification to cut false alarms, it captures clear, actionable footage day or night. Built for tough outdoor use with IP67 weatherproofing, 120 dB WDR, H.265+ compression, PoE power and on-board microSD storage, the camera supports alarm I/O for integrated security workflows and remote management via standard NVRs and mobile apps.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 113°
Low light: Dark Fighter tech; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 80 m; Smart IR support
Video Compression: H.265+, H.265, H.264
AI / Analytics: AcuSense human and vehicle classification (on-device)
WDR: 120 dB wide dynamic range
Alarm I/O: External alarm input/output for integration
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compatible; remote viewing via Hikvision apps/NVRs
Typical Power Draw: ~6–8 W (varies with IR/AI activity)
Mounting: Bullet form factor with 3-axis adjustable bracket
Model / SKU: DS-2CD2T46G2H-4I-2.8mm

The Hikvision DS-2CD2347G2H-LIU is a 4MP ColorVu turret camera that delivers vivid full‑colour imaging day and night with Smart Hybrid Light up to 40 m. Featuring a 2.8 mm wide‑angle lens (~138.5°), ultra‑low‑light ColorVu sensitivity (0.0005 lux), AI human/vehicle detection, 130 dB WDR, PoE, IP67 durability, H.265+ compression and on‑board microSD storage (up to 512 GB), it’s ideal for perimeter, entrance and street‑level monitoring where true‑colour detail and intelligent alerts matter.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 138.5°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 40 m
IR / Night Tech: Hybrid Smart Illumination + ColorVu
Video Compression: H.265+, H.265, H.264
AI Analytics: Human and vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone (audio support)
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot, up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2347G2H-LIU-2.8mm

The Hikvision DS-2CD2146G2H-I is a 4MP fixed dome powered by DarkFighter low-light technology for exceptional night-time colour and clarity. Equipped with a 2.8 mm wide-angle lens (≈119.7°), 30 m IR, 120 dB WDR and on-device AI for human and vehicle detection, it reliably captures high-detail footage in challenging lighting and high-contrast scenes. Ruggedly built to IP67 weatherproof and IK10 vandal-resistant standards, it supports H.265+ compression, PoE or 12 VDC power, and local recording via microSD (up to 512 GB). Ideal for perimeter, entrance and critical-site surveillance where low-light performance and durability matter.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of view ≈ 119.7°
Low-light tech: DarkFighter; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 30 m; Smart IR support
WDR: 120 dB wide dynamic range
AI Analytics: Human & vehicle detection (on-device)
Video Compression: H.265+, H.265, H.264
Weather & Impact Rating: IP67 (weatherproof) & IK10 (vandal resistant)
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot, up to 512 GB (card not included)
Network: ONVIF compliant; mobile/web remote viewing support
Mounting: Dome form factor with multi-axis adjustable mount
Typical Power Draw: ~6–8 W (varies with IR/AI use)
Model / SKU: DS-2CD2146G2H-I-2.8mm

The Hikvision DS-2CD2146G2H-I is a 4MP Dark Fighter dome IP camera engineered for superior low-light surveillance. With a 2.8 mm wide-angle lens (≈119.7°), Dark Fighter sensitivity to 0.001 lux, and 30 m IR, it captures clear colour and monochrome detail in extreme lighting. Built-in AI for human and vehicle detection reduces false alerts while 120 dB WDR handles high-contrast scenes. Rugged IP67 weatherproofing and IK10 vandal resistance make it ideal for outdoor and exposed locations. H.265+ compression, PoE power, and microSD support up to 512 GB deliver efficient storage and flexible installation for perimeter, entrance, and critical-site monitoring.

Technical Details
Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 119.7°
Low light: Dark Fighter technology; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 30 m; Smart IR support
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on-device)
WDR: 120 dB wide dynamic range
Weather & Impact Rating: IP67 (weatherproof) & IK10 (vandal resistant)
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; mobile and web remote viewing support
Mounting: Dome form factor with multi-axis adjustable mount
Typical Power Draw: ~6–8 W (varies with IR/AI activity)
Model / SKU: DS-2CD2146G2H-I-2.8mm

The Hikvision DS-2CD2046G2H-I is a compact 4MP mini bullet IP camera engineered for high-clarity outdoor surveillance. Equipped with a 2.8 mm wide-angle lens and DarkFighter low-light technology (0.001 lux), it delivers crisp colour by night and detailed 4MP daytime footage. Advanced features include up to 40 m IR, 120 dB WDR for high-contrast scenes, and on-device AI for human and vehicle detection to reduce false alerts. Built for harsh environments with IP67 weatherproofing, H.265+ compression for bandwidth efficiency, PoE for simple deployment, and microSD support up to 512 GB for local recording. Ideal for perimeter, entrance and street-level monitoring where resolution, low-light performance and intelligent detection matter.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View: ~119.7° (horizontal)
Low light: Dark Fighter; Min. Illumination: 0.001 lux (colour)
IR Night Vision: Up to 40 m; Smart IR compensation
Video Compression: H.265+, H.265, H.264
AI Features: Human and vehicle detection (on-device analytics)
WDR: 120 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) or 12 VDC (check local SKU)
Storage: microSD slot, up to 512 GB (card sold separately)
Network: ONVIF compliant; mobile app support; remote viewing
Mounting: 3-axis mini bullet bracket for flexible aiming
Typical Power Draw: ~6 W (varies by configuration)
Model / SKU: DS-2CD2046G2H-I-2.8mm

The Hikvision DS-2CD1023G0E-I is a rugged 2MP outdoor bullet IP camera built for reliable perimeter protection. Featuring a 2.8 mm fixed lens, 1080p Full HD video, 30 m IR night vision, IP67 weatherproof rating and H.265+ compression, it delivers clear day/night footage with efficient bandwidth use. Built-in microSD support, PoE and 12 VDC power options, 120 dB WDR and ICR low-light sensitivity ensure dependable performance across challenging lighting conditions. Compact, easy to mount with a 3-axis bracket, and fully manageable via mobile app and standard NVRs, this camera is ideal for homes, SMBs and outdoor installations.

Technical Details:

Resolution: 2 MP (1920 × 1080)
Lens: 2.8 mm fixed
Night Vision: IR up to 30 m; ICR, 0.01 lux (low light)
Video Compression: H.265+ / H.265 / H.264
Weatherproofing: IP67
WDR: 120 dB wide dynamic range
Power: PoE (802.3af) or 12 VDC
Storage: microSD slot (local recording)
Features: Motion detection, mobile app remote view, ONVIF compatible, 3-axis adjustable bracket
Typical Power Draw: 4 W
Mounting: 3-axis bracket for flexible aiming
Product Code / Model: DS-2CD1023G0E-I-2.8mm
