Ubiquiti's NBE-213AC is an airMAX AC 2GHz radio with a 13dBi antenna. It is designed as a lightweight, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 13dBi
Beam-width: 60°
Data Rate: 450Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7.5W
Mounting: Pole-Mount
Operating System: airMAX
Operating Temperature: -40°C to 80°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None
Dimensions: 189 x 189 x 125mm
Weight: 530g

Ubiquiti's LOCO-M2 is an airMAX M series 2GHz radio with a 10dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) access point solution. It can be managed via the UISP network management platform.

Specifications

Antenna Gain: 8.5dBi
Beam-width: 60°
Data Rate: 150Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 5.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -30°C to 75°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None
Dimensions: 161 x 31 x 80mm
Weight: 180g

Ubiquiti's LOCO-5ACL is an airMAX AC 5GHz radio with a 13dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) solution or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: The LOCO-5ACL does not ship with a PoE adapter; we recommend powering the unit with our UPOE-24G12W

Specifications

Antenna Gain: 13dBi
Beam-width: 45°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V Passive PoE
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None
Dimensions: 179 x 77.5 x 59.1mm
Weight: 180g

Ubiquiti's LBE-523 is an airMAX M series 5GHz radio with a 23dBi antenna. It is designed as a lightweight, cost-effective, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. It can be managed via the UISP network management platform.

Specifications

Antenna Gain: 23dBi
Beam-width: 15°
Data Rate: 150Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 4W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.2A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None
Dimensions: 362 x 267 x 184mm
Weight: 750g

Ubiquiti's LBE-529ACXR is an airMAX AC 5GHz radio with a 29dBi antenna. It is designed as a lightweight, long-range, CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

Specifications

Antenna Gain: 29dBi
Beam-width: 7.5°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22-26V
USB Ports: None
Dimensions: 747 x 525 x 347 mm
Weight: 3.2 kg

Brand: Ubiquiti
Product Code: LBE‑523ACG2
Description: Ubiquiti UISP airMAX LiteBeam AC 5GHz 23dBi Radio

Product Overview
The Ubiquiti LiteBeam AC Gen2 (LBE‑5AC‑Gen2) is a lightweight, cost‑effective 5GHz radio solution designed for long‑distance CPE (client premises equipment) or PtP (point‑to‑point) deployments. Featuring a 23dBi antenna with a 15° beamwidth, it delivers reliable connectivity with speeds up to 867Mbps. The dedicated 2.4GHz management radio allows for simplified setup and monitoring via the UISP network management platform. Compact and durable, it is ideal for extending wireless coverage in rural, enterprise, or ISP environments.

Key Features
23dBi high‑gain antenna for long‑distance connectivity
15° beamwidth for focused point‑to‑point links
Data rate up to 867Mbps
Dedicated 2.4GHz management radio for easy setup
1 × Gigabit Ethernet port
Pole‑mount design for outdoor installations
Max power consumption: 7W
Operating temperature: –40°C to 70°C
Includes 24V Gigabit PoE injector
Dimensions: 358 × 271.95 × 272.5 mm
Net weight: 980g
Gross shipping weight: 1.5–1.8 kg (including packaging)

Technical Specifications
Feature Details
Product Code LBE‑523ACG2
Antenna Gain 23dBi
Beamwidth 15°
Data Rate 867Mbps
Ethernet Ports 1 × 10/100/1000
Hardware Button Reset
Max Power Consumption 7W
Mounting Pole‑mount
Operating System airOS
Operating Temp –40°C to 70°C
PoE Input 24V Passive PoE
PoE Output None
Power Input 24V; 0.3A Gigabit PoE Injector (included)
Dimensions 358 × 271.95 × 272.5 mm
Net Weight 980g
Gross Shipping Weight 1.5–1.8 kg

What’s Included
1 × Ubiquiti LiteBeam AC Gen2 (LBE‑5AC‑Gen2)
1 × 24V Gigabit PoE Injector
Pole‑mounting kit
User documentation

Brand: Ubiquiti
Product Code: LAP‑517AC
Description: Ubiquiti UISP airMAX LiteAP AC 5GHz 17dBi 90° Radio with GPS

Product Overview
The Ubiquiti LiteAP AC GPS (LAP‑GPS) is a lightweight, cost‑effective PtMP (point‑to‑multipoint) access point solution designed for outdoor deployments. Featuring a 17dBi, 90° sector antenna, it delivers reliable connectivity with speeds up to 867Mbps. The integrated GPS radio is optimized for co‑location environments, helping mitigate interference and improve network performance. With a dedicated 2.4GHz management radio, setup and monitoring are simplified via the UISP network management platform. Its pole‑mount bracket requires minimal tools, ensuring quick and easy installation.

Key Features
17dBi high‑gain, 90° sector antenna
Optimized for PtMP access point deployments
GPS synchronization for interference mitigation in co‑location environments
Data rate up to 867Mbps
Dedicated 2.4GHz management radio for simplified setup
1 × Gigabit Ethernet port
Pole‑mount design for outdoor installations
Max power consumption: 7.1W
Operating temperature: –40°C to 70°C
Includes 24V Gigabit PoE injector
Dimensions: 360.98 × 124.57 × 71.28 mm
Net weight: 752g
Gross shipping weight: 1.2–1.5 kg (including packaging)

Technical Specifications
Feature Details
Product Code LAP‑517AC
Antenna Gain 17dBi
Beamwidth 90°
Data Rate 867Mbps
Ethernet Ports 1 × 10/100/1000
Hardware Button Reset
Max Power Consumption 7.1W
Mounting Pole‑mount
Operating System airOS
Operating Temp –40°C to 70°C
PoE Input 24V Passive PoE
PoE Output None
Power Input 24V; 0.3A Gigabit PoE Injector (included)
Dimensions 360.98 × 124.57 × 71.28 mm
Net Weight 752g
Gross Shipping Weight 1.2–1.5 kg

What’s Included
1 × Ubiquiti LiteAP AC GPS (LAP‑GPS)
1 × 24V Gigabit PoE Injector
Pole‑mounting kit
User documentation

Ubiquiti's LAP-516AC is an airMAX ac 5GHz radio with 16dBi, 120° sector antenna. It is designed as a lightweight, cost-effective PtMP (point to multipoint) access point solution. The bracket requires minimal tools for adjustment to simplify installation.

Specifications

Antenna Gain: 16dBi
Beam-width: 120°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V, 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20-26V
USB Ports: None
Dimensions: 452.3 x 78.7 x 54.4mm
Weight: 420g

Brand: Ubiquiti
Product Code: ISO‑514AC
Description: Ubiquiti UISP airMAX IsoStation AC 5GHz 14dBi Horn Radio

Product Overview
The Ubiquiti IsoStation AC (IS‑5AC) is a shielded airMAX AC 5GHz radio featuring a 14dBi, 45° symmetrical horn antenna. Designed for PtMP (point‑to‑multipoint) deployments in high‑interference environments, it offers excellent co‑location performance in a compact form factor. It can also serve as a short‑range CPE (client premises equipment). The antenna is interchangeable with other Ubiquiti horn antennas (sold separately), providing deployment flexibility. A dedicated 2.4GHz management radio simplifies setup and monitoring via the UISP network management platform.

Key Features
14dBi gain, 45° symmetrical horn antenna
Optimized for PtMP access point deployments in high‑interference environments
Can also be used as short‑range CPE
Interchangeable horn antennas for flexible deployments (sold separately)
Dedicated 2.4GHz management radio for easy setup
Data rate up to 867Mbps
1 × Gigabit Ethernet port
Pole‑mount design for outdoor installations
Max power consumption: 8.5W
Operating temperature: –40°C to 70°C
Includes 24V Gigabit PoE injector
Dimensions: 174 × 174 × 150 mm
Net weight: 725.7g
Gross shipping weight: 1.2–1.5 kg (including packaging)

Technical Specifications
Feature Details
Product Code ISO‑514AC
Antenna Gain 14dBi
Beamwidth 45°
Data Rate 867Mbps
Ethernet Ports 1 × 10/100/1000
Hardware Button Reset
Max Power Consumption 8.5W
Mounting Pole‑mount
Operating System airOS
Operating Temp –40°C to 70°C
PoE Input 24V Passive PoE
PoE Output None
Power Input 24V; 0.5A Gigabit PoE Injector (included)
Dimensions 174 × 174 × 150 mm
Net Weight 725.7g
Gross Shipping Weight 1.2–1.5 kg

What’s Included
1 × Ubiquiti IsoStation AC (IS‑5AC)
1 × 24V Gigabit PoE Injector
Pole‑mounting kit
User documentation

Ubiquiti's AIR-S522AC is a 5GHz 22dBi, 45° airMAX AC sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.

Specifications

Antenna Gain: 22dBi
Beam-width: 45°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 347N @ 200km/h
Dimensions: 750 x 215 x 94mm
Weight: 6kg

Ubiquiti's AIR-S521AC is a 5GHz 21dBi, 60° airMAX ac, sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.

Specifications

Antenna Gain: 21dBi
Beam-width: 60°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 391N @ 200km/h
Dimensions: 750 x 173 x 78mm
Weight: 4.8Kg

Ubiquiti's AIR-D534 is a 5GHz 34dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D534 features robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 34dBi
Beam-width: 3°
Connector: 2x RP SMA Female
Frequency Range: 4.9 – 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 1;779N @ 200km/h

Dimensions: Ø 1050 x 421mm
Weight: 13.5kg

Ubiquiti's AIR-D530LW is a 5GHz 30dBi lightweight dish antenna designed to seamlessly integrate with the Ubiquiti Radios.
*Note: Radio not included.

Specifications

Antenna Gain: 30dBi
Beam-width: 5.8°
Connector: 2x RP SMA Female
Frequency Range: 5.1GHz - 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 790N @ 200km/h

Dimensions: Ø 650 x 386mm
Weight: 7.4kg

Ubiquiti's UISP-DISH is a 5GHz 30dBi dish antenna designed to seamlessly integrate with Ubiquiti radios. The antenna provides extended coverage by utilising a wide frequency range. The unit comes with a precision mounting bracket for easy installation and alignment.

*Note: Radio not Included.

Specifications

Antenna Gain: 30dBi
Beam-width: 5 to 6° (3 dB) / 6.5 to 8° (6 dB)
Connector: WaveGuide Adapter (Included)
Frequency Range: 5.15 - 6.875GHz
Polarization: Vertical & Horizontal
Wind Loading: 860 N at 200 km/h
Dimensions: Ø 650 x 200 mm
Weight: 7.64Kg

Ubiquiti's AIR-D530 is a 5GHz 30dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D530 features a robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 30dBi
Beam-width: 5°
Connector: 2x RP SMA Female
Frequency Range: 4.9GHz - 5.8GHz
Polarization: Vertical & Horizontal
Wind Loading: 787N @ 200km/h

Dimensions: Ø 650 x 304mm
Weight: 9.8kg

Ubiquiti's AIR-S520 is a 5GHz 20dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 20dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 182N @ 200km/h
Dimensions: 700 x 135 x 70mm
Weight: 5.9kg

Ubiquiti's AIR-S519 is a 5GHz 19dBi, 120° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 19dBi
Beam-width: 120°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 137.9N @ 200km/h

Dimensions: 700 x 135 x 73mm
Weight: 5.9kg

Ubiquiti's AIR-S517 is a 5GHz 17dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Specifications

Antenna Gain: 17dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 4.90GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 41.7N @ 200km/h

Dimensions: 367 x 63 x 41mm
Weight: 1.1kg

Ubiquiti's AIR-O513 is a 5GHz 13dBi, 360° airMAX Omni antenna designed to seamlessly integrate with Ubiquiti Radio's.

*Note: Radio not included.

Specifications

Antenna Gain: 13dBi
Beam-width: 360°
Connector: 2x RP SMA Female
Frequency Range: 5.45GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 84.52N @ 200km/h
Dimensions: 799 x 90 x 65mm
Weight: 0.82kg

Ubiquiti's AIR-O510 is a 5GHz 10dBi, 360° airMAX Omni antenna designed to seamlessly integrate with Ubiquiti Radio's.

*Note: Radio not included.

Specifications

Antenna Gain: 10dBi
Beam-width: 360°
Connector: 2x RP SMA Female
Frequency Range: 5.45GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 71.17N @ 200km/h
Dimensions: 582 x 90 x 65mm
Weight: 0.68kg
