Hikvision 8-ch 1080p 1U H.265 AcuSense DVR 1 SATA 12TB supports 2ch facial recognition or 4ch advanced perimeter VCA or 8ch Motion 2.0
Feature
8 channels and 1 HDD 1U AcuSense DVR
Support 2-ch Facial Recognition or 4-ch advanced model Perimeter Protection based on Deep Learning algorithm
Support 4-ch AcuSearch Technology
Efficient H.265 pro+ compression technology
Encoding ability up to 3K/5M Lite @ 12 fps
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Up to 12 -ch network cameras can be connected
Support All channels Motion Detection Technology
Support All channels HDTVI Two-Way Audio Technology
Network
Remote Connection64
Total Bandwidth96 Mbps
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Wi-FiConnectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary Interface
Serial InterfaceRS-485 (half-duplex)
SATA1 SATA interface, up to 10 TB capacity for each disk
Alarm In/OutN/A (optional to support)
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
General
Power Supply12 VDC, 1.5 A
Consumption≤ 18 W (without HDD)
Working Temperature-10 °C to + 55 °C (14 °F to 131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
Weight≤ 1.78 kg (3.9 lb) (without HDD)

Hikvision 16-ch 1080p Mini 1U H.265 AcuSense DVR
Deep learning based human and vehicle targets classification of Motion Detection 2.0
Deep learning-based perimeter protection
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video inputs
Audio via coaxial cable
Up to 24-ch IP camera inputs (up to 6 MP)
Encoding ability up to 3K/5M Lite @ 12 fps

Motion Detection 2.0
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported
Perimeter Protection
Line Crossing Detection/Intrusion Detection4-ch
Facial Detection
Facial Detection and CaptureFace picture detection, face picture search
Recording
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution
When 1080p Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Network
Remote Connection128
Total Bandwidth128 Mbps
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface
1, RJ45 10M/100M/1000M
self-adaptive Ethernet interface
General
Power Supply12 VDC, 2A
Consumption≤ 24W
Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)285 × 210 × 48 mm (11.2 × 8.3 × 1.9 inch)
Weight≤ 1 kg (2.2 lb)

Hikvision 16-channel 1080p 1U H.265 AcuSense DVR IDS-7216HQHI-M2/XT

Features:

16 channels and 2 HDD 1U AcuSense DVR
Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm
Support 8-ch AcuSearch Technology
Efficient H.265 pro+ compression technology
Encoding ability up to 3K/5MP Lite@12fps
Up to 24 channels IP camera inputs, each channel up to 6MP
Up to 24*1080P@30fps decoding ability
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Support All channels Motion Detection Technology
Support All channels HDTVI Two-Way Audio technology
General
Power Supply12 VDC, 3.3 A
Consumption≤40 W
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch)
Weight≤ 2 kg (4.4 lb)

Hikvision Pro Series 32-channel 1080p 1U H.265 AcuSense DVR iDS-7232HQHI-M2/XT

Pro Series with AcuSense
Detect humans & vehicles and search fast with deep learning technology

- 32 channels and 2 HDD 1U AcuSense DVR
- Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm
- Support 8-ch AcuSearch Technology
- Efficient H.265 pro+ compression technology
- Encoding ability up to 3K/ 5MP Lite@12fps
- Up to 40 channels IP camera inputs, each channel up to 6MP
- Up to 24*1080P@30fps decoding ability
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Support All channels Motion Detection Technology
- Support All channels HDTVI Two-Way Audio Technology
Specifications:

Product colour: Black
Maximum video resolution: 3840 x 2160 pixels
Video compression formats: H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Video resolutions: 1280 x 720,1920 x 1080,2560 x 1440,3840 x 2160
Video input channels: 32 channels
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Supported network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
Ethernet LAN data rates: 10,100,1000 Mbit/s
Maximum HDD capacity: 12 TB
Supported HDD interfaces: Serial ATA
General
Power Supply12 VDC, 5 A
Consumption≤ 60 W
Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)384 × 313 × 52 mm (15.1 × 12.3 × 2.0 inch)
Weight≤ 2.1 kg (4.6 lb)

Hikvision Pro Series 32-channel 1080p 1U H.265 AcuSense DVR iDS-7232HQHI-M2/XT

32 channels and 2 HDD 1U AcuSense DVR
Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm
Support 8-ch AcuSearch Technology
Efficient H.265 pro+ compression technology
Encoding ability up to 3K/ 5MP Lite@12fps
Up to 40 channels IP camera inputs, each channel up to 6MP
Up to 24*1080P@30fps decoding ability
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Support All channels Motion Detection Technology
Support All channels HDTVI Two-Way Audio Technology
Facial Recognition
Face Picture Library Up to 16 face picture libraries;
HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
Face Picture Comparison (Captured from Camera)4-ch face picture comparison alarm (HD analog camera)
Motion Detection 2.0
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels,
it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights.
Quick search by object or event type is supported.
Perimeter Protection
Human/Vehicle Analysis Up to 8-ch (advanced model)
Facial Detection
Facial Detection and Capture
Face picture detection, face picture search.
4-ch face picture capture
General
Power Supply12 VDC, 5 A
Consumption≤ 60 W
Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)384 × 313 × 52 mm (15.1 × 12.3 × 2.0 inch)
Weight≤ 2.1 kg (4.6 lb)

Asus 3U Rack Mount 16 bay AS7116RDX NAS - Intel Xeon E-2224 3.4GHz up to 4.6GHz 8MB Cache Quad 4x Core Processor with no intergrated Graphics, 8GB DDR4 ECC UDIMM Memory, 16x (2.5 inch / 3.5 inch SATA II/III HDD or SSD), 2x M.2 22110/2280/2260/2242 NVMe or SATAIII SSD, 4x USB 3.2 Gen 2 Type-A, 2x USB 3.2 Gen 2 Type-C, 4x Gigabit Ethernet (1G/100M), 1x Gen3 x8 slot (x8 link); 2x Gen3 x4 slots (x4 link) *for optional expansion 10, 25, 40, 50 GbE / SAS card, 2x 550W Power Supply unit, Retail Box, 1 year warranty

Product Overview
The Asus AS7116RDX 3U Rack Mount NAS features an Intel Xeon E-2224 processor with a powerful 8GB DDR4 ECC memory, designed for robust data management and storage solutions. With 16 bays for SATA HDDs or SSDs and dual M.2 slots for NVMe drives, it supports extensive expansion and RAID configurations for optimized performance. Equipped with multiple USB and Gigabit Ethernet ports, this NAS ensures high-speed connectivity and reliability for enterprise-level applications
Specifications
•Product code: AS7116RDX
•Description: Asus 3U Rack Mount 16 bay AS7116RDX NAS
•CPU Quad-Core: 3.4 to 4.6 GHz
•Processor Intel Xeon E-2224
•Memory 8 GB ECC DDR4
•RAM Configuration / Capacity 1x User-Replaceable 8 GB / 4 Slots Supporting up to 128 GB
•RAID Yes, Supported RAID Modes: 6 / 5 / JBOD / 0 / 1
•Number of Bays 2x M.2 (22110) NVMe
•16x 2.5"/3.5" SATA III (Hot-Swap)
•Maximum Capacity
•With Drives Installed up to 288 TB
•With Drives Installed up to 432 TB (with Expansion)
•Inputs/Outputs
•4x RJ45 Gigabit Ethernet
•4x USB-A 3.1/3.2 Gen 2
•2x USB-C 3.1/3.2 Gen 2
•PCI Expansion
•2x PCIe 3.0
•1x PCIe 3.0
•Yes, 512 LUN / 256 Target
•Software
•Installed Operating System
•ADM 3.5
•OS Compatibility
•Windows XP or Later
•Windows Server 2003 or Later
•Linux
•FreeBSD
•Security
•Encryption
•256-Bit AES
•Security Features
•Input Power
•100 to 240 VAC, 60 / 50 Hz
•Power Consumption
•121.7 W (Typical)
•51.5 W (Idle)
•7.55 W (Standby)
•PSU Wattage
•32 to 104°F / 0 to 40°C at 5 to 95% Humidity
•Cooling 3x 60 mm Fans
•Dimensions 21.1 x 17.3 x 5.2" / 535.9 x 439.4 x 132.1 mm
•Weight 33.7 lb / 15.3 kg

Asus 2U Rack Mount 12 bay AS7112RDX NAS - Intel Xeon E-2224 3.6GHz up to 4.6GHz 8MB Cache Quad 4x Core Processor with no intergrated Graphics, 8GB DDR4 ECC UDIMM Memory, 8GB USB DOM Flash Memory, 12x Drive bays, 2x M.2 Drive slots, 3.5" SATA Hard Disk Drive & 2.5" SATA Hard Disk Drive compatible Drive Type, 4x USB 3.2 Gen 2 Type-A, 2x USB 3.2 Gen 2 Type-C, 4x Gigabit Ethernet (1G/100M), 2x Gen3 x4 slots (x4 Link), 1x Gen3 x8 slots (x8 Link), 2x 550W Power Supply unit, Retail Box, 1 year warranty

Product Overview
The Asus 2U Rack Mount AS7112RDX NAS offers robust performance with an Intel Xeon E-2224 processor, 8GB ECC UDIMM memory, and extensive connectivity including 12 drive bays and multiple USB ports. Ideal for storage-intensive tasks, it features dual M.2 drive slots and supports both 3.5" and 2.5" SATA HDDs, backed by reliable power delivery from dual 550W PSU units.
Features
•Intel Xeon 9th generation Quad-Core CPU
•2U chassis design, 12 SATA drive bays
•Dual M.2 NVMe SSD ports for fast caching
•Supports Virtualization and Docker apps

Specifications
•Product code: AS7112RDX
•Specifications: Asus 2U Rack Mount 12 bay AS7112RDX NAS
•CPU Model: Intel Xeon E-2224
•CPU Architecture: x64 64-bit
•CPU Frequency: Quad-Core 3.4GHz up to 4.6GHz
•Memory: 8GB DDR4-2666 ECC UDIMM
•Memory Module Pre-installed: 8GB (1x 8GB)
•Total Memory Slots: 4
•Memory Expandable up to 128GB (4x 32GB)
•Support mixed capacity
•Flash Memory: 8GB USB DOM
•Drive Bays: 12
•M.2 Drive Slots: 2
•Compatible Drive Type
•Maximum Drive Bays with Expansion Unit 24
•Supports Hot Swappable Drives
•Expansion: 4x USB 3.2 Gen 2 (10Gbps) Type-A ; 2x USB 3.2 Gen 2 (10Gbps) Type-C
•Network: 4x Gigabit Ethernet (1G/100M)
•PCIe Expansion Slots: 2x Gen3x4 slots (x4 link) ; 1x Gen3x8 slots (x8 link)
•for optional 10/25/40/50 GbE card and SAS card
•System Fan: 3x 60mm
•Power Supply Unit / Adapter: 550W x2
•Input Power Voltage: 100V to 240V AC
•Certification: FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS
•Power Consumption: 92.4W (Operation);
•45.5W (Disk Hibernation)
•7.55 W (Sleep Mode);
•Operation Temperature: 0°C~40°C (32°F~104°F)
•Storage Temperature: -20°C~70°C (-4°F~158°F)
•Humidity: 5% to 95% RH
•Size: 88(H) x 439(W) x 535(D) mm
•Weight: 13 (kg) / 28.6(lb)

Asustor Lockerstor 10 Pro AS7110T Series Enterprise Network Attached Storage, 3.4GHz Quad-Core, One 10GbE Port, Three 2.5GbE Ports, Two M.2 Slots for NVMe SSD Cache, 8GB RAM DDR4 (10 Bay Diskless NAS), Retail Box, 1 year warranty

Product Overview
The Asustor Lockerstor 10 Pro AS7110T Series offers enterprise-level network storage with a powerful 3.4GHz quad-core processor, 8GB DDR4 RAM, and extensive connectivity including one 10GbE port and three 2.5GbE ports, alongside dual M.2 slots for NVMe SSD cache, providing high-speed data access and storage flexibility for demanding applications.
Specifications
•Product code: AS7110T
•Description: Asustor Lockerstor 10 Pro AS7110T Series Enterprise Network Attached Storage
•Number of Bays
•10x 2.5"/3.5"
•2x M.2 (2280)
•Inputs/Outputs
•2x USB-A 3.1/3.2 Gen 2
•1x USB-A 3.0 / 3.1/3.2 Gen 1
•3x RJ45 2.5GbE
•1x RJ45 10GbE
•Compatible Drive Interface: SATA III, NVMe
•RAID: RAID 0/1/5/6/JBOD
•CPU: Quad-Core: 3.4 to 4.6 GHz
•Processor: Intel Xeon E-2224
•Total Installed Memory: 8 GB ECC DDR4
•User-Replaceable Memory: 1x 8 GB
•Total Memory Slots: 2x SO-DIMM
•Flash Memory: 8 GB eMMC
•Number of Bays
•10x 2.5"/3.5"
•2x M.2 (2280)
•Inputs/Outputs
•2x USB-A 3.1/3.2 Gen 2
•1x USB-A 3.0 / 3.1/3.2 Gen 1
•3x RJ45 2.5GbE
•1x RJ45 10GbE
•Compatible Drive Interface
•SATA III, NVMe
•Maximum Capacity
•With Drives Installed up to 180 TB
•With Drives Installed up to 396 TB (with Expansion)
•RAID: RAID 0/1/5/6/JBOD
•Wake on LAN: Yes
•Link Aggregation and Failover Support: Yes
•iSCSI LUN: 256
•iSCSI Target: 256
•Max Concurrent Connections: 2048
•Max Folders: 512
•Max Groups: 512
•Max User Accounts: 16,384
•Max Cameras Supported: 100
•Encryption: 256-Bit AES
•Power Source: AC Adapter
•PSU Wattage: 1 x 350 W
•Status Monitoring: LED Indicator
•Cooling: 2x 120 mm Fans
•Noise Level: 22 dBA
•Dimensions: 11.5 x 9.1 x 8.5" / 293 x 230 x 215.5 mm
•Weight: 15.6 lb / 7.1 kg
•Package Weight: 20.905 lb
•Box Dimensions (LxWxH): 15.7 x 14.6 x 13.6"

Asustor Lockerstor 12RD AS6512RD - 12 Bay NAS, Quad-Core 2.1GHz CPU, 2.5GbE Port, 8GB RAM DDR4, 2U Rackmount Server with redundant Power Supply (Diskless)
Product Overview

Quickly expand your small or medium business's network storage capacity for smooth backups, file sharing, and more with the Asustor LOCKERSTOR 12RD AS6512RD 12-Bay Rackmount NAS Enclosure. This 2 RU rackmount NAS supports up to twelve 3.5"/2.5" SATA III drives, which can be configured for RAID 0, 1, 5, 6, 10, Single or JBOD modes to balance between security and performance according to your needs. Integrate the NAS into your network using the dual Gigabit Ethernet ports and two 2.5G Ethernet connectors. The LOCKERSTOR 12RD AS6512RD is designed to deliver read speeds of up to 591 MB/s with 565 MB/s write speeds when both 2.5G Ethernet ports are combined through link aggregation for 5G Ethernet speeds and the drives are in RAID 5 configuration. Performance can be boosted to 1180 MB/s read and write speeds by installing a compatible 10G Ethernet adapter into the available PCIe 3.0 x8 slot.
Other convenient features include two redundant 350W power supplies and four USB 3.2 Gen 1 Type-A ports that can transfer up to 5 Gb/s of data with compatible devices such as storage expansion systems. The Asustor LOCKERSTOR 12RD AS6512RD 12-bay rackmount NAS enclosure has the ADM operating system installed, which supports a variety of backup, virtualization, and security applications.

Highlights
• Intel Atom C3538 2.1GHz Quad-Core CPU
• 8 GB DDR4-2133 - 128 GB maximum
• Two Gigabit Ethernet and two 2.5-Gigabit Ethernet ports. Can provide up to 5 gbps when aggregated.
• Supports Wake-on-LAN and Wake-on-WAN
• Complete iSCSI/IP-SAN and NFS support - Supports VMware, Citrix and Hyper-V - Supports virtual machines and Docker applications
• Supports ACL and AD. Improves business application efficiency.
• PCIe slot for 10-Gigabit Ethernet card
Item model number AS6512RD
ASIN B0952S1YDY
Date First Available 15 December 2023

Asustor Flashstor 12 Pro FS6712X 12 Bay All-SSD NAS Storage - Quad-Core 10 nm Intel Celeron N5105 CPU, 12x M.2 NVMe slots, Megafast 10-Gigabit Ethernet, 4 GB of fast and efficient DDR4-2933 RAM, Dual USB 3.2 Gen 2x1, HDMI 2.0b, S/PDIF output for amazing sound quality, Smooth 4K hardware transcoding, Supports Wake on LAN, Retail Box, 1 year warranty

Product Overview
Archiving and unfinished raw content are among the most common storage problems content creators encounter when working on a Mac. Final Cut Pro Libraries can grow rapidly and out of control. Content creators often turn to USB external drives to store material for Final Cut Pro. When using a Mac, especially portable Macs like the MacBook Pro, external drives are often connected and disconnected, which can lead to wear and tear of the port. External drives are also inconvenient as the files cannot be conveniently shared with coworkers or collaborators and external drives are susceptible to damage in ways a NAS is not. A NAS remains stationary while digitally making your files available to you while an external drive is portable, increasing the risk of drops, spills or other types of damage.
Features
•Quad-Core 10 nm Intel Celeron N5105 CPU
•12x M.2 NVMe slots
•Megafast 10-Gigabit Ethernet
•4 GB of fast and efficient DDR4-2933 RAM
•S/PDIF output for amazing sound quality
•Smooth 4K hardware transcoding
•Supports Wake on LAN

Specifications
•Product code: FS6712X
•Description: Asustor Flashstor 12 Pro FS6712X 12 Bay All-SSD NAS Storage
•CPU Model: Intel Celeron N5105
•CPU Architecture: x64 64-bit
•CPU Frequency Quad-Core 2.0GHz (burst up 2.90 GHz)
•Memory 4GB SO-DIMM DDR4
•Memory Module Pre-installed 4GB (1x 4GB)
•Total Memory Slots 2
•Memory Expandable up to 16GB (2x 8GB)
•Support mixed capacity
•Flash Memory 8GB eMMC
•M.2 Drive Slots 12
•Compatible Drive Type
•M.2 2280 NVMe
•Maximum Drive Bays with Expansion Unit 20
•External Ports
•Expansion: 2x USB 3.2 Gen 2x1; 2 x USB 2.0
•Network 1 x 10 Gigabit Ethernet (10G/5G/2.5G/1G/100M/10M)
•Multimedia Output 1x HDMI 2.0b, 1x S/PDIF
•System Fan: 1 x 80mm
•Power Supply Unit / Adapter 90W x1
•Input Power Voltage 100V to 240V AC
•Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
•Power Consumption: 26 W
•Noise Level: 18.7dB
•Operation Temperature: 0°C~40°C (32°F~104°F)
•Humidity: 5% to 95% RH
•Size and Weight
•Size 48.3 (H) x 308.26 (W) x 193 (D) mm
•Weight 1.37 kg / 3 lb

Asustor Lockerstor 6 Gen2 6 Bay NAS No Hard Drive - Quad-Core 10 nm Intel Celeron N5105 CPU brings 31% more performance, Superfast 2.5-Gigabit Ethernet ports, Flexible PCIe slot for 10GbE NICs or M.2 SSDs, Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0., Uses DDR4-2933 with 40% more performance, USB 3.2 Gen2 ports – 10Gbps speed, Enjoy, download, upload and stream content with 4K transcoding, Increased ventilation for SSDs, Supports Wake on LAN and Wake on WAN , Retail Box, 1 year warranty


Product Overview
Powered by the Latest 10 nm Intel Jasper Lake Celeron Quad-Core Processors. The Lockerstor Gen2 comes with Intel’s newest Quad-Core Celeron CPUs. The N5105 comes with Intel 10 nm technology and is up to 31% faster than Gemini Lake SoCs. The Celeron N5105 is clocked at 2.0 GHz with 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.

All New Hardware – Same Great Case
ASUSTOR Ultimate 6 bays hybrid storage. Giant space and elastic high speed with M.2 or 10G card.

Four M.2 Slots - Have Your Cake and Eat it Too
The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs. Four M.2 SSD slots bring a number of custom scenarios to your NAS when it comes to accelerating your storage.
Keeping Cool
With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.

Tool-Free M.2 SSD Installation
Uses latches instead of screws for easier installation.
Highlights
• Quad-Core 10 nm Intel Celeron N5105 CPU brings 31% more performance
• Superfast 2.5-Gigabit Ethernet ports
• Flexible PCIe slot for 10GbE NICs or M.2 SSDs
• Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0.
• Uses DDR4-2933 with 40% more performance
• USB 3.2 Gen2 ports – 10Gbps speed
• Enjoy, download, upload and stream content with 4K transcoding
• Increased ventilation for SSDs
• Supports Wake on LAN and Wake on WAN


Specifications
CPU
CPU Model: Intel Celeron N5105
CPU Architecture: x64 64-bit
CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)

Memory
Memory: 8GB SO-DIMM DDR4
Memory Module Pre-installed: 8GB (1x 8GB)
Total Memory Slots: 2
Memory Expandable up to: 16GB (2x 8GB)
Flash Memory: 8GB eMMC

Storage
Drive Bays: 6
M.2 Drive Slots: 4
Compatible Drive Types:
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe
Maximum Drive Bays with Expansion Unit: 14

External Ports
Expansion: 2x USB 3.2 Gen 2x1
Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
PCIe Expansion Slots: 1x for optional expansion 10 GbE card
HDMI Output: 1x HDMI 2.0b

Others
System Fan : 1x 120mm
LCD Panel: Yes
Infrared Receiver: Yes
Power Supply Unit / Adapter: 250W x1
Input Power Voltage: 100V to 240V AC

Asustor Lockerstor 4 Gen2 4 Bay NAS No Hard Drive - Quad-Core 10 nm Intel Celeron N5105 CPU - 31% more performance over Gemini Lake, Superfast 2.5-Gigabit Ethernet ports, Flexible PCIe slot for 10GbE NICs or M.2 SSDs, Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0., Uses DDR4-2933 with 40% more performance, USB 3.2 Gen2 ports – 10Gbps speed, Enjoy, download, upload and stream content with 4K transcoding, Increased ventilation for SSDs, Supports Wake on LAN and Wake on WAN , Retail Box, 1 year warranty

Product Overview
Enthusiast-grade NAS with two, four or six bays. The LOCKERSTOR Gen2 series of NAS devices come with the all-new Quad-Core Intel Celeron N5105 CPU featuring Intel 10 nm technology. Intel’s Jasper Lake Celeron CPUs bring up to 31% extra performance over the previous generation of Celeron CPUs. The LOCKERSTOR Gen2 is flexible. Install up to four M.2 SSDs or a 10-Gigabit Ethernet card in the available PCI Express slot for maximum performance. The LOCKERSTOR Gen2 uses DDR4-2933 and super-fast 2.5-Gigabit Ethernet which makes content creation even easier than ever before.

CPU
Intel’s newest N5105 Quad-Core CPU comes with Intel 10 nm technology and up to 31% increased performance over Gemini Lake SoCs. The N5105 is clocked at 2.0 GHz with a boost of up to 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.
Keeping Cool
With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.
USB 3.2 Gen 2x1 – A First for ASUSTOR
The Lockerstor Gen2 series now support USB 3.2 Gen 2x1 for the first time on an ASUSTOR NAS. Enjoy up to double the performance compared with USB 3.2 Gen1 at up to 10 Gbps.

Four M.2 Slots
The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs.
Also Supports 10-Gigabit Ethernet
The PCIe slot in the Lockerstor Gen2 series is no longer proprietary and now accepts 10-Gigabit Ethernet cards for maximum flexibility.

Highlights
• Quad-Core 10 nm Intel Celeron N5105 CPU - 31% more performance over Gemini Lake
• Superfast 2.5-Gigabit Ethernet ports
• Flexible PCIe slot for 10GbE NICs or M.2 SSDs
• Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0.
• Uses DDR4-2933 with 40% more performance
• USB 3.2 Gen2 ports – 10Gbps speed
• Enjoy, download, upload and stream content with 4K transcoding
• Increased ventilation for SSDs
• Supports Wake on LAN and Wake on WAN
Weight 4.73 kg
Dimensions 33 × 26.4 × 35.2 cm

Asustor Flashstor 6 FS6706T 6 Bay All-SSD NAS Storage - Quad-Core 10 nm Intel Celeron N5105 CPU, 6x M.2 NVMe slots, Dual Superfast 2.5-Gigabit Ethernet ports, 4 GB of fast and efficient DDR4-2933 RAM, Dual USB 3.2 Gen 2x1, HDMI 2.0b, S/PDIF output for amazing sound quality, Smooth 4K hardware transcoding, Supports Wake on WAN and Wake on LAN, Retail Box, 1 year warranty

Product Overview
Archiving and unfinished raw content are among the most common storage problems content creators encounter when working on a Mac. Final Cut Pro Libraries can grow rapidly and out of control. Content creators often turn to USB external drives to store material for Final Cut Pro. When using a Mac, especially portable Macs like the MacBook Pro, external drives are often connected and disconnected, which can lead to wear and tear of the port. External drives are also inconvenient as the files cannot be conveniently shared with coworkers or collaborators and external drives are susceptible to damage in ways a NAS is not. A NAS remains stationary while digitally making your files available to you while an external drive is portable, increasing the risk of drops, spills or other types of damage.
Features
•Quad-Core 10 nm Intel Celeron N5105 CPU
•6x M.2 NVMe slots
•Dual Superfast 2.5-Gigabit Ethernet ports
•4 GB of fast and efficient DDR4-2933 RAM
•S/PDIF output for amazing sound quality
•Smooth 4K hardware transcoding
•Supports Wake on WAN and Wake on LAN

Specifications
•Product Code: FS6706T
•Description: Asustor Flashstor 6 FS6706T 6 Bay All-SSD NAS Storage
•CPU Model: Intel Celeron N5105
•CPU Architecture: x64 64-bit
•CPU Frequency Quad-Core 2.0GHz (burst up 2.90 GHz)
•Memory 4GB SO-DIMM DDR4
•Memory Module Pre-installed 4GB (1x 4GB)
•Total Memory Slots 2
•Memory Expandable up to 16GB (2x 8GB)
•Support mixed capacity
•Flash Memory 8GB eMMC
•M.2 Drive Slots 6
•Compatible Drive Type
•M.2 2280 NVMe
•Maximum Drive Bays with Expansion Unit 14
•Expansion: 2x USB 3.2 Gen 2x1; 2 x USB 2.0
•Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
•Multimedia Output 1x HDMI 2.0b, 1x S/PDIF
•System Fan 1 x 80mm
•Power Supply Unit / Adapter 65W x1
•0.83 W (Sleep Mode)
•Noise Level 18.7dB
•Operation Temperature 0°C~40°C (32°F~104°F)
•Humidity 5% to 95% RH
•Size 48.3 (H) x 308.26 (W) x 193 (D) mm
•Weight 1.35kg / 2.98 lb

Asustor Lockerstor 2 2 Bay NAS No Hard Drive - Intel Celeron J4125 64-bit Quad Core 2.0GHz (with Turbo Boost up to 2.70GHz) CPU, Integrated Memory 4GB SO-DIMM DDR4 Pre-installed, Total Memory Slots 2, Memory expandable up to 8GB (2 x 4GB), Note: Support mixed capacity, 8GB eMMC Storage, HDD 2 x SATA3 6Gb/s; 3.5"/2.5" HDD/SSD, Maximum Internal Raw Capacity: 36 TB (18 TB HDD X 2, Capacity may vary by RAID types), Maximum Drive Bays with Expansion Unit 14, Maximum Raw Capacity with Expansion Units 252 TB (18 TB HDD X 14, Capacity may vary by RAID types), USB 3.2 Gen 1 x3, 2.5 Gigabit Ethernet x 2 (2.5G/1G/100M), HDMI 2.0a x1, System Fan 70mm x 1, Power Supply Unit Adapter 65W x1, Input Power Voltage 100V to 240V AC, Retail Box, 1 year warranty

Product Overview
The Asustor Lockerstor 2 2 Bay NAS Enclosure Unit allows you to expand your storage. Designed for home or small-business applications, this 2-bay NAS enclosure sports a 2.0 GHz Intel Celeron J4125 quad-core CPU and 4GB of DDR4 RAM. Memory can be extended up to 8GB, while two M.2 2280 SSD bays allow users to install cache drives. 8GB of eMMC memory is also present for caching data. Supporting RAID 0, 1, and JBOD modes, this enclosure's bays accept 2.5 or 3.5" SATA III SSDs or HDDs. Two 2.5 Gigabit Ethernet ports provide networking connections, while additional accessories can be connected using a USB 3.2 Gen 1 Type-A port on the front panel, or two ports on the rear panel. An HDMI 2.0a port is also present on the rear panel, providing graphic as well as audio output.

The ASUSTOR’s exclusive EZ-Connect technology allows you to connect to your NAS from anywhere with your Android or iOS device to securely access, download, upload and share files and information. ASUSTOR mobile apps securely protect your privacy and data by requiring passwords in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security. At your convenience, browse through and download any applications that pique your interest from App Central. With over 200 unique apps, App Central provides you with a virtually boundless variety of applications that to satisfy your digital lifestyle needs. Explore the virtually unlimited potential of your ASUSTOR NAS while creating a personalized experience for yourself.
Highlights
• 2 x 3.5/2.5" SATA III Drive Bays and 2 x M.2 (2280) Slots
• Maximum Internal Raw Capacity 36 TB (18 TB HDD X 2, Capacity may vary by RAID types)
• Maximum Raw Capacity with Expansion Units 252 TB (18 TB HDD X 14, Capacity may vary by RAID types)
• 2.0 GHz Intel Celeron J4125 Quad-Core
• 4GB DDR4 2400-RAM Expandable to 8GB ( 2x Memory Slots
• GPU Intel UHD Graphics 600
• 2 x 2.5 Gigabit RJ45 Ethernet Ports
• 3 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s))
• 1 x HDMI Type-A (HDMI 2.0)
• RAID 0, 1 and JBOD
• Overwhelming 4K experience
• Supports Wake on LAN and Wake on WAN
• Up to 588 & 583 MB/s Read & Write Speeds
• AES 256-Bit Encryption
• 70mm Cooling Fan
• ADM 3.5 Operating System
The Asustor Lockerstor 2 AS6602T 2-Bay NAS has a gross weight of 2.4 kg. The product dimensions are 108 x 163.5 x 230 mm,

Asustor Xpanstor 4 AS5004U 4 Bay Expansion NAS Unit - Plug and play, 10Gbps USB 3.2 Gen 2 using Type-C, Use up to 22TB per drive tray, Smart power sync helps save power, Smart fan circuit helps keep hard drives cool, Supports MyArchive cold backup technology, Retail Box, 1 year warranty

Product Overview
The Asustor Xpanstor 4 AS5004U 4 Bay Expansion NAS Unit features plug-and-play functionality with a 10Gbps USB 3.2 Gen 2 Type-C connection, allowing for rapid data transfer and easy expansion of your NAS storage capacity up to 22TB per drive tray. Designed with smart power sync and a cooling fan circuit, it optimizes energy efficiency while keeping hard drives cool during operation. Additionally, it supports MyArchive cold backup technology, making it a versatile solution for managing and archiving large volumes of data effortlessly.
Specifications
•Product code: AS5004U
•Description: Asustor Xpanstor 4 AS5004U 4 Bay Expansion NAS Unit
•Number of Bays 4x 2.5"/3.5" SATA III (Hot-Swap)
•Inputs/Outputs 1x USB-C 3.1/3.2 Gen 2
•Media Card Slots No
•Input Power 100 to 240 VAC, 60 / 50 Hz
•Power Consumption
•24.68 W (Typical)
•6.02 W (Standby)
•PSU Wattage 1 x 90 W
•Operating Conditions 32 to 104°F / 0 to 40°C at 5 to 95% Humidity
•Certifications FCC, CE, VCCI, BSMI, C-Tick, BIS, Kcc, EAC
•Cooling 1x 120 mm Fan
•Dimensions 9.1 x 6.9 x 6.7" / 230 x 174 x 170 mm
•Weight 4.5 lb / 2.0 kg

Asustor Drivestor 2 Pro AS3302T - 2 Bay NAS, 1.4GHz Quad Core, 2.5GbE Port, 2GB RAM DDR4, Network Attached Storage, Retail Box, 1 year warranty

Product Overview

Streamline cloud storage with the Drivestor 2 Pro 2-Bay NAS Enclosure from Asustor. Featuring two 3.5" SATA III drive bays, this Drivestor 2 Pro provides read and write speeds up to 216 and 275 MB/s, respectively. A 1.4 GHz Realtek RTD1296 quad-core CPU and 2GB of DDR4 RAM ensure smooth performance and multitasking, while a 2.5 Gigabit Ethernet port enables snappy networking. Three USB 3.2 Gen 1 Type-A ports are also present. Supporting RAID 0, 1, and JBOD modes, this NAS enclosure can be used to serve files or backup critical data.
Stay safe thanks to 256-bit AES encryption as well as military-grade construction tested to resist drops and extreme temperatures. A 70mm cooling fan prevents overheating, while LED indicators on the front panel allow for easy status monitoring. Running on ADM 4.0, the Asustor Drivestor 2 Pro supports a range of apps and cloud-based storage options for easy access via a computer or iOS or Android device. This NAS enclosure is compatible with Windows Vista or later, macOS 10.6 or later, Linux, UNIX, and FreeBSD operating systems. An AC adapter, Cat 5e Gigabit Ethernet cable, and hard drive screws are included.

Highlights
• CPU：Realtek RTD1296 Quad Core 1.4GHz
• Memory：2GB DDR4 (not expandable)
• Storage：2 x SATA3 6Gb/s; 3.5" HDD up to 36TB (18 TB HDD X 2)
• USB Expansion：USB 3.2 Gen 1 x3
• Network port：2.5 Gigabit Ethernet (2.5G/1G/100M) x 1
• File System - Internal Disk：EXT4
• File System - External Disk：FAT32, NTFS, EXT3, EXT4, HFS+, exFAT
• RAID Volume Type：Single, JBOD, RAID 0, RAID 1
• Size：170(H) x 114(W) x 230(D) mm
• Weight：1.6kg / 3.53 lbs

Asustor Drivestor 2 Lite AS1102TL 2 Bay NAS - Equipped with Realtek RTD1619B 1.7GHz quad-core processor, 1 GB DDR4 RAM, Enjoy, download, upload and stream content with 4K transcoding, Supports Wake on LAN (WOL), Btrfs/iSCSI Snapshots, Tool-free installation, Retail Box, 1 year warranty

Product Overview
The Asustor Drivestor 2 Lite AS1102TL 2 Bay NAS is powered by a Realtek RTD1619B 1.7GHz quad-core processor and 1GB DDR4 RAM, providing efficient performance for downloading, uploading, and streaming content with 4K transcoding capabilities. Designed for easy setup, it features tool-free installation and supports Wake on LAN (WOL) along with Btrfs/iSCSI snapshots for enhanced data protection. This versatile NAS solution is perfect for home or small office use, ensuring reliable storage and access to your digital content.
Specifications
•Product code: AS1102TL
•Description: Asustor Drivestor 2 Lite AS1102TL 2 Bay NAS
•CPU Quad-Core: Up to 1.7 GHz
•Processor Realtek RTD1619B
•Memory 1 GB DDR4
•Raid Yes, Supported RAID Modes: JBOD / 0 / 1
•Inputs/Outputs
•1x USB-A 3.0 / 3.1/3.2 Gen 1
•1x USB-A 2.0
•Media Card Slots No
•Link Aggregation and Failover Support No
•iSCSI Support Yes, 256 LUN / 256 Target
•OS Compatibility
•Windows 7 to 11
•macOS
•UNIX
•Linux
•Mobile App Compatible Yes: Android & iOS
•Encryption 256-Bit AES
•Security Features No
•Input Power 100 to 240 VAC, 60 / 50 Hz
•Power Consumption 11.7 W
•PSU Wattage 1 x 65 W
•Operating Conditions 32 to 104°F / 0 to 40°C at 5 to 95% Humidity
•Certifications FCC, CE, VCCI, BSMI, C-Tick, Kcc, BIS, CCC
•Cooling 1x 70 mm Fan
•Noise Level 18.6 dBA
•Dimensions 8.6 x 6.5 x 4" / 218 x 165 x 102 mm
•Weight 2.5 lb / 1.1 kg
•Package Weight 4.5 lb
•Box Dimensions (LxWxH) 12.5 x 9.4 x 6.3"

Toshiba 18TB MG Series 3.5 inch Enterprise SATA Hard Drive, , 1 year warranty

Product Overview
The Toshiba 18TB MG Series 3.5-inch Enterprise SATA Hard Drive delivers industry-leading capacity and performance for demanding enterprise environments. Featuring a 9-disk helium-sealed design and Toshiba's innovative Flux Control Microwave Assisted Magnetic Recording (FC-MAMR) technology, it achieves a massive 18TB capacity while maintaining compatibility with conventional magnetic recording (CMR).
Specifications
•Product code: HDEPZ10GEA51
•Description: Toshiba 18TB MG Series 3.5 inch Enterprise SATA Hard Drive
•Available Capacities 18 TB
•Form Factor 3.5-inch
•Buffer Size 512 MiB
•Rotation Speed 7200 rpm
•Data Transfer Speed (Sustained)(Typical) 268 MiB/s
•Power Consumption (Idle-A) SAS
•18 TB: 4.49W
•MTTF/MTBF (AFR) 2,500,000 hours (0.35% Annual Failure Rate)
•Weight (Max) 18 TB/16 TB: 720g

Toshiba 16TB MG Series 3.5 inch Enterprise SATA Hard Drive, , 1 year warranty

Product Overview
The Toshiba 16TB MG Series 3.5-inch Enterprise SATA Hard Drive is designed for high-capacity storage and reliable performance in demanding enterprise environments. Featuring a 7200 RPM rotational speed and a helium-sealed 9-disk design, it provides optimal data integrity and efficiency for cloud-scale and business-critical applications. With a workload rating of 550 TB/year and a 5-year warranty, this hard drive ensures durability and peace of mind for critical data storage needs.
Specifications
•Product code: HDEPX10GEA51
•Description: Toshiba 16TB MG Series 3.5 inch Enterprise SATA Hard Drive,
•Available Capacities 16 TB
•Form Factor 3.5-inch
•Buffer Size 512 MiB
•Rotation Speed 7200 rpm
•Maximum Data Transfer Speed (Sustained)(Typ.) 16 TB: 262 MiB/s
•Power Consumption (Idle - A) SATA: 4.00W
•SAS: 4.46W
•MTTF/MTBF 2,500,000 hours
•Weight (Max) 720g

Seagate Exos 7E10 10TB Hard Drive - Internal - SATA (SATA/600) - Storage System, Video Surveillance System Device Supported - 7200rpm , , 3 year warranty

Product Overview
Specifically designed to address the needs of storing unstructured data cost effectively.
eatures
Optimised for Enterprise Workloads
•High-capacity, high-performance drives for demanding bulk data applications.
Robust 24×7 Performance
•Consistent performance in replicated and RAID multi-drive systems.
Cost-Effective Footprint
•The most efficient and cost-effective data centre footprint on the market today.
Advanced Security Features
•Safeguard data at rest and comply with corporate and government data security mandates.

Specifications
•Product code: ST10000NM017B
•Description: Seagate Exos 7E10 10TB Hard Drive
•Capacity: 10TB
•Dimensions: H x W x D: 26.11 mm/1.028 in × 101.85 mm/4.010 in × 147.0mm/5.787in
•Weight: 720 g/1.59 lb
