The Reolink RLC‑81PA is a 4K Ultra HD PoE security camera designed for wide‑area coverage with its 180° horizontal pan rotation. Control the camera remotely via the Reolink App/Client and set custom preset points for instant monitoring of key zones. With color night vision, multiple night modes, AI detection, active deterrence, and two‑way audio, it delivers powerful, intelligent protection for homes and businesses. The rugged IP67 aluminum housing, PoE installation, and flexible recording options make it a reliable, long‑term surveillance solution.

✅ Key Specifications
4K Ultra HD (3840×2160) clarity
180° horizontal pan rotation
Color night vision with spotlight
Multiple night modes (IR, color, smart)
AI detection: person, vehicle, pet
Active deterrence: siren + spotlight
Two‑way audio (mic + speaker)
Time‑lapse recording support
PoE single‑cable installation
microSD/NVR/FTP storage options
IP67 weatherproof aluminum housing

✅ Technical Details
Feature Specification
Resolution 4K Ultra HD (3840×2160)
Pan Range 180° horizontal
Night Vision IR up to 30m + color spotlight
Detection AI person, vehicle, pet
Audio Two‑way
Installation PoE (Power over Ethernet)
Storage microSD (256GB), NVR, FTP
Weather Rating IP67
Operating Temperature –10°C to 55°C
Housing Rugged aluminum
Dimensions — (not provided by Reolink)

The Reolink RLC‑81MA is a 4K Ultra HD dual‑lens PoE security camera designed to eliminate blind spots with simultaneous panoramic and telephoto views. Its 109° wide‑angle lens captures the full scene, while the telephoto lens provides detailed close‑ups — all displayed side‑by‑side in one unified feed. With AI‑powered person, vehicle, and pet detection, active deterrence, two‑way audio, and flexible night vision modes, it delivers professional‑grade protection for homes and businesses. The IP66 weatherproof housing, PoE installation, and multiple recording options make it a powerful, long‑term surveillance solution.

✅ Key Specifications
Dual‑lens panoramic + telephoto dual view
4K Ultra HD 8MP resolution
Flexible night vision: B&W, color, smart
AI detection: person, vehicle, pet
Active deterrence: siren + spotlights
Two‑way audio (mic + speaker)
Time‑lapse recording (wide‑angle only)
PoE single‑cable installation
microSD/NVR/FTP storage options
IP66 weatherproof housing

✅ Technical Details
Feature Specification
Resolution 4K Ultra HD (3840×2160)
Lenses Dual (wide‑angle + telephoto)
Field of View 109° panoramic + telephoto close‑up
Night Vision IR up to 30m + full‑color spotlight
Detection AI person, vehicle, pet
Deterrence Siren + dual spotlights
Audio Two‑way (mic + speaker)
Installation Power over Ethernet (PoE)
Storage microSD (256GB), NVR, FTP
Weather Rating IP66
Operating Temperature –10°C to

The Reolink RLC‑811A is a 4K Ultra HD PoE security camera built for powerful, intelligent protection. With AI‑powered person, vehicle, and pet detection, it filters out false alerts from shadows, insects, and tree movement so you only get notifications that matter. The built‑in dual spotlights and siren provide active deterrence, while the 5× optical zoom and motorized varifocal lens deliver flexible, high‑detail coverage. Enjoy full‑color night vision, two‑way audio, PoE installation, and multiple recording options, all inside a durable IP66 weatherproof housing.

✅ Key Specifications
4K Ultra HD (3840×2160) clarity
AI person/vehicle/pet detection
Active deterrence: spotlights + siren
Two‑way audio (mic + speaker)
5× optical zoom (31°–105° FoV)
Full‑color night vision with spotlights
30m IR night vision
PoE single‑cable installation
microSD/NVR/FTP/Cloud storage options
IP66 weatherproof housing

✅ Technical Details
Feature Specification
Resolution 4K Ultra HD (3840×2160)
Lens Motorized varifocal, 5× optical zoom (31°–105° FoV)
Night Vision IR up to 30m + full‑color spotlight mode
Audio Two‑way (microphone + speaker)
Deterrence Siren + dual spotlights
Detection AI person/vehicle/pet recognition
Connectivity PoE (Power over Ethernet)
Storage microSD (256GB), NVR, FTP, Cloud
Weather Rating IP66
Operating Temperature –10°C to 55°C
Dimensions 238 × 90 × 90

The Reolink RLC‑810A is a 4K Ultra HD PoE security camera built for high‑precision monitoring with AI‑powered person, vehicle, and pet detection. Its advanced motion analysis filters out irrelevant triggers like insects, shadows, and moving branches, ensuring you only receive alerts that matter. With 18× IR LEDs, 100ft night vision, and PoE single‑cable installation, it delivers professional‑grade performance for homes, businesses, and multi‑camera setups. The IP66 weatherproof housing and flexible microSD/NVR/FTP storage options make it a durable, long‑term surveillance solution.

✅ Key Specifications
4K Ultra HD (3840×2160) clarity
AI person/vehicle/pet detection
18× IR LEDs with 30m night vision
Time‑lapse recording support
PoE single‑cable power & data
Reolink NVR compatible
IP66 weatherproof housing
microSD/NVR/FTP/Cloud storage options

✅ Technical Details
Feature Specification
Resolution 4K Ultra HD (3840×2160)
Lens Fixed 4.0mm
Night Vision 18× IR LEDs, up to 30m
Audio None (video only)
Detection AI person/vehicle/pet
Connectivity PoE (Power over Ethernet)
Storage microSD (256GB), NVR, FTP, Cloud
Weather Rating IP66
Operating Temperature –10°C to 55°C
Dimensions 186 × 66 × 66 mm

The Reolink RLC‑520A is a 5MP Super HD PoE dome camera built for reliable, discreet, and accurate outdoor monitoring. With AI‑powered person and vehicle detection, it filters out false alerts from insects, rain, and moving branches, ensuring you only get notifications that matter. Its 18× IR LEDs deliver up to 30m night vision, while the built‑in microphone adds valuable audio context. The IP66 weatherproof dome, PoE single‑cable installation, and microSD/NVR/FTP storage options make it ideal for entrances, high‑traffic areas, and commercial environments.

✅ Key Specifications
5MP Super HD (2560×1920) clarity
AI person & vehicle detection
18× IR LEDs with 30m night vision
Built‑in microphone for audio capture
Time‑lapse recording support
PoE single‑cable power & data
Reolink NVR compatible
IP66 weatherproof dome housing
microSD/NVR/FTP/Cloud storage options

✅ Technical Details
Feature Specification
Resolution 5MP (2560 × 1920)
Lens Fixed 4.0mm
Night Vision 18× IR LEDs, up to 30m
Audio Built‑in microphone
Detection AI person/vehicle
Connectivity PoE (Power over Ethernet)
Storage microSD (256GB), NVR, FTP, Cloud
Weather Rating IP66
Operating Temperature –10°C to 55°C
Dimensions 108 × 93 mm

The Reolink RLC‑510A is a 5MP Super HD PoE security camera designed to deliver accurate, reliable protection with AI‑powered person and vehicle detection. Its advanced motion analysis filters out shadows, insects, and tree movement, ensuring you only receive alerts that matter. With 30m infrared night vision, a built‑in microphone, and PoE single‑cable installation, it’s ideal for homes, offices, and retail environments. The IP66 weatherproof housing, microSD/NVR/FTP storage options, and time‑lapse recording make it a versatile and dependable surveillance solution.

✅ Key Specifications
5MP Super HD (2560×1920) clarity
AI person & vehicle detection
18× IR LEDs with 30m night vision
Built‑in microphone for audio recording
Time‑lapse recording support
PoE single‑cable power & data
Reolink NVR compatible
IP66 weatherproof housing
microSD/NVR/FTP/Cloud storage options

✅ Technical Details
Feature Specification
Resolution 5MP (2560 × 1920)
Lens Fixed 4.0mm
Night Vision 18× IR LEDs, up to 30m
Audio Built‑in microphone
Detection AI person/vehicle
Connectivity PoE (Power over Ethernet)
Storage Options microSD (256GB), NVR, FTP, Cloud
Operating Conditions –10°C to 55°C
Weatherproof IP66
Dimensions 186 × 66 × 66 mm

The Reolink RLC‑1224A is a 12MP Ultra HD PoE security camera engineered for forensic‑grade clarity. With 4000×3000 resolution, an F1.6 super‑aperture lens, and dual night vision (color spotlight + 100ft IR), it captures every detail in both daylight and darkness. AI‑powered detection for people, vehicles, and pets ensures accurate alerts, while forensic zoom allows clear identification of license plates up to 50ft away. Built with IP67 weatherproofing, PoE single‑cable installation, and triple storage options, the RLC‑1224A is ideal for businesses, high‑security homes, and long‑range monitoring.

✅ Key Specifications
12MP Ultra HD resolution
F1.6 super‑aperture low‑light lens
Dual night vision: color + 100ft IR
AI detection: people, vehicles, pets
Forensic zoom for license plate capture
Two‑way audio with noise‑canceling mic
PoE 802.3af single‑cable installation
IP67 weatherproof housing
microSD/NVR/FTP storage options

✅ Technical Details
Feature Specification
Resolution 12MP (4000 × 3000 @ 20fps)
Sensor 1/1.7" CMOS
Night Vision Color spotlight + IR (100 ft)
Smart Detection People, Vehicles, Pets
Audio Two‑way (noise‑canceling)
PoE Standard 802.3af (15.4W)
Weatherproof

The Reolink RLC‑1212A is a forensic‑grade 12MP Ultra HD PoE+ security camera engineered for maximum detail capture. With 4000×3000 resolution, an F1.6 super‑aperture lens, and true color night vision, it delivers evidence‑level clarity day and night. The advanced 1/1.7" CMOS sensor captures more light than standard 4K cameras, while AI detection for people, vehicles, and pets ensures accurate alerts with minimal false triggers. Featuring PoE+ power, two‑way audio, IP67 weatherproofing, and triple storage options, the RLC‑1212A is ideal for businesses, high‑security homes, and long‑range identification tasks such as license plate capture.

✅ Key Specifications
12MP Ultra HD (4000×3000) clarity
F1.6 super‑aperture lens for enhanced low‑light capture
True color night vision + 100ft IR
AI detection: people, vehicles, pets
Forensic zoom for license plate identification
Two‑way audio with noise‑canceling mic
PoE+ 802.3at 30W power delivery
IP67 weatherproof housing
microSD/NVR/FTP storage with AES‑256 encryption

✅ Technical Details
Feature Specification
Resolution 12MP (4000 × 3000 @ 20fps)
Sensor Size 1/1.7" CMOS
Night Vision Color spotlight + IR (100 ft)
Smart Detection People, Vehicles, Pets
Audio Two‑way (noise‑canceling mic)
PoE Standard 802.3at (30W)
Weatherproof IP67
Warranty 2‑Year Limited

The Reolink E1 Outdoor PoE is a compact yet powerful 4K PTZ security camera designed for discreet, intelligent monitoring. With 355° pan, 50° tilt, and auto‑tracking, it keeps people and vehicles perfectly centered in the frame. The dual‑light system delivers full‑color night vision, while AI detection ensures accurate alerts with minimal false triggers. Featuring PoE installation, two‑way audio, hyperlapse recording, and Alexa/Google integration, the E1 Outdoor PoE is ideal for homes, retail spaces, and Airbnb properties needing high‑performance surveillance in a small form factor.

✅ Key Specifications
4K Ultra HD resolution
355° pan + 50° tilt PTZ control
Auto‑tracking for people/vehicles
3000K warm‑light color night vision
IR night vision up to 30 ft
AI detection: people, vehicles
Two‑way audio
PoE 802.3af single‑cable installation
Hyperlapse/time‑lapse recording
IP66 weatherproof housing
Works with Alexa & Google Assistant

✅ Technical Details
Feature Specification
Resolution 4K (3840 × 2160 @ 25fps)
PTZ Range 355° pan / 50° tilt
Night Vision Color (3000K) + IR up to 30 ft
Smart Detection People, Vehicles
Audio Two‑way (mic + speaker)
PoE Standard 802.3af (15.4W)
Weatherproof IP66

The Reolink CX410 is a next‑generation 4MP 2K PoE security camera engineered for unmatched low‑light performance. Featuring ColorX technology, a F1.0 super aperture, and a 1/1.8" advanced sensor, it captures true full‑color footage even at 0.0001 lux, delivering clarity where most cameras fail. The built‑in 3000K warm light, AI smart detection, and dual deterrent system (spotlight + siren) provide intelligent, proactive protection. With PoE installation, two‑way audio, and NVR compatibility, the CX410 is ideal for homes, businesses, and wildlife monitoring.

✅ Key Specifications
4MP 2K ColorX full‑color night vision
F1.0 super aperture + 1/1.8" sensor
3000K adjustable warm light
AI detection: people, vehicles, pets
Dual deterrent: spotlight + siren
PoE single‑cable installation
Two‑way audio
Works with Reolink NVRs (RLN8/16‑410)
IP67 weatherproof housing

✅ Technical Details
Feature Specification
Resolution 4MP (2560 × 1440 @ 30fps)
Night Vision ColorX (0.0001 lux) + IR up to 30 ft
Lens F1.0, 2.8mm fixed (110° FOV)
Smart Detection People, Vehicles, Pets
Audio Two‑way (mic + speaker)
PoE Standard 802.3af (15.4W)
Weatherproof IP67

The Reolink Argus Eco is a 100% wire‑free outdoor security camera designed for effortless installation and reliable protection. With 1080p Full HD clarity, 33ft night vision, and a 130° wide viewing angle, it captures clear footage day and night. The long‑lasting 5200mAh rechargeable battery and optional solar panel provide true maintenance‑free operation. Featuring PIR motion detection, customizable siren alerts, two‑way audio, and Google Assistant integration, the Argus Eco delivers smart, flexible security for any home.

✅ Key Specifications
1080p Full HD video
33ft infrared night vision
130° wide viewing angle
PIR motion detection
5200mAh rechargeable battery
Solar‑ready for continuous power
Two‑way audio
microSD storage up to 256GB
IP65 weatherproof housing
Google Assistant compatible

✅ Technical Details
Feature Spec
Resolution 1080p (1920 × 1080 @ 15fps)
Field of View 130° diagonal
Night Vision IR up to 33 ft
Power 5200mAh battery + solar input
Detection PIR motion sensor
Storage microSD (256GB max)
Smart Home Google Assistant compatible

The Reolink Argus 3 Ultra delivers true 4K 8MP Ultra HD clarity, capturing faces, vehicles, and fine details with exceptional sharpness. With Starlight Color Night Vision, dual‑band Wi‑Fi, and PIR motion detection, it provides reliable, intelligent outdoor protection day and night. Powered by a long‑lasting rechargeable battery or an optional solar panel, it offers complete wire‑free freedom. The IP65 weatherproof design, two‑way audio, and local/cloud storage options make it a powerful, flexible security solution for any home.

✅ Key Specifications
4K 8MP Ultra HD resolution
Starlight color night vision
PIR motion detection
Dual‑band Wi‑Fi 2.4/5GHz
6400mAh rechargeable battery
Solar panel compatible
Two‑way audio
microSD storage up to 256GB + cloud
IP65 weatherproof housing

✅ Technical Details
Feature Spec
Resolution 4K (3840×2160 @15fps) / 2K @30fps
Lens f/1.6 aperture, 130° diagonal FOV
Night Vision Color (0.1 lux) + IR up to 33 ft
Power 6400mAh battery + solar input (5W/2A)
Wi‑Fi Dual‑band 2.4/5GHz (802.11ac)
Weatherproof IP65 (–10°C ~ 55°C)
Storage microSD (256GB max) + Cloud

The Reolink Argus 3 Pro is a professional‑grade wire‑free security camera delivering 5MP Super HD clarity and AI‑powered person/vehicle detection. With color night vision, a customizable spotlight, and dual‑band Wi‑Fi, it ensures smarter alerts and uninterrupted streaming. Powered by a long‑lasting rechargeable battery or optional solar panel, it offers true freedom from wiring. The IP65 weatherproof design makes it ideal for outdoor installation, while local microSD storage and optional cloud backup provide flexible recording options.

✅ Key Specifications
5MP 2K Super HD resolution
130° wide viewing angle
Color night vision + IR up to 33ft
AI person/vehicle detection
6400mAh rechargeable battery
Solar panel ready (optional)
Dual‑band Wi‑Fi (2.4/5GHz)
microSD storage up to 256GB + cloud
IP65 weatherproof housing

✅ Technical Details
Feature Specification
Resolution 2K 5MP (2560 × 1920 @ 15fps)
Night Vision Color spotlight + IR (up to 33 ft)
Detection AI person/vehicle detection
Power 6400mAh battery + solar input
Wi‑Fi Dual‑band 2.4/5GHz
Storage microSD (256GB max) + cloud
Weatherproof IP65 rated (–10°C ~ 55°C)
Viewing Angle 130° wide coverage

The Reolink RLN8‑410 is a complete, ready‑out‑of‑the‑box 4K surveillance hub for homes and small businesses. With an integrated 8‑port PoE switch, it powers and connects up to eight 8MP/4K Reolink cameras using single Ethernet cables and auto‑detects them for true plug‑and‑play setup. H.265+ compression extends retention without sacrificing clarity, while the pre‑installed 6 TB HDD provides ample space for continuous 24/7 recording. Smart person/vehicle detection delivers focused alerts, and 4K HDMI output ensures crystal‑clear local monitoring.

Key features:

Crystal‑clear monitoring: 8 channels at up to 8MP/4K; smooth 3840×2160 @ 25 fps per channel.
Storage built‑in: 6 TB HDD pre‑installed for long retention; expandable for larger archives.
Efficient compression: H.265+ reduces storage needs by up to 80% vs. H.264.
Simplified installation: 8 × PoE ports (15.4 W/port); auto camera discovery for zero‑config setup.
Smart security: AI person/vehicle detection; app‑based smart alerts and remote playback.
Flexible outputs: 4K HDMI for primary display, 1080p VGA for secondary.
Perfect use cases: Whole‑property 4K security, retail/office/warehouse coverage, and easy expandability for tech enthusiasts.

Technical specifications:

Feature Specification
Video input 8 channels @ 8MP (3840×2160 @ 25 fps)
Compression H.265+, H.265, H.264
PoE ports 8 × PoE, 15.4 W per port
Smart detection People, vehicles (NVR and/or camera‑side)
Video outputs 4K HDMI, 1080p VGA
Storage (included) 1 × 6 TB HDD (pre‑installed)
Storage (max) Up to 12 TB total capacity
Plug‑and‑play Auto‑detects Reolink cameras
Note: AI features and frame rates depend on camera capabilities. For third‑party ONVIF cameras, confirm stream compatibility and PoE power requirements.

What’s included:

NVR: Reolink RLN8‑410 with 6 TB HDD pre‑installed
Accessories: Power adapter, USB mouse, quick start guide
Cabling: Ethernet cables and cameras are typically sold separately

Deployment tips:

Power budget: 15.4 W per port suits most fixed‑lens cameras; PTZ or high‑draw models may need external PoE injectors/switches.
Retention planning: Use H.265+ and motion recording with smart filters to extend storage without losing key events.
Network hygiene: Place cameras on a dedicated VLAN, enforce strong credentials, and keep firmware up to date.
Display setup: Use 4K HDMI for your main wall and 1080p VGA for a secondary console.

Brand: Reolink
Product Code: RLN36
Description: Reolink 36‑Channel Smart Network Video Recorder (NVR)

Product Overview
The Reolink RLN36 is a professional‑grade 36‑channel NVR designed for large‑scale surveillance deployments. Supporting 12MP/4K cameras, it offers up to 48TB local storage (3 × 16TB HDD bays) and gigabit networking for reliable 24/7 performance. Smart AI person/vehicle detection streamlines alerts, while 4K HDMI output ensures crisp local monitoring. With 8 alarm inputs and 4 alarm outputs, plus 2‑way audio support, the RLN36 integrates seamlessly into enterprise security setups for campuses, logistics hubs, and multi‑building estates.

Key Features
36 channels with 12MP/4K camera compatibility
Up to 48TB storage (3 × 16TB HDD bays)
Compression formats: H.265+, H.265, H.264
Smart AI detection (person/vehicle)
4K HDMI video output + secondary outputs
ONVIF/RTSP configurable (disabled by default)
8 alarm inputs / 4 alarm outputs
2‑way audio via NVR
Gigabit LAN networking
Dimensions: 330 × 310 × 48 mm
Net weight: 2.26 kg
Estimated gross shipping weight: 3.0–3.5 kg (unit + packaging)

Technical Specifications
Feature Details
Product Code RLN36
Channels 36 (12MP/4K compatible)
Storage Capacity Up to 48TB (3 × 16TB HDD bays)
Compression H.265+, H.265, H.264
Video Output 4K HDMI + secondary outputs
Smart Detection AI person/vehicle (camera/NVR dependent)
Interoperability ONVIF & RTSP configurable
Alarm I/O 8 inputs / 4 outputs
Audio 2‑way audio via NVR
Networking Gigabit LAN
Dimensions 330 × 310 × 48 mm
Net Weight 2.26 kg
Gross Shipping Weight 3.0–3.5 kg
Recommended Setup Direct monitor connection for configuration

What’s Included
1 × Reolink RLN36 NVR
Power adapter
User documentation

Built for demanding, always-on environments, the Reolink RLN16-410 is a 16‑channel PoE NVR that’s truly ready to deploy. With 16 integrated PoE ports (15.4 W each), it powers and connects cameras over single cables, auto‑detects Reolink cameras for instant setup, and supports up to 12MP/4K streams for ultra‑detailed monitoring. H.265+ compression maximizes retention, while the pre‑installed 4 TB HDD and expansion up to 24 TB keep 24/7 recordings accessible. AI person/vehicle detection helps cut false alerts, and 4K HDMI ensures local monitoring at full resolution.

Key features:

All‑in‑one PoE: 16 built‑in PoE ports (15.4 W/port) for power + data over single cables; true plug‑and‑play with Reolink cameras.
Ultra HD support: Compatible with 12MP/4K cameras; 4K HDMI output for sharp local viewing.
Efficient storage: H.265+ compression for reduced bandwidth and storage; pre‑installed 4 TB HDD, expandable up to 24 TB (4 × 6 TB).
AI detection: On‑device smart person/vehicle recognition to reduce false alarms.
Scalable performance: 16 channels at high resolution for multi‑site and enterprise deployments.
Flexible outputs: 4K HDMI + 1080p VGA for versatile monitoring setups.
Deploy anywhere: Ideal for retail, warehouses, offices, estates, farms, and multi‑building sites.

Technical specifications:

Feature Spec
Channels 16 (supports up to 12MP; 8MP at 30 fps)
PoE ports 16 × PoE, 15.4 W per port
Compression H.265+, H.265, H.264
Smart detection People, vehicles
Video outputs 4K HDMI, 1080p VGA
Storage (included) 1 × 4 TB HDD (pre‑installed)
Storage (max) Up to 24 TB (4 × 6 TB)
Plug‑and‑play Auto‑detects Reolink cameras

Tip: For non‑Reolink ONVIF cameras, confirm stream compatibility (codec, resolution, frame rate) and PoE power requirements.

What’s included:

NVR: Reolink RLN16‑410 with 4 TB HDD pre‑installed
Power & accessories: NVR power adapter, mouse, quick start guide
Note: Ethernet cables and cameras are typically sold separately

Deployment recommendations:

Power planning: The total PoE budget is bound by the NVR’s PSU; high‑draw cameras (PTZ, heaters) may need external PoE injectors/switches.
Storage strategy: Use H.265+ where supported; set motion‑based recording with AI filters to extend retention.
Network setup: Isolate camera VLANs for security; enable remote access via secure ports or Reolink app with strong credentials.
Display & monitoring: Use the 4K HDMI output for local multi‑camera walls; VGA for secondary stations.

The Reyee RG-EST350 V2 Wireless Bridge is a high-performance outdoor solution designed for long-range, real-time data transmission. Operating on 5GHz dual-stream 802.11ac (Wi-Fi 5 Wave2), it delivers speeds up to 867Mbps and supports MU-MIMO 2×2 for efficient multi-device communication.

With a 15dBi directional antenna, it can transmit data up to 5KM, making it ideal for surveillance, remote access, and point-to-point networking. The bridge supports up to 45 × 2MP cameras at 3KM and 20 × 2MP cameras at 5KM, ensuring robust throughput for high-density deployments.

Installation is simplified with automatic long-distance pairing, eliminating complex alignment procedures. Rated IP54 weatherproof and built to operate in extreme temperatures from -30°C to 65°C, it’s engineered for reliable outdoor performance. Remote monitoring and maintenance are made easy via Ruijie Cloud, offering intuitive statistics and control.

Key Features
🌐 5GHz Dual-Stream Wi-Fi 5 (802.11ac Wave2) – Fast and stable wireless transmission
📡 15dBi Directional Antenna – Optimized for long-range point-to-point links
🚀 Up to 867Mbps Speed – High bandwidth for real-time data and video
🔄 Automatic Long-Distance Pairing – No complex alignment required
🛡️ IP54 Weatherproof Rating – Built for outdoor environments
❄️ Wide Operating Temperature – -30°C to 65°C for extreme conditions
📷 Supports 45 × 2MP Cameras @ 3KM / 20 @ 5KM – Ideal for surveillance networks
📊 Ruijie Cloud Monitoring – Remote management and performance stats
🔌 2 × Gigabit Ethernet Ports – Seamless wired integration
🕒 3-Year Manufacturer Warranty – Long-term reliability

Technical Specifications
Feature Details
Product Code RG-EST350-V2
Wireless Standard Wi-Fi 5 (IEEE 802.11ac Wave2)
Frequency Band 5GHz
Wi-Fi Speed Up to 867Mbps
Antenna Gain 15dBi Directional
MIMO 2×2 MU-MIMO
Transmission Range Up to 5KM
Wireless Power ≤400mW (26dBm, adjustable)
Ethernet Ports 2 × 10/100/1000Base-T
Operating Temperature -30°C to 65°C
Weatherproof Rating IP54
Certifications CE, RoHS
Environment Outdoor
Warranty 3 Years Limited Manufacturer Warranty

What’s Included
1 × Reyee RG-EST350 V2 Wireless Bridge
1 × Mounting Kit
1 × Quick Start Guide

Brand: Astrum
SKU/Product Code: KBTOL850‑CB
Description: Astrum KBTOL850‑CB is a Chocolate Black US replacement keyboard designed for Toshiba Satellite L850 and compatible series laptops.

Product Overview
The Astrum KBTOL850‑CB replacement keyboard is engineered for Toshiba Satellite L850, L850D, L855, L855D, L870, L870D, L875, and L875D series laptops, offering a durable Chocolate Black US layout with responsive tactile keys. Built with UV‑printed soft‑touch QWERTY keys, it ensures seamless compatibility, reliable performance, and easy installation. Crafted from eco‑friendly components and rigorously factory‑tested, this keyboard delivers both sustainability and uncompromising quality.

Key Features
100% compatible with Toshiba Satellite L850/L855/L870/L875 series
Chocolate Black US layout with soft‑touch QWERTY keys
UV‑printed keys for durability and clarity
Eco‑friendly construction, rigorously factory tested
Easy installation, no special tools required
Warranty: 12 months

Technical Specifications
Feature Details
Product Code KBTOL850‑CB
Brand Astrum
Type Laptop Keyboard Replacement
Layout Black US (QWERTY, Chocolate style)
Frame Without Frame
Warranty 12 months
Certifications CE, RoHS

Compatible Part Numbers
MP‑11B93US‑528W, MP‑11B93US‑528, KBTOL850‑CB, MP‑11B53US‑930W, MP‑11B93US‑930W, 6037B0068102, B0068102120954747

Compatible Models
Toshiba Satellite Series: L850, L850D, L855, L855D, L870, L870D, L875, L875D

Brand: Astrum
SKU/Product Code: KBLEX390‑B
Description: Astrum KBLEX390‑B is a Backlit Black US replacement keyboard with pointer, designed for Lenovo ThinkPad X390 and compatible series laptops.

Product Overview
The Astrum KBLEX390‑B replacement keyboard is engineered for Lenovo ThinkPad X390, X395, and L13 Yoga series laptops, offering a durable Backlit Black US layout with integrated pointer for enhanced navigation. Built with UV‑printed soft‑touch QWERTY keys, it ensures seamless compatibility, reliable performance, and easy installation. Crafted from eco‑friendly components and rigorously factory‑tested, this keyboard delivers both sustainability and uncompromising quality.

Key Features
100% compatible with Lenovo ThinkPad X390/X395/L13 Yoga series
Black US layout with soft‑touch QWERTY keys
Integrated pointer for precision navigation
Backlit design for low‑light typing convenience
UV‑printed keys for durability and clarity
Eco‑friendly construction, rigorously factory tested
Easy installation, no special tools required
Warranty: 12 months

Technical Specifications
Feature Details
Product Code KBLEX390‑B
Brand Astrum
Type Laptop Keyboard Replacement
Layout Black US (QWERTY, Backlit, With Pointer)
Frame Without Frame
Warranty 12 months
Certifications CE, RoHS

Compatible Part Numbers
01YP040, 01YP200, KBLEX390‑B

Compatible Models
Lenovo ThinkPad Series: X390, X395, L13 Yoga

Brand: Astrum
SKU/Product Code: KBLEX270‑B
Description: Astrum KBLEX270‑B is a Backlit Black US replacement keyboard designed for Lenovo ThinkPad X270 and compatible series laptops.

Product Overview
The Astrum KBLEX270‑B replacement keyboard is engineered for Lenovo ThinkPad X270, T460, A275, X230S, X250, X240S, and X260S series laptops, offering a durable Backlit Black US layout with responsive tactile keys. Built with UV‑printed soft‑touch QWERTY keys, it ensures seamless compatibility, reliable performance, and easy installation. Crafted from eco‑friendly components and rigorously factory‑tested, this keyboard delivers both sustainability and uncompromising quality.

Key Features
100% compatible with Lenovo ThinkPad X270/T460/A275/X230S/X250/X240S/X260S series
Backlit Black US layout with soft‑touch QWERTY keys
UV‑printed keys for durability and clarity
Eco‑friendly construction, rigorously factory tested
Easy installation, no special tools required
Warranty: 12 months

Technical Specifications
Feature Details
Product Code KBLEX270‑B
Brand Astrum
Type Laptop Keyboard Replacement
Layout Black US (QWERTY, Backlit)
Frame Without Frame
Warranty 12 months
Certifications CE, RoHS
Compatible Models
Lenovo ThinkPad Series: X270, T460, A275, X230S, X250, X240S, X260S
