The Ubiquiti UniFi Protect G6 Dome (UVC‑G6‑Dome‑W) is a premium 8MP 4K IP camera designed for professional surveillance. Featuring a 1/1.8" image sensor, ultra‑wide viewing angle, and Multi‑TOPS AI engine, it delivers intelligent detection and crystal‑clear video quality.
With long‑range IR night vision up to 30m and a mechanical IR cut filter, the G6 Dome ensures reliable performance day and night. Built to last, it is both IP66 weatherproof and IK10 vandal‑resistant, making it ideal for outdoor and high‑risk environments.
The camera includes a built‑in microphone for audio capture and supports H.264 and MJPEG compression for efficient storage. Powered via 802.3af/at PoE (injector not included), it consumes just 9.25W and operates in temperatures from ‑20°C to 50°C.
Compact at Ø144.7 × 96.3 mm and weighing 820 g, the G6 Dome is designed for wall or ceiling mounting and integrates seamlessly with the UniFi Protect application for centralized management.

Technical Details:

Model / SKU: UVC‑G6‑Dome‑W
Resolution: 3840 × 2160 (16:9), 8MP 4K
Sensor: 1/1.8" 8MP image sensor
Lens: Fixed focal length, ultra‑wide angle
Frame Rate: Up to 30 FPS (resolution dependent)
Night Vision: IR LEDs with mechanical IR cut filter, up to 30m
AI Engine: Multi‑TOPS for intelligent detection
Audio: Built‑in microphone
Ethernet Ports: 1 × 10/100
PoE Input: 802.3af/at PoE, 37–57V
Power Consumption: Max 9.25W
Mounting: Wall or ceiling mount
Operating Temperature: ‑20°C to 50°C
Protection: IP66 weatherproof, IK10 vandal‑resistant
Video Compression: H.264, MJPEG
Dimensions: Ø144.7 × 96.3 mm
Weight: 820 g

The Ubiquiti UniFi Cloud Gateway Fiber (UCG‑Fiber + M.2 Tray) is a 10Gbps dual‑WAN desktop gateway designed for full‑stack UniFi network management. Equipped with a quad‑core ARM Cortex‑A73 processor at 2.2GHz and 3GB RAM, it delivers enterprise‑grade performance for demanding deployments.
This model includes an M.2 SSD tray (SSD not included), enabling NVR storage expansion up to 2TB for UniFi Protect, making it a versatile gateway + video recorder solution.

Connectivity highlights include:

1× 10Gbps WAN port
4× 2.5Gbps LAN ports (Port 4 supports 802.3at PoE+ output)
2× SFP+ ports (1 WAN, 1 LAN)

Running on UniFi OS, the UCG‑Fiber integrates seamlessly with the UniFi Network Application, offering centralized management of routing, switching, security, and video. Compact at 212.8 × 127.6 × 30 mm and weighing 675 g, it consumes just 29.4W and is powered via a 54V 1.1A adapter (included).

Technical Details:

Model / SKU: UCG‑Fiber + UACC‑SSD‑Tray
Processor: Quad‑core ARM Cortex‑A73, 2.2GHz
System Memory: 3GB
Storage: M.2 SSD tray (≤2TB, SSD not included)
Ethernet Ports: 4 × 2.5Gbps LAN (Port 4 PoE+), 1 × 10Gbps WAN
SFP+ Ports: 2 × (1 WAN, 1 LAN)
PoE Output: 802.3at PoE+ on Port 4
Power Input: 54V 1.1A adapter (included)
Max Power Consumption: 29.4W
Operating System: UniFi OS
Operating Temperature: 0°C to 40°C
Dimensions: 212.8 × 127.6 × 30 mm
Weight: 675 g
Mounting: Desktop

The Ubiquiti UniFi Access Reader Pro Black (UA‑G3‑Pro‑B) is a premium IP55‑rated intercom and access reader designed for seamless integration with UniFi Access Hubs. Featuring a 4.7" touchscreen, face recognition, built‑in NFC card reader, and two‑way audio, it delivers secure, modern, and user‑friendly access control.
With Touch Pass support (10 free passes included in the first year), users can enjoy convenient mobile access, with annual renewals available thereafter. Connectivity options include BLE 4.2, NFC, and Gigabit Ethernet, while 802.3af PoE ensures simple powering with a maximum consumption of just 6W.
Compact at 160 × 40.4 × 40.55 mm and weighing only 136 g, the UA‑G3‑Pro‑B is designed for wall‑mount or gang‑box installation, with optional angle and junction box mounts available. Built to withstand harsh conditions, it operates reliably in temperatures from ‑30°C to 45°C (device) and ‑10°C to 45°C (display).

Technical Details:

Model / SKU: UA‑G3‑Pro‑B
Type: UniFi Access Reader Pro (Black)
Display: 4.7" touchscreen
Features: Face recognition, NFC card reader, Touch Pass support, 2‑way audio
Connectivity: BLE 4.2, NFC, 1 × Gigabit Ethernet
Power Input: 802.3af PoE (not included), max 6W
Mounting: Wall‑mount & gang‑box (included); angle mount & junction box (optional)
Operating Temperature: Device: ‑30°C to 45°C; Display: ‑10°C to 45°C
Protection: IP55 weatherproof
Dimensions: 160 × 40.4 × 40.55 mm
Weight: 136 g

Requirement: Must be paired with UniFi Access Hub

SKU: UVC-AIPTZ-W
Manufacturer: Ubiquiti

🌟 Overview
The Ubiquiti UVC-AI-PTZ-W is a high-performance industrial-grade PTZ camera engineered for precision surveillance in demanding environments. Featuring a 1/1.8" 8MP sensor with 4K resolution, 22× optical zoom, and long-range IR night vision up to 100 meters, it delivers crystal-clear imaging day or night. Advanced AI capabilities include face recognition, license plate detection, and smart object tracking (people, vehicles, animals). Fully managed via UniFi Protect, it supports PoE++ (802.3bt) for streamlined installation.

Note: PoE Injector not included.

📦 Key Specifications
Attribute Details
Resolution 8MP (3840 × 2160), 4K UHD
Sensor 1/1.8" CMOS
Zoom 22× Optical Zoom Lens
Frame Rate Up to 30 FPS (resolution dependent)
Night Vision IR up to 100m
AI Features Face recognition, license plate detection, smart tracking (people, vehicles, animals)
Compression H.264, MJPG
Ethernet Port 1 × 10/100/1000 Mbps RJ45
PoE Standard 802.3bt (PoE++), 60W
Max Power Consumption 51W
Mounting Options Wall, pole, desk stand (included)
Operating Temperature -40°C to 50°C
Weather Rating IP66 (outdoor-rated)
Microphone None
Reset Button Yes
Dimensions (L × W × H) 207 × 223.7 × 341.3 mm
Weight 3.8 kg
Management Platform UniFi Protect
Warranty 1 Year Limited
Packaging Retail Box
Gross Weight: 4.5 kg
Box Dimensions (L × W × H): 400 × 300 × 250 mm
Volumetric Weight: 6.0 kg (based on standard courier formula)

Product Code: VIGI-C485(2.8MM)
Brand: TP-Link

🌟 Overview
The TP-Link VIGI C485 is a high resolution 8MP turret camera designed for 24/7 full color surveillance. With 4K Ultra HD clarity, smart detection features, and a robust metal housing, it’s ideal for outdoor and indoor security applications. AI powered human and vehicle classification, two-way audio, and flexible illuminator controls ensure intelligent monitoring and proactive protection. Compatible with PoE and 12V DC power, it integrates seamlessly into modern surveillance setups.

📦 Key Specifications
Attribute Details
Resolution 3840 × 2160 (4K UHD)
Image Sensor 1/2.7" Progressive Scan CMOS
Lens Fixed 2.8 mm, F1.6, M12 mount
Field of View H: 111.4°, V: 58.8°, D: 134°
Night Vision Full color with 4× white LEDs (30m range)
Minimum Illumination 0.005 Lux (Color), 0 Lux with IR/LED
Day/Night Mechanism IR Cut Filter, Auto/Scheduled/Unified
Smart Detection Human/Vehicle classification, line-crossing, tamper alerts
Compression Format H.265+/H.265/H.264+/H.264
Bitrate Control CBR/VBR (Main: 256 Kbps–6 Mbps, Sub: 64 Kbps–512 Kbps)
Wide Dynamic Range 120 dB
Audio Two-way audio, noise filtering
Storage Cloud support, ROI region, privacy mask (up to 4 zones)
Power Supply 12V DC ±5% (Max 11.5W) or PoE 802.3af/at (Max 12.5W)
Operating Temp -30°C to +60°C
Material Metal housing
Net Weight 0.48 kg
Dimensions (L × W × H) ~150 × 150 × 100 mm (estimated)
Warranty 1 Year Limited
Gross Weight: ~0.7 to 1.0 kg
Box Dimensions (L × W × H): ~180 × 160 × 110 mm

Ubiquiti's UVC-AI-PORT enhances any UniFi or third-party ONVIF camera with AI detection, classification, and recognition capabilities. It features advanced AI for people detection, license plate recognition and is wall, pole or rack-mountable with the UACC-AIPORT-RM.

KU UP-AI-PORT
Manufacturer Ubiquiti
Manufacturer Product Code UP-AI-Port

Specifications

Ethernet Ports: 2x 10/100/1000
Max. camera resolution: 3840 x 2160 (16:9)
Operating Temperature: -20°C to 40°C
PoE Input: PoE+ required for PoE output (12.95W) ; PoE++ required for PoE+ output (25.5W)
PoE Output: 802.3af/at (Dependent on Input)
Dimensions: 152.7 x 69 x 47.8 mm
Weight: 294g

Ubiquiti's UVC-G6T-W is an IP66, IK04 tamper-resistant, 8MP PoE camera with Multi-TOPS AI Engine, and 3-axis manual adjustment for flexible installation. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 30 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 12.5W
Mounting: Wall or Pole-Mount
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -30°C to 50°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 3864 x 2160 (16:9)
Sensor: 1/1.8" 8MP
Video Compression: H.264 ; MJPEG
Dimensions: : Ø100 x 95 mm
Weight: 550g

Ubiquiti's UVC-G5TU-W is a compact, tamper-resistant white IP Camera featuring a 4MP ultra-wide image and integrated microphone housed in a weatherproof IP66 enclosure with integrated long-range IR night vision up to 30m.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Ceiling (optional mounting arm: UACC-G5TAM)
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 1/2.4" CMOS
Video Compression: H.264; MJPEG
Dimensions: Ø90 x 71.2 mm
Weight: 330g

Ubiquiti's UVC-G5TU-B is a compact, tamper-resistant black IP Camera featuring a 4MP ultra-wide image and integrated microphone housed in a weatherproof IP66 enclosure with integrated 30m long-range IR night vision.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Ceiling (optional mounting arm: UACC-G5TAM)
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 1/2.4"" CMOS
Video Compression: H.264; MJPEG
Dimensions: Ø90 x 71.2 mm
Weight: 330g

Ubiquiti's UVC-G5PTZ features a 4MP image with a built-in microphone, 2x optical zoom and AI smart detection. It is also IP66 rated with both wall and pole-mount options for both indoor and outdoor installations. The camera has built-in IR & white LED illumination with IR cut filter.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: F 3.42–6.85 mm; ƒ/1.85–ƒ/2.4
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 14W
Mounting: Wall or Pole-Mount
Night Mode: IR LED illumination and IR cut filter (20m)
Operating Temperature: -30°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 37-57V PoE
Resolution: 4MP 2688 x 1512 (16:9)
Sensor: 5MP 1/2.7"" CMOS
Video Compression: H.264; MJPEG
Dimensions: 90 x 94 x 179.5 mm
Weight: 650g

Ubiquiti's UVC-G5PTZ-W features a 4MP image with a built-in microphone, 2x optical zoom and AI smart detection. It is also IP66 rated with both wall and pole-mount options for both indoor and outdoor installations. The camera has built-in IR & white LED illumination with IR cut filter.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.
SKU UVC-G5PTZ-W
Manufacturer Ubiquiti
Manufacturer Product Code UVC-G5-PTZ

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: F 3.42–6.85 mm; ƒ/1.85–ƒ/2.4
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 14W
Mounting: Wall or Pole-Mount
Night Mode: IR LED illumination and IR cut filter (20m)
Operating Temperature: -30°C to 45°C
PoE Input: 802.3af/at PoE
Power Input: 37-57V PoE
Resolution: 4MP 2688 x 1512 (16:9)
Sensor: 5MP 1/2.7"" CMOS
Video Compression: H.264; MJPEG
Dimensions: 90 x 94 x 179.5 mm
Weight: 650g

Ubiquiti's UVC-G5B-3 offers 3x UVC-G5B in a single package. The units feature a 4MP image with a built-in microphone and a versatile 3-axis mount that enables quick and easy adjustment for both indoor and outdoor mounting. The camera has infrared LEDs with an automatic IR cut filter for both day and night surveillance up to 10 meters.

It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100
Hardware Button: Reset
Lens: Fixed Focal Length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max. Power Consumption: 4W
Mounting: Wall/Pole
Night Mode: IR LED illumination and IR cut filter
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af PoE
Power Input: 37-57V PoE
Resolution: 2688 x 1512 (16:9)
Sensor: 5MP CMOS Sensor
Video Compression: H.264; MJPEG
Dimensions: : Ø75.5 x 150 mm
Weight: 315g

Ubiquiti's UVC-G3FLEX-PWM is a white flexible outdoor mounting option for the UVC-G5F cameras. It is IPX4-rated for splash resistance, and it supports upside-down mounting. The camera image orientation is automatically adjusted in the UniFi Protect Application.

Specifications

Material: Polycarbonate; Rubber
Rating: IPX4
Dimensions: 133.5 x 52 x 62mm
Weight: 65g

Ubiquiti's UVC-G3FLEX-CM3 is a recessed ceiling mount accessory for the UVC-G5F cameras. Mount your camera inside the ceiling or a ceiling tile for a clean, low-profile installation. Includes mounting hardware for drywall, solid surface, or ceiling tile installation. An optional screw locks the camera to the mount from above for added security.

The UVC-G3FLEX-CM3 is packaged to include 3 units per pack.

SKU UVC-FLEX-CM3
Manufacturer Ubiquiti
Manufacturer Product Code UVC-G3-F-C-3
Download N/A
Specifications N/A

Brand: Ubiquiti
Product Code: UVC‑AIPRO‑W
Description: Ubiquiti UniFi Protect AI Pro 8MP White IP Camera

Product Overview
The Ubiquiti UniFi Protect AI Pro (UVC‑AI‑Pro‑White) is a high‑performance 8MP, 4K PoE camera designed for professional surveillance. Featuring 3× optical zoom, long‑range IR night vision up to 25m, and advanced AI detection capabilities including face recognition, license plate recognition, and smart object detection (people, vehicles, animals), it ensures reliable monitoring in both indoor and outdoor environments. With an IP65 weather‑resistant housing and IK04 tamper resistance, the camera is built for durability. It integrates seamlessly with the UniFi Protect Application for configuration and management.

Key Features
8MP resolution (3840 × 2160, 16:9) with 4K video quality
3× optical zoom lens (F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3)
AI detection: face recognition, license plate recognition, smart detections (people, vehicles, animals)
Long‑range IR night vision up to 25m
Two‑way audio with built‑in microphone
IP65 weather‑resistant housing and IK04 tamper resistance
Mounting options: wall, ceiling, pole (included)
Max frame rate: 30 FPS (resolution dependent)
Power input: 802.3af/at PoE (injector not included)
Max power consumption: 11W
Dimensions: Ø86 × 175.3 mm
Net weight: 820g
Gross shipping weight: 1.2–1.5 kg (including packaging)

Technical Specifications
Feature Details
Product Code UVC‑AIPRO‑W
Lens F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3
Resolution 8MP (3840 × 2160, 16:9)
Sensor 1/1.8″ 8MP
Max Frame Rate 30 FPS
Video Compression H.264, MJPG
Ethernet Ports 1 × 10/100/1000
Microphone Two‑way audio
Max Power Consumption 11W
Mounting Wall, ceiling, pole (included)
Night Mode Up to 25m
Operating Temp –20°C to 40°C
PoE Input 802.3af/at
Power Input 802.3af/at
Dimensions Ø86 × 175.3 mm
Net Weight 820g
Gross Shipping Weight 1.2–1.5 kg

What’s Included
1 × Ubiquiti UniFi Protect AI Pro 8MP White IP Camera
Mounting kit (wall, ceiling, pole)
User documentation

Ubiquiti's UVC-AIPRO-B is an 8MP, 4K PoE camera with 3x optical zoom, long-range IR night vision up to 25m, and enhanced AI detection capabilities such as face recognition, license plate recognition and smart detections (People, Vehicles, Animals). The IP65 weather-resistant housing and IK04-rated tamper resistance allow it to be mounted both indoors and outdoors. It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Two-Way Audio
Max Power Consumption: 11W
Mounting: Wall, Ceiling, Pole-Mount (Included)
Night Mode: Up to 25m
Operating Temperature: -20°C to 40°C
PoE Input: 802.3af/at
Power Input: 802.3af/at
Resolution: 8MP 3840 x 2160 (16:9)
Sensor: 1/1.8" 8MP
Video Compression: H.264, MJPG
Dimensions: Ø86 x 175.3 mm
Weight: 820g

Brand: Ubiquiti
Product Code: UVC‑AILPR‑B
Description: Ubiquiti UniFi Protect AI LPR 8MP Black IP Camera

Product Overview
The Ubiquiti UniFi Protect AI LPR (UVC‑AI‑LPR‑B) is a specialised 8MP, 4K IP camera designed for license plate recognition. With 3× optical zoom and long‑range IR night vision, it can accurately capture plates on vehicles moving up to 90 km/h. Built with an IP66 weather‑resistant housing and IK04 tamper resistance, it is suitable for both indoor and outdoor installations. Managed via the UniFi Protect Application, it integrates seamlessly into UniFi surveillance systems for advanced monitoring.

Key Features
8MP resolution (3840 × 2160, 16:9) with 4K video quality
Optimised for license plate recognition up to 90 km/h
3× optical zoom with fixed focal length lens
Long‑range IR LED night vision with IR cut filter
IP66 weather‑resistant housing, IK04 tamper resistance
Two‑way audio with built‑in microphone
Wall or ceiling mounting options
Max frame rate: 30 FPS (resolution dependent)
Power input: 802.3at PoE+ (injector not included)
Max power consumption: 25.5W
Dimensions: 130 × 151.4 × 302.9 mm
Net weight: 1.5 kg
Gross shipping weight: 2.0–2.3 kg (including packaging)

Technical Specifications
Feature Details
Product Code UVC‑AILPR‑B
Lens Fixed focal length
Resolution 8MP (3840 × 2160, 16:9)
Sensor 1/1.8″ 8MP
Max Frame Rate 30 FPS
Video Compression H.264, MJPEG
Ethernet Ports 1 × 10/100/1000
Microphone Yes
Max Power Consumption 25.5W
Mounting Wall or ceiling
Night Mode IR LED illumination, IR cut filter
Operating Temp –30°C to 50°C
PoE Input 802.3at (PoE+)
Power Input 42.5–57V (PoE+)
Dimensions 130 × 151.4 × 302.9 mm
Net Weight 1.5 kg
Gross Shipping Weight 2.0–2.3 kg

What’s Included
1 × Ubiquiti UniFi Protect AI LPR 8MP Black IP Camera
Mounting kit (wall/ceiling)
User documentation

Ubiquiti's UVC-AIDOME-W is an 8MP, 4K PoE camera with long-range IR night vision up to 40m, and enhanced AI detection capabilities such as license plate recognition and smart detections (People, Vehicles, Animals). The IP66 weather-resistant housing and IK10-rated tamper resistance allow it to be mounted indoors or outdoors. It can be configured and managed using the UniFi Protect Application.

*Note: PoE Injector not included.

Specifications

Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Lens: Fixed focal length
Max Frame Rate: 30 FPS (Resolution Dependent)
Microphone: Yes
Max Power Consumption: 10W
Mounting: Wall, Ceiling, Pole-Mount (Included)
Night Mode: Up to 40m (Built-in IR LED illumination and IR cut filter)
Operating Temperature: -30°C to 50°C
PoE Input: 802.3af/at
Power Input: 802.3af/at
Resolution: 8MP 3840 x 2160 (16:9)
Sensor: 1/1.8" 8MP
Video Compression: H.264, MJPG
Dimensions: Ø118 x 90.8 mm
Weight: 700g

Ubiquiti UP-SL is a long-range, low-latency wireless gateway for UniFi Protect sensors. It supports up to 96 Super Link clients and 7 UP-Sense devices over a range of up to 2 km. Featuring a 10/100 Mbps Ethernet port and Bluetooth/Super Link management, it’s powered via PoE or USB-C (adapter not included). It is configured and managed through the UniFi Protect Application.

*Note: PoE and USB-C Adapter not included.

Specifications

Antenna Gain: Bluetooth: 3dBi; Super Link: 1dBi
Ethernet Ports: x1 10/100
Max. Power Consumption: 3.4W
Mounting: Wall or DIN-rail
Operating Temperature: 0 to 40°C
Power Input: PoE or USB-C
PoE Input: 802.3af
Dimensions: 159.3 x 81.9 x 30.5 mm
Weight: 179g

Brand: Ubiquiti
Product Code: UNAS‑PRO
Description: Ubiquiti UniFi NAS Pro 2U 7 Drive Bays

Product Overview
The Ubiquiti UniFi NAS Pro (UNAS‑Pro) is a powerful 2U rack‑mount network attached storage solution designed for enterprise‑level file storage and sharing. Featuring 7 × 2.5/3.5″ drive bays, 1 × Gigabit Ethernet port, and 1 × 10Gbps SFP+ uplink port, it delivers high‑capacity storage with fast connectivity. Equipped with a 1.3″ touchscreen for easy management, RAID storage technology for data protection, and a 1.7GHz Quad‑Core ARM Cortex‑A57 CPU with 8GB system memory, the UNAS‑Pro ensures reliable performance for demanding environments.

Key Features
2U rack‑mount NAS with 7 × 2.5/3.5″ drive bays
1 × Gigabit Ethernet port and 1 × 10Gbps SFP+ port
1.3″ touchscreen for system management
RAID storage technology for data protection
Quad‑Core ARM Cortex‑A57 CPU at 1.7GHz
8GB system memory
Max power consumption: 160W (135W drive budget)
Operating system: UniFi Drive
Operating temperature: –5°C to 40°C
Dimensions: 442 × 325 × 87 mm
Net weight: 7.5 kg
Gross shipping weight: 9.0–9.5 kg (including packaging)

Note: Hard drives not included

Technical Specifications
Feature Details
Product Code UNAS‑PRO
Ethernet Ports 1 × 10/100/1000
SFP Ports 1 × 10Gbps
Hardware Button Reset
Max Power Consumption 160W
Drive Power Budget 135W
Mounting 2U rack‑mount
Operating System UniFi Drive
Operating Temp –5°C to 40°C
PoE Input None
PoE Output None
Power Input 1 × IEC Power Cord (included)
Processor Quad‑Core ARM Cortex‑A57 at 1.7GHz
System Memory 8GB
Serial Interface 1 × RJ45
USB Ports None
Dimensions 442 × 325 × 87 mm
Net Weight ~7.5 kg
Gross Shipping Weight 9.0–9.5 kg

What’s Included
1 × Ubiquiti UniFi NAS Pro (UNAS‑Pro)
1 × IEC Power Cord
Rack‑mount accessories (as per retail packaging)
User documentation
