Ubiquiti's WAVE-PICO is a 60GHz radio system with an integrated high-gain antenna, and a WiFi 6, 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 3km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 1.3km) or WAVE-APM (900m) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For P2P links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 27.7dBi; 5.8GHz: 9dBi
Beamwidth: 60GHz: 6°; 5GHz: 50°
Data Rate: 60GHz: Up to 2Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.5A, Gigabit PoE Injector (Included)
Serial Interface: None
SFP Ports: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V Passive PoE
USB Ports: None
Dimensions: Ø152.1 x 55.8 mm
Weight: 347g

Ubiquiti's WAVE-NANO is a 60GHz radio system with an integrated high-gain antenna, GPS, and a 5GHz backup radio. It features Wave technology with true duplex gigabit performance P2P links up to 12 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 5km) or WAVE-APM (4km) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For P2P links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 41dBi; 5.8GHz: 19dBi
Beamwidth: 60GHz: 1° ; 5GHz: 17°
Data Rate: 60GHz: Up to 2Gbps; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V or 48V
USB Ports: None
Dimensions: Ø256.5 x 113.5 mm
Weight: 1.2kg

Ubiquiti's WAVE-LR is a long-range 60GHz radio system with an integrated high-gain antenna, GPS, precision mount bracket, and a 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 15 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 8km) or WAVE-APM (6km) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For PtP links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 46dBi; 5.8GHz: 22dBi
Beamwidth: 60GHz: 1.1°; 5GHz: 10°
Data Rate: 60GHz: Up to 2Gbps; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V or 48V
USB Ports: None
Dimensions: Ø424.4 x 166.2mm
Weight: 2.59kg

Ubiquiti's WAVE-AP is a UISP 60GHz Point-to-MultiPoint Access Point featuring 5GHz failover, 1x 10Gbps SFP+ Port, 1x 2.5Gbps Ethernet Port and an integrated GPS antenna. Utilizing 60GHz point-to-multipoint technology, it can connect up to 15 stations with a total throughput of 5.4Gbps at distances of up to 1.3km when paired with the WAVE-PICO, 5km when paired with the WAVE-NANO, and 8km when paired with the WAVE-LR.

The dedicated Bluetooth radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 60GHz: 24dBi; 5.8GHz: 12dBi
Beamwidth: 60GHz/5GHz: 30°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A 2.5GbE PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Other: 1x SFP+
Dimensions: 212 x 205 x 187mm
Weight: 2.3kg

Ubiquiti's WAVE-APM is a UISP 60GHz Point-to-MultiPoint Access Point featuring 5GHz failover, 1x 2.5Gbps Ethernet Port and an integrated GPS antenna. Utilising 60GHz point-to-multipoint technology, it can connect up to 15 stations with a total throughput of 5Gbps at distances of up to 900m when paired with the WAVE-PICO, 4km when paired with the WAVE-NANO, and 6km when paired with the WAVE-LR. Mount up to 4x WAVE-APM using the WAVE-MM mounting for full 360° coverage.

The dedicated Bluetooth radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 60GHz: 20dBi ; 5.8GHz: 13.5dBi
Beamwidth: 60GHz/5GHz: 90°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Pole-Mount, or WAVE-MM for 360° coverage
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A 2.5GbE PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Dimensions: 284 x 156 x 76 mm
Weight: 1.3kg

Ubiquiti's UCG-ULTRA is a powerful and compact multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features. The unit runs UniFi Network for full-stack network management and features 4x Gigabit Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display and multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 3x 10/100/1000 (LAN); 1x 10/100/1000 (LAN / WAN);1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 6.2W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 3A USB Power Adapter (Included);
Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's UCG-ULTRA is a powerful and compact multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features. The unit runs UniFi Network for full-stack network management and features 4x Gigabit Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display and Multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.
SKU UCG-ULTRA
Manufacturer Ubiquiti
Manufacturer Product Code UCG-Ultra

Specifications

Ethernet Ports: 3x 10/100/1000 (LAN); 1x 10/100/1000 (LAN / WAN);1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 6.2W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 3A USB Power Adapter (Included);
Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's UPOE-48G30W is a 48V, 0.65A, Gigabit, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UPOE-48G15W is a 48V, 0.32A, Gigabit, PoE injector. The unit is compatible with products that require 802.3af PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 0.32A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 86 x 46 x 33mm
Weight: 100g

Ubiquiti's UCG-MAX is a powerful and compact 2.5Gbps multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features with 1.5Gbps IPS routing and a 512GB SSD for NVR storage. The unit can run all UniFi applications for full-stack network management and features 4x 2.5Gbps Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display, and Multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 16.1W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 5A USB Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A53 at 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's UPOE48-30W-2G is a 48V, 0.65A, 2.5Gbps, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power cable not included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000/2500
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UK-ULTRA is an indoor and outdoor, IPX6 WiFi 5 dual band access point with versatile mounting options and external antenna support via two RP SMA connectors. It is capable of reaching up to 1167Mbps aggregate over both 2.4GHz and 5GHz 2x2 MIMO radios.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Antenna Gain: 2.4GHz: 6dBi ; 5.8GHz: 6dBi (2x RP-SMA for optional external antennas)

Specifications

Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Wall, Ceiling or Pole Mount
Operating System: UniFi
Operating Temperature: -40°C to 60°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 802.3af/at PoE (44-57V)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44-57V
USB Ports: None
Dimensions: 137 x 84 x 34 mm
Weight: 173g

Ubiquiti's UXG-MAX is a compact, Multi-WAN, independent gateway featuring a 1.5GHz quad-core processor, 1x 2.5Gbps WAN and 4x 2.5Gbps LAN ports, with one of the LAN ports remappable to WAN. It also features intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter. It can be configured and managed with a Cloud key, Official UniFi Hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000/2500 (WAN): 3x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (LAN/WAN)
Hardware Button: Reset
Max. Power Consumption: 9.6W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V 3A USB-C Power Supply (Included)
Processor: Quad-core 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A
System Memory: 2 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 520g

Ubiquiti's UXG-LITE features a compact design, a 1GHz dual-core processor, 1x Gigabit Ethernet WAN and 1x Gigabit Ethernet LAN port. It also features next-generation security with intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter.

It can be configured and managed with a Cloud key, Official UniFi hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000 (WAN): 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 3.83W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V USB-C Power Supply (Included)
Processor: Dual core 1GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V
System Memory: 1 GB DDR3L
USB Ports: None
Dimensions: 98 x 98 x 30 mm
Weight: 320g

Ubiquiti's UVC-VIEWPORT is a PoE-powered device that makes provision for viewing up to 16 UniFi Protect cameras on an HDMI display. It uses Power over Ethernet (PoE) and connects to the local network to host your cameras. It enables UniFi Protect systems to be viewed in custom high-density camera matrix configurations.

*Note: PoE Injector not Included. The UniFi Protect Application is required to run this product with full functionality.

Specifications

Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.5W
Operating Temperature: 0°C to 40°C
PoE Input: 802.3af
PoE Output: None
Supported Voltage Range: 802.3af PoE
Dimensions: 156.9 x 52 x 37.35mm
Weight: 252g

Ubiquiti's UVC-G5PRO features an 8MP image with a built-in microphone, 3x optical zoom and AI event detection. It is also IP65 rated with a versatile 3-axis mount for both indoor and outdoor installations. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 25 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 10W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 50°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 3840 x 2160 (16:9)
Sensor: 1/2" 8MP
Video Compression: H.264; MJPEG
Dimensions: Ø86 x 153.8 mm
Weight: 670g

Ubiquiti's UVC-G5F features a 4MP image with a wide-angle (102.4°) lens in a weatherproof IPX4-rated enclosure. It features various mounting options for both indoor and outdoor installation and has infrared LEDs with an automatic IR cut filter.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed focal length
Max Frame Rate: 30 FPS
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Desktop, wall, pole or hard-ceiling
Night Mode: IR LEDs with Mechanical IR Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 802.3af PoE (Not Included)
Resolution: 2688 x 1512
Sensor: 5MP CMOS sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø48 x 107.5 mm
Weight: 170g

Ubiquiti's UVC-G5DU features an ultra-compact and tamper-resistant enclosure, a 4MP image with an ultra-wide-angle lens, 20m IR night vision as well as AI Detections.

It can be configured and managed using the UniFi Protect Application.

*Note: The G5 Dome Ultra is for indoor use only. PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: No
Max. Power Consumption: 4.2W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: Ø63.6 x 68.2 mm
Weight: 175g

Ubiquiti's UVC-G5D features a 4MP image with a wide-angle lens, enhanced dynamic range and low-light performance. It is IK08 vandal-resistant with a built-in microphone and speaker. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependant)
Microphone: Yes
Max. Power Consumption: 5W
Mounting: Wall or Ceiling Mount
Night Mode: IR LEDs with Mechanical IR Cut Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at PoE
Power Input: 802.3af/at PoE
Resolution: 2688 x 1512
Sensor: 5MP CMOS Sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø109.2 x 64.5 mm
Weight: 390g

Ubiquiti's UVC-G5B features a 4MP image with a built-in microphone and a versatile 3-axis mount that enables quick and easy adjustment for both indoor and outdoor mounting. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 10 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: : Ø75.5 x 150 mm
Weight: 315g
