Ubiquiti's USW-5FLEX is a managed, Layer 2, UniFi switch with 5x Gigabit Ethernet Ports. It includes 4x 802.3af PoE+ Ports and 1x 802.3af/at/bt PoE input. It is designed for indoor or outdoor use with its weatherproof housing and versatile mounting options. The USW-Flex provides both flexibility and durability for environments with extreme temperature variations.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
We recommend using the UPOE-48G60W or a Ubiquiti UniFi Switch to power these devices. When making use of the UPOE-48G60W, be sure to set the power source on the UniFi Network Application to injector.

Specifications

Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 5W
Mounting: Desktop, Wall and Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 55°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af on Ports 2~5
Power Input: 802.3af/at/bt on Port 1
Serial Interface: 1x RJ45 Ethernet In-Band
SFP Ports: None
Supported Voltage Range: 44–57V (802.3af) 50-57V (802.3bt)
Dimensions: 122.5 x 107.1 x 28.0mm
Weight: 230g

Ubiquiti's UPL-AMP-B is a premium WiFi 5 speaker amplifier with 2x Gigabit Ethernet Ports designed for high-fidelity multi-zone audio streaming and immersive spatial sound experiences. It features low-latency wireless audio streaming with Apple AirPlay 2 and Spotify, 130W per channel at 8 ohms, 2x speaker terminal outputs with 2x custom-designed banana plugs included. Also included is 1x RCA analog subwoofer output, 2x RCA analog inputs for left and right channels, 1x HDMI eARC input with immersive spatial sound powered by Dolby Atmos as well as a 1.43" rotary knob with touchscreen.

This unit can be configured and managed via the UniFi Play mobile app.

Specifications

Amplifier class: Class D
Audio input: 1x HDMI eARC input, 2x RCA analog inputs L/R
Audio output: 1x RCA analog subwoofer output, 2x Speaker terminal outputs with 2x banana plugs
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Grouping: Up to 32 PowerAmps
Max. Power Consumption: 17W
Mounting: Desktop
Operating System: UniFi Play
Operating Temperature: -5 to 40° C
Output: Mono / Stereo sound
Per channel power (Continuous power): 130 W, 8 Ω, 1 kHz, < 0.05% THD+N, EIA (CEA-490-A) 260 W, 4 Ω, 1 kHz, < 0.09% THD+N, EIA (CEA-490-A)
Streaming: AirPlay2, Spotify Connect, Soundtrack Your Brand
Dimensions: 217 x 236.8 x 63.7 mm
Weight: 2.4kg

Ubiquiti's USW-MAX16 is a 16 port, fully managed, Layer 3, Etherlighting™ switch. The unit features 12x Gigabit Ports, 4x 2.5Gbps ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fibre uplinks to your network.

Note: It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 325.1 x 160 x 43.7 mm
Weight: 1.95kg

Ubiquiti's USW-MAX16P is a 16 port, fully managed, Layer 3 Etherlighting™ switch. The switch includes a rack-mount kit for 10-inch racks and wall mounting. The UACC-MAX16P-RM accessory makes provision for 19 inch rack-mount deployments. The unit features a 180W PoE budget with 12x Gigabit PoE+ (802.3af/at) Ports, 4x 2.5Gbps PoE++ (802.3af/at/bt) ports and 2x SFP+ Uplink Ports. It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps: 4x 802.3af/at/bt ; Gigabit: 12x 802.3af/at
Power Input: 1x 54V, 3.9A, 210W DC adapter (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 54V
Dimensions: 325.1 x 160 x 43.7 mm
Weight: 2.1kg

Ubiquiti's UVC-G5F features a 4MP image with a wide-angle (102.4°) lens in a weatherproof IPX4-rated enclosure. It features various mounting options for both indoor and outdoor installation and has infrared LEDs with an automatic IR cut filter.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed focal length
Max Frame Rate: 30 FPS
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Desktop, wall, pole or hard-ceiling
Night Mode: IR LEDs with Mechanical IR Filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 802.3af PoE (Not Included)
Resolution: 2688 x 1512
Sensor: 5MP CMOS sensor
Video Compression: H.264 ; MJPEG
Dimensions: Ø48 x 107.5 mm
Weight: 170g

Ubiquiti's UXG-LITE features a compact design, a 1GHz dual-core processor, 1x Gigabit Ethernet WAN and 1x Gigabit Ethernet LAN port. It also features next-generation security with intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter.

It can be configured and managed with a Cloud key, Official UniFi hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000 (WAN): 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 3.83W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V USB-C Power Supply (Included)
Processor: Dual core 1GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V
System Memory: 1 GB DDR3L
USB Ports: None
Dimensions: 98 x 98 x 30 mm
Weight: 320g

Ubiquiti's UXG-MAX is a compact, Multi-WAN, independent gateway featuring a 1.5GHz quad-core processor, 1x 2.5Gbps WAN and 4x 2.5Gbps LAN ports, with one of the LAN ports remappable to WAN. It also features intrusion detection and prevention systems (IDS/IPS), advanced networking features, and is powered by the included USB-C adapter. It can be configured and managed with a Cloud key, Official UniFi Hosting, or UniFi Network Server with UniFi Network 8.0.7 and later.

Specifications

Ethernet Ports: 1x 10/100/1000/2500 (WAN): 3x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (LAN/WAN)
Hardware Button: Reset
Max. Power Consumption: 9.6W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V 3A USB-C Power Supply (Included)
Processor: Quad-core 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A
System Memory: 2 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 520g

Ubiquiti's USW-LITE16P is a fully managed layer 2 switch with 16x Gigabit Ethernet ports, 8x 802.3af/at PoE+ ports and a PoE budget of 45W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fanless, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100 to 240VAC
Dimensions: 99.6 x 163.7 x 31.7mm
Weight: 450g

Ubiquiti's USW-LITE8P is a fully managed, Layer 2, UniFi switch with 8x Gigabit Ethernet ports, 4x auto-sensing 802.3at PoE+ ports and a PoE budget of 52W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fan less, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktop or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 4
Power Input: 54V 1A Power Supply (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 50-57V
Dimensions: 99.6 x 163.7 x 31.7 mm
Weight: 450g

Ubiquiti's USW-PRO8P is a fully managed 8-Port Gigabit Layer 3 UniFi switch. It has 6x 802.3at PoE+ Ports, 2x 802.3bt PoE++ Ports, 2x 10Gbps SFP+ and a PoE budget of 120W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -5°C to 45°C
PoE Input: None
PoE Output: 6x 802.3af/at ; 2x 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V
Dimensions: 200 x 248 x 44mm
Weight: 2.1kg

Ubiquiti's USW-U210 is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget of 202W when powered with the included Power Supply.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (With Included Power Supply)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: -20°C to 60°C (When Powered With Included Power Supply)
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: PoE: 802.3af/at/bt on Port 1 ; DC: 54V, 3.9A
Serial Interface: None
SFP Ports: None
Supported Voltage Range: PoE: 44–57V ; DC: 54V
Dimensions: 203 x 76 x 33 mm
Weight: 1.35kg

Ubiquiti's USW-U60 is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget of 52W when powered with the included Power Supply.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (with included power supply)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: -20°C to 45°C (when powered with included power supply)
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: 802.3af/at/bt on Port 1
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 44–57V
Dimensions: 203 x 76 x 33 mm
Weight: 320kg

Ubiquiti's USW-ULTRA is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget dependent on the power source.

It can be configured and managed with the UniFi Network Application.

*Note: Power Supply not included.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (Using a Power Supply) 9W (Using a PoE Adapter)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: PoE++ input: -30 to 60°C ; 60W AC input: -20 to 45°C ; 210W AC input: -20 to 60°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: 802.3af/at/bt on Port 1 ; 44-57V DC terminal ; 57V Power Supply (Not Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 44–57V
Dimensions: 203 x 76 x 33 mm
Weight: 320g

Ubiquiti’s U6-MESH is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point with a compact IPX5 indoor/outdoor enclosure. It delivers an aggregate data rate of up to 5.3 Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

Specifications
Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11.4W
Mounting: Desktop ; Wall-Mount ; Pole Mount ; Ceiling Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af PoE
PoE Output: None
Power Input: 48V; 0.32A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44V-57V
USB Ports: None
Dimensions: Ø 48.50 x 159.49mm
Weight: 400g

Ubiquiti’s U6-MESH-PRO is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point featuring 2x Gigabit Ethernet ports, 4 spacial streams and integrated high power 8dBi antennas. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

Note: It can be configured and managed with the UniFi Network Application.

Specifications
Antenna Gain: 2.4GHz: 8dBi ; 5.8GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop ; Wall-Mount ; Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af/at PoE
PoE Output: None
Power Input: 48V; 0.5A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5V-57V
USB Ports: None
Dimensions: 343.2 x 181.2 x 60.2 mm
Weight: 819g

Western Digital Purple - 2.0TB 3.5" SATA3 6.0Gbps Surveillance HDD, Intellipower™ Speed Management, 256MB Cache, 150MB/s Host to/from (Sustained), AllFrame, HD Video Optimised, , 2 year warranty

Product Overview
WD Purple drives are designed to meet the challenges of 24x7 video surveillance recording. These drives are engineered specifically for surveillance to help withstand the elevated heat fluctuations and equipment vibrations within NVR environments. An average desktop drive is built to run for only short intervals, not the harsh 24/7 always-on environment of a high-definition surveillance system. With WD Purple drives, you get reliable, surveillance-class storage that’s tested for compatibility in a wide range of security systems. Exclusive AllFrame™ technology helps reduce frame loss and improve overall video playback.
Features
Western Digital's Exclusive AllFrame™ Technology
•All WD Purple drives are equipped with AllFrame™ technology, which helps reduce video frame drops and improves video recording and playback.
Enhanced Workload Ratings
•WD Purple drives feature a workload rating of up to 180TB/year2 - up to three times that of desktop drives - to handle the unique demands of mainstream video surveillance DVR and NVR systems.
Multiple Cameras, Multiple Streams
•Modern recorders now support multiple video streams per camera. WD Purple drives support up to 64 single-stream HD cameras5. With so many options, you have the flexibility to upgrade or expand your security applications in the future.
Wide Compatibility. Seamless Integration
•WD Purple hard drives are built with compatibility in mind, so you can quickly and seamlessly add capacity to your surveillance system. With a wide range of industry-leading enclosures and chipsets supported, you’re sure to find the DVR or NVR configuration that’s right for you.

Specifications
•Product code: WD23PURZ
•Description: Western Digital Purple
•Capacity: 3TB
•Form Factor: 3.5-Inch
•Connector: SATA
•Compatibility
•: Up to 64 HD cameras
•: Up to 16 drive bays
•: All Frame firmware technology
•Interface: SATA
•Transfer Rate: up to 175MB/s
•Recording Technology: CMR
•Cache Size: 256MB
•Dimensions (L x W x H): 5.79" x 4" x 1.03"
•Weight: 570gms
•Operating Temperature: 0°C to 65°C
•Non-Operating Temperature: -40°C to 70°C


What’s in the box
•Surveillance HDD x 1

Western Digital Purple - 6.0TB 3.5" SATA3 6.0Gbps Surveillance HDD, Intellipower™ Speed Management, 256MB Cache, 150MB/s Host to/from (Sustained), AllFrame, HD Video Optimised, , 2 year warranty

Product Overview
WD Purple drives are designed to meet the challenges of 24x7 video surveillance recording. These drives are engineered specifically for surveillance to help withstand the elevated heat fluctuations and equipment vibrations within NVR environments. An average desktop drive is built to run for only short intervals, not the harsh 24/7 always-on environment of a high-definition surveillance system. With WD Purple drives, you get reliable, surveillance-class storage that’s tested for compatibility in a wide range of security systems. Exclusive AllFrame™ technology helps reduce frame loss and improve overall video playback.
Features
Western Digital's Exclusive AllFrame™ Technology
•All WD Purple drives are equipped with AllFrame™ technology, which helps reduce video frame drops and improves video recording and playback.
Enhanced Workload Ratings
•WD Purple drives feature a workload rating of up to 180TB/year2 - up to three times that of desktop drives - to handle the unique demands of mainstream video surveillance DVR and NVR systems.
Multiple Cameras, Multiple Streams
•Modern recorders now support multiple video streams per camera. WD Purple drives support up to 64 single-stream HD cameras5. With so many options, you have the flexibility to upgrade or expand your security applications in the future.
Designed for Surveillance Solutions
•With an MTBF of up to 1 million hours3, WD Purple drives are engineered for mainstream surveillance DVRs and NVRs that operate 24/7. With tarnish-resistant components and support in storage systems with more than eight drive bays4, WD Purple drives deliver reliable operation even in harsh environments.

Specifications
•Product code: WD64PURZ
•Description: Western Digital Purple - 6.0TB 3.5" SATA3 6.0Gbps Surveillance HDD
•Capacity: 6TB
•Form Factor: 3.5-Inch
•Connector: SATA
•Up to 64 HD cameras
•Up to 16 drive bays
•All Frame firmware technology
•Interface: SATA
•Transfer Rate: up to 175MB/s
•Recording Technology: CMR
•Cache Size: 256MB
•Dimensions (L x W x H): 5.79" x 4" x 1.03"
•Weight: 570gms
•Operating Temperature: 0°C to 65°C
•Non-Operating Temperature: -40°C to 70°C
