HiLook 16-ch 1080p Lite 1U H.265 DVR
Deep learning-based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video inputs
Audio via coaxial cable
Up to 18-ch IP camera input (up to 5 MP)
Up to 1080p Lite@15 fps encoding capability
Max. 1200 m for 720p HDTVI signal
Motion Detection 2.0 Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported.
Video and Audio
IP Video Input
2-ch (up to 18-ch)
Up to 5 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30

General
Power Supply12 VDC, 2 A
Consumption≤ 10 W (without HDD)
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)263 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch)
Weight≤ 1.1 kg (without HDD, 2.4 lb.)

HiLook 8-ch 1080p 1U H.265 DVR
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Long distance transmission over UTP and coaxial cable
H.265 Pro+ compression to improve encoding efficiency and reduce data storage costs
Supports 4 MP lite, and when enabled the image effect is similar with 4 MP
One HDD for continuous video recording
Smart search for efficient playback.
Video and Audio
IP Video Input
4-ch (up to 12-ch)
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input
4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30
*: The 3 MP signal input is only available for channel 1/2.
AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS Input PAL/NTSC
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
8-ch via coaxial cable
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)
Synchronous playback8-ch

General
Power Supply12 VDC, 1.33 A
Consumption≤ 12 W (without HDD)
Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight≤ 1 kg (2.2 lb.)

HiLook 8-ch 1080p Lite 1U H.265 DVR
Deep learning based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video input
Audio via coaxial cable
Up to 10-ch IP camera input (up to 5 MP)
Encoding ability up to 1080p lite @ 15 fps
Max. 1200 m for 720p HDTVI signal

Motion Detection 2.0 Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
Video and Audio
IP Video Input
2-ch (up to 10-ch)
Up to 5 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
CVBS InputSupport
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output ModeHDMI/VGA simultaneous output
Audio Input
1-ch RCA (2.0 Vp-p, 1 KΩ)
8-ch via coaxial cable
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way AudioReuse the first audio input
Synchronous playback8-ch

General
Power Supply12 VDC, 1.5 A
Consumption≤ 17 W (without HDD)
Working Temperature-10 °C to 55 °C (14 °F to +31 °F)
Working Humidity10% to 90%
Dimension (W × D × H)263 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch)
Weight≤ 1 kg (without HDD, 2.2 lb.)

HiLook 4-ch 1080p Lite 1U H.265 DVR
Deep learning-based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video input
Audio via coaxial cable
Up to 5-ch IP camera input (up to 2 MP)
Encoding ability up to 1080p lite @ 30 fps
Max. 1200 m for 720p HDTVI signal
Motion Detection 2.0 Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights Quick search by object or event type is supported.
Video and Audio
IP Video Input
1-ch (up to 5-ch)
Up to 1080p resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
CVBS Input Support
HDTVI Input1080p25, 1080p30, 720p25, 720p30
Synchronous playback4-ch
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
Video Output Mode HDMI/VGA simultaneous output
Audio Output1-ch, RCA (Linear, 1 KΩ)
Audio Input
1-ch RCA (2.0 Vp-p, 1 KΩ)
4-ch via coaxial cable
Two-Way Audio Reuse the first audio input

General
Power Supply12 VDC, 1.5 A
Consumption≤ 16 W (without HDD)
Working Temperature-10 °C to 55 °C (14 °F to +31 °F)
Working Humidity10% to 90%
Dimension (W × D × H)263 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch)
Weight≤ 0.8 kg (without HDD, 1.8 lb.)

🎥 Professional Video Capture for Live Streaming & Conferencing

✅ 4K30 HDMI Input – Capture high-resolution video sources
✅ USB-C 3.1 Output – Plug-and-play UVC compatibility
✅ PD 3.0 Pass-Through – 60W power delivery to host device
✅ No Drivers Needed – Works with Zoom/OBS/Teams out-of-the-box
✅ Compact Aluminum Body – Durable and portable

📊 Technical Specifications

Feature Specification
Model UC3021
Input HDMI 2.0 (4K30/1080p60)
Output USB-C 3.1 Gen 1
Power Delivery 60W PD 3.0 pass-through
Compatibility UVC 1.5 compliant
Dimensions 3.9 × 2.4 × 0.8 in (100×60×20mm)
OS Support Windows/macOS/Android/Linux
Warranty 2-Year Limited

🎬 Ideal For:

✔ Content Creators – Capture DSLR/mirrorless cameras
✔ Live Streamers – Connect consoles to streaming PCs
✔ Business Hybrid Meetings – Integrate pro cameras with laptops
✔ Education – Lecture capture setups

📦 Package Includes:

UC3021 Capture Device
USB-C to USB-C Cable (1m)
Quick Start Guide

"The ultimate all-in-one capture solution – no extra power bricks needed!"

⚙️ Pro Setup Tips:

• For 4K capture: Use high-quality HDMI 2.0 cables
• Power Priority: Connect PD charger to capture device first
• OBS Settings: Configure as UVC device at native resolution
• Mac Users: Enable camera permissions in System Preferences

🔍 Why Choose UC3021?

✔ Cleaner Setup – Single-cable solution with power delivery
✔ Wider Compatibility – Works with M1/M2 Macs and iPads
✔ Better Heat Dissipation – Aluminum enclosure vs plastic competitors

*(For multi-input capture, see Aten VS1821 model)*

Astrum MT25 Pro Bluetooth calling wireless smart sports fitness watch seamlessly blends innovation, fashion, and sports functionality with comprehensive health monitoring features, making it an indispensable accessory for busy professionals, modern workers, and active sports enthusiasts alike.

With its 1.52-inch HD full touchscreen, supporting intuitive taps and swipes, navigating and operating the watch is a breeze. It also offers hassle-free OTT firmware updates, ensuring your device stays current, and enhancing your daily life.

Crafted with precision, the MT25 smartwatch boasts an ultra-thin, aviation-grade Zinc Alloy body, and a comfortable food-grade silicone strap, ideal for those with sensitive skin.

Monitor your health with real-time blood oxygen tracking, sleep monitoring, sedentary reminders and the 24-hour heart rate monitor which aids in optimizing your exercise and training sessions and overall well-being.

The vivid screen displays built-in apps and icons with clarity, ensuring you never miss essential call or message notifications. Customize your display style with dynamic multi-themes, and receive notifications for calls, SMS, and various social media platforms right on your wrist, staying connected effortlessly.

Elevate your fitness game with the enhanced multi-sports mode, all while the IP67 water-resistant technology shields the watch from sweat, splashes, or rain.

Recharge your smartwatch effortlessly with the wireless charger, providing up to 7 days of normal usage on a single charge. Stay consistent with your fitness routine thanks to sedentary alerts and an alarm clock, eliminating the need for frequent recharging.

Features:

– 1.52″ 33mm ultra-retina HD full touchscreen
– Full HD touchscreen with colorful dynamic multi interchangeable dial interfaces
– Blood oxygen, 24-hour heart rate, sedentary reminder, and sleep monitoring
– IP67 water-resistant technology to prevent damage from sweat and water splash
– Support wireless charging with a wireless charging cable
– Supports continuous OTT firmware update
– Supports wireless bluetooth calling directly from the smartwatch
– Ultra-thin, aviation-grade Zinc Alloy body
– Food-grade silicone strap for sensitive and delicate skins
– Multi-sport mode and eye-catching multi-themes display
– Calls, SMS, Social, and Email alerts
– Supports Smart Siri and Google Assistant
– Control smartphone camera and music playback from the smartwatch

Technical Specifications:
– Connectivity: BLE V5.2
– Display Screen: 1.52 inch 360×360 HD full touchscreen
– Water Resistance: IP67
– Strap Material: Food-grade silicone
– Strap Length: 46.5 x 260mm
– Strap Width: 33mm
– Battery Life: Up to 30 days (Standby)
– Usage Time: Up to 7 days (Without call pairing)
– Call/Music Usage Time: Up to 8 hours (Continuous use)
– Charging Time: Up to 3 hours
– Weight: 73.6g (approx.)
– Dimensions: 49.9 x 46.9 x 11.1mm (L x W x H)
What’s in the box
1 x MT25 Pro Bluetooth Sports Smart Watch
1 x Wireless Charger
1 x User Manual

🏢 Professional-Grade Wi-Fi in a Discreet Wall Plate Design

✅ AC1200 Dual-Band Wi-Fi – 867Mbps @5GHz + 300Mbps @2.4GHz
✅ 3x Gigabit Ports (2x PoE+) – Powers IP phones/cameras while uplinking
✅ Sleek Wall-Plate Design – Replaces standard Ethernet wall jack
✅ Nuclias Connect Cloud Management – Centralized control for multi-AP deployments

📊 Technical Specifications

Category Specification
Model DAP-2622
Wi-Fi Standard 802.11ac Wave 2
PoE Support 802.3at (Ports 1-2)
Antennas Internal (4× 3dBi)
Mounting Standard wall plate (included)
Dimensions 4.7 × 2.6 × 1.1 in (120 × 66 × 28 mm)
Warranty 3-year limited

**🏢 Ideal For:

✔ Hotel rooms & dormitories
✔ Office workstations
✔ Retail POS systems
✔ Smart home installations

**📦 What's Included?

DAP-2622 Access Point
Wall plate & mounting hardware
Quick install guide

"The invisible enterprise AP—perfect for clean, professional installations!"

**⚙️ Pro Tips:

Use Port 3 for wired backhaul to avoid bandwidth sharing
Enable band steering to optimize 5GHz device connections
Pair with Nuclias Cloud for multi-site management

**🔍 Why Choose DAP-2622?

✔ Saves space – No bulky ceiling/wall mounts
✔ Simplifies cabling – Combines Wi-Fi + Ethernet in one outlet
✔ Enterprise features – VLAN, QoS, captive portal
*(For Wi-Fi 6, see DAP-2682 model)*

SKU: A71552-B | 24-Month Warranty | Dual Vibration | 2.4GHz Wireless
Universal Gaming Freedom Across 5 Platforms

Experience seamless cross-platform gaming with the Astrum GW520 Wireless Gamepad, engineered for PC, PS2, PS3, Android TV, and media players. Featuring dual analog sticks, force feedback vibration, and 2.4GHz wireless connectivity, this controller delivers console-grade precision for emulators, modern titles, and living room entertainment.

🔥 Key Features

✔ 5-System Compatibility – Works with Windows PC, PS2, PS3, Android TV, and media boxes
✔ Dual Shock Vibration – Rumble feedback for immersive explosions, crashes, and impacts
✔ 2.4GHz Wireless – 10-meter range with stable, low-latency connectivity
✔ Dual Analog Sticks – Precision control for 3D movement and camera adjustments
✔ Turbo Function – Programmable rapid-fire for arcade and shooter games
✔ Ergonomic Grip – Rubberized texture prevents slipping during long sessions
✔ 12 Action Buttons + 8-Way D-Pad – Responsive inputs for any genre

📊 Technical Specifications
Feature Specification
Connectivity 2.4GHz wireless (USB receiver included)
Compatibility Windows (10 and below), PS2, PS3, Android TV, media players
Vibration Dual-motor force feedback
Battery Built-in rechargeable (USB charging)
Buttons 12 action buttons + 8-way D-pad + dual analog sticks
Wireless Range Up to 10 meters
Weight 130g (lightweight yet durable)
Dimensions 161 × 111 × 69.5mm

✅ Why Gamers Choose This Controller

✔ No Wires, No Limits – Wireless freedom across 5 platforms
✔ Realistic Feedback – Dual vibration enhances immersion in supported games
✔ Plug & Play – Auto-pairs with included multi-platform USB receiver
✔ Long Battery Life – Rechargeable battery for extended play
✔ Turbo Ready – Dominate retro and modern games with auto-fire
📦 What’s Included

1 × Astrum GW520 Wireless Controller
1 × USB 5-in-1 Receiver (for PC/PS2/PS3/Android/TV)
1 × USB Charging Cable
1 × User Manual

"Game anywhere, on any screen—backed by a 24-month warranty!"

SKU: A71523-B | 24-Month Warranty | Dual Shock | 2-Player Ready
Double the Fun with Immersive Dual-Player Gaming

Level up your gaming sessions with the Astrum GP230 Twin Gamepad Set, designed for 2-player PC gaming with dual vibration feedback, precision controls, and plug-and-play simplicity. Each controller features dual analog sticks, 12 action buttons, and ergonomic grips—perfect for racing, fighting, sports, and retro games. Includes two controllers for instant multiplayer action!

🔥 Key Features

✔ Twin Controllers – Two gamepads included for competitive/co-op play
✔ Dual Shock Vibration – Force feedback motors enhance immersion in supported games
✔ Dual Analog Sticks – Precision movement and camera control for 3D games
✔ 12 Programmable Buttons – Includes 8-way D-pad + turbo functionality
✔ Plug & Play USB – No drivers required for Windows 10 and earlier
✔ Ergonomic Design – Rubberized grips prevent fatigue during long sessions
✔ Turbo Fire – Assign rapid-fire to any button for arcade-style advantage

📊 Technical Specifications
Feature Specification
Connectivity Wired USB (shared interface for both controllers)
Vibration Dual-motor force feedback (per controller)
Buttons 12 fire buttons + 8-way D-pad + 2 analog sticks (per controller)
Compatibility Windows 10/8/7/XP/Vista (No drivers needed)
Cable Length 1.5 meters (tangle-resistant)
Controller Weight 195g each (lightweight yet durable)
Dimensions 161 × 111 × 69.5mm (per controller)
Set Weight 395g (both controllers + cable)

✅ Why Gamers Love This Twin Set

✔ Instant Multiplayer – Perfect for fighting games, emulators, and couch co-op
✔ Realistic Vibration – Feel every crash, hit, and explosion in supported titles
✔ Broad Game Support – Works with Steam, emulators, and indie games
✔ No Charging/Batteries – USB-powered for uninterrupted gameplay
✔ Durable Build – Withstands intense button-mashing sessions

📦 What’s Included

2 × Astrum GP230 Vibration Gamepads (twin pack)
1 × Shared USB Cable (for both controllers)
1 × User Manual

"Grab a friend and feel the game—backed by a 24-month warranty!"

SKU: A71521-B | 24-Month Warranty | Dual Motor Vibration | Plug & Play
Immerse Yourself in Realistic Feedback & Precision Control

Experience next-level gaming immersion with the Astrum GP210 Vibration Gamepad, designed for PC gamers who demand tactile feedback and precision. Featuring dual motor vibration, dual analog sticks, and 12 programmable buttons, this controller delivers console-like realism for action, racing, and sports titles. Its plug-and-play USB setup ensures instant compatibility with Windows 98 to Windows 10.

🔥 Key Features

✔ Dual Shock Vibration – Dual motors provide immersive force feedback during explosions, crashes, and impacts
✔ Dual Analog Sticks – Precision control for 3D movement and camera adjustments
✔ 12 Programmable Buttons – Includes 8-way D-pad + 12 action buttons for complex commands
✔ Turbo/Auto-Fire – Customize rapid-fire actions for shooters and arcade games
✔ Plug & Play USB – No drivers needed; works instantly on Windows 98/XP/7/8/10
✔ Ergonomic Design – 195g weight with contoured grip for long sessions

📊 Technical Specifications
Feature Specification
Connectivity Wired USB 2.0 (supports USB 1.0/1.1/2.0)
Vibration Dual-motor force feedback
Buttons 12 fire buttons + 8-way D-pad + 2 analog sticks
Compatibility Windows 98SE/ME/XP/Vista/7/8/10
Software Support DirectX 7.0a or higher
Cable Length 1.5 meters (integrated)
Weight 195g (balanced heft)
Dimensions 165 × 65 × 100mm

✅ Why Gamers Choose This Gamepad

✔ Console-Like Vibration – Feel every crash, punch, and explosion with dual motors
✔ Broad Compatibility – Works with 20+ years of Windows games (DirectX supported)
✔ Precision Analog Sticks – Perfect for racing, FPS, and adventure games
✔ Turbo Functionality – Dominate bullet-hell and fighting games with auto-fire
✔ No Batteries Needed – USB-powered for uninterrupted play

📦 What’s Included

1 × Astrum GP210 Vibration Gamepad
1 × User Manual

"Feel the game—backed by a 24-month warranty!"

💎 Key Features (Bullet Points)

✔ AMD Ryzen 5-7530U - 6-core Zen3 (2.0-4.5GHz) with Radeon Graphics
✔ 13.3" FHD IPS Touchscreen - 250-nits BrightView display with 178° viewing angles
✔ Military-Grade Durability - MIL-STD-810H tested for extreme conditions
✔ Enterprise Security - Fingerprint reader + 5MP IR camera with privacy shutter
✔ Upgrade-Friendly - 1x open RAM slot (max 32GB) + Gen4 NVMe SSD

📊 Technical Specifications

• CPU: AMD Ryzen 5-7530U (6C/12T, 16MB cache)
• RAM: 16GB DDR4-3200 (1x16GB, 1 slot free)
• Storage: 512GB PCIe Gen4 NVMe SSD
• Display: 13.3" FHD (1920x1080) IPS Touch, 250 nits
• Ports: 1x USB-C 10Gbps, 2x USB-A 5Gbps, HDMI 2.0
• Weight: 1.45kg (3.2lbs) | Battery: 3-cell 51Whr

🎯 Perfect For

✓ Business travelers needing versatile 2-in-1 functionality
✓ Healthcare professionals using tablet mode for patient charts
✓ Educators leveraging touchscreen for presentations
✓ Financial analysts working with spreadsheets on-the-go

⚠️ Important Notes

• Not for gaming - Integrated Radeon Graphics only
• Moderate brightness (250 nits) - Best for indoor use
• No Thunderbolt - USB-C limited to 10Gbps

📦 What's Included

HP ProBook x360 435 G10
65W USB-C Charger
HP Active Pen (optional)
3-Year Warranty

🛡️ Why Choose This Model?

✓ HP Wolf Security - Hardware-enforced malware protection
✓ Self-Healing BIOS - Automatically recovers from corruption
✓ 100% sRGB color accuracy for presentations

💡 Pro Tip

Use HP QuickDrop for seamless file transfers between devices - preinstalled on all ProBooks.

Professional and Reliable

 Dual-OS design to ensure high reliability of system running

 ANR technology to enhance the storage reliability when the network is disconnected HD Input

 H.265/H.265+/H.264/H.264+/MPEG4 video formats

 Connectable to the third-party network cameras

 Up to 32 IP cameras can be connected

 Recording at up to 8 MP resolution

 Supports live view, storage, and playback of the connected camera at up to 8 MP resolution HD Output

 HDMI and VGA independent outputs provided

 HDMI Video output at up to 4K (3840 × 2160) resolution HD Storage

 Up to 2 SATA interfaces connectable for recording and backup

 Storage space effectively saved by 50% to 70% with the use of H.264+ decoding format HD Transmission

 1 self-adaptive 10 M/100 M/1000 Mbps network interfaces Various Applications

 Adopt stream over TLS encryption technology (enhanced SD K service and RTP over HTTPS protocol) which provides

 more secure stream transmission service (max. 128 Mbps TLS stream outgoing bandwidth)

 Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.

 Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be realized

 VCA detection alarm is supported

 Instant playback for assigned channel during multi-channel display mode

 Smart search for the selected area in the video; and smart playback to improve the playback efficiency

 Supports HDD quota and group modes; different capacity can be assigned to different channels

 Hik-Connect for easy network management

8 Independent 100MPS POE ports; Video Content Analytics; 1-Ch Audio input; HDMI and VGA output at up to 1920×1080P; 1x SATA interface(Up to 6TB); Mini 1U case; 12VDC
Description
NVR-108-B
8-ch Mini 1U 4 PoE 4K NVR
Connectable to the third-party network cameras
Up to 8 network cameras can be connected
H.264+ compression effectively reduces the storage space and costs by up to 50%
Full channel recording at up to 4 MP resolution
HDMI/VGA output at 1080p resolution
2-ch playback at 4 MP resolution or 4-ch at 1080p resolution
1 SATA hard disk can be connected with 6TB capacity
HDD quota management: different capacity can be assigned to different channel
Supports line crossing detection and intrusion detection
Smart search for the selected area in the video; and smart playback to improve the
playback efficiency
One-key operation: automatically search, modify and add IP cameras after device is
activated
Hik-Connect and DyDDNS for easy network management
100 Mbps Ethernet network interface

General
Power supply48 VDC
Working temperature-10 °C to +55 °C (14 °F to 131 °F)
Working humidity10 % to 90 %
Consumption (without hard disk and PoE)≤ 10 W
Chassis1U chassis
Dimensions(W × D × H)285 × 215 × 48 mm(11.2" × 8.5" × 1.9")
Weight(without hard disk)≤ 1 kg (2.2 lb)

Experience immersive entertainment on the Hisense 100Q7N 100-inch QLED TV, featuring Quantum Dot technology and a 4K UHD display. Enjoy smooth, lag-free gaming with its 144Hz refresh rate and Game Mode Pro123. The TV also boasts Dolby Vision Atmos, a built-in subwoofer, and the VIDAA U7.6 smart platform for seamless access to your favorite app.

Product Overview

The Hisense 100E7N PRO is a 100-inch QLED Smart TV that delivers stunning 4K UHD resolution with Quantum Dot technology for vibrant colors and deep contrasts. Featuring a 144Hz refresh rate and Game Mode PRO, it ensures an ultra-smooth gaming experience with minimal input lag. Enhanced with Dolby Vision and Atmos, this TV offers immersive audio-visual experiences alongside a user-friendly VIDAA smart platform for easy access to popular streaming apps.
Features
•Dolby Vision & Atmos for enhanced picture and sound quality
•Built-in Wi-Fi and screen casting
•Voice control (availability may vary)
•Digital TV tuner
•Apps & Games support


Specifications

•Product Code: 100E7NPRO
•Description: Hisense 100-Inch QLED UHD 144HZ Smart TV
•Screen Size: 100 inches
•Resolution: 3840 x 2160 (4K UHD)
•Display Tech: QLED (Quantum Dot Light-Emitting Diode)
•Refresh Rate: 120Hz to 144Hz (VRR - Variable Refresh Rate)
•Operating System: VIDAA U7.6
•Built-in Apps: Netflix, YouTube, Prime Video, Disney+, etc.
•144Hz Game Mode PRO
•Quantum Dot Colour
•Full Array Local Dimming
•Built-in Subwoofer
•Dolby Vision Atmos
•A/V Inputs: 1
•Bluetooth: Yes
•Built-in Wi-Fi: Yes
•Digital Audio Coaxial Output: Yes
•Ethernet Port: Yes
•HDMI ARC: Yes
•HDMI Inputs: 4
•USB 2.0 Ports: 1
•USB 3.x Ports: 1
Installation
Stand area (Width / Depth) 1682×455
Wall mount dimensions (Horiz x Vert) 600×400
Wall mount, screw thread M8/10
VESA compliance Yes
Detachable power cord Yes
Power cord length 200
Accessories
Remote controller (Technology / Part number ) IR /ERF2R36H
Battery (size / quantity) AAA / 2
User manual (Available online) / Quick setup guide (Print) 1 / 1
Warranty [In User manual | In separate sheet] In separate sheet
Skype camera (Qty / Part number) -
3D glasses type [Passive | Shutter] / Link [RF | IR | BT] -
3D glasses (Qty / Part number) -
Dimensions
Dimensions with stand (W x H x D) 2235×1318×500
Dimensions without stand (W x H x D) 2235×1286×90
Carton box dimensions (W x H x D) 2402×297×1514
Net weight (with stand / without stand) 73.5 Kg/71.3 Kg
Gross weight 100 Kg

🔒 Next-Gen Biometric Security for Turnstiles

✅ AI Face Recognition – 0.3s fast verification with 99% accuracy
✅ Dual-Lens Technology – Wide-angle + IR camera for day/night operation
✅ 10,000 Face Capacity – Ideal for high-traffic areas
✅ Anti-Spoofing Protection – Detects photos, masks, and videos

📊 Technical Specifications

Category Specification
Model DS-K5671-ZV
Recognition Speed ≤0.3 seconds
Face Capacity 10,000
Camera Dual-lens (RGB + IR)
Wiegand Output Supports 26/34-bit formats
Operating Temp -30°C to 60°C (-22°F to 140°F)
Warranty 2-year limited

**🏢 Ideal For:

✔ Office building turnstiles
✔ Metro/airport security gates
✔ University/school access control
✔ Smart city infrastructure

**📦 What's Included?

DS-K5671-ZV module
Mounting brackets
Quick start guide

"Seamless, touchless access control—powered by AI facial recognition!"

**⚙️ Pro Tips:

Mount at 1.5m height for optimal face capture
Enable anti-tailgating in paired turnstile controller
Use with iVMS-4200 for centralized management

**🔍 Why Choose DS-K5671-ZV?

✔ Faster than card/fingerprint systems
✔ Hygienic touchless entry
✔ Integrates with Hikvision turnstiles

*(For standalone terminals, see DS-K1T671TM model)*

⚡ Reliable Power for Small to Medium Surveillance Systems

✅ 4-Channel Output – Powers up to 4 cameras (12V DC, 1A per channel)
✅ Advanced Protection – Overcurrent | Short Circuit | Overvoltage safeguards
✅ Voltage Boost Mode – Compensates for long cable runs:

Normal (12V) | Long (13.5V) | Extra-Long (15V)
✅ Wide Input Range (150-285V AC) – Stable operation in fluctuating power conditions

📊 Technical Specifications

Category Specification
Model DS-2FA1225-C4
Total Output 48W (12V DC, 1A per channel)
Protections Per-channel fault isolation
Input 150-285V AC, 47-63Hz
Dimensions 5.67 × 3.15 × 1.30 in (144 × 80 × 33 mm)
Warranty 1-year limited

📹 Ideal For:

✔ Small business/retail CCTV systems
✔ Home surveillance setups
✔ Long-distance camera installations (100m+ with voltage boost)

📦 Package Includes:

DS-2FA1225-C4 PSU
1m AC power cord (C4 connector)
Terminal connectors
Quick start guide

"Compact yet powerful—perfect for smaller surveillance systems requiring stable, protected power!"

⚙️ Pro Tips:

Use voltage compensation for long cable runs:
Normal (12V) – Standard distances
Long (13.5V) – 50-100m cables
Extra-Long (15V) – 100m+ cables

Label each channel for easy troubleshooting
Check the green LED for power status

🔍 Why Choose This PSU?

✔ Compact size – Fits in tight spaces
✔ Dedicated per-channel protection – Prevents system-wide failures
✔ Hikvision-optimized – Ideal for IP cameras and DVRs

*(For larger setups, see 8-channel DS-2FA1205-C8 or 16-channel DS-2FA1208-C16 models)*

⚡ Professional-Grade Power for Large Surveillance Systems

✅ 16-Channel Output – Powers up to 16 cameras (12V DC, 1A per channel)
✅ Triple Protection – Overcurrent | Short Circuit | Overvoltage safeguards
✅ Voltage Boost Mode – Compensates for voltage drop in long cable runs:

Normal (12V) | Long (13.5V) | Extra-Long (15V)
✅ Wide Input Range (150-285V AC) – Handles unstable power grids

📊 Technical Specifications

Category Specification
Model DS-2FA1208-C16
Total Output 60W (12V DC, 1A/channel)
Protections Per-channel fault isolation
Input 150-285V AC, 47-63Hz
Dimensions 5.67 × 4.31 × 1.30 in (144 × 109.5 × 33 mm)
Warranty 1-year limited

📹 Ideal For:

✔ Large camera arrays (16-channel DVR/NVR systems)
✔ Long-distance cabling (100m+ with voltage boost)
✔ Mission-critical surveillance (banks, warehouses, etc.)

📦 Package Includes:

DS-2FA1208-C16 PSU
1m AC power cord (SA plug)
Terminal connectors
Quick start guide

"The ultimate power backbone for professional CCTV installations—engineered for reliability!"

⚙️ Pro Tips:

Group cameras by distance – Assign higher voltage (13.5V/15V) to longer runs
Test each channel before final installation
Pair with Hikvision cameras for optimized performance

🔍 Why This PSU Stands Out:

✔ True per-channel protection – Faults won't cascade
✔ Voltage compensation eliminates image quality loss
✔ Compact rack-mountable design saves space

*(For smaller setups, see 8-channel DS-2FA1205-C8 model)*

⚡ Reliable Multi-Camera Power Solution

✅ 8-Channel Output – Powers up to 8 cameras (12V DC, 1A per channel)
✅ Advanced Protection – Overcurrent/short circuit/overvoltage safeguards
✅ Wide Voltage Input (150-285V AC) – Stable performance in fluctuating power conditions
✅ Compact & Lightweight – Easy rack/desk mounting

📊 Technical Specifications

Category Specification
Model DS-2FA1205-C8
Input 150-285V AC, 47-63Hz
Output 12V DC, 1A per channel (10A total)
Protections Overcurrent, short circuit, overvoltage
Dimensions 5.67 × 4.31 × 1.30 in (144 × 109.5 × 33 mm)
Warranty 1-year limited

**📹 Ideal For:

✔ Hikvision/IP camera systems
✔ Small to medium surveillance setups
✔ DVR/NVR installations
✔ Long cable runs (voltage compensation up to 15V DC)

**📦 What's Included?

DS-2FA1205-C8 PSU
1m AC power cord (C8 connector)
Grid terminal connectors
Quick start guide

"The perfect power hub for multi-camera setups—ensures stable, protected operation!"

**⚙️ Pro Tips:

Use voltage compensation for long cable runs:

Normal (12V) – Standard distances
Long (13.5V) – 50-100m cables
Ex-Long (15V) – 100m+ cables
Label channels for easy camera identification
Check LED indicator (green = normal operation)

**🔍 Why Choose This PSU?

✔ Dedicated per-channel protection – One camera failure won’t disrupt others
✔ Energy-efficient – Good EMC performance
✔ Hikvision-compatible – Optimized for CCTV systems

*(For higher-wattage needs, consider DS-2FA1205-C16 model)*

Keep an eye on your home or office with the Astrum IP110 Wireless Security Camera. This indoor camera seamlessly connects to your Wi-Fi network (2.4GHz) using the built-in dual-band technology. Monitor activity and control the camera from anywhere with the user-friendly smartphone app.

See every detail, even at night. The Astrum IP110 boasts a powerful 2K Quad HD camera for crisp visuals. Zoom in to focus on what matters most. Plus, the camera’s flexible design allows for 355 horizontal and 90 vertical movement, giving you a comprehensive view of your space. And with HD infrared night vision, you’ll have long-distance clarity even in low light.

Get set up in minutes. Simply power on the Astrum IP110 and connect it to your Wi-Fi or with an Ethernet cable. Control everything from your smartphone app. Never miss a moment. Choose cloud storage or a TF card up to 128GB to keep your footage safe and accessible.

Talk and hear clearly with anyone. The built-in two-way microphone and speaker let you chat with family or deter intruders with a warning. The user-friendly app is compatible with iOS and Android devices, so you can download it from the Apple Store or Google Play.

Features:

– Wifi enabled camera for remote mobile control

– Built-in microphone and speaker for two-way communication

– 2K Quad HD video resolution with infrared for night vision

– Supports cloud storage TF card upto 128GB

– Compatible with both iOS and Android devices

– 355 rotatable camera with 90 adjustable angle controlled by mobile App

Resolution: 2560 x 1440 Quad HD

– Recording: H.265

– Camera lens: 3.6mm

– Pan: up to 355

– Tilt: up to 90

– Power Supply: 5V USB-C

– TF Support: up to 128GB

– Connectivity: Wi-Fi 2.4Ghz

– Dimensions: 84 x 84 x 118mm (L x W x H)

– Weight: 340g (Approx.)

What’s in the box
1 x Wifi Smart IP Camera
1 x Power Supply Adapter & Cable
1 x Assemble Screws
1 x User Manual

LG 77 Inch LG OLED evo C4 Series webOS24 Smart TV with AI Magic Remote - 3840 x 2160 Resolution, Refresh Rate Refresh Rate 120Hz, Digital TV Reception (Terrestrial, Cable, Satellite) DVB-T2/C/S2, 4x HDMI Ports, 3x USB, 1x LAN Port, Built in Wi-Fi 802.11.b/g/n/ac, Stereo 2-way, 2.2 Channel 40W Total, webOS 24 Smart TV, Remote Control, Retail Box , 2 year Limited Warranty

Product Overview
The LG 77 Inch OLED evo C4 Series webOS24 Smart TV offers stunning 3840 x 2160 resolution and a smooth 120Hz refresh rate, delivering exceptional picture quality for an immersive viewing experience. Equipped with AI Magic Remote, it provides seamless access to smart features and connectivity options, including four HDMI ports and built-in Wi-Fi. With Dolby Vision and Dolby Atmos support, this TV enhances both visual and audio performance, making it perfect for movies, gaming, and streaming.
Specifications
•Product code: OLED77C46LA
•Description: LG 77 Inch LG OLED evo C4 Series webOS24 Smart TV with AI Magic Remote
•Display Type: 4K OLED
•Screen Size: 77″
•Resolution: 4K Ultra HD (3,840 x 2,160)
•Refresh Rate: 120Hz Native
•Wide Colour Gamut: OLED Colour
•Processor: α9 AI Processor 4K Gen7
•HDR Compatibility: Dolby Vision | HDR10 | HLG
•Video Features: AI Super Upscaling | OLED Dynamic Tone Mapping Pro | FILMMAKER MODE™ | AI Brightness Control
•Picture Modes: 10 modes (Vivid | Standard | Eco | Cinema | Sports | Game | Filmmaker | ISF Bright Room | ISF Dark Room | Personalized Picture Wizard)
•Audio Features: LG Sound Sync | Sound Mode Share | Simultaneous Audio Output | Bluetooth Surround Ready | AI Sound Pro | AI Acoustic Tuning
•Audio Codec: AC4 | AC3 (Dolby Digital) | EAC3 | HE-AAC | AAC | MP2 | MP3 | PCM | WMA | apt-X
•Sound Output: 40 W
•Speaker Type: 2.2 Channel (Down-firing)
•Game Features: G-Sync Compatible (NVIDIA) | FreeSync Compatible (AMD) | Game Optimizer | Game Dashboard | Auto Low Latency Mode (ALLM) | HGIG Mode | VRR (Variable Refresh Rate up to 144Hz)
•Smart TV Functions: webOS 24 | Full Web Browser | USB Camera Compatible | Family Settings | Smartphone Remote App (LG ThinQ) | Intelligent Voice Recognition | Home Hub | Magic Remote | AI Concierge | Quick Card | My Profile
•Connectivity: 4 x HDMI (supports eARC, ALLM, VRR) | 3 x USB (v 2.0) | Wi-Fi (Wi-Fi 5) | Ethernet Input | SPDIF (Optical Digital Audio Out) | Simplink (HDMI CEC) | Bluetooth Support (v 5.1) | 2 x RF Input (Antenna/Cable)
•Power Supply: AC 100~240V 50-60Hz
•Dimensions (With Stand): 1,711 mm (W) x 1,035 mm (H) x 267 mm (D)
•Dimensions (Without Stand): 1,711 mm (W) x 982 mm (H) x 47.1 mm (D)
•Weight (With Stand): 27.1 kg
•Weight (Without Stand): 23.5 kg
