UltraLAN Installer Series - CAT5e CCA Solid UTP WHITE (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.

General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: White

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Packaging dimensions: 22x35x35cm

Gross weight: 7.6kg

UltraLAN Installer Series - CAT5e Solid UTP (500m)


500m roll of UltraLAN CAT5e Installer Series solid-core Ethernet bulk cable suitable for everyday networking installations.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.




General Specifications

Packaging: 500m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Gross weight: 13.5kg

"Shipping Policy for Heavy/Bulky Items:

This item requires special shipping arrangements due to its size/weight. After your order is placed, our team will:

1.Calculate the most economical shipping option

2.Contact you with the exact additional charges

3.Process your order after receiving your confirmation

Note: Standard checkout shipping rates don't apply. Delivery timeline begins after shipping payment confirmation."

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (500m)

Short Description:

500 m timber drum with UV-stable PE jacket
FTP shielding + drain wire for ESD protection
CCA or BC variants; 100 MHz verified, 1 GbE ready
Direct-burial rated, gel-free, Ø 6.0 mm, 60 kg/km
Sequential metre marks every 1 m for fast, waste-free cuts

Key Specifications:

Length & Packaging: 500 m timber drum
Jacket Material: UV-stable polyethylene (PE); sunlight resistant
Operating Temperature: –40 °C to +75 °C
Cable Type: FTP (Foiled Twisted Pair) with drain wire
Conductor Options: 24 AWG CCA (Copper-Clad Aluminium) or BC (Bare Copper)
Performance: 100 MHz verified; Gigabit Ethernet (1 GbE) ready
Compliance: ETL verified to TIA-568.2-D Cat-5e
Installation: Outdoor/direct burial rated; gel-free construction
Diameter & Weight: Ø 6.0 mm; approx. 60 kg/km
Cutting Aid: Sequential metre marks every 1 m

"Shipping Policy for Heavy/Bulky Items:

This item requires special shipping arrangements due to its size/weight. After your order is placed, our team will:
1.Calculate the most economical shipping option
2.Contact you with the exact additional charges
3.Process your order after receiving your confirmation
Note: Standard checkout shipping rates don't apply. Delivery timeline begins after shipping payment confirmation."

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (305m)

305m Drum of UltraLAN Installer Series UV-resistant CAT5e Ethernet cable with drain wire suitable for outdoor networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

A drain wire provides the ability to ground outdoor networking equipment, reducing risk of damage to the hardware as a result of ESD or storm activity. Shielded RJ45 connectors should be used and all power supplies and/or injectors properly grounded to get the benefits of this high quality cable.

UltraLAN's Installer Series Outdoor cable dramatically increases Ethernet link states, speeds and overall performance. It has been designed and manufactured to perform in the harshest weather environments, and is suitable for any outdoor applications that requires robust and reliable cabling.

FTP (Foil Twisted Pair) cable provides excellent external interface mitigation.
Drain wire provides additional protection from ESD.
Meets and exceeds CAT5e rating (suitable for Gigabit applications).

"Shipping Policy for Heavy/Bulky Items:

This item requires special shipping arrangements due to its size/weight. After your order is placed, our team will:

1.Calculate the most economical shipping option

2.Contact you with the exact additional charges

3.Process your order after receiving your confirmation

Note: Standard checkout shipping rates don't apply. Delivery timeline begins after shipping payment confirmation."

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (100m)

100m Box of UltraLAN Installer Series UV-resistant CAT5e Ethernet cable with drain wire suitable for outdoor networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

A drain wire provides the ability to ground outdoor networking equipment, reducing risk of damage to the hardware as a result of ESD or storm activity. Shielded RJ45 connectors should be used and all power supplies and/or injectors properly grounded to get the benefits of this high-quality cable.

UltraLAN's Installer Series Outdoor cable dramatically increases Ethernet link states, speeds and overall performance. It has been designed and manufactured to perform in the harshest weather environments and is suitable for any outdoor applications that requires robust and reliable cabling.
Multi-layered UV protected cable sheath allows for superior protection from the elements.
FTP (Foil Twisted Pair) cable provides excellent external interface mitigation.
Drain wire provides additional protection from ESD.
Meets and exceeds CAT5e rating (suitable for Gigabit applications).

UltraLAN Installer Series - CAT5e CCA Solid UTP (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices! This cable features a blue colored outer jacket for easier cable identification.

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m Easy Pull Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Blue

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

UltraLAN Installer Series - CAT5e CCA Solid UTP (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Packaging dimensions: 22x35x35cm

Gross weight: 7.6kg

UltraLAN Installer Series - CAT5e CCA Solid UTP (100m)


100m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 100m Easy Pull Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m Box

Conductor material: Solid Bare Copper

Conductor diameter: 0.51mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

"Shipping Policy for Heavy/Bulky Items:

This item requires special shipping arrangements due to its size/weight. After your order is placed, our team will:

1.Calculate the most economical shipping option

2.Contact you with the exact additional charges

3.Process your order after receiving your confirmation

Note: Standard checkout shipping rates don't apply. Delivery timeline begins after shipping payment confirmation."

UltraLAN High Precision Fiber Optic Cleaver

The ultimate tool for single and ribbon cleaving. Built on a robust high-quality platform, the UltraLAN fiber cleaver is ideal for use with fusion splicing or other precision applications, setting a new standard for flexibility and performance. By using a rotating blade for multiple scoring positions enables a typical blade life of 36000 cleaves or more, with a cleave angle better than 0.5 degrees.

The UltraLAN fiber cleaver is available with a single fiber adapter for 250 to 900 micron coated single fibers. It is a simple operation for the user to remove or install the single fiber adapter and alternate between mass and single fiber cleaving.

Product Features:
Used for Mass or Single Fiber Cleaving
Utilizes an Automatic Anvil Drop for easy of use and provides better cleave consistency
Prevents Double Scoring of the Fibers.
Has Superior Blade Height and Rotational Adjustment.
Can Be Operated With Minimal Steps

UltraLAN Gigabit RJ45 SFP Module - 10/100/1000 Ethernet Module

The UltraLAN Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective modules compliant with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supports up to Gigabit data rates up to 100 meters in distance over unshielded twisted-pair CAT5 cabling.


The module supports 1000Mbps (or 10/100/1000Mbps) full duplex data-links with 5-level Pulse Amplitude Modulation (PAM) signals. All four pairs in the cable are used with symbol rate at 250Mbps on each pair.

This SFP module is compatible with all vendor devices that has an SFP slot.

Product Features:

Gigabit bi-directional data links
Compact RJ-45 connector
Hot pluggable SFP footprint
1 Gigabit Ethernet over CAT5 cable
Applicable for 100m distance transmission
Low power consumption, < 1.2W
Access to physical layer IC via 2-wire serial bus

UltraLAN GPON SFP Class C++ SC/UPC for OLT (FIB-SFP-GP-C++)

The UltraLAN GPON SFP Class C++ module is engineered for high-performance Gigabit-capable Passive Optical Networks (GPON), offering seamless integration with Fiber OLT units. With a bi-directional data link supporting 2488Mbps transmit and 1244Mbps receive rates, this module features a compact SC/UPC connector, operates within a temperature range of 0 to 70°C, and is powered by a single 3.3V supply. Designed for reliability, it includes advanced digital diagnostics, low EMI, and robust ESD protection, all while adhering to stringent safety and compliance standards. Enhance your network's efficiency with this cutting-edge SFP module.

Applications:

• Gigabit-capable Passive Optical Networks (GPON)

Features:

• Single fiber bi-directional data links asymmetric TX 2488Mbps/RX1244Mbps application

• 1490nm continuous-mode DFB laser transmitter and 1310nm burst-mode APD-TIA receiver

• Small Form Factor Pluggable package with SC/UPC Connector

• 0 to 70°C operating temperature

• Single 3.3V power supply

• Digital diagnostic monitoring interface

• Digital burst RSSI function to monitor the input optical power level

• LVPECL compatible data input/output interface

• LVTTL transmitter disable control

• LVTTL transmitter laser fault alarm

• Fast LVTTL receiver Signal Detect (SD) indication response

• Low EMI and excellent ESD protection

• Class I laser safety standard IEC-60825 compliant

• RoHS6 Compliance

Standards:

• Complies with SFP Multi-Source Agreement (MSA) SFF-8074i

• Complies with ITU-T G.984.2 Amendment 1

• Complies with FCC 47 CFR Part 15, Class B

• Complies with FDA 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007

• Complies with SFF-8472

• Compatible with TR-NWT-000870 4.1 ESD sensitivity classification Class2.

• Compatible with Telcordia GR-468-CORE

Brand: UltraLAN
Product Code: (HGU – SC/APC)
Description: UltraLAN GPON ONT (Home Gateway Unit) SC/APC

Product Overview
The UltraLAN GPON ONT (HGU – SC/APC) is a robust, high‑performance fiber CPE designed for FTTX deployments. With low power consumption (≤3W) and support for GPON links up to 20km, it delivers downstream speeds of 2.5Gbps and upstream speeds of 1.25Gbps. Compatible with major third‑party OLT units, this ONT supports plug‑and‑play auto detection, auto configuration, and firmware upgrades. As a Home Gateway Unit, it offers advanced routing, NAT, DHCP, and firewall features, making it ideal for residential and small business fiber connectivity.

Key Features
GPON mode with access to GPON OLTs
Plug and play with auto detection, configuration, and firmware upgrades
Downstream 2.5Gbps / Upstream 1.25Gbps, up to 20km transmission distance
Fiber SC/APC port + Gigabit LAN port for fast transfer speeds
Supports OMCI remote management
IPv4/IPv6 IGMP snooping and MLD snooping
Bridge, route, and mixed bridge/route modes supported
NAT, DHCP server, port forwarding, VLAN, and firewall security features
Compact design with ≤3W power consumption
Estimated gross shipping weight: ~0.5–0.7 kg (device + PSU + packaging)

Technical Specifications
Feature Details
Product Code HGU – SC/APC
Distance 20km maximum
Data Rates 2.5Gbps downstream / 1.25Gbps upstream
PON TX Power 1–5dBm (1310nm)
PON RX Sensitivity
Power Consumption ≤ 3W
Interfaces 1 × SC/APC PON port, 1 × Gigabit LAN port
Buttons Reset
Power Supply DC 12V 0.5A
Operating Temp –10°C to 50°C
Storage Temp –40°C to 70°C
Operating Humidity 10%–90% non‑condensing
Storage Humidity 5%–90% non‑condensing
WAN Type Dynamic IP / Static IP / PPPoE
DHCP Server, Client, Reservation
QoS Bandwidth control
Port Forwarding Virtual server, port triggering, UPnP, DMZ
VLAN Port‑based VLAN, IEEE802.1Q VLAN
Access Control Local management, host list, access schedule
Routing NAT, PPPoE, server/client routing
Firewall Security DoS, SPI, IP/MAC/domain filtering, IP/MAC binding
Gross Shipping Weight 0.5–0.7 kg

What’s Included
1 × UltraLAN GPON ONT (HGU – SC/APC)
1 × Power Supply Unit (DC 12V 0.5A)
1 × User Manual

UltraLAN Fusion Splicer Power Supply

Keep your UltraLAN Fusion Splicer operational with our reliable power supply. Whether you need a spare or a replacement, this power supply ensures your equipment stays powered up and ready for any task. Designed specifically for the UltraLAN Fusion Splicer, it offers seamless compatibility to keep your splice machine charged.

Features:
Input: AC 100-240V, 50/60Hz, 1.4A Max
Output: DC 13.6V, 5A

Please Note:
The power supply is sold without a power cord. A compatible power cord can be purchased separately

UltraLAN Fiber to Gigabit RJ45 Converter

The UltraLAN FIB-MCGSFP is a media converter designed to convert fiber to 10/100/1000Base-T copper media or vice versa. The UltraLAN media converters are compatible with a wide range of transceiver modules, such as general 1000Base SFP transceiver modules, BiDi transceiver modules, CWDM transceiver modules, etc. The media converter is unmanaged and requires no configuration, simply plug-and-play.

Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX standards, the FIB-MCGSFP is designed for use with multi-mode or single-mode fiber SFP modules. The fiber media converter supports 850nm/1310nm/1550nm wavelengths depending on the SFP module that is inserted. Other features of this media converter include Auto MDI/MDI-X for TX port and status LED's (Link speed, Link activity, Power).

Product Features:

Gigabit copper to fiber conversion: 10/100/1000Base-T-to-1000Base-X
SFP design: For flexibility, an SFP (Mini-GBIC) slot is provided for the fiber port to support any type of SFP fiber transceiver when needed.
Supports full wire speed copper-to-fiber conversion
Auto MDI/MDI-X detection function on the copper port
Auto-negotiation support
Plug and play: no configuration settings is required
Low power consumption

UltraLAN Fiber to Gigabit Converter PSU (5V 2A)

This power supply is intended for use with the UltraLAN Fiber to Gigabit Ethernet convertor.
Features a SA 3pin power plug on side, and a DC barrel on the other.

Product Specifications

Input Voltage: 100-250 V AC
Input Frequency: 50-60Hz 0.28A
Output Voltage: 5V DC 2.0A
SA 3pin power plug
DC Barrel on output of PSU

The UltraLAN FIB-TB-8P Fiber Termination Box is a compact, wall mountable solution for indoor fiber optic distribution and termination. Designed to accommodate up to 8 SC or LC connectors (midcouplers not included), it features an internal tray for neat pigtail routing and splice protection.

This model includes a value-added Installation Pack with cable ties, coach screws and plugs, and fiber splice protectors, making it ideal for clean, professional setups in residential, commercial, or enterprise environments.

Key Features
🔌 8-Port Fiber Termination Box – Supports SC or LC connectors
🧰 Installation Pack Included – Cable ties, wall plugs, coach screws, splice protectors
📦 Integrated Splice Tray – Organize and protect pigtails and splices
🧱 Wall-Mountable Design – Ideal for indoor fiber terminations
🛠️ Compact & Durable Housing – Built for clean, professional installations
📦 Retail Box Packaging – Ready for deployment

Technical Specifications
Feature Details
Product Code FIB-TB-8P
Brand UltraLAN
Type Fiber Termination / Distribution Box
Ports 8 × SC or LC (midcouplers not included)
Mounting Wall-mountable
Internal Tray Yes – for pigtail and splice management
Included Accessories Cable ties, coach screws, wall plugs, splice protectors
Application Indoor fiber termination and distribution
Compatibility SC/LC connectors
Packaging Retail Box

What’s Included
1 × UltraLAN FIB-TB-8P Fiber Termination Box

UltraLAN Fiber Termination Box (2port) & Installation Pack

UltraLAN's 2 port termination box is used for fiber termination inside a building. It supports two LC or SC connectors (midcouplers not included) and a small tray for better pigtail and splicing management.

This sleek design also provides additional robustness to your installation with a cover plate to protect the sensitive connection between the patch lead and the termination box itself.

The termination box is also supplied with a value added Installation Pack consisting of:

2 cable ties to secure your fiber cable inside the box
2 coach screws and plugs for wall mounting the box
2 fibre splice protectors

UltraLAN Fiber Termination Box (1port) & Installation Pack


UltraLAN's 1 port termination box is used for fiber termination inside a building. It supports one LC or SC connector (midcoupler not included) and a small tray for better pigtail and splicing management.

This sleek design also provides additional robustness to your installation with a cover plate to protect the sensitive connection between the patch lead and the termination box itself.


The termination box is also supplied with a value added Installation Pack consisting of:

2 cable ties to secure your fiber cable inside the box
2 coach screws and plugs for wall mounting the box

UltraLAN Fiber Power Meter with 10mw VFL

The UltraLAN Fiber Power Meter and Visual Fault Locator (VFL) is a handheld optical power meter, which also conveniently includes a built-in laser based Visual Fault Locator. The ergonomically designed instrument uses advanced technology for outstanding functionality and durability.

The power meter uses microprocessor control and includes a variety of advanced features and user selectable settings. It is used for optical signal power measurement at a variety of wavelengths from 800-1700nm. The Visual Fault Locator can be used to inspect optical fiber cables and connectors for potential failures and issues when connected to an optical interface and/or with a single mode or multi-mode optical fiber.

It is an indispensable tool in fiber project installations, construction, fiber network maintenance, for testing fusion or field-installed connectorized cables, optical component manufacture and research, etc.
