The Hikvision DS-7608NXI-K2 is a compact 1U 8‑channel AcuSense NVR designed for small-to-medium deployments that need smart analytics and reliable local monitoring. It features eight integrated PoE ports for streamlined camera power and connectivity, supports up to 12MP recording with H.265+ compression, and offers 4K HDMI output for crisp local display. AcuSense AI provides face and perimeter detection to reduce false alerts, while dual SATA bays allow flexible storage (up to 20 TB total). With 80 Mbps incoming bandwidth, robust alarm I/O, and a compact chassis, this NVR balances performance, manageability, and cost-effectiveness.

Technical Details:

Channels: 8 IP camera inputs
PoE: 8 × PoE ports (power budget depends on SKU/PSU)
Max recording: Up to 12 MP
Incoming bandwidth: 80 Mbps
Decoding / Playback: Multi‑channel playback; H.265+/H.265/H.264 support
Video outputs: 1 × 4K HDMI (local monitor)
Storage: 2 × SATA bays, up to 20 TB total (manufacturer guidance recommended)
AI features: AcuSense face detection and perimeter protection
Alarm I/O: 4 inputs / 1 output
Dimensions: 385 × 315 × 52 mm
Weight: ~3.0 kg (unit)
Operating conditions: Typical commercial operating ranges (refer to datasheet for specifics)
Model / SKU: DS‑7608NXI‑K2 (8‑PoE variant)

The Hikvision DS-7716NXI-I4/16P/S is a 16‑channel 1.5U AcuSense 4K NVR engineered for mid‑to‑large deployments that require smart analytics and heavy storage. With a 160 Mbps incoming bandwidth, 16 integrated PoE ports, and four 4K HDMI outputs, it delivers high‑throughput recording and flexible local monitoring. AcuSense AI supports face recognition and perimeter protection on up to four channels to reduce false alarms and prioritise events. Robust storage options (4 × SATA up to 56 TB total), H.265+ compression, multi‑channel 1080p decoding, and comprehensive alarm I/O make this NVR ideal for campuses, retail, and enterprise installations demanding reliable, intelligent video management.

Technical Details:

Channels: 16‑channel input; 32‑channel 1080p decode
Form Factor: 1.5U chassis
Incoming Bandwidth: 160 Mbps
Video Outputs: 4 × 4K HDMI (local displays)
Compression: H.265+, H.265, H.264
AI Features: AcuSense face recognition & perimeter protection (up to 4 channels)
Storage: 4 × SATA bays, up to 14 TB per bay (total up to 56 TB)
Alarm I/O: 16 inputs / 9 outputs (16/9 configuration)
PoE: 16 × PoE ports integrated (power budget dependent on PSU/ SKU)
Playback: Multi‑channel synchronous playback; smart search & playback features
Network: Gigabit NIC(s); ONVIF compatibility for third‑party cameras
Model / SKU: DS-7716NXI-I4/16P/S

The Hikvision DS-7732NXI-I4/16P/S is a 32‑channel 1U AcuSense 4K NVR built for large deployments that need smart analytics and ample storage. It supports 16 PoE ports for direct camera power, up to 256 Mbps incoming bandwidth, and 4K HDMI output for crisp monitoring. AcuSense AI enables perimeter protection and face recognition on up to 4 channels, while 32‑channel 1080p decoding ensures smooth playback across many streams. With four SATA bays (up to 16 TB each) plus eSATA expansion, flexible alarm I/O (16 in / 9 out), and a robust 445 × 400 × 75 mm chassis, it’s ideal for campuses, retail estates, and multi‑site systems.

Technical details:

Channels: 32‑channel input; 32‑channel 1080p decode
PoE ports: 16 × PoE (integrated)
Bandwidth: Up to 256 Mbps incoming
Video output: 4K HDMI (plus standard outputs)
AI features: AcuSense perimeter protection + face recognition (up to 4 channels)
Playback: Multi‑channel synchronous playback
Compression: H.265+, H.265, H.264
Storage: 4 × SATA bays, up to 16 TB each; 1 × eSATA expansion
Alarm I/O: 16 inputs / 9 outputs
Dimensions: 445 × 400 × 75 mm
Model / SKU: DS-7732NXI-I4/16P/S

The Hikvision DS-7104NI-Q1/4P is a compact 4‑channel 1U Mini NVR with built‑in PoE for simplified installation. Supporting up to 6MP recording and 4‑channel 1080p decoding, it delivers reliable performance for small to medium surveillance setups. With 40 Mbps incoming bandwidth and 60 Mbps outgoing, HDMI/VGA outputs, and H.265+ compression, it ensures efficient storage and smooth playback. A single SATA interface supports up to 6 TB HDD, while the 36 W PoE budget powers up to four IP cameras directly. Compact (200 × 200 × 48 mm), powered by DC 48V, and operating in -10~55°C, this NVR is ideal for cost‑effective, space‑saving deployments.

Technical Details:

Channels: 4‑channel input
Form Factor: 1U Mini NVR
PoE Ports: 4 × PoE, 36 W total budget
Recording: Up to 6MP/4MP resolution
Bandwidth: 40 Mbps incoming, 60 Mbps outgoing
Decoding: 4‑channel 1080p synchronous playback
Video Output: HDMI & VGA
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 6 TB HDD
Power: DC 48V
Operating Temperature: -10°C to +55°C
Dimensions: 200 × 200 × 48 mm
Model / SKU: DS-7104NI-Q1/4P

The TP-Link VIGI-NVR1104H-4P is a 4‑channel PoE+ 4K NVR designed for efficient and intelligent video management. Supporting up to 16 MP decoding, 4K HDMI output, and 4‑channel synchronous playback, it delivers crisp, high‑resolution monitoring. With a 53 W PoE+ power budget, it can directly power and connect up to four IP cameras, simplifying installation. Featuring H.265+ compression for optimized storage, a single SATA interface supporting up to 10 TB HDD, ONVIF compatibility, and a built‑in speaker, this NVR integrates seamlessly with the VIGI app for remote access and management. Compact and reliable, it’s ideal for small to medium surveillance setups.

Technical Details:

Channels: 4‑channel input
PoE+ Budget: 53 W total
Video Output: 4K HDMI
Decoding Capability: Up to 16 MP
Playback: 4‑channel synchronous playback
Compression: H.265+, H.265, H.264
Storage: 1 × SATA interface, up to 10 TB HDD
Audio: Built‑in speaker
Integration: ONVIF compliant; remote management via VIGI app
Power: PoE+ and 12 VDC support
Model / SKU: VIGI-NVR1104H-4P

The Hikvision DS-7604NXI-K1 is a 4‑channel 1U AcuSense 4K NVR designed for intelligent video management. Supporting up to 40 Mbps incoming bandwidth and 4K HDMI output, it delivers crisp playback and recording. Advanced AcuSense AI provides face recognition and perimeter protection, reducing false alarms and enhancing security efficiency. With H.265+ compression, a single SATA interface supporting up to 10 TB HDD, and 4‑channel synchronous playback, this NVR ensures reliable storage and smooth performance. Compact (320 × 240 × 48 mm) and powered by 12 VDC/PoE, it’s ideal for small to medium surveillance setups requiring smart analytics and efficient storage.

Technical Details:

Channels: 4‑channel input
Form Factor: 1U rackmount
Incoming Bandwidth: 40 Mbps
Video Output: 4K HDMI
Compression: H.265+, H.265, H.264
AI Features: AcuSense face recognition & perimeter protection
Playback: 4‑channel synchronous playback
Storage: 1 × SATA interface, up to 10 TB HDD
Power: 12 VDC / PoE support
Dimensions: 320 × 240 × 48 mm
Model / SKU: DS-7604NXI-K1

The Hikvision DS-2CD2T27G2-L is a 2MP ColorVu fixed bullet IP camera designed for vivid full‑colour imaging day and night. With a 2.8 mm wide‑angle lens (≈126°), ultra‑low‑light sensitivity down to 0.0005 lux, and 40 m white‑light illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 120 dB WDR balances high‑contrast scenes. Built‑in microphone, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 256 GB make this compact bullet camera ideal for perimeter, entrance, and outdoor monitoring.

Technical Details:

Resolution: 2 MP (1920 × 1080)
Lens: 2.8 mm fixed; Field of View ≈ 126°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: 40 m white‑light LED
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 120 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~5–6 W
Model / SKU: DS-2CD2T27G2-L-2.8mm

The TP-Link VIGI-C445 is a 4MP full‑color turret IP camera designed for reliable outdoor surveillance. With a 2.8 mm wide‑angle lens (≈122°), ultra‑low‑light sensitivity down to 0.005 lux, and dual Smart Illumination (30 m white‑light and 30 m IR), it ensures clear detail day and night. On‑device AI for human and vehicle detection reduces false alarms, while 3D DNR and 130 dB WDR deliver sharp, balanced images. Built with IP67 weatherproof housing, PoE/12V power options, H.265+ compression, and microSD storage up to 256 GB, this turret camera is compact (111 × 111 × 83 mm) and ideal for perimeter, entrance, and commercial monitoring.

Technical Details
Resolution: 4 MP (2560 × 1440)
Lens: 2.8 mm fixed; Field of View ≈ 122°
Low‑light: Min. illumination 0.005 lux (colour)
Illumination: 30 m white‑light + 30 m IR night vision
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
Noise Reduction: 3D DNR (Digital Noise Reduction)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) or 12 VDC
Storage: microSD slot up to 256 GB (card not included)
Dimensions: 111 × 111 × 83 mm
Network: ONVIF compliant; remote viewing via VIGI app/NVRs
Model / SKU: VIGI-C445-2.8mm

The Hikvision DS-2CD2347G2H-LISU-SL is a 4MP ColorVu fixed turret IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Equipped with a 4 mm lens (≈117.4° wide view), ultra‑low‑light sensitivity down to 0.0005 lux, and up to 30 m Smart Illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. With built‑in mic and speaker for two‑way audio, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 512 GB, this turret camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 4 mm fixed; Field of View ≈ 117.4°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone & speaker (two‑way audio)
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2347G2H-LISU-SL-4mm

The Hikvision DS-2CD2047G2H-LIU-SL is a 4MP ColorVu fixed mini bullet IP camera in sleek black finish, designed for vivid full‑colour imaging day and night. With a 2.8 mm lens (≈133.6° wide view), Smart Hybrid Light up to 40 m, and ultra‑low‑light sensitivity (0.0005 lux), it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. Built‑in microphone, IP67 weatherproof housing, PoE support, H.265+ compression, and microSD storage up to 512 GB make this camera ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 133.6°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 40 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Finish: Black
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Mini bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2047G2H-LIU-SL-2.8mm-BLK

The TP‑Link Tapo C125 is a premium 2K QHD indoor smart security camera featuring advanced AI detection for people, pets, and baby cries. With a physical privacy shutter, invisible IR night vision, 140° wide‑angle lens, and two‑way audio, it delivers reliable day‑and‑night monitoring for modern homes. The magnetic base allows flexible placement, while support for Apple HomeKit, Alexa, and Google Assistant ensures seamless smart‑home integration. Store footage locally up to 512GB or use encrypted cloud options for added convenience.

Key Specifications
2K QHD indoor Wi‑Fi smart camera
140° wide‑angle lens
AI detection: person, pet, baby cry
Physical privacy shutter
Invisible IR night vision
Two‑way audio
microSD storage up to 512GB
Apple HomeKit, Alexa & Google Assistant compatible
Magnetic base for flexible mounting

Technical Details
Feature Details
Resolution 2K QHD (2560 × 1440)
Lens 140° wide‑angle
AI Detection Person, pet, baby cry
Privacy Physical privacy shutter
Night Vision Invisible IR night vision
Mounting Magnetic base
Storage microSD up to 512GB
Smart Home Integration Apple HomeKit, Alexa, Google Assistant
Connectivity Wi‑Fi enabled
Model / SKU TAPO‑C125

The Hikvision DS-2CD2955G0-ISU is a 5MP fixed fisheye IP camera designed for wide‑area monitoring with a 180° panoramic view. Featuring a 1.05 mm lens, 2560×1920 resolution at 25 fps, and IR coverage up to 8 m, it delivers sharp detail across large spaces. With H.265+ compression, PoE support, and microSD storage up to 512 GB, it ensures efficient recording and easy installation. Audio I/O enables two‑way communication, while flexible mounting options (wall, ceiling, or table) and compact Ø119 mm design make it ideal for retail, offices, and public areas requiring full coverage.

Technical Details:

Resolution: 5 MP (2560 × 1920 @ 25 fps)
Lens: 1.05 mm fixed fisheye; 180° panoramic view
IR Night Vision: Up to 8 m
Video Compression: H.265+, H.265, H.264
Audio I/O: Built‑in microphone and external audio interface
Mounting Options: Wall, ceiling, or table mount
Dimensions: Ø119 mm compact design
Weatherproofing: Indoor/outdoor adaptable (check installation environment)
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Model / SKU: DS-2CD2955G0-ISU-1.05mm

The Hikvision DS-2CD2347G2H-LI is a 4MP ColorVu fixed turret IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈138.5°), ultra‑low‑light sensitivity down to 0.0005 lux, and up to 30 m Smart Illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR balances high‑contrast scenes. With IP67 weatherproof housing, built‑in microphone, PoE support, H.265+ compression, and microSD storage up to 512 GB, this turret camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 138.5°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Dimensions: Ø138 × 115 mm
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W
Model / SKU: DS-2CD2347G2H-LI-2.8mm

The Hikvision DS-2CD2041G0-LIU is a compact 4MP fixed bullet IP camera with Smart Hybrid Light for clear imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈114°), low‑light sensitivity down to 0.005 lux, and 30 m Smart Illumination, it delivers sharp detail in challenging conditions. With 120 dB WDR for high‑contrast scenes, built‑in microphone for audio capture, and support for microSD storage up to 256 GB, this camera offers versatile functionality. Rugged IP67 weatherproof housing, PoE support, and H.265+ compression make it efficient, durable, and ideal for outdoor surveillance.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 114°
Low‑light: Min. illumination 0.005 lux (colour)
Illumination: Smart Hybrid Light up to 30 m
Video Compression: H.265+, H.265, H.264
WDR: 120 dB wide dynamic range
Audio: Built‑in microphone
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~5–6 W
Model / SKU: DS-2CD2041G0-LIU-2.8mm

The Hikvision DS-2CD2T47G2H-LI is a 4MP ColorVu fixed bullet IP camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Equipped with a 4 mm lens (≈108° wide view), ultra‑low‑light sensitivity (0.0005 lux), and up to 60 m Smart Hybrid illumination, it ensures clear detail even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms, while 130 dB WDR delivers balanced images in high‑contrast scenes. With IP67 weatherproofing, PoE support, H.265+ compression, and microSD storage up to 512 GB, this camera is ideal for outdoor perimeter and entrance monitoring.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 4 mm fixed; Field of View ≈ 108°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 60 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2T47G2H-LI-4mm

The Hikvision DS-2CD2T47G2H-LI is a 4MP ColorVu fixed bullet camera with Smart Hybrid Light for vivid full‑colour imaging day and night. Featuring a 2.8 mm wide‑angle lens (≈126.7°), ultra‑low‑light ColorVu sensitivity (0.0005 lux) and up to 60 m Smart Hybrid illumination, it captures detailed colour footage even in near‑dark conditions. On‑device AI for human and vehicle detection reduces false alarms while 130 dB WDR manages high‑contrast scenes. Built for outdoor reliability with IP67 weatherproofing, PoE for simplified installs, H.265+ compression and microSD support up to 512 GB, it’s ideal for perimeter, entrance and street‑level monitoring.

Technical Details
Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View: ≈ 126.7°
Low‑light: ColorVu; Min. illumination: 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 60 m
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps/NVRs
Mounting: Bullet form factor with 3‑axis adjustable bracket
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2T47G2H-LI-2.8mm

The Hikvision DS-2CD2T46G2H-4I is a 4MP AcuSense bullet camera delivering precise perimeter protection with Dark Fighter low-light performance and long-range IR. Featuring a 2.8 mm wide-angle lens (≈113°), up to 80 m IR, and AcuSense human/vehicle classification to cut false alarms, it captures clear, actionable footage day or night. Built for tough outdoor use with IP67 weatherproofing, 120 dB WDR, H.265+ compression, PoE power and on-board microSD storage, the camera supports alarm I/O for integrated security workflows and remote management via standard NVRs and mobile apps.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 113°
Low light: Dark Fighter tech; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 80 m; Smart IR support
Video Compression: H.265+, H.265, H.264
AI / Analytics: AcuSense human and vehicle classification (on-device)
WDR: 120 dB wide dynamic range
Alarm I/O: External alarm input/output for integration
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 256 GB (card not included)
Network: ONVIF compatible; remote viewing via Hikvision apps/NVRs
Typical Power Draw: ~6–8 W (varies with IR/AI activity)
Mounting: Bullet form factor with 3-axis adjustable bracket
Model / SKU: DS-2CD2T46G2H-4I-2.8mm

The Hikvision DS-2CD2347G2H-LIU is a 4MP ColorVu turret camera that delivers vivid full‑colour imaging day and night with Smart Hybrid Light up to 40 m. Featuring a 2.8 mm wide‑angle lens (~138.5°), ultra‑low‑light ColorVu sensitivity (0.0005 lux), AI human/vehicle detection, 130 dB WDR, PoE, IP67 durability, H.265+ compression and on‑board microSD storage (up to 512 GB), it’s ideal for perimeter, entrance and street‑level monitoring where true‑colour detail and intelligent alerts matter.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 138.5°
Low‑light: ColorVu; Min. illumination 0.0005 lux (colour)
Illumination: Smart Hybrid Light up to 40 m
IR / Night Tech: Hybrid Smart Illumination + ColorVu
Video Compression: H.265+, H.265, H.264
AI Analytics: Human and vehicle detection (on‑device)
WDR: 130 dB wide dynamic range
Audio: Built‑in microphone (audio support)
Weatherproof: IP67 rated housing
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot, up to 512 GB (card not included)
Network: ONVIF compliant; remote viewing via Hikvision apps
Mounting: Turret form factor with multi‑axis adjustable mount
Typical Power Draw: ~6–8 W (varies with illumination/AI use)
Model / SKU: DS-2CD2347G2H-LIU-2.8mm

The Hikvision DS-2CD2146G2H-I is a 4MP fixed dome powered by DarkFighter low-light technology for exceptional night-time colour and clarity. Equipped with a 2.8 mm wide-angle lens (≈119.7°), 30 m IR, 120 dB WDR and on-device AI for human and vehicle detection, it reliably captures high-detail footage in challenging lighting and high-contrast scenes. Ruggedly built to IP67 weatherproof and IK10 vandal-resistant standards, it supports H.265+ compression, PoE or 12 VDC power, and local recording via microSD (up to 512 GB). Ideal for perimeter, entrance and critical-site surveillance where low-light performance and durability matter.

Technical Details:

Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of view ≈ 119.7°
Low-light tech: DarkFighter; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 30 m; Smart IR support
WDR: 120 dB wide dynamic range
AI Analytics: Human & vehicle detection (on-device)
Video Compression: H.265+, H.265, H.264
Weather & Impact Rating: IP67 (weatherproof) & IK10 (vandal resistant)
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot, up to 512 GB (card not included)
Network: ONVIF compliant; mobile/web remote viewing support
Mounting: Dome form factor with multi-axis adjustable mount
Typical Power Draw: ~6–8 W (varies with IR/AI use)
Model / SKU: DS-2CD2146G2H-I-2.8mm

The Hikvision DS-2CD2146G2H-I is a 4MP Dark Fighter dome IP camera engineered for superior low-light surveillance. With a 2.8 mm wide-angle lens (≈119.7°), Dark Fighter sensitivity to 0.001 lux, and 30 m IR, it captures clear colour and monochrome detail in extreme lighting. Built-in AI for human and vehicle detection reduces false alerts while 120 dB WDR handles high-contrast scenes. Rugged IP67 weatherproofing and IK10 vandal resistance make it ideal for outdoor and exposed locations. H.265+ compression, PoE power, and microSD support up to 512 GB deliver efficient storage and flexible installation for perimeter, entrance, and critical-site monitoring.

Technical Details
Resolution: 4 MP (2688 × 1520)
Lens: 2.8 mm fixed; Field of View ≈ 119.7°
Low light: Dark Fighter technology; Min. illumination 0.001 lux (colour)
IR Night Vision: Up to 30 m; Smart IR support
Video Compression: H.265+, H.265, H.264
AI Analytics: Human & vehicle detection (on-device)
WDR: 120 dB wide dynamic range
Weather & Impact Rating: IP67 (weatherproof) & IK10 (vandal resistant)
Power: PoE (802.3af) and 12 VDC support (model-dependent)
Storage: microSD slot up to 512 GB (card not included)
Network: ONVIF compliant; mobile and web remote viewing support
Mounting: Dome form factor with multi-axis adjustable mount
Typical Power Draw: ~6–8 W (varies with IR/AI activity)
Model / SKU: DS-2CD2146G2H-I-2.8mm
