The Hikvision DS‑2AE4225TI‑D Turbo Speed Dome Camera is a powerful 2MP analogue PTZ solution designed for professional surveillance. Featuring 1920×1080 resolution and a 25× optical zoom (4.8–120mm) with 16× digital zoom, it delivers sharp detail across wide coverage areas.

Equipped with IR illumination up to 30m, the camera ensures clear imaging in low‑light conditions. Its 360° endless pan and 300 preset positions provide flexible monitoring, while 4 pattern scans allow automated patrols.

Built to withstand harsh environments, the DS‑2AE4225TI‑D is rated IP66 weatherproof with TVS 4kV lightning protection. Powered via 12VDC or PoE+, it offers installation flexibility. Compact at Φ164.5 × 290 mm and weighing 2kg, it is ideal for outdoor and high‑security applications.

Technical Details:

Model / SKU: DS‑2AE4225TI‑D
Resolution: 2MP (1920×1080)
Optical Zoom: 25× (4.8–120mm)
Digital Zoom: 16×
IR Range: 30m
Pan/Tilt: 360° endless pan, multiple tilt angles
Presets: 300 positions, 4 pattern scans
Protection: IP66 weatherproof, TVS 4kV surge protection
Power Supply: 12VDC / PoE+
Dimensions: Φ164.5 × 290 mm
Weight: 2kg
Form Factor: 4" Turbo Speed Dome

The Ubiquiti UniFi Protect G6 Dome (UVC‑G6‑Dome‑W) is a premium 8MP 4K IP camera designed for professional surveillance. Featuring a 1/1.8" image sensor, ultra‑wide viewing angle, and Multi‑TOPS AI engine, it delivers intelligent detection and crystal‑clear video quality.
With long‑range IR night vision up to 30m and a mechanical IR cut filter, the G6 Dome ensures reliable performance day and night. Built to last, it is both IP66 weatherproof and IK10 vandal‑resistant, making it ideal for outdoor and high‑risk environments.
The camera includes a built‑in microphone for audio capture and supports H.264 and MJPEG compression for efficient storage. Powered via 802.3af/at PoE (injector not included), it consumes just 9.25W and operates in temperatures from ‑20°C to 50°C.
Compact at Ø144.7 × 96.3 mm and weighing 820 g, the G6 Dome is designed for wall or ceiling mounting and integrates seamlessly with the UniFi Protect application for centralized management.

Technical Details:

Model / SKU: UVC‑G6‑Dome‑W
Resolution: 3840 × 2160 (16:9), 8MP 4K
Sensor: 1/1.8" 8MP image sensor
Lens: Fixed focal length, ultra‑wide angle
Frame Rate: Up to 30 FPS (resolution dependent)
Night Vision: IR LEDs with mechanical IR cut filter, up to 30m
AI Engine: Multi‑TOPS for intelligent detection
Audio: Built‑in microphone
Ethernet Ports: 1 × 10/100
PoE Input: 802.3af/at PoE, 37–57V
Power Consumption: Max 9.25W
Mounting: Wall or ceiling mount
Operating Temperature: ‑20°C to 50°C
Protection: IP66 weatherproof, IK10 vandal‑resistant
Video Compression: H.264, MJPEG
Dimensions: Ø144.7 × 96.3 mm
Weight: 820 g

The Ubiquiti UniFi USW‑Pro‑XG‑8‑PoE is a compact Layer‑3 Etherlighting™ switch designed for high‑performance enterprise networks. Featuring 8× 10Gbps PoE++ ports and 2× 10Gbps SFP+ uplinks, it delivers powerful throughput and flexible connectivity for next‑generation deployments.
With a 155W PoE budget (up to 60W per port), the switch can power demanding devices such as Wi‑Fi 7 access points, PTZ cameras, and VoIP systems. Its fanless design ensures silent operation, while desktop or wall‑mount options make it versatile for different environments.
Managed through the UniFi Network Application, the USW‑Pro‑XG‑8‑PoE integrates seamlessly into UniFi ecosystems, offering centralized configuration, monitoring, and automation. Compact at 210 × 174 × 44 mm and weighing 1.6 kg, it is engineered for reliability with ‑5°C to 45°C operating range and 100–240V AC input.

Technical Details:

Model / SKU: USW‑Pro‑XG‑8‑PoE
Ethernet Ports: 8 × 10Gbps (PoE++)
PoE Output: 802.3af/at/bt, up to 60W per port, 155W total budget
SFP+ Ports: 2 × 10Gbps uplinks
Switching Features: Layer‑3 Etherlighting™, fully managed
Power Input: IEC power cord (included), 100–240V AC
Max Power Consumption: 61W
Operating System: UniFi OS
Operating Temperature: ‑5°C to 45°C
Design: Fanless, silent operation
Mounting: Desktop or wall mount
Dimensions: 210.4 × 173.8 × 43.7 mm
Weight: 1.6 kg

The Ubiquiti UniFi Cloud Gateway Fiber (UCG‑Fiber + M.2 Tray) is a 10Gbps dual‑WAN desktop gateway designed for full‑stack UniFi network management. Equipped with a quad‑core ARM Cortex‑A73 processor at 2.2GHz and 3GB RAM, it delivers enterprise‑grade performance for demanding deployments.
This model includes an M.2 SSD tray (SSD not included), enabling NVR storage expansion up to 2TB for UniFi Protect, making it a versatile gateway + video recorder solution.

Connectivity highlights include:

1× 10Gbps WAN port
4× 2.5Gbps LAN ports (Port 4 supports 802.3at PoE+ output)
2× SFP+ ports (1 WAN, 1 LAN)

Running on UniFi OS, the UCG‑Fiber integrates seamlessly with the UniFi Network Application, offering centralized management of routing, switching, security, and video. Compact at 212.8 × 127.6 × 30 mm and weighing 675 g, it consumes just 29.4W and is powered via a 54V 1.1A adapter (included).

Technical Details:

Model / SKU: UCG‑Fiber + UACC‑SSD‑Tray
Processor: Quad‑core ARM Cortex‑A73, 2.2GHz
System Memory: 3GB
Storage: M.2 SSD tray (≤2TB, SSD not included)
Ethernet Ports: 4 × 2.5Gbps LAN (Port 4 PoE+), 1 × 10Gbps WAN
SFP+ Ports: 2 × (1 WAN, 1 LAN)
PoE Output: 802.3at PoE+ on Port 4
Power Input: 54V 1.1A adapter (included)
Max Power Consumption: 29.4W
Operating System: UniFi OS
Operating Temperature: 0°C to 40°C
Dimensions: 212.8 × 127.6 × 30 mm
Weight: 675 g
Mounting: Desktop

The Ubiquiti UniFi Access Reader Pro Black (UA‑G3‑Pro‑B) is a premium IP55‑rated intercom and access reader designed for seamless integration with UniFi Access Hubs. Featuring a 4.7" touchscreen, face recognition, built‑in NFC card reader, and two‑way audio, it delivers secure, modern, and user‑friendly access control.
With Touch Pass support (10 free passes included in the first year), users can enjoy convenient mobile access, with annual renewals available thereafter. Connectivity options include BLE 4.2, NFC, and Gigabit Ethernet, while 802.3af PoE ensures simple powering with a maximum consumption of just 6W.
Compact at 160 × 40.4 × 40.55 mm and weighing only 136 g, the UA‑G3‑Pro‑B is designed for wall‑mount or gang‑box installation, with optional angle and junction box mounts available. Built to withstand harsh conditions, it operates reliably in temperatures from ‑30°C to 45°C (device) and ‑10°C to 45°C (display).

Technical Details:

Model / SKU: UA‑G3‑Pro‑B
Type: UniFi Access Reader Pro (Black)
Display: 4.7" touchscreen
Features: Face recognition, NFC card reader, Touch Pass support, 2‑way audio
Connectivity: BLE 4.2, NFC, 1 × Gigabit Ethernet
Power Input: 802.3af PoE (not included), max 6W
Mounting: Wall‑mount & gang‑box (included); angle mount & junction box (optional)
Operating Temperature: Device: ‑30°C to 45°C; Display: ‑10°C to 45°C
Protection: IP55 weatherproof
Dimensions: 160 × 40.4 × 40.55 mm
Weight: 136 g

Requirement: Must be paired with UniFi Access Hub

The UltraLAN SF1010PG AI PoE Switch is a compact yet powerful 10‑port Fast Ethernet switch designed for branch networks, CCTV surveillance, and wireless access deployments. Featuring 8 PoE ports and 2 Gigabit uplinks, it ensures smooth connectivity to NVRs and core networks.
With a 65W PoE budget and support for IEEE 802.3af/at/bt standards, ports 7–8 deliver up to 60W each, making it ideal for powering PTZ cameras or high‑power wireless radios.
Advanced AI features include:
AI VLAN: isolates PoE ports to prevent broadcast storms
AI Extend: supports long‑distance PoE runs up to 250m
AI Auto‑Recovery: automatically reboots failed PD devices
The switch also provides 6kV surge protection, overload, and thermal safeguards, ensuring reliable operation in challenging environments. With a 5.6Gbps switching capacity and fanless design, the SF1010PG is optimized for quiet, efficient performance in compact installations.

Technical Details:

Model / SKU: SF1010PG
Ports: 8 × Fast Ethernet PoE + 2 × Gigabit uplinks
PoE Budget: 65W total, up to 60W on ports 7–8
PoE Standard: IEEE 802.3af/at/bt
Long‑Reach PoE: Up to 250m (Extend mode)
Switching Capacity: 5.6Gbps
Surge Protection: 6kV lightning, overload, thermal protection
Design: Fanless, metal enclosure
Dimensions: 210 × 152 × 40 mm
Use Case: Branch networks, NVR backhaul, PTZ cameras, wireless APs

The UltraLAN SF1018P AI PoE Switch is a powerful 16‑port Fast Ethernet PoE switch with 2 Gigabit uplinks and 1 Gigabit SFP combo port, engineered for surveillance, hospitality, and enterprise edge networks.
With a 150W PoE budget and support for 802.3af/at/bt standards, it delivers up to 60W per port on ports 15–16, making it ideal for powering PTZ cameras or high‑draw wireless radios.

Advanced AI automation features include:
AI PoE auto‑recovery automatically reboots failed devices
AI Extend mode supports long‑distance PoE up to 250m
AI QoS: prioritizes video traffic for smoother CCTV performance

The switch also provides 6kV surge protection, over‑voltage, and thermal safeguards, ensuring reliability in demanding environments. With a 7.2Gbps switching capacity and 8K MAC table, it is optimized for large camera clusters and multi‑floor deployments.

Technical Details:

Model / SKU: SF1018P
Ports: 16 × Fast Ethernet PoE + 2 × Gigabit RJ45 + 1 × Gigabit SFP
PoE Budget: 150W total, up to 60W on ports 15–16
PoE Standard: IEEE 802.3af/at/bt
Long‑Reach PoE: Up to 250m (ports 1–8)
Switching Capacity: 7.2Gbps
MAC Table: 8K entries
AI Features: Auto‑recovery, Extend mode, QoS prioritization
Surge Protection: 6kV lightning, over‑voltage, thermal protection
Design: Fanless, metal enclosure
Dimensions: 440 × 180 × 44 mm
Use Case: Hotels, schools, apartment buildings, factories, CCTV clusters

The UltraLAN SF1026PG AI PoE Switch is a robust 24‑port Fast Ethernet PoE switch with 2 Gigabit uplinks and 1 Gigabit SFP combo port, purpose‑built for large CCTV and wireless deployments in hotels, campuses, residential complexes, and SMEs.
Delivering a 250W PoE budget (30W per port), it powers high‑draw devices such as IP cameras and access points with ease. Advanced AI automation modes include:
AI VLAN: isolates ports to stabilize CCTV networks
AI Extend: enables 250m long‑range PoE on ports 1–8
AI PoE recovery: auto‑restores unresponsive devices
AI QoS: prioritizes video streams for smoother surveillance
With enterprise‑grade surge protection (6kV) and fanless metal design, the SF1026PG ensures silent, reliable operation. Its 8.8Gbps switching capacity and 8K MAC table provide strong performance for multi‑floor and high‑density environments.

Technical Details:

Model / SKU: SF1026PG
Ports: 24 × Fast Ethernet PoE + 2 × Gigabit RJ45 + 1 × Gigabit SFP (combo)
PoE Budget: 250W total, 30W per port
Switching Capacity: 8.8Gbps
MAC Table: 8K entries
AI Features: VLAN, Extend (250m on ports 1–8), PoE recovery, QoS prioritization
Surge Protection: 6kV lightning, power & temperature protection
Design: Fanless, metal enclosure
Dimensions: 440 × 180 × 44 mm
Use Case: Large CCTV clusters, hotels, campuses, SMEs

The Reolink Home Hub (RLH‑HH0164) is a compact wireless security center designed to manage and protect your home surveillance system with encrypted local storage and multi‑device management.
It comes with a 64GB microSD card included and supports expansion up to 2×512GB via dual microSD slots, giving you flexible storage without monthly fees. Unlike cloud storage, your recordings remain offline, encrypted, and fully private, ensuring maximum data security.
Supporting up to 8 Reolink cameras with 16MP ultra‑HD live view and playback, the Home Hub integrates seamlessly with dual‑band Wi‑Fi and Wi‑Fi 6 cameras. It also functions as a smart alarm hub, triggering alerts when connected IP cameras detect motion, with customizable ringtones for a personalized experience.
Additional features include LAN access for local control, multi‑user permissions (1 admin + 10 sub‑accounts), timelapse recording, and regular security summaries to track detection events daily, weekly, or monthly.
Compact and easy to set up, the Reolink Home Hub is the perfect solution for privacy‑focused, fee‑free home security management.

Technical Details:

Model / SKU: RLH‑HH0164
Storage: 64GB microSD included; expandable up to 2×512GB
Camera Support: Up to 8 Reolink cameras (PoE, plug‑in Wi‑Fi, most battery Wi‑Fi; excludes 2MP battery & 4G cams)
Streaming: Up to 16MP live view & playback
Connectivity: Dual‑band Wi‑Fi, LAN access
Smart Features: Alarm hub, timelapse recording, regular security summaries
Management: Multi‑user permissions (1 admin + 10 sub‑accounts), Reolink App
Operating Temperature: 0°C to 40°C
Power Supply: 12V DC
Setup: Simple 3‑step installation (hub setup, initialization, camera add)

The Reolink Home Hub Pro (RLH‑HHP01) is a next‑generation wireless security center designed to unify and protect your home surveillance system. With a built‑in 2TB HDD and support for expansion up to 16TB, it provides encrypted local storage with no monthly fees, ensuring your data remains private and under your control.
Supporting up to 24 Reolink cameras (including PoE, plug‑in Wi‑Fi, and most battery Wi‑Fi models), the Home Hub Pro delivers 16MP live streaming and smart playback across multiple channels. It integrates seamlessly with Wi‑Fi 6 technology, offering superior speed, coverage up to 1000 m², and lag‑free connectivity for modern Reolink cameras.
The hub doubles as a smart alarm center, triggering siren alerts for person, vehicle, or animal detection, with customizable ringtones. Weekly summaries provide clear insights into alarm trends and events, while multi‑user permissions and QR‑code sharing make management simple.
With USB export for secure backups, LAN access for local control, and features like timelapse recording, the Reolink Home Hub Pro is the ultimate all‑in‑one NVR solution for residential and SMB security.

Technical Details:

Model / SKU: RLH‑HHP01
Storage: Built‑in 2TB HDD, expandable up to 16TB
Camera Support: Up to 24 Reolink cams (PoE, plug‑in Wi‑Fi, most battery Wi‑Fi; excludes 2MP battery & 4G cams)
Streaming: Up to 16MP live view & playback
Connectivity: Wi‑Fi 6 (5GHz/2.4GHz), LAN access
Coverage: Up to 1000 m² Wi‑Fi range
Smart Features: Siren alerts, weekly summaries, timelapse recording
Backup: USB export, encrypted local storage
Management: Multi‑user permissions, QR‑code sharing, Reolink App
Operating Temperature: 0°C to 40°C
Power Supply: 12V DC
Dimensions: Compact desktop/wall‑mount design

The Hikvision DS‑KIS602 IP Video Intercom Kit is a complete solution for secure villa or house entry management. Featuring a 2MP door‑station camera with a wide 146° field of view and IR night vision up to 3m, it ensures clear monitoring day or night.
The kit includes a 7" indoor touch‑screen monitor (1024×600 resolution) for intuitive operation, supporting PoE or 12V power supply. With 4 alarm inputs, 2 lock relay outputs, and Wi‑Fi connectivity, it integrates seamlessly into modern smart home setups.
Designed for durability, the outdoor station operates in extreme temperatures from ‑40°C to 60°C and is surface‑mountable for easy installation. The Hik‑Connect mobile app provides remote access, notifications, and video communication, making it ideal for residential security.

Technical Details:

Model / SKU: DS‑KIS602
Kit Components: 2MP door‑station + 7" indoor touch‑screen
Door‑station camera: 2MP, 146° wide angle, IR 3m
Indoor monitor: 7" touch‑screen, 1024×600 resolution
Power: PoE or 12V DC
Connectivity: Wi‑Fi, Hik‑Connect app support
Alarm inputs: 4
Lock relay outputs: 2
Operating temperature: ‑40°C to 60°C
Mounting: Surface mount
Warranty: 1 year

The Hikvision DS‑E04NI‑Q1‑4P‑SSD‑1TB is a compact, palm‑size 4‑channel PoE NVR built for discrete, low‑power surveillance applications. It ships with a pre‑installed 1 TB embedded SSD for reliable continuous recording and fast boot times. Supporting up to 4 MP recording with H.265+ compression and 4‑channel decoding, the unit offers efficient storage and smooth playback in a tiny footprint. Four integrated PoE AF/AT ports deliver power and network over single cables, while HDMI and USB outputs provide easy local monitoring and export. With very low power consumption and wide operating temperatures, this NVR is ideal for kiosks, retail counters, small offices, and remote sites that need dependable 24/7 recording without a large physical or power footprint.

Technical Details:

Model / SKU: DS‑E04NI‑Q1‑4P‑SSD‑1TB
Channels: 4 IP camera inputs
Storage (included): 1 × 1 TB embedded SSD (pre‑installed)
Max recording: Up to 4 MP
Incoming bandwidth: 40 Mbps
Decoding: Up to 4‑ch 1080p decode (4‑ch simultaneous playback)
Compression: H.265+, H.265, H.264
PoE: 4 × PoE AF/AT ports (power budget dependent on SKU)
Video outputs: HDMI local output
I/O: 1 × USB (export/backup), HDMI, Reset button
Power: ≤ 10 W (typical)
Operating temp / humidity: -10 to 50 °C; commercial humidity ranges
Dimensions: 160 × 112 × 27 mm
Form factor: Ultra‑compact / palm‑size
Use cases: Retail counters, kiosks, remote offices, home entry points

The Hikvision DS‑7616NXI‑K2 is a compact 1U AcuSense NVR delivering enterprise‑grade features in a small footprint. It combines 16 built‑in PoE ports with a 200 W power budget, 160 Mbps incoming throughput, and support for up to 12MP recording. AcuSense AI performs face and perimeter detection to reduce false alarms, while 4K HDMI output and dual SATA bays (up to 20 TB) provide flexible local monitoring and storage. Optimized H.265+ compression, robust alarm I/O, and multi‑channel playback make this NVR ideal for retail, SMB, and campus deployments that need intelligent, reliable surveillance.

Technical Details:

Model / SKU: DS‑7616NXI‑K2
Channels: 16 IP camera inputs
PoE: 16 × PoE ports; total PoE budget 200 W
Incoming bandwidth: 160 Mbps
Max recording: Up to 12 MP
Compression: H.265+, H.265, H.264
Video outputs: 1 × 4K HDMI (local display)
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection (channel limits per firmware)
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Form factor: 1U rack/desktop
Typical operating ranges: commercial temperature/humidity (refer to datasheet for exact specs)

The TP‑Link VIGI‑NVR1008H‑8MP is an 8‑channel PoE+ 4K NVR offering robust performance for small to medium surveillance installations. With a 113 W PoE power budget it supplies power and network to up to eight PoE+ cameras, supports up to 8MP recording, and provides H.265+ compression to maximise storage efficiency. Local monitoring is via 4K HDMI output; playback supports up to eight channels simultaneously. A single SATA bay supports up to 16 TB for long retention, while ONVIF compatibility and the VIGI app enable flexible integrations and remote management. Compact (294 × 180 × 44 mm) and easy to deploy, it’s ideal for retail, offices, and residential estates.

Technical Details:

Model / SKU: VIGI‑NVR1008H‑8MP
Channels: 8 IP camera inputs
PoE: PoE+ with 113 W total budget (powers up to eight cameras depending on camera draw)
Max recording: Up to 8 MP
Incoming bandwidth: 80 Mbps
Outgoing bandwidth: 60 Mbps
Compression: H.265+, H.265, H.264
Decoding / Playback: Up to 8‑ch simultaneous playback
Video outputs: 1 × 4K HDMI (local monitor)
Storage: 1 × SATA bay, up to 16 TB (single HDD)
Integration: ONVIF compliant; remote management via VIGI app
Form factor / Dimensions: Compact desktop / rackable style; 294 × 180 × 44 mm
Operating environment: Typical commercial ranges (refer to official datasheet for exact specs)

The Hikvision DS‑7616NXI‑K2/16P is a compact 1U 16‑channel AcuSense NVR delivering intelligent, high‑resolution surveillance for medium sites. It includes 16 built‑in PoE ports for streamlined camera power and connectivity, supports up to 12MP recording with H.265+ compression to save storage, and provides a 4K HDMI output for crisp local monitoring. AcuSense AI offers face recognition and perimeter protection to reduce false alarms and prioritise critical events. Dual SATA bays allow flexible storage (up to 20 TB total), while 160 Mbps incoming bandwidth and robust alarm I/O make this NVR suitable for retail, SMB, and campus deployments requiring reliable, feature‑rich video management.

Technical Details:

Model / SKU: DS‑7616NXI‑K2/16P
Channels: 16 IP camera inputs
PoE: 16 × PoE ports (total power budget depends on SKU/PSU)
Max recording: Up to 12 MP
Incoming bandwidth: 160 Mbps
Compression: H.265+, H.265, H.264
Video output: 1 × 4K HDMI (local display)
Decoding / Playback: Multi‑channel playback; smart search/playback features supported
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection (channel limits per firmware)
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Operating environment: Commercial operating ranges (refer to datasheet for specifics)

The Hikvision DS-7608NXI-K2 is a compact 1U 8‑channel AcuSense NVR designed for small-to-medium deployments that need smart analytics and reliable local monitoring. It features eight integrated PoE ports for streamlined camera power and connectivity, supports up to 12MP recording with H.265+ compression, and offers 4K HDMI output for crisp local display. AcuSense AI provides face and perimeter detection to reduce false alerts, while dual SATA bays allow flexible storage (up to 20 TB total). With 80 Mbps incoming bandwidth, robust alarm I/O, and a compact chassis, this NVR balances performance, manageability, and cost-effectiveness.

Technical Details:

Channels: 8 IP camera inputs
PoE: 8 × PoE ports (power budget depends on SKU/PSU)
Max recording: Up to 12 MP
Incoming bandwidth: 80 Mbps
Decoding / Playback: Multi‑channel playback; H.265+/H.265/H.264 support
Video outputs: 1 × 4K HDMI (local monitor)
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Weight: ~3.0 kg (unit)
Operating conditions: Typical commercial operating ranges (refer to datasheet for specifics)
Model / SKU: DS‑7608NXI‑K2 (8‑PoE variant)

The Hikvision DS-7716NXI-I4/16P/S is a 16‑channel 1.5U AcuSense 4K NVR engineered for mid‑to‑large deployments that require smart analytics and heavy storage. With a 160 Mbps incoming bandwidth, 16 integrated PoE ports, and four 4K HDMI outputs, it delivers high‑throughput recording and flexible local monitoring. AcuSense AI supports face recognition and perimeter protection on up to four channels to reduce false alarms and prioritise events. Robust storage options (4 × SATA up to 56 TB total), H.265+ compression, multi‑channel 1080p decoding, and comprehensive alarm I/O make this NVR ideal for campuses, retail, and enterprise installations demanding reliable, intelligent video management.

Technical Details:

Channels: 16‑channel input; 32‑channel 1080p decode
Form Factor: 1.5U chassis
Incoming Bandwidth: 160 Mbps
Video Outputs: 4 × 4K HDMI (local displays)
Compression: H.265+, H.265, H.264
AI Features: AcuSense face recognition & perimeter protection (up to 4 channels)
Storage: 4 × SATA bays, up to 14 TB per bay (total up to 56 TB)
Alarm I/O: 16 inputs / 9 outputs (16/9 configuration)
PoE: 16 × PoE ports integrated (power budget dependent on PSU/ SKU)
Playback: Multi‑channel synchronous playback; smart search & playback features
Network: Gigabit NIC(s); ONVIF compatibility for third‑party cameras
Model / SKU: DS-7716NXI-I4/16P/S

The Hikvision DS-7732NXI-I4/16P/S is a 32‑channel 1U AcuSense 4K NVR built for large deployments that need smart analytics and ample storage. It supports 16 PoE ports for direct camera power, up to 256 Mbps incoming bandwidth, and 4K HDMI output for crisp monitoring. AcuSense AI enables perimeter protection and face recognition on up to 4 channels, while 32‑channel 1080p decoding ensures smooth playback across many streams. With four SATA bays (up to 16 TB each) plus eSATA expansion, flexible alarm I/O (16 in / 9 out), and a robust 445 × 400 × 75 mm chassis, it’s ideal for campuses, retail estates, and multi‑site systems.

Technical details:

Channels: 32‑channel input; 32‑channel 1080p decode
PoE ports: 16 × PoE (integrated)
Bandwidth: Up to 256 Mbps incoming
Video output: 4K HDMI (plus standard outputs)
AI features: AcuSense perimeter protection + face recognition (up to 4 channels)
Playback: Multi‑channel synchronous playback
Compression: H.265+, H.265, H.264
Storage: 4 × SATA bays, up to 16 TB each; 1 × eSATA expansion
Alarm I/O: 16 inputs / 9 outputs
Dimensions: 445 × 400 × 75 mm
Model / SKU: DS-7732NXI-I4/16P/S

The Hikvision DS-7104NI-Q1/4P is a compact 4‑channel 1U Mini NVR with built‑in PoE for simplified installation. Supporting up to 6MP recording and 4‑channel 1080p decoding, it delivers reliable performance for small to medium surveillance setups. With 40 Mbps incoming bandwidth and 60 Mbps outgoing, HDMI/VGA outputs, and H.265+ compression, it ensures efficient storage and smooth playback. A single SATA interface supports up to 6 TB HDD, while the 36 W PoE budget powers up to four IP cameras directly. Compact (200 × 200 × 48 mm), powered by DC 48V, and operating in -10~55°C, this NVR is ideal for cost‑effective, space‑saving deployments.

Technical Details:

Channels: 4‑channel input
Form Factor: 1U Mini NVR
PoE Ports: 4 × PoE, 36 W total budget
Recording: Up to 6MP/4MP resolution
Bandwidth: 40 Mbps incoming, 60 Mbps outgoing
Decoding: 4‑channel 1080p synchronous playback
Video Output: HDMI & VGA
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 6 TB HDD
Power: DC 48V
Operating Temperature: -10°C to +55°C
Dimensions: 200 × 200 × 48 mm
Model / SKU: DS-7104NI-Q1/4P

The TP-Link VIGI-NVR1104H-4P is a 4‑channel PoE+ 4K NVR designed for efficient and intelligent video management. Supporting up to 16 MP decoding, 4K HDMI output, and 4‑channel synchronous playback, it delivers crisp, high‑resolution monitoring. With a 53 W PoE+ power budget, it can directly power and connect up to four IP cameras, simplifying installation. Featuring H.265+ compression for optimized storage, a single SATA interface supporting up to 10 TB HDD, ONVIF compatibility, and a built‑in speaker, this NVR integrates seamlessly with the VIGI app for remote access and management. Compact and reliable, it’s ideal for small to medium surveillance setups.

Technical Details:

Channels: 4‑channel input
PoE+ Budget: 53 W total
Video Output: 4K HDMI
Decoding Capability: Up to 16 MP
Playback: 4‑channel synchronous playback
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 10 TB HDD
Audio: Built‑in speaker
Integration: ONVIF compliant; remote management via VIGI app
Power: PoE+ and 12 VDC support
Model / SKU: VIGI-NVR1104H-4P
