Scoop’s SPS-8G2S is an unmanaged 8 port Gigabit Ethernet AI PoE switch, with 2 x 1.25Gbps SFP Uplink Ports. Each of these PoE ports are IEEE 802.3af/at compliant which enables them to identify whether the connected device is compatible and requires power. The total PoE budget is 96W, or up to a maximum of 36W per port.

The SPS-8G2S supports 4 working modes:

AI Extend: PoE transmission distance of ports 1-8 can be increased to up to 250 metres at 10Mbps using Cat6 solid copper cable.
AI VLAN: Enables Port Isolation on Ports 1-8.
AI QoS: Prioritizes network bandwidth based on network usage history and analytics.
AI PoE: Automatically restarts a PoE powered device if no data passes through the port for a set time.

SKU SPS-8G2S
Manufacturer Scoop

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: AI VLAN; AI Extender; AI PoE; AI QOS
Max. Power Consumption: 6W
Mounting: Desktop
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 52V 1.85A Power Adapter (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps Ports
Supported Voltage Range: 52V
Dimensions: 185mm x 95mm x 28mm
Weight: 0.95kg

Ubiquiti's UCG-FIBER is a desktop 10Gbps dual WAN, UniFi cloud gateway with selectable NVR storage via SSD up to 2TB. The unit runs the complete UniFi application suite for full stack network management and features 1x 10Gbps WAN port, 4x 2.5Gbps LAN Ports, one with 802.3at (PoE+) PoE output, as well as 2 x SFP+ ports.

It can be configured and managed with the UniFi Network Application.

Note: NVMe SSD not included. Third-party SSD installation requires tray accessory.

Specifications
Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/10000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 29.4W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3at (PoE+) on Port 4
Power Input: 54V 1.1A Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
Serial Interface: None
SFP Ports: 2 x SFP+ (1x WAN ; 1 x LAN)
Supported Voltage Range: 50-57V
System Memory: 3GB
USB Ports: None
Dimensions: 212.8 x 127.6 x 30 mm
Weight: 675g

Ubiquiti's UXG-FIBER is a desktop 10Gbps dual WAN, independent gateway which features 1x 10Gbps SFP+ port, 4x 2.5Gbps LAN Ports, one with PoE+ (802.3at) output as well as 1x SFP+ and 1x 10Gbps Ethernet WAN ports.

It can be configured and managed with a Cloud key, Official UniFi Hosting, or UniFi Network Server.

Specifications

Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/10000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3at (PoE+) on Port 4
Power Input: 54V 1.1A Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
Serial Interface: None
SFP Ports: 2 x SFP+ (1x WAN ; 1 x LAN)
Supported Voltage Range: 50-57V
System Memory: 2GB
USB Ports: None
Dimensions: 212.8 x 127.6 x 30 mm
Weight: 605g

Ubiquiti's UPOE54-60W-10G is a 54V, 1.15A, 10Gbps, PoE injector. The unit is compatible with products that require 802.3bt PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power cable not included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000/2500/10000
PoE Output: 54V 1.15A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UPOE48-30W-2G is a 48V, 0.65A, 2.5Gbps, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power cable not included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000/2500
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UCG-MAX is a powerful and compact 2.5Gbps multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features with 1.5Gbps IPS routing and a 512GB SSD for NVR storage. The unit can run all UniFi applications for full-stack network management and features 4x 2.5Gbps Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display, and Multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 16.1W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 5A USB Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A53 at 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's UACC-PSU-210W is a wall mountable AC power adapter which delivers 210W at 54V DC, ideal for powering PoE Switches.

Specifications
Compatibility: USW-ULTRA, USW-U60, USW-PRO-MAX16P, USW-U210
Connector: IEC
DC plug: 5.5 x 2.1 x 11.5 mm
DC cable: UL11353 16AWG 1.5 m
Voltage: 54V
Wattage: 210W
Dimensions: 190 x 86 x 26 mm
Weight: 2kg

The POE-802O adapter transforms almost any Ubiquiti PoE device into a fully compliant 48V, PoE-compatible product.

The Instant PoE Adapter works seamlessly with a variety of PoE switches for remote power control applications. You can conveniently power or power cycle your remote devices using your PoE switch.
Specifications
Interface In: (1) Gigabit RJ45 Port
Interface Out: (1) Gigabit Ethernet Cable
Power Input : 48V; 802.3af
Max Power Output: 24V; 0.5A
Ethernet ESD/Surge Protection: ±15kV
Dimensions: Ø 30.2 x 166 mm
Dimensions with RJ45 Cable: Ø 30.2 x 366.6 mm
Weight: 90g
Operating Temperature: -30 to 70° C

All-in-one router and security gateway with an integrated PoE switch and network video recorder.

The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).


Features:
1.7 GHz quad-core processor
Dual WAN ports (10G SFP+ and 2.5GbE RJ45)
(8) GbE RJ45 ports, including (6) PoE and (2) PoE+ LAN ports
(1) 10G SFP+ LAN port
(1) 1.3" LCM color touchscreen for at-a-glance network monitoring
Customizable internet threat filtration and traffic identification for enhanced network security
Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app
1U-sized, rack-mountable device
Connect a SmartPower Redundant Power System to create an uninterruptible network
Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5" HDDs
128 GB integrated storage for full UniFi OS Application experience
Dimensions
442.4 x 43.7 x 285.6 mm
(17.4 x 1.7 x 11.2")
Weight 5 kg (10.9 lb)

Ubiquiti's UPOE24-12W is a 24V, 0.5A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.5A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range:100V-240V
Dimensions: 89 x 46 x 33mm
Weight: 75g

Ubiquiti's UPOE24-24W is a 24V, 1A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 1A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 88 x 57 x 33mm
Weight: 158.5g

Ubiquiti's UPOE24-7W is a 24V, 0.3A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.3A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 72 x 45 x 33mm
Weight: 72.1g

Ubiquiti's UPOE-48G15W is a 48V, 0.32A, Gigabit, PoE injector. The unit is compatible with products that require 802.3af PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 0.32A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 86 x 46 x 33mm
Weight: 100g

Ubiquiti's UPOE-48G30W is a 48V, 0.65A, Gigabit, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UPOE48-60W is a 48V, 1.25A, Gigabit, PoE injector, compatible with Ubiquiti's AF-11. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 1.25A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 106 x 63 x 34mm
Weight: 210g

Ubiquiti's UB-ETHSP is a Gigabit Ethernet surge protector designed to protect outdoor, PoE or non-PoE Ethernet devices from electrostatic discharge and surges.

Specifications

Data Line Protection: RJ45 10/100/1000
DC Spark-Over Voltage: 90V 100V/s
Discharge Current: 10kA+
Ethernet Ports: 2x 10/100/1000
Maximum Impulse Spark-Over Voltage: 700V 1kV/µs
Operating Temperature: -30°C to 65°C
PoE Support: 802.3af & Passive PoE
Dimensions: 91 x 61 x 32.5mm

Ubiquiti's UACC-LRE is an outdoor Gigabit Ethernet adapter which establishes long-range connections between PoE switches and devices. The unit features 2x Gigabit Ethernet ports. Port one receives 802.3af/at PoE input while port two provides PoE passthrough for distances up to 1km when making use of multiple adapters. The unit also offers 10kA+ surge protection and works reliably in extreme temperatures to protect your deployment from weather and electrical damage.

*Note: This device does not support MTU's larger than 1500. If making use of jumbo frames across the device, it will not work.

Specifications
Ethernet Ports: 2x 10/100/1000
Hardware Button: None
Max. Power Consumption: 1.5W
Mounting: Pole-Mount
Operating System: None
Operating Temperature: -40°C to 80°C
PoE Input: 802.3af/at
PoE Output: 802.3af PoE Passthrough
Power Input: 802.3af/at
SFP Ports: None
Supported Voltage Range: 37-57V
Dimensions: 196.5 x 93.5 x 39 mm
Weight: 350g

Ubiquiti's UCG-ULTRA is a powerful and compact multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features. The unit runs UniFi Network for full-stack network management and features 4x Gigabit Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display and multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 3x 10/100/1000 (LAN); 1x 10/100/1000 (LAN / WAN);1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 6.2W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 3A USB Power Adapter (Included);
Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's NS4 is an unmanaged, outdoor, 4 port Gigabit switch with PoE passthrough. If powered by 24V Passive PoE can provide up to 24W of power on three PoE out ports. The NanoSwitch is designed for outdoor deployment and supports up to 4 Gbps total, non-blocking line rate.

*Note: PoE Injector not Included.

Specifications

Ethernet Ports: 4x 10/100/1000
Max. Power Consumption: 30W
Mounting: Wall or Pole Mount
Operating Temperature: -30C ~ 70C
PoE Input: Passive 24V PoE
PoE Output: 24V Passive PoE Pass-through
Power Input: 24V Passive PoE (Not Included)
Supported Voltage Range: 21.6 - 30V
Dimensions: 196.4 x 93.5 x 32.4mm
Weight: 271g

Ubiquiti's WAVE-APM is a UISP 60GHz Point-to-MultiPoint Access Point featuring 5GHz failover, 1x 2.5Gbps Ethernet Port and an integrated GPS antenna. Utilising 60GHz point-to-multipoint technology, it can connect up to 15 stations with a total throughput of 5Gbps at distances of up to 900m when paired with the WAVE-PICO, 4km when paired with the WAVE-NANO, and 6km when paired with the WAVE-LR. Mount up to 4x WAVE-APM using the WAVE-MM mounting for full 360° coverage.

The dedicated Bluetooth radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 60GHz: 20dBi ; 5.8GHz: 13.5dBi
Beamwidth: 60GHz/5GHz: 90°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Pole-Mount, or WAVE-MM for 360° coverage
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A 2.5GbE PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Dimensions: 284 x 156 x 76 mm
Weight: 1.3kg
