UltraLAN Installer Series - CAT5e Solid UTP (500m)


500m roll of UltraLAN CAT5e Installer Series solid-core Ethernet bulk cable suitable for everyday networking installations.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.




General Specifications

Packaging: 500m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Gross weight: 13.5kg

UltraLAN Installer Series - CAT5e CCA Solid UTP WHITE (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.

General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: White

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Packaging dimensions: 22x35x35cm

Gross weight: 7.6kg

UltraLAN Installer Series - CAT6 Bare Copper Solid UTP (305m)


305m Box of UltraLAN CAT6 Installer Series solid-core Bare Copper Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m Box

Conductor material: Solid Bare Copper

Conductor diameter: 23AWG

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 Bare Copper Solid UTP (500m)


500m Drum of UltraLAN CAT6 Installer Series solid-core Bare Copper Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 500m Drum

Conductor material: Solid Bare Copper

Conductor diameter: 23AWG

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (305m - Grey)


305m box of Ultra LAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (305m)

305m box of Ultra LAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Blue

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (500m - Grey)


305m box of UltraLAN CAT6 solid CCA Ethernet cable for high-performance networks. This cable has a grey cable jacket which blends better in environments when no trunking/ducting is used (in comparison to the standard blue color CAT6).
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 500m Drum

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Grey

Operation temperature range: -20°C~70°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (500m)

500m Drum of UltraLAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient

General Specifications

Packaging: 500m Drum

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Blue

Operation temperature range: -20°C~70°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (100m)


100m box of UltraLAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.

General Specifications

Packaging: 100m Easy Pull Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN LC/APC Fast Connector (for 0.9mm Fiber)

The UltraLAN LC Fast Connector can easily and quickly be installed onto fiber cabling while in the field. These fast connectors allows the fiber installer to terminate and make connection in minutes at equipment and fiber patch panels.

This Fast Connector is suitable for 0.9mm fiber cables.

UltraLAN LC/APC Fast Connector (for drop cables)

The UltraLAN LC Fast Connector can easily and quickly be installed onto fiber cabling while in the field. These fast connectors allows the fiber installer to terminate and make connection in minutes at equipment and fiber patch panels.

This Fast Connector is suitable for 2.0x3.0mm drop cables.

UltraLAN LC/UPC Fast Connector (for 0.9mm Fiber)

The UltraLAN LC Fast Connector can easily and quickly be installed onto fiber cabling while in the field. These fast connectors allows the fiber installer to terminate and make connection in minutes at equipment and fiber patch panels.

This Fast Connector is suitable for 0.9mm fiber cables.

UltraLAN LC/UPC Fast Connector (for drop cables)

The UltraLAN LC Fast Connector can easily and quickly be installed onto fiber cabling while in the field. These fast connectors allows the fiber installer to terminate and make connection in minutes at equipment and fiber patch panels.

This Fast Connector is suitable for 2.0x3.0mm drop cables.

UltraLAN Midspan Coupler LC-LC APC Duplex

UltraLAN's fiber coupler, also sometimes called a fiber midspan adapter, is a small device designed to link the fiber optic cables/connectors between two fiber lines.

By linking two lines or connectors precisely, fiber optic couplers allow the light sources to be transmitted almost seamlessly and lowers the loss as much as possible. At the same time, fiber optic couplers have the merits of low insertion loss and good interchangeability to suit your specific needs.
UltraLAN's midspan couplers can easily and quickly be installed inside fiber termination boxes and fiber patch panels.

Connector Type LC-LC Body Style Duplex
Polish Type APC Fiber Mode Single/Multi mode
Insertion Loss ≤0.2dB Mounting Type Full Flanged

UltraLAN Midspan Coupler LC-LC UPC Duplex

UltraLAN's fiber coupler, also sometimes called a fiber midspan adapter, is a small device designed to link the fiber optic cables/connectors between two fiber lines.

By linking two lines or connectors precisely, fiber optic couplers allow the light sources to be transmitted almost seamlessly and lowers the loss as much as possible. At the same time, fiber optic couplers have the merits of low insertion loss and good interchangeability to suit your specific needs.

UltraLAN's midspan couplers can easily and quickly be installed inside fiber termination boxes and fiber patch panels.

Connector Type LC-LC Body Style Duplex
Polish Type UPC Fiber Mode Single/Multi mode
Insertion Loss ≤0.2dB Mounting Type Full Flanged

UltraLAN Midspan Coupler SC-SC APC Simplex

UltraLAN's fiber coupler, also sometimes called a fiber midspan adapter, is a small device designed to link the fiber optic cables/connectors between two fiber lines.

By linking two lines or connectors precisely, fiber optic couplers allow the light sources to be transmitted almost seamlessly and lowers the loss as much as possible. At the same time, fiber optic couplers have the merits of low insertion loss and good interchangeability to suit your specific needs.

UltraLAN's midspan couplers can easily and quickly be installed inside fiber termination boxes and fiber patch panels.
Connector Type SC-SC Body Style Simplex
Polish Type APC Fiber Mode Single mode
Insertion Loss ≤0.2dB Mounting Type Full Flanged

UltraLAN Midspan Coupler ST-ST UPC Duplex


UltraLAN's fiber coupler, also sometimes called a fiber midspan adapter, is a small device designed to link the fiber optic cables/connectors between two fiber lines.

By linking two lines or connectors precisely, fiber optic couplers allow the light sources to be transmitted almost seamlessly and lowers the loss as much as possible. At the same time, fiber optic couplers have the merits of low insertion loss and good interchangeability to suit your specific needs.
UltraLAN's midspan couplers can easily and quickly be installed inside fiber termination boxes and fiber patch panels.

Connector Type ST-ST Body Style Duplex
Polish Type UPC Fiber Mode Single mode
Insertion Loss ≤0.2dB Mounting Type Full Flanged

UltraLAN Multi-Function Fiber & Network Cable Tester

The UltraLAN FIB-T-MPCT-OPM-VFL is a powerful hybrid tester combining RJ45 cable diagnostics with fiber optic testing — making it the ultimate tool for both copper and fiber environments. In addition to standard network functions like cable tracing, pin sequence checks, length measurement (up to 600m), and PoE diagnostics, this unit also features an integrated Optical Power Meter (OPM) and Visual Fault Locator (VFL). These built-in fiber tools enable quick and accurate identification of optical signal strength, fiber continuity, and break detection — all from one compact device. Ideal for technicians working across both wired and fiber infrastructure.

Support for PoE testing up to 90W (IEEE 802.3bt/at/af and non-standard) makes it perfect for CCTV, VoIP, and access control setups. Additional features include switch port flashing, cable tracing with adjustable sensitivity, NCV detection for live wires, and optional built-in modules for optical power measurement and visual fault location.

Key Features:

Tests RJ45 cable sequence, continuity, crimping quality, and pin faults
Cable length test up to 600m with ±3% accuracy
Real-time PoE testing (IEEE 802.3af/at/bt) up to 90W: Voltage, power, polarity
Switch/router port identification using port flash mode
Digital cable tracer with adjustable sensitivity and anti-interference design
NCV detection with live/neutral wire identification and audible alerts
Optical Power Meter (optional): -70 to +6 dBm, 850–1650nm wavelengths
Visual Fault Locator (optional): 10mW red laser, 650nm, range up to 10km
LED light and auto power-off features

Specifications:

General:

Display: 3" high-contrast LCD
Operating Temperature: -10°C to +50°C
Operating Humidity: 30%–90%
Power: 3x AA batteries (emitter), 2x AA batteries (receiver)

Network Cable Testing

Supported Cable Types: RJ45 (UTP/STP), RJ11, low-voltage metal cables
Cable Length Measurement: 1–600m (±3% ±1m accuracy)
Wiremap Test: Detects open, short, miswire, cross, and split pairs
Continuity Test: Pin-level fault detection and crimp verification
Port Flashing: Locates switch/router ports and identifies 100M/1000M link speed
PoE Testing: Supports IEEE802.3af/at/bt and non-standard PoE detection
Power supply pinout, polarity, real-time voltage & wattage (0–90W load)
Cable Tracer: Anti-interference digital signal tracing with adjustable sensitivity
NCV Function: Detects AC voltage in cables and power outlets

Fiber Testing:

Optical Power Meter (OPM):
Supported Wavelengths: 980, 1270, 1300, 1577, 1650nm
Measurement Range: -70 to +6 dBm
Features: Real-time optical power display, wavelength selection, REF mode for fiber loss comparison, and user calibration support
Visual Fault Locator (VFL):
Output Power: 10mW
Wavelength: 650nm red laser
Modes: Continuous and pulse (1Hz, 2Hz)
Detection Range: Up to 10km — ideal for locating fiber breaks, cracks, and bends

UltraLAN OTDR with VFL, OPM & Cable Tester

The UltraLAN FIB-T-OTDR1315 is a professional-grade, multifunctional OTDR (Optical Time Domain Reflectometer) tester designed for fiber network construction, diagnostics, and maintenance. Combining the capabilities of multiple tools into a compact 5.5-inch touchscreen unit, it streamlines fiber testing with high precision, user-friendly controls, and intelligent analysis.

With support for testing up to 100km, wavelengths of 1310/1550nm, and dynamic ranges of 26/24dB, the FIB-T-OTDR1315 delivers accurate insight into fiber link performance. Its core functions include OTDR testing, visual fault locating (VFL), optical power meter (OPM), loss testing, stable laser source output, RJ45 TDR testing, UTP cable diagnostics, and fiber end inspection.

Product Highlights:

5.5" OLED touchscreen with 1280×720 resolution
OTDR support for 1310/1550/ with up to 100km range
Dual dynamic range (26/24dB) for high-accuracy fiber diagnostics
Stable laser source with CW/270/330/1000/2000Hz modes
Loss test, VFL, optical power meter, cable tracer, and RJ45 TDR included
4000mAh rechargeable battery, USB/SD card data export, and PDF/Excel report generation

Key Features:

High-Precision OTDR with auto and expert modes for fault location, attenuation analysis, and event mapping
Dual Wavelength Support: Optional 1310/1550nm testing for both short and long-range applications
Event Map & Trace Graph: Automatically detect and analyze reflection and non-reflection events such as splices, bends, and breaks
Visual Fault Locator (VFL): 10mW red laser source tests for visible fiber breaks up to 8km
Loss Test Mode: Calibrate and evaluate insertion loss of optical passive devices with real-time power readings
Optical Power Meter: Multi-wavelength support (850 to 1625nm) for both linear and non-linear power display
Cable Tester: RJ45 wiremap and TDR mode to detect pin faults, breaks, and measure cable length (up to 600m)
Data Export: Save reports in .SOR, PDF, or Excel formats via USB or SD card
Rugged Interface: SC-PC port, LED lamp, Type-C power input, RS-485, and Micro SD card slot
Portable & Durable: Compact and lightweight, with 4000mAh Li-ion battery for 5+ hours of field use

Ideal For:

Fiber link deployment & certification
FTTH/FTTX installation and troubleshooting
Data center and telecom maintenance
CCTV and CATV infrastructure validation
