HiLook16 Port Fast Ethernet Unmanaged POE Switch | NS-0318P-130(B)

16 Port Fast Ethernet Unmanaged POE Switch
Unmanaged switch with 16 x 100 Mbps PoE ports, 1 x 1000 Mbps RJ45 port, and 1 x 1000 Mbps SFP port
All ports support 6 kV lighting protection
130 W PoE power budget
Maximum transmission distance is 250 meters for port 9 to 16 in "extend" mode
MAC address auto learning and auto aging
General
Shell Metal material
Operating temperature-10 °C to 55 °C (14 °F to 131 °F)
Storage temperature-40 °C to 85 °C (-40 °F to 185 °F)
Power supply100 to 240 VAC, 50/60 Hz, Max. 2.5 A
Storage humidity5% to 95% (no condensation)
Net weight1.8 kg (4.0 lb)
Gross weight2.58 kg (5.69 lb)
Dimension (L × H × D)266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)
Operating humidity5% to 95% (no condensation)
Power consumption in idle20 W

Network parameters
Port number16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
Port typeRJ45 port, full duplex, MDI/MDI-X adaptive
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding mode Store-and-forward switching
Working mode Standard mode (default); Extend mode
MAC address table4 K
Switching capacity7.2 Gbps
Packet forwarding rate5.356 Mpps
Internal cache2.75 Mbits
High priority ports Ports 1 to 8
Ports for long-distance transmission Ports 9 to 16
PoE power supply
PoE standard IEEE 802.3af, IEEE 802.3at
PoE power pin
Ports for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.
Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.
PoE portPorts 1 to 16
Max. port power30 W
PoE power budget130 W
Max. power consumption150 W
