Ubiquiti's UB-ETHSP is a Gigabit Ethernet surge protector designed to protect outdoor, PoE or non-PoE Ethernet devices from electrostatic discharge and surges.

Specifications

Data Line Protection: RJ45 10/100/1000
DC Spark-Over Voltage: 90V 100V/s
Discharge Current: 10kA+
Ethernet Ports: 2x 10/100/1000
Maximum Impulse Spark-Over Voltage: 700V 1kV/µs
Operating Temperature: -30°C to 65°C
PoE Support: 802.3af & Passive PoE
Dimensions: 91 x 61 x 32.5mm

Ubiquiti's UACC-LRE is an outdoor Gigabit Ethernet adapter which establishes long-range connections between PoE switches and devices. The unit features 2x Gigabit Ethernet ports. Port one receives 802.3af/at PoE input while port two provides PoE passthrough for distances up to 1km when making use of multiple adapters. The unit also offers 10kA+ surge protection and works reliably in extreme temperatures to protect your deployment from weather and electrical damage.

*Note: This device does not support MTU's larger than 1500. If making use of jumbo frames across the device, it will not work.

Specifications
Ethernet Ports: 2x 10/100/1000
Hardware Button: None
Max. Power Consumption: 1.5W
Mounting: Pole-Mount
Operating System: None
Operating Temperature: -40°C to 80°C
PoE Input: 802.3af/at
PoE Output: 802.3af PoE Passthrough
Power Input: 802.3af/at
SFP Ports: None
Supported Voltage Range: 37-57V
Dimensions: 196.5 x 93.5 x 39 mm
Weight: 350g

Ubiquiti Multi Mode (LC) SFP Module Pair

The UF-MM1G is ideal for short-distance, outdoor, bi-directional, multi-mode fiber runs for distances of up to 550m at 1 Gbps.

Outdoor Fiber Installations

For short-distance runs of 300+ meters, use UFiber 1G multi-mode modules for maximum reuse of existing infrastructure.
UF-MM-1G-S
Supported Media Multi-Mode Fiber
Connector Type (1) LC
BiDi ✓
TX Wavelength
850 nm

RX Wavelength
850 nm

Data Rate 1.25 Gbps SFP
Cable Distance 550 m
Pack Options 1-Pair

Please note: This kit is only sold as a pair (one box with 2 units inside)

Ubiquiti's UACC-MM1G allows for multi-mode fiber connections delivering up to 1.25Gbps speeds at distances of up to 550m.

*Note: The price reflected is for a pair (one box of 2 units). This product is only sold as a pair, and no single units are available.

Specifications

Connector: 2x LC
Data Rate: 1.25Gbps
Form Factor: SFP
Mode: Multi Mode
Supported Distance: 550m
Wavelength: 850nm

Ubiquiti's UACC-MM10G allows for multi-mode fibre connections delivering up to 10Gbps speeds at distances of up to 300m.

*Note: The price reflected is for a pair (one box of 2 units). This product is only sold as a pair, and no single units are available.

Specifications
Connector: 2x LC
Data Rate: 10Gbps
Form Factor: SFP
Mode: Multi Mode
Supported Distance: 300m
Wavelength: 850nm

Ubiquiti's UCG-ULTRA is a powerful and compact multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features. The unit runs UniFi Network for full-stack network management and features 4x Gigabit Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display and multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 3x 10/100/1000 (LAN); 1x 10/100/1000 (LAN / WAN);1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 6.2W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 3A USB Power Adapter (Included);
Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3 GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's NS4 is an unmanaged, outdoor, 4 port Gigabit switch with PoE passthrough. If powered by 24V Passive PoE can provide up to 24W of power on three PoE out ports. The NanoSwitch is designed for outdoor deployment and supports up to 4 Gbps total, non-blocking line rate.

*Note: PoE Injector not Included.

Specifications

Ethernet Ports: 4x 10/100/1000
Max. Power Consumption: 30W
Mounting: Wall or Pole Mount
Operating Temperature: -30C ~ 70C
PoE Input: Passive 24V PoE
PoE Output: 24V Passive PoE Pass-through
Power Input: 24V Passive PoE (Not Included)
Supported Voltage Range: 21.6 - 30V
Dimensions: 196.4 x 93.5 x 32.4mm
Weight: 271g

Ubiquiti Single Mode (LC) SFP Module Pair
The UF-SM1G is ideal for long-distance, outdoor, bi-directional, single-mode fiber runs for distances of up to 3 km at 1 Gbps.
Outdoor Fiber Installations
For long-distance runs of 300+ meters, use UFiber 1G single-mode modules for maximum reuse of existing infrastructure.
UF-SM-1G-S
Supported Media Single-Mode Fiber
Connector Type (1) LC
BiDi ✓
TX Wavelength Blue1310 nm Yellow1550 nm
RX Wavelength Blue 1550 nm Yellow 1310 nm
Data Rate 1.25 Gbps SFP
Cable Distance 3 km
Pack Options 1-Pair

Ubiquiti's UACC-SM1GS is ideal for long-distance, bi-directional, single-mode connections. It can deliver up to 1.25Gbps speeds at distances of up to 3km.

These SFP modules make use of Wavelength-Division Multiplexing (WDM). This means it uses two different light wavelengths to transmit data in both directions at once, resulting in fewer fiber cables required to run. It also aids in maximizing the use of existing infrastructure and simplifying installations.

*Note: The price reflected is for a pair (one box of 2 units). This product is only sold as a pair, and no single units are available.

Specifications
Connector: 1x LC
Data Rate: 1.25Gbps
Form Factor: SFP (BiDi)
Mode: Single Mode
Supported Distance: 3km
Wavelength: 1310nm / 1550nm

Ubiquiti's UACC-SM10G allows for long-distance, single-mode fiber connections. It can deliver up to 10Gbps speeds at distances of up to 10km.

*Note: The price reflected is for a pair (one box of 2 units). This product is only sold as a pair, and no single units are available.

Specifications
Connector: 2x LC
Data Rate: 10Gbps
Form Factor: SFP
Mode: Single Mode
Supported Distance: 10km
Wavelength: 1310nm

Ubiquiti's UF-TBOX is an outdoor IPX5, weatherproof, pole-mountable enclosure for UFiber devices. This heavy-duty enclosure features a screw-lock design and includes a pole-mounting kit.

*Note: Compatible with UF-LOCO and UF-AE.

Specifications
SKU UF-TBOX
Manufacturer Ubiquiti
Manufacturer Product Code UF-TERMINAL-BOX
Specifications Compatibility: UF-LOCO ; UF-AE
Material: UV stabilized polycarbonate
Dimensions: 249 x 218 x 60 mm
Weight: 680g

Ubiquiti's UISP-HORN is a 5GHz 19dBi, 30° high isolation horn antenna designed to seamlessly integrate with Ubiquiti radios. The antenna covers a wide frequency range and with low back lobes. It is ideal for co-location deployments.

*Note: Radio not Included.

Specifications

Antenna Gain: 19.5dBi
Beam-width: 30°
Connector: Waveguide Adapter (Included)
Frequency Range: 5.15 - 6.875GHz
Polarization: Vertical & Horizontal
Wind Loading: 90N @ 200km/h
Dimensions: 282 x 224 x 380 mm
Weight: 3.98kg

Ubiquiti's WAVE-APM is a UISP 60GHz Point-to-MultiPoint Access Point featuring 5GHz failover, 1x 2.5Gbps Ethernet Port and an integrated GPS antenna. Utilising 60GHz point-to-multipoint technology, it can connect up to 15 stations with a total throughput of 5Gbps at distances of up to 900m when paired with the WAVE-PICO, 4km when paired with the WAVE-NANO, and 6km when paired with the WAVE-LR. Mount up to 4x WAVE-APM using the WAVE-MM mounting for full 360° coverage.

The dedicated Bluetooth radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 60GHz: 20dBi ; 5.8GHz: 13.5dBi
Beamwidth: 60GHz/5GHz: 90°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Pole-Mount, or WAVE-MM for 360° coverage
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A 2.5GbE PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Dimensions: 284 x 156 x 76 mm
Weight: 1.3kg

Ubiquiti's WAVE-AP is a UISP 60GHz Point-to-MultiPoint Access Point featuring 5GHz failover, 1x 10Gbps SFP+ Port, 1x 2.5Gbps Ethernet Port and an integrated GPS antenna. Utilizing 60GHz point-to-multipoint technology, it can connect up to 15 stations with a total throughput of 5.4Gbps at distances of up to 1.3km when paired with the WAVE-PICO, 5km when paired with the WAVE-NANO, and 8km when paired with the WAVE-LR.

The dedicated Bluetooth radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 60GHz: 24dBi; 5.8GHz: 12dBi
Beamwidth: 60GHz/5GHz: 30°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A 2.5GbE PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Other: 1x SFP+
Dimensions: 212 x 205 x 187mm
Weight: 2.3kg

Ubiquiti's WAVE-LR is a long-range 60GHz radio system with an integrated high-gain antenna, GPS, precision mount bracket, and a 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 15 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 8km) or WAVE-APM (6km) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For PtP links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 46dBi; 5.8GHz: 22dBi
Beamwidth: 60GHz: 1.1°; 5GHz: 10°
Data Rate: 60GHz: Up to 2Gbps; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V or 48V
USB Ports: None
Dimensions: Ø424.4 x 166.2mm
Weight: 2.59kg

Ubiquiti's WAVE-NANO is a 60GHz radio system with an integrated high-gain antenna, GPS, and a 5GHz backup radio. It features Wave technology with true duplex gigabit performance P2P links up to 12 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 5km) or WAVE-APM (4km) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For P2P links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 41dBi; 5.8GHz: 19dBi
Beamwidth: 60GHz: 1° ; 5GHz: 17°
Data Rate: 60GHz: Up to 2Gbps; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V or 48V
USB Ports: None
Dimensions: Ø256.5 x 113.5 mm
Weight: 1.2kg

Ubiquiti's WAVE-PICO is a 60GHz radio system with an integrated high-gain antenna, and a WiFi 6, 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 3km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 1.3km) or WAVE-APM (900m) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For P2P links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 27.7dBi; 5.8GHz: 9dBi
Beamwidth: 60GHz: 6°; 5GHz: 50°
Data Rate: 60GHz: Up to 2Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.5A, Gigabit PoE Injector (Included)
Serial Interface: None
SFP Ports: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V Passive PoE
USB Ports: None
Dimensions: Ø152.1 x 55.8 mm
Weight: 347g

Ubiquiti's WAVE-PRO is a high-capacity 60GHz radio system with 5GHz backup radio, an integrated high-gain antenna, 2x 2.5Gbps Ethernet Ports, 1x 10Gbps SFP+ as well as integrated GPS and precision mount bracket. It features Wave technology with true duplex gigabit performance PtP links up to 15 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 8km) or WAVE-APM (6km) with a total throughput of up to 5.4Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For P2P links, firmware v.3.2.0 or later is required.

Specifications

Antenna Gain: 60GHz: 46dBi; 5.8GHz: 22dBi
Beamwidth: 60GHz: 1.3°; 5GHz: 8°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 2x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 26W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 44–54V or 22–27V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Other: 1x SFP+
Dimensions: Ø424.4 x 166.2mm
Weight: 4kg

Ubiquiti's UISP-CON is a UISP Console with the pre-installed UISP application which features a built-in switch with 8x Gigabit Ethernet Ports and 1x 10Gbps SFP+ Port. It also offers 1x 10Gbps SFP+ and 1x Gigabit Ethernet WAN connections and can be wall or rack mounted with the included kit.

Specifications

Ethernet Ports: 8x 10/100/1000 (LAN) 1x 10/100/1000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop, Wall or Rack-Mount
Operating System: UISP
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: None
Power Input: 24V 2.5A power supply (Included)
Processor: Quad-Core 1.7 GHz ARM® Cortex®-A57
Serial Interface: None
SFP Ports: 1x 10Gbps (LAN) 1x 10Gbps (WAN)
Supported Voltage Range: 24-28V
System Memory: 4 GB DDR4
USB Ports: None
Other: 1x MicroSD card slot
Dimensions: 210.4 x 140.2 x 43.7 mm
Weight: 1.5kg

Ubiquiti's ER-6P is a professional 5 port Gigabit Ethernet router with SFP connectivity. Based on EdgeOS, it contains a quad-core, 1Ghz processor and 24v PoE out. It is designed for ISP (internet service provider) or SME (small to medium enterprise) deployments which require advanced routing features. It can be managed via the UISP network management platform.

Specifications

Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16W
Mounting: Wall Mount or Desktop
Operating System: EdgeMAX
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 24V Passive PoE Output on Ports 0~4
Power Input: 24V 2.5A Power Supply (Included)
Processor: 4-Core 1GHz; MIPS64
Serial Interface:1x RJ45 Serial Port
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 16 - 30VDC
System Memory: 1GB DDR3 RAM
USB Ports: 1x USB 3
Dimensions: 229 x 136.5 x 31.1 mm
Weight: 730 g
