Product Overview

The Mimosa C5C is a high-performance connectorized point-to-point (PTP) backhaul radio designed for long-range, high-throughput wireless links. Ideal for ISPs and network providers, it delivers up to 700 Mbps TCP throughput and supports flexible antenna configurations for custom client deployments—even in challenging environments with dense vegetation.
Key Features

High-Speed Long-Range Backhaul — Optimized for PTP and point-to-multipoint (PTMP) GigaPoP and MicroPoP links with reliable performance over long distances.

Connectorized Design — Compatible with a wide range of dual-polarization antennas via 2x2:2 MIMO RP-SMA connectors, allowing custom antenna selection for optimal link quality.

Easy Installation & Auto-Provisioning — Use the Mimosa Install App for rapid subscriber setup, automated device provisioning, and smooth integration into your ISP network, reducing deployment time and operational costs.

Spectrum Reuse Synchronization (SRS) Client — Works in SRS mode for improved medium access control (MAC) efficiency, interference coordination, and lower jitter by synchronizing transmissions with the Access Point (A5/A5c).

Flexible Mounting Options — Can be pole-mounted with hose clamps or clipped onto compatible antenna mounting brackets for versatile deployment.

Technical Specifications
Specification Details
Throughput Up to 700 Mbps TCP
Connectivity 2x2:2 MIMO with dual RP-SMA connectors
Supported Modes PTP, PTMP GigaPoP, PTMP MicroPoP
Auto-Provisioning Supported via Mimosa Install App
Antenna Compatibility Compatible with many dual-pol antennas
Mounting Options Pole mount (hose clamps), clip-on brackets
Spectrum Access Spectrum Reuse Synchronization (SRS) client
Environmental Suitability Optimized for areas with vegetation interference
Package Contents

1 × Mimosa C5C Connectorized PTP Backhaul Radio

Mounting accessories

User manual

Why Shop at QuickStore.co.za?

✔ Genuine Mimosa networking products with local warranty
✔ Fast, reliable shipping across South Africa
✔ Expert technical support for your network needs

MikroTik netPower Lite 7R – 8-Port GPEN Switch | Reverse PoE | 56Gbps Throughput

Fiber-Speed Ethernet for ISPs – No GPON Splitters Needed

The MikroTik netPower Lite 7R revolutionizes last-mile connectivity with GPEN technology, delivering fiber-like speeds over Ethernet at a fraction of GPON’s cost. Featuring 7 reverse PoE ports and a rugged outdoor design, it’s the ultimate solution for apartment ISPs, MDUs, and harsh environments.
⚡ Key Features

✔ GPEN Technology – Replace expensive GPON with simple Ethernet deployments.
✔ Reverse PoE Innovation – 7 ports can draw power from clients (or supply power via Port 8).
✔ Carrier-Grade Performance – 56Gbps switching capacity & 41.7 Mpps forwarding rate.
✔ Outdoor Tough – IP54-rated for attics, poles, or elevator shafts (hose-clamp compatible).
✔ Flexible Power Options – DC jack, 2-pin terminal, or PoE-powered (adapter sold separately).
📊 Technical Specifications

Ports:

7x Gigabit Ethernet (Reverse PoE-in)

1x Gigabit Ethernet (PoE-out, same voltage as input)

Throughput: Non-blocking 28Gbps

Switching Capacity: 56Gbps

Power Input:

Reverse PoE (from clients)

12-57V DC (jack/terminal)

802.3af/at (Port 8 output)

Enclosure: IP54 metal housing (-40°C to 60°C operation)

🏆 Why Choose netPower Lite 7R?

✅ Cost Savings – Eliminates GPON splitters and ONTs.
✅ Zero Power Anxiety – Draws power from just 1 client if needed.
✅ Future-Proof – Ideal for ISPs transitioning from copper to fiber areas.
🔍 Ideal For:

🏢 Apartment ISPs – Deliver gigabit to individual units without ONTs.
📶 MDU Deployments – Centralize switching in basements/attics.
🌧️ Harsh Environments – Survives damp, dusty, or extreme-temp locations.
⚠️ Note

Power adapter NOT included (sold separately).

GPEN requires compatible CPE (e.g., MikroTik devices with PoE-out).

The MikroTik hAP ax lite LTE6 is a compact WiFi 6 router with integrated LTE6 modem, designed for apartments, homes, and small offices where both wired and mobile connectivity are essential.
Powered by a dual-core ARM CPU and RouterOS v7 (Level 4 licence), it delivers advanced networking features with reliable performance.
It supports 2.4GHz WiFi 6 with speeds up to 600Mbps, alongside 4 Gigabit Ethernet ports for wired devices.
The integrated LTE6 modem provides mobile broadband with 300Mbps downlink and 50Mbps uplink, making it ideal for areas with limited fixed-line connectivity.
Compact, USB-C powered, and versatile, the hAP ax lite LTE6 is backed by a 24-month warranty.

Key Features
WiFi 6 (802.11ax) router/AP, 2.4GHz band
Data rate: up to 600Mbps WiFi + LTE6 (300Mbps DL / 50Mbps UL)
Dual-core ARM CPU with RouterOS v7 (L4 licence)
Integrated LTE6 modem with Micro SIM slot
4 × Gigabit Ethernet ports (10/100/1000Mbps)
Antenna gain: 2.4GHz: 4.3dBi; LTE: 4dBi
Compact desktop design with USB-C power input
Max power consumption: 12W
Operating temperature: -40°C to 60°C
24-month limited warranty

Specifications
Antenna Gain: 2.4GHz: 4.3dBi; LTE: 4dBi
Beam-width: 360°
Data Rate: 2.4GHz WiFi: 600Mbps; LTE: 300Mbps DL / 50Mbps UL
Ethernet Ports: 4 × 10/100/1000Mbps
Hardware Buttons: Reset & Mode
Max Power Consumption: 12W
Mounting: Desktop
Operating System: RouterOS v7 (Level 4 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 5V USB-C (adapter included)
SIM Slots: 1 × Micro SIM
USB Ports: 1 × USB Type C
Dimensions: 124 × 100 × 54mm
Warranty: 24 Months

The MikroTik hAP ac² is a dual-concurrent access point/router that provides simultaneous Wi-Fi coverage for both 2.4GHz and 5GHz bands.
Equipped with five Gigabit Ethernet ports, it ensures fast wired connections for multiple devices, while the USB 2.0 port supports external storage or 4G/LTE modem connectivity.
Powered by RouterOS (Level 4 licence), it offers advanced networking features such as firewall, bandwidth shaping, and user access control.
Its universal case design allows flexible placement — either horizontally or vertically — making it ideal for home or office setups.
Backed by a 24-month warranty, the hAP ac² delivers reliable WiFi 5 performance with Gigabit-class wired networking.

Key Features
Dual-band WiFi 5 router/AP (2.4GHz + 5GHz)
2.4GHz: 300Mbps, 5GHz: 867Mbps throughput
5 × Gigabit Ethernet ports (10/100/1000Mbps)
USB 2.0 port for external storage or 4G/LTE modem
RouterOS (Level 4 licence) with advanced features
Universal case design: horizontal or vertical positioning
Passive PoE-in support (18V–28V)
Max power consumption: 15W
Operating temperature: -40°C to 50°C
24-month limited warranty

Specifications
Antenna Gain: 2.4GHz: 2.5dBi, 5.8GHz: 2.5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps, 5.8GHz: 867Mbps
Ethernet Ports: 5 × 10/100/1000Mbps
Hardware Buttons: Reset & Mode
Max Power Consumption: 15W
Mounting: Desktop (horizontal or vertical)
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 50°C
PoE Input: 18V–28V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A (adapter included)
USB Ports: 1 × USB 2.0
Dimensions: 34 × 119 × 98mm
Warranty: 24 Months

The MikroTik hAP ac Lite Tower Case is a dual-concurrent access point/router that provides simultaneous Wi-Fi coverage for both 2.4GHz and 5GHz bands.
Equipped with a 650MHz CPU and 64MB RAM, it delivers reliable performance for home or small office networks.
It features five Fast Ethernet ports, with PoE output on port #5, dual-chain 802.11b/g/n 2.4GHz wireless, single-chain 802.11ac 5GHz wireless, and a USB port for 3G/4G modem support.
Running RouterOS (Level 4 licence), it offers advanced networking features such as firewall, bandwidth shaping, and user access control.
Compact tower-style design with included power adapter, backed by a 24-month warranty.

Key Features
Dual-band WiFi 5 router/AP (2.4GHz + 5GHz)
2.4GHz: 300Mbps, 5GHz: 433Mbps throughput
5 × Fast Ethernet ports (10/100Mbps)
PoE-in support (10V–28V passive PoE)
PoE-out pass-through on port #5
USB 2.0 port for 3G/4G modem connectivity
RouterOS (Level 4 licence) with advanced features
Compact tower case desktop design, power adapter included
Max power consumption: 7W
24-month limited warranty

Specifications
Antenna Gain: 2.4GHz: 1.5dBi, 5.8GHz: 2dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps, 5.8GHz: 433Mbps
Ethernet Ports: 5 × 10/100Mbps
Hardware Button: Reset
Max Power Consumption: 7W
Mounting: Desktop Tower Case
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -30°C to 70°C
PoE Input: 10V–28V (Passive PoE)
PoE Output: Passive PoE pass-through on Port 5
Power Input: 24V 1.2A (adapter included)
USB Ports: 1 × USB 2.0
Dimensions: 34 × 119 × 98mm
Warranty: 24 Months

The MikroTik hAP ac Lite is a dual-concurrent access point/router that provides simultaneous Wi-Fi coverage for both 2.4GHz and 5GHz bands.
Equipped with a 650MHz CPU and 64MB RAM, it delivers reliable performance for home or small office networks.
It features five Fast Ethernet ports, with PoE output on port #5, dual-chain 802.11b/g/n 2.4GHz wireless, single-chain 802.11ac 5GHz wireless, and a USB port for 3G/4G modem support.
Running RouterOS (Level 4 licence), it offers advanced networking features such as firewall, bandwidth shaping, and user access control.
Compact and desktop-friendly, it’s backed by a 24-month warranty.

Key Features
Dual-band WiFi 5 router/AP (2.4GHz + 5GHz)
2.4GHz: 300Mbps, 5GHz: 433Mbps throughput
5 × Fast Ethernet ports (10/100Mbps)
PoE-in support (12V–30V passive PoE)
PoE-out pass-through on port #5
USB 2.0 port for 3G/4G modem connectivity
RouterOS (Level 4 licence) with advanced features
Compact desktop design, power adapter included
Max power consumption: 8W
24-month limited warranty

Specifications
Antenna Gain: 2.4GHz: 1.5dBi, 5.8GHz: 2dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps, 5.8GHz: 433Mbps
Ethernet Ports: 5 × 10/100Mbps
Hardware Button: Reset
Max Power Consumption: 8W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
PoE Input: 12V–30V (Passive PoE)
PoE Output: Passive PoE pass-through on Port 5
Power Input: 24V 1.2A (adapter included)
USB Ports: 1 × USB 2.0
Dimensions: 113 × 89 × 28mm
Warranty: 24 Months

The MikroTik hAP Lite Tower Case is a compact home access point/router, ideal for apartments, houses, or small offices.
It delivers WiFi 4 (2.4GHz, 300Mbps) wireless connectivity and includes 4 Fast Ethernet ports for wired devices.
With button-triggered WPS, visitors can connect easily without typing complex passwords. It can also switch to cAP mode to join a centrally managed CAPsMAN network at the push of a button.
Powered by a 650MHz CPU with 32MB RAM, it runs RouterOS (Level 4 licence), offering advanced features like bandwidth shaping, firewall, and user access control.
Compact, tower-style, and USB‑powered, it’s a reliable entry-level router/AP backed by a 24-month warranty.

Key Features
WiFi 4 (2.4GHz, 300Mbps) wireless access point/router
4 × Fast Ethernet ports for wired connectivity
Button-triggered WPS for easy guest access
cAP mode support for CAPsMAN centralized management
RouterOS (Level 4 licence) with advanced networking features
650MHz CPU with 32MB RAM
Tower case desktop design, USB power supply included
Operating temperature: -20°C to 70°C
24-month limited warranty

Specifications
Antenna Gain: 1.5dBi
Beam-width: 360°
Data Rate: 2.4GHz 300Mbps
Ethernet Ports: 4 × 10/100
Hardware Button: Reset
Max Power Consumption: 3.5W
Mounting: Desktop Tower Case
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -20°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 5V 1A USB (included)
USB Ports: 1 × Micro USB (power only)
Dimensions: 124 × 100 × 54mm
Warranty: 24 Months

The MikroTik hAP Lite is a compact home access point/router, ideal for apartments, houses, or small offices.
It delivers WiFi 4 (2.4GHz, 300Mbps) wireless connectivity and includes 4 Fast Ethernet ports for wired devices.
With button-triggered WPS, visitors can connect easily without typing complex passwords. It can also switch to cAP mode to join a centrally managed CapsMAN network at the push of a button.
Powered by a 650MHz CPU with 32MB RAM, it runs RouterOS (Level 4 licence), offering advanced features like bandwidth shaping, firewall, and user access control.
Compact and USB‑powered, it’s a reliable entry-level router/AP backed by a 24-month warranty.

Key Features
WiFi 4 (2.4GHz, 300Mbps) wireless access point/router
4 × Fast Ethernet ports for wired connectivity
Button-triggered WPS for easy guest access
cAP mode support for CapsMAN centralized management
RouterOS (Level 4 licence) with advanced networking features
650MHz CPU with 32MB RAM
Compact desktop design, USB power supply included
Operating temperature: -20°C to 60°C
24-month limited warranty

Specifications
Antenna Gain: 1.5dBi
Beam-width: 360°
Data Rate: 2.4GHz 300Mbps
Ethernet Ports: 4 × 10/100
Hardware Button: Reset
Max Power Consumption: 3.5W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 5V 1A USB (included)
USB Ports: 1 × Micro USB (power only)
Dimensions: 113 × 89 × 28mm
Warranty: 24 Months

The MikroTik hAP RB951Ui-2nD is a compact home access point/router, ideal for homes or small offices.
It delivers WiFi 4 (2.4GHz, 300Mbps) wireless connectivity and includes 5 Fast Ethernet ports for wired devices.
Powered via DC jack or passive PoE, it also features PoE-out on port 5 to power another MikroTik device.
Preconfigured for quick setup, it runs RouterOS (Level 4 licence), offering advanced routing and firewall features in a small desktop form factor.
Backed by a 24-month warranty, it’s a reliable entry-level router/AP solution.

Key Features
WiFi 4 (2.4GHz, 300Mbps) wireless access point
5 × 10/100 Ethernet ports for wired connectivity
Passive PoE-in and PoE-out support (port 5)
Compact desktop design with included power adapter
RouterOS (Level 4 licence) for advanced networking features
Antenna gain: 1.5dBi, 360° beamwidth
Operating temperature: -30°C to 70°C
USB 2.0 port for expansion
24-month limited warranty

Specifications
Antenna Gain: 1.5dBi
Beam-width: 360°
Data Rate: 2.4GHz 300Mbps
Ethernet Ports: 5 × 10/100
Hardware Button: Reset
Max Power Consumption: 5W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -30°C to 70°C
PoE Input: 10V–28V (Passive PoE)
PoE Output: Passive PoE pass-through on Port 5
Power Input: 24V 0.8A (adapter included)
USB Ports: 1 × USB 2.0
Dimensions: 113 × 89 × 28mm
Warranty: 24 Months

MikroTik cAP-2nD – Ceiling-Mount 2.4GHz WiFi AP | 802.11n | PoE Powered

Discreet, High-Performance Access Point for Hotels, Offices & Public Spaces

The MikroTik cAP-2nD is a ceiling-mounted 2.4GHz WiFi AP designed for seamless deployment in hospitality, retail, and enterprise environments. With 802.11n support, 802.3af/at PoE compatibility, and CAPsMAN integration, it delivers reliable wireless coverage while blending into any decor.
🚀 Key Features

✔ Upgraded Hardware – 650MHz CPU & 2x memory vs. previous model (cAP-2n).
✔ 802.11n WiFi – 2.4GHz coverage for legacy and IoT devices.
✔ Flexible Power Options – 802.3af/at PoE or 11-57V DC input.
✔ CAPsMAN Support – Centrally manage multiple APs from any RouterBOARD device.
✔ Complete Mounting Kit – Includes PoE injector, screws, and ceiling/wall brackets.
📊 Technical Specifications

WiFi Standards: 802.11b/g/n (2.4GHz)

Max Speed: 150Mbps (theoretical)

Antennas: Internal 2x2 MIMO

PoE Support: 802.3af/at (included injector)

Power Input: 11-57V DC (passive PoE or adapter)

Mounting: Ceiling/wall (hardware included)

Dimensions: Ø 160mm x 35mm (low-profile)

🏆 Why Choose the cAP-2nD?

✅ Plug-and-Play Setup – Pre-installed RouterOS + CAPsMAN ready.
✅ Cost-Effective – No need for a separate controller PC.
✅ Discreet Design – Blends into ceilings for aesthetic installations.
🔍 Ideal For:

🏨 Hotels & Hospitality – Reliable guest WiFi without bulky hardware.
🛒 Retail Stores & Malls – Uniform coverage for POS/customer access.
🏢 Office Spaces – Easy deployment with PoE-powered simplicity.
📦 What’s Included?

cAP-2nD access point

PoE injector & power adapter

Ceiling/wall mount kit (screws + anchors)

MikroTik RouterBoard RB3011UiAS (Rackmount) – High-Performance 10x Gigabit + SFP Router

Enterprise-Grade Networking with ARM CPU, USB 3.0 & LCD Touchscreen

The MikroTik RB3011UiAS-RM is a rack-mounted powerhouse featuring 10x Gigabit ports, SFP uplink, and a USB 3.0 port for storage/4G modems. Driven by an ARM CPU for superior throughput, it’s ideal for SMBs, ISPs, and data centers needing reliability and advanced routing.
🚀 Key Features

✔ 10x Gigabit Ethernet Ports – Dual switch groups (5 ports each) for VLAN/load balancing.
✔ SFP Fiber Uplink – Add a 1G optical connection for backbone links.
✔ USB 3.0 Port – Attach 3G/4G modems or external storage for backups.
✔ PoE Output – Last Ethernet port powers devices like APs (24V Passive PoE).
✔ Touchscreen LCD – Monitor status/configs without a console.
✔ RouterOS L6 License – Advanced firewall, QoS, VPN, and wireless features.
📊 Technical Specifications

CPU: Dual-core ARM 1.4GHz

RAM: 1GB

Ports:

10x Gigabit Ethernet (2x switch groups)

1x SFP (1G)

1x USB 3.0

1x Serial Console

PoE: Port 10 (24V Passive PoE-out)

Rack Size: 1U (included)

Power: 24V DC input (adapter sold separately)

🏆 Why Choose the RB3011UiAS?

✅ Future-Proof – ARM CPU handles VLANs, VPNs, and high-speed routing.
✅ All-in-One – LCD touchscreen for easy monitoring + USB 3.0 for expandability.
✅ ISP-Grade – Perfect for hotspots, VPN servers, or edge routing.
🔍 Ideal For:

🏢 Small/Medium Businesses – Robust routing with 10Gig LAN/SFP flexibility.
📶 Wireless ISPs – PoE-powered CPEs + fiber backhaul support.
🔒 VPN Gateways – High-speed encryption with RouterOS L6.
📦 What’s Included?

RB3011UiAS-RM router (rack ears pre-installed)

Power adapter (region-specific)

Mounting screws

MikroTik RBHGO-antenna-OUT – Dual-Band Outdoor Antenna (2.4GHz 3.3dBi / 5GHz 5.5-7.1dBi) | RP-SMA

Upgrade Your NetMetal ac² with High-Performance Outdoor WiFi Coverage

The MikroTik RBHGO-antenna-OUT is a weatherproof dual-band antenna designed to enhance outdoor wireless performance. With RP-SMA female connectors, it delivers 3.3dBi gain (2.4GHz) and 5.5-7.1dBi gain (5GHz), making it ideal for NetMetal ac² access points and other outdoor WiFi deployments.
📡 Key Features

✔ Dual-Band Optimization – 2.4GHz (3.3dBi) and 5GHz (5.5-7.1dBi) for versatile coverage.
✔ Weatherproof Design – Built to withstand rain, UV, and extreme temperatures.
✔ RP-SMA Connectors – Compatible with MikroTik NetMetal ac² and other outdoor APs.
✔ Easy Installation – Screw-on design for quick setup.
✔ Cost-Effective Upgrade – Boost signal range and stability without replacing your AP.
📦 Compatibility

✅ MikroTik NetMetal ac² (use two antennas for dual-band operation)
✅ Other outdoor WiFi devices with RP-SMA female ports
📋 Specifications

Frequency Bands: 2.4GHz & 5GHz

Gain:

2.4GHz: 3.3dBi

5GHz: 5.5-7.1dBi

Connector: RP-SMA female

Weather Resistance: IP54 (splash/dust resistant)

Cable Length: XX cm (if applicable)

🏆 Why Choose RBHGO-antenna-OUT?

✅ Plug-and-Play – No tools required for installation.
✅ Improved Coverage – Higher gain for better signal penetration.
✅ MikroTik Reliability – Built for long-term outdoor use.
🔍 Perfect For:

📶 Outdoor WiFi Networks – Extend coverage for NetMetal ac² APs.
🏡 Home & Business Deployments – Enhance backyard or parking lot WiFi.
🏗️ Temporary Setups – Durable enough for events or construction sites.

MikroTik QuickMount Pro Bracket – Premium 140° Wall/Pole Mount for Small Antennas

Advanced Mounting Solution for SXT, OmniTik & Lightweight Devices (<1.5kg)

The MikroTik QuickMount Pro Bracket is a high-durability mounting system designed for small antennas and networking devices (up to 1.5kg). Featuring 140° dual-axis adjustment and anvilNITE™ composite construction, it ensures precise alignment and long-term reliability for PtP, sector, or repeater setups.
🔧 Key Features

✔ 140° Dual-Axis Adjustment – Fine-tune horizontal & vertical angles for optimal signal strength.
✔ Ultra-Durable Material – Made with anvilNITE™ composite for weather/UV resistance.
✔ Multi-Mount Compatibility – Works with walls, poles, or MikroTik’s small mounting clips.
✔ Lightweight Yet Strong – Supports devices up to 1.5kg (e.g., SXT, OmniTik, BaseBox).
✔ Tool-Free Installation – Includes clamps & hardware for quick setup.
📦 Compatibility

✅ MikroTik SXT Series (Lite5, sq, etc.)
✅ OmniTik & NetMetal Devices
✅ Other Pole-Mountable Gear (<1.5kg)
📋 Specifications

Max Load Capacity: 1.5kg

Adjustment Range: 140° horizontal & vertical

Material: anvilNITE™ composite (impact/weather-resistant)

Mounting Options: Wall, pole, or clip (U-bolt included)

Weight: 0.4kg (lightweight but rugged)

🏆 Why Choose QuickMount Pro?

✅ Precision Alignment – Graduated scale for exact angle adjustments.
✅ Carrier-Grade Durability – Withstands rain, wind, and UV exposure.
✅ Versatile Use – Ideal for PtP links, sector antennas, or repeaters.
🔍 Perfect For:

📶 WISPs & Home Networks – Optimize SXT/Sector antenna positioning.
🏢 Urban Wireless Deployments – Secure mounting for rooftop setups.
🌦️ Harsh Environments – AnvilNITE™ resists corrosion and extreme temps.

MikroTik quickMOUNT extra – Heavy-Duty Antenna Mount | 190° Adjustment | Wall/Pole Compatible

Professional-Grade Mounting Solution for Large Sector & PtP Antennas

The MikroTik quickMOUNT extra is an industrial-strength wall/pole mount adapter designed for large antennas like the mANT 30 (30dBi dish) and mANT 19s (19dBi sector). Featuring 190° rotation range and universal compatibility, it ensures precise alignment for long-range wireless links.
🔩 Key Features

✔ 190° Articulation – Fine-tune antenna positioning horizontally & vertically
✔ Heavy-Duty Build – Supports large antennas up to XX kg (specify max load)
✔ Dual Mounting Options – Wall or pole (adapts to small/large diameters)
✔ All-Weather Design – Powder-coated steel for rust resistance
✔ Tool-Free Adjustment – Secure clamping with graduated scale for precision
📦 Compatibility

• MikroTik mANT 30 (30dBi parabolic dish)
• MikroTik mANT 19s (19dBi sector antenna)
• Other large PtP/sector antennas with standard mounting points
📋 Specifications

Material: 2mm steel with anti-corrosion coating

Rotation Range: 190° (horizontal + vertical)

Pole Diameter: XX-XX mm (adjust based on clamp specs)

Weight Capacity: XX kg (verify with antenna specs)

Installation: Includes U-bolts, clamps, and hardware

🏆 Why Choose quickMOUNT extra?

✅ Carrier-Grade Stability – No signal drift in high winds
✅ Future-Proof – Works with MikroTik’s largest antennas
✅ 5-Minute Setup – Pre-drilled holes for hassle-free mounting
🔍 Perfect For:

📶 WISPs – Secure mounting for tower/base station antennas
🏢 Enterprise PtP Links – Precise alignment for long-range bridges
🌪️ Harsh Environments – Withstands storms, salt spray, and UV exposure

MikroTik LHG Mount – Universal Metal Pole Bracket for LHG Series (Incl. LHG XL)

Durable, Low-Cost Mounting Solution for LHG Wireless Antennas

The MikroTik LHG Mount is a heavy-duty metal bracket designed to securely install LHG series antennas (including LHG XL models) on poles or masts. Includes U-bolt and K-58 mounting kit for quick, tool-free assembly.
🔩 Key Features

✔ Universal Compatibility – Fits all LHG series devices (LHG 5, LHG XL, LHG HP, etc.)
✔ Rugged Metal Construction – Withstands harsh outdoor conditions
✔ Easy Installation – Includes U-bolt + K-58 kit for poles up to XX mm diameter (specify max pole size)
✔ Cost-Effective – Affordable alternative to complex mounting systems
✔ Precision Alignment – Ensures optimal antenna positioning for signal strength
📦 Package Includes

1x LHG metal mounting bracket

1x U-bolt (stainless steel)

1x K-58 mounting kit (clamps, nuts, washers)

📋 Specifications

Material: Powder-coated steel

Pole Diameter Range: XX-XX mm (adjust based on U-bolt specs)

Weight: 0.5kg (lightweight but sturdy)

Weather Resistance: IP54 (splash/dust resistant)

🏆 Why Choose This Mount?

✅ No Tools Required – Hardware included for immediate installation
✅ Future-Proof – Works with current & future LHG models
✅ MikroTik-Quality – Engineered for long-term reliability
🔍 Perfect For:

📶 WISPs – Rapid deployment of LHG antennas on towers
🏡 Home Installations – Secure mounting for rooftop/sidewall setups
🏗️ Temporary Setups – Easy to relocate as needed

MikroTik LHG XL HP5 – 5GHz 27dBi High-Power Wireless Bridge | 40km Range

Long-Range PtP Connectivity with Integrated High-Gain Grid Antenna

The MikroTik LHG XL HP5 combines a 630mW high-power radio with an integrated 27dBi dual-polarization grid antenna, delivering 40km+ point-to-point links at full throughput. Designed for ISPs and enterprise backhauls requiring carrier-grade performance at minimal cost.
⚡ Key Features

✔ Extreme 5GHz Range – 40km+ in ideal conditions (FCC/ETSI compliant)
✔ High TX Power – 630mW output (27dBm) for penetrating obstacles
✔ Zero Cable Loss – Integrated antenna design maximizes signal integrity
✔ Nv2 Protocol – TDMA support for efficient airtime utilization
✔ All-Weather Durability – Wind-resistant grid (-40°C to 60°C operation)
✔ Tool-Free Tilt Adjustment – Includes 5° tilt adapter for precise alignment
📊 Technical Specifications

Frequency: 5GHz (802.11a/n)

Antenna Gain: 27dBi (dual-polarization)

Max TX Power: 630mW (27dBm)

Protocols: NV2, Nstreme, MIMO

Ports: 1x Gigabit Ethernet (24V Passive PoE-in)

Wind Survival: 60 m/s (134 mph)

Dimensions: 500 x 500 x 60mm (assembled)

Weight: 2.2kg (per unit)

🏆 Why Choose LHG XL HP5?

✅ Plug-and-Play Deployment – Ships flat-packed; assembles in minutes
✅ No RF Expertise Needed – Pre-tuned for optimal performance
✅ Carrier-Grade Reliability – Trusted by WISPs worldwide
🔍 Ideal For:

🌉 ISP Backhauls – Cost-effective 40km PtP links
🏗️ Industrial Sites – Mines, oil rigs, and remote campuses
📡 Emergency Comms – Rapid deployable long-range networks
📦 Package Includes

1x LHG XL HP5 unit (disassembled)

Mounting hardware & grounding kit

5° tilt adjustment adapter

Quick-start guide

MikroTik 3-Pack LHG 5 (Light Head Grid) – 5GHz 24.5dBi Outdoor Wireless Kit

High-Gain, Cost-Effective PtP & PtMP Solutions for ISPs

This 3-pack bundle of MikroTik’s LHG 5 delivers 5GHz 802.11a/n connectivity with integrated 24.5dBi dual-polarization grid antennas, perfect for long-distance point-to-point links or CPE deployments. Includes Nv2 TDMA protocol support for efficient airtime utilization.
📦 What’s Included?

3x LHG 5 units (pre-configured for easy deployment)

Integrated 24.5dBi grid antennas (no cable loss)

Grounding kits & tilt adapters (+5° adjustment)

Mounting hardware (pre-assembled for quick setup)

✨ Key Features

✔ High-Gain 5GHz Wireless – 24.5dBi antenna for up to 10km+ links (conditions apply).
✔ Nv2 TDMA Protocol – Enhanced throughput and interference resistance.
✔ All-in-One Design – Antenna + radio integrated (no cable loss).
✔ Wind-Resistant Grid – Durable in harsh outdoor environments.
✔ Easy Assembly – Ships flat-packed; tools included.
📋 Specifications (Per Unit)

Frequency: 5GHz (802.11a/n)

Antenna Gain: 24.5dBi (dual-polarization)

Max Power: 28dBm (adjustable)

Protocols: NV2, Nstreme, MIMO

Ports: 1x Gigabit Ethernet (24V Passive PoE-in)

Wind Survival: 60 m/s

Operating Temp: -40°C to 60°C

Dimensions: 400 x 400 x 50mm (assembled)

🏆 Why Choose LHG 5?

✅ Plug-and-Play – Pre-assembled for quick deployment.
✅ Carrier-Grade – Trusted by ISPs for PtMP networks.
✅ No RF Expertise Needed – Optimized for easy setup.
🔍 Ideal For:

📶 Wireless ISPs (WISPs) – Affordable PtP/PtMP backhaul.
🏗️ Remote Sites – Oil rigs, surveillance, or rural connectivity.
🌉 Bridge Links – Connect buildings up to 10km apart.

MikroTik Cloud Router Switch RBCRS125-24G-1S-RM – 24x Gigabit + 1x SFP | RouterOS L4

Enterprise-Grade L3 Switching & Routing in a 1U Rack Chassis

The MikroTik RBCRS125-24G-1S-RM combines 24x Gigabit Ethernet ports and 1x SFP fiber uplink in a compact rack-mount design, powered by RouterOS L4 for advanced networking at an unbeatable price. Ideal for SMBs, ISPs, and enterprise edge deployments.
🔧 Key Specifications

✔ 24x Gigabit Ethernet Ports – Full wire-speed switching
✔ 1x SFP Port – Fiber uplink (1.25Gbps)
✔ Switch Chip: 88E6393X (Dual-core 800MHz CPU)
✔ Switching Capacity: 26 Gbps
✔ Layer 3 Features: VLAN, QoS, RIP, OSPF (RouterOS L4)
✔ Power Input: 100-240V AC (internal PSU)
✔ Max Power Consumption: 24W
✔ Rack-Mountable: 1U (440 x 220 x 44 mm)
✔ Operating Temp: -40°C to 60°C
🚀 Why This Switch?

✅ RouterOS Flexibility – Firewall, VPN, bandwidth management
✅ Silent Operation – Fanless design for office environments
✅ Future-Proof – SFP port for fiber expansion
✅ MikroTik Reliability – Trusted by ISPs worldwide
💼 Perfect For:

🏢 Office Networks – Connect workstations, servers, and IP phones
📶 ISP Edge Deployments – Cost-effective customer aggregation
🎥 Surveillance Systems – Bandwidth for multiple IP cameras
📦 What's Included?

RBCRS125-24G-1S-RM switch

Rack mounting ears

Power cable

1-year warranty

MikroTik RB-CRS310 Cloud Router Switch – 8x 2.5Gbps + 2x 10G SFP+ | RouterOS L5

Enterprise-Grade L3 Switching & Routing in a Compact Rack Unit

The MikroTik RB-CRS310 is a high-performance cloud router switch featuring 8x 2.5Gbps Ethernet ports and 2x 10G SFP+ cages, powered by a Marvell 98DX226S chipset and RouterOS L5 for advanced networking in data centers, ISPs, or office backbones.
🔧 Key Specifications

Switch Chip: Marvell 98DX226S (Dual-core ARM 800MHz)

Ports:

8x 2.5Gbps Ethernet (10/100/1000/2500Base-T)

2x 10G SFP+ (fiber or DAC cables)

1x USB (for storage/configuration)

Performance:

Switching Capacity: 56 Gbps non-blocking

System Memory: 256MB

Power:

Input: 18-57V DC (24V 1.5A PSU included)

Max Consumption: 21W

Durability:

Operating Temp: -40°C to 60°C

Rack-Mount: 1U (200 x 206 x 44 mm)

✨ Standout Features

✔ Multi-Gig Ready – Future-proof 2.5Gbps ports for high-speed LANs.
✔ Layer 3 Capabilities – VLAN, QoS, and routing via RouterOS L5 License.
✔ Dual 10G Uplinks – Fiber/copper SFP+ for backbone connectivity.
✔ Industrial Tough – Operates in extreme temperatures (-40°C to 60°C).
✔ Plug-and-Play – USB port for easy config backup/restore.
🏆 Why Choose MikroTik?

✅ Cost-Effective – Enterprise features at SMB pricing.
✅ Energy-Efficient – Only 21W max power draw.
✅ Scalable – Ideal for ISP aggregation, CCTV networks, or lab environments.
🔍 Ideal For:

🏢 Office Networks – High-density 2.5G device connectivity.
📡 ISP Backhauls – SFP+ uplinks for tower/base station links.
🎥 Video Surveillance – Bandwidth for 4K IP cameras.
📋 Compliance & Logistics

Gross Weight: ~2 kg (rack ears included)

Certifications: CE, FCC, RoHS

Warranty: 1-year manufacturer warranty

MikroTik RB-ATL18 Outdoor LTE Cat 18 CPE – 1.2Gbps 4x4 MIMO Router with High-Gain Antennas

Enterprise-Grade LTE Connectivity for Remote & Harsh Environments

The MikroTik RB-ATL18 is a high-performance outdoor LTE Cat 18 CPE designed for mission-critical connectivity. Featuring 4x4 MIMO support, 1.2Gbps download speeds, and ruggedized construction, it delivers carrier-grade internet in remote areas, industrial sites, or mobile deployments.
📦 Key Specifications

LTE Modem: Category 18 (1.2Gbps DL / 150Mbps UL)

Antenna System:

4x High-Gain Antennas: 2x 13dBi + 2x 9dBi (1.7–2.7 GHz)

2x Low-Band Antennas: 3dBi (700MHz–1GHz, Band 28 support)

Ports:

1x Gigabit Ethernet (PoE-in, 802.3af/at)

1x Micro SIM Slot

1x Mini PCIe Slot (for expandability)

Power:

Input: 12V–57V (24V 0.8A PSU included)

Max Consumption: 8W

Durability:

Operating Temp: -40°C to 70°C

Pole-Mount Design: Ø 315mm x 170mm

✨ Standout Features

✔ Blazing Fast LTE-A Pro – 1.2Gbps download with 4x4 MIMO for low-latency applications.
✔ Global Band Support – Covers LTE Bands 1-5, 7-8, 20, 28, 38, 40, 41 (ideal for rural/weak signal areas).
✔ Plug-and-Play PoE – Single cable for data + power (802.3af/at compatible).
✔ RouterOS v7 (L3 License) – Advanced QoS, firewall, and VPN management via WinBox/WebFig.
✔ Industrial Ruggedness – Survives extreme cold, heat, and humidity.
🏆 Why Choose MikroTik?

✅ Carrier-Grade Reliability – Trusted by ISPs and enterprises worldwide.
✅ Future-Proof – Mini PCIe slot for optional 5G/NB-IoT upgrades.
✅ Low TCO – Energy-efficient (8W max) with no recurring license fees.
🔍 Ideal For:

🌐 Rural Broadband – Stable internet in low-coverage zones.
🏭 Industrial IoT – Oil rigs, mining, and smart agriculture.
🚚 Mobile Deployments – Emergency response, vehicles, or temporary sites.
📋 Compliance & Logistics

Gross Weight: ~2.5 kg (with packaging)

Certifications: CE, FCC, RoHS

Warranty: 1-year manufacturer warranty
