Ubiquiti 10Gbps RJ45 Copper SFP+ Module

Ubiquiti Networks offers a variety of U® Fiber modules to suit your fiber connectivity applications.

To connect copper Ethernet cables to SFP ports, use the UF-RJ45-10G in an SFP+ port for speeds of up to 10 Gbps and distances of up to 30 m, or use the UF-RJ45-1G in an SFP port for speeds of up to 1 Gbps and distances of up to 100 m.
Supported Media Copper
Connector Type RJ45
BiDi N/A
TX Wavelength N/A
RX Wavelength N/A
Data Rate 1/10 Gbps
Cable Distance
1 Gbps
(Cat 5e)
100 m
10 Gbps
(Cat 6A)
30 m
Pack Options 1-Pack

Ubiquiti 10Gbps Single Mode (LC) SFP+ Module Pair


The UF-SM-10G is ideal for long-distance, outdoor, bi-directional, single-mode fiber runs for distances of up to 10 km at 10 Gbps.

Outdoor Fiber Installations

For long-distance runs of up to 10KM, use UFiber 10G single-mode modules for maximum reuse of existing infrastructure and maximum speed.
UF-SM-10G
Supported Media Single-Mode Fiber
Connector Type (2) LC
BiDi No
TX Wavelength
1310nm
RX Wavelength
1310nm
Data Rate 10 Gbps SFP+
Cable Distance 10 km
Pack Options 1-Pair

Please note: This kit is only sold as a pair (one box with 2 units inside)

Ubiquiti 1Gbps RJ45 Copper SFP Module


Ubiquiti Networks offers a variety of U® Fiber modules to suit your fiber connectivity applications.


To connect copper Ethernet cables to SFP ports, use the UF-RJ45-10G in an SFP+ port for speeds of up to 10 Gbps and distances of up to 30 m, or use the UF-RJ45-1G in an SFP port for speeds of up to 1 Gbps and distances of up to 100m.
upported Media Copper
Connector Type RJ45
BiDi N/A
TX Wavelength N/A
RX Wavelength N/A
Data Rate 10/100/1000 Mbps
Cable Distance 100 m

Ubiquiti's UPOE48-30W-2G is a 48V, 0.65A, 2.5Gbps, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power cable not included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000/2500
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UCG-MAX is a powerful and compact 2.5Gbps multi-WAN UniFi Cloud Gateway with a full suite of advanced routing and security features with 1.5Gbps IPS routing and a 512GB SSD for NVR storage. The unit can run all UniFi applications for full-stack network management and features 4x 2.5Gbps Ethernet ports, 1x 2.5Gbps WAN Port, a quad-core 1.5GHz CPU, 0.96" LCM status display, and Multi-WAN load balancing.

It can be configured and managed with the UniFi Network Application.

Specifications

Ethernet Ports: 4x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 16.1W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x 5V 5A USB Power Adapter (Included)
Processor: Quad-core ARM® Cortex®-A53 at 1.5GHz
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V 3A via USB
System Memory: 3GB DDR4
USB Ports: None
Dimensions: 141.8 x 127.6 x 30 mm
Weight: 0.52kg

Ubiquiti's UACC-PSU-210W is a wall mountable AC power adapter which delivers 210W at 54V DC, ideal for powering PoE Switches.

Specifications
Compatibility: USW-ULTRA, USW-U60, USW-PRO-MAX16P, USW-U210
Connector: IEC
DC plug: 5.5 x 2.1 x 11.5 mm
DC cable: UL11353 16AWG 1.5 m
Voltage: 54V
Wattage: 210W
Dimensions: 190 x 86 x 26 mm
Weight: 2kg

The POE-802O adapter transforms almost any Ubiquiti PoE device into a fully compliant 48V, PoE-compatible product.

The Instant PoE Adapter works seamlessly with a variety of PoE switches for remote power control applications. You can conveniently power or power cycle your remote devices using your PoE switch.
Specifications
Interface In: (1) Gigabit RJ45 Port
Interface Out: (1) Gigabit Ethernet Cable
Power Input : 48V; 802.3af
Max Power Output: 24V; 0.5A
Ethernet ESD/Surge Protection: ±15kV
Dimensions: Ø 30.2 x 166 mm
Dimensions with RJ45 Cable: Ø 30.2 x 366.6 mm
Weight: 90g
Operating Temperature: -30 to 70° C

Ubiquiti's UACC-AIPORT-RM is a 1U rack-mount accessory that supports up to 6x AI Ports.

Specifications
Enclosure Material: SGCC steel, polycarbonate
Mounting: Mini rack/rack
Ambient Operating Temperature: -20° to 40° C (-4° to 104° F)
Dimensions: 442.4 x 158.5 x 42.8 mm
Weight: 650g

Ubiquiti's UACC-PM is an easy-to-install wall mount bracket for the U7-PRO or U6-PRO.
Specifications
Dimensions: 174 x 189 x 30 mm
Weight: 136g

All-in-one router and security gateway with an integrated PoE switch and network video recorder.

The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).


Features:
1.7 GHz quad-core processor
Dual WAN ports (10G SFP+ and 2.5GbE RJ45)
(8) GbE RJ45 ports, including (6) PoE and (2) PoE+ LAN ports
(1) 10G SFP+ LAN port
(1) 1.3" LCM color touchscreen for at-a-glance network monitoring
Customizable internet threat filtration and traffic identification for enhanced network security
Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app
1U-sized, rack-mountable device
Connect a SmartPower Redundant Power System to create an uninterruptible network
Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5" HDDs
128 GB integrated storage for full UniFi OS Application experience
Dimensions
442.4 x 43.7 x 285.6 mm
(17.4 x 1.7 x 11.2")
Weight 5 kg (10.9 lb)

Ubiquiti's UACC-HDD16 is an enterprise-grade 3.5" 16TB SATA hard drive, ideal for storage-intensive UniFi camera security and NAS systems.

Specifications
Capacity: 16TB
Hard Disk Form Factor: 3.5-inch
Mean Time Between Failure (MTBF): 2,500,000 h
Management Interface: SATA 6Gb/s
Operating temperature: 5 to 60° C
Power Method: 5V/12V input
Rotation Speed: 7200 RPM
Workload Rating: 550TB/year
Dimensions: 147 x 101.9 x 26.1 mm
Weight: 720g

Ubiquiti's UACC-HDD8 is an enterprise-grade 3.5" 8TB SATA hard drive, ideal for storage-intensive UniFi camera security and NAS systems.

Specifications

Capacity: 8TB
Hard Disk Form Factor: 3.5-inch
Mean Time Between Failure (MTBF): 2,000,000 h
Management Interface: SATA 6Gb/s
Operating temperature: 5 to 60°C
Power Method: 5V/12V input
Rotation Speed: 7200 RPM
Workload Rating: 550TB/year
Dimensions: 147 x 101.9 x 26.1 mm
Weight: 720g

Ubiquiti's UF-GPC module increases the capacity of your UFiber OLT and allows you to connect with your new customers quickly. The UFiber UF-GPC module is designed for use with the Ubiquiti UISP UFiber GPON OLT (UF-OLT-4).

It can be managed via the UISP network management platform.

Specifications

Connector: 1x SC/UPC
Data Rate: Downstream: 2.5Gbps; Upstream: 1.25Gbps
Form Factor: SFP
Mode: Single Mode
Supported Distance: 20km
Wavelength: 1490nm

A compact and powerful UniFi gateway with a full suite of advanced routing and security features.

Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues)
Managed by a CloudKey, Official UniFi Hosting, or UniFi Network Server with UniFi Network 8.0.7 and later
(1) GbE WAN port
(1) GbE LAN port
Compact footprint
USB-C powered (adapter included)
Key Features
1 x Gbe LAN, 1 x Gbe WAN, USB Type-C PSU
Weight & Dimensions
W : 13cm
L : 13cm
H : 8cm
Weight : 520g

Ubiquiti's UPOE24-12W is a 24V, 0.5A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.5A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range:100V-240V
Dimensions: 89 x 46 x 33mm
Weight: 75g

Ubiquiti's UPOE24-24W is a 24V, 1A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 1A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 88 x 57 x 33mm
Weight: 158.5g

Ubiquiti's UPOE24-7W is a 24V, 0.3A, Gigabit PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 24V 0.3A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 72 x 45 x 33mm
Weight: 72.1g

Ubiquiti's UPOE-48G15W is a 48V, 0.32A, Gigabit, PoE injector. The unit is compatible with products that require 802.3af PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 0.32A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 86 x 46 x 33mm
Weight: 100g

Ubiquiti's UPOE-48G30W is a 48V, 0.65A, Gigabit, PoE injector. The unit is compatible with products that require 802.3at PoE and features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
PoE Output: 48V 0.65A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V

Ubiquiti's UPOE48-60W is a 48V, 1.25A, Gigabit, PoE injector, compatible with Ubiquiti's AF-11. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

*Note: Power Cable Not Included, we recommend POWU.

Specifications

Ethernet Ports: 2x 10/100/1000
Operating Temperature: 0°C to 40°C
PoE Output: 48V 1.25A Passive PoE
Power Input: Clover Power Cord (Not Included)
Supported Voltage Range: 100V-240V
Dimensions: 106 x 63 x 34mm
Weight: 210g
