Cudy's CD-UH606 is a plug and play USB-C hub featuring 1x 4K 60Hz HDMI port, 3x 5Gbps USB-A ports, 1x 100W USB-C port for power supply charging, 1x 5Gbps USB-C data port and 1x Gigabit Ethernet port.

Specifications

Ethernet Ports: 1x 10/100/1000
Upstream Port: 1x USB-C
Video Output: 1x HDMI 2.0
Video Output Resolution: 4K @ 60Hz ; 2K @ 144Hz ; 1080P @ 240Hz
USB Ports: 1x USB-C ; 3x USB-A
Power Input: USB-C Male with 25cm cable
Input Voltage: 5-20V 0-5A
Max Power Consumption: 100W (powered by PD Adapter); 10W if powered by the host client's USB Power
Max Idle Power Consumption: 0.4W
Dimensions: 113.1 x 44.2 x 15.7mm
Weight: 78g

Plug-and-Play USB-C dongle for extending a PC with HDMI, USB-C, USB-A, and SD/TF slots, ideal for photographers, businesspeople, lecturers, and school students.

Specifications

1× HDMI 2.0, 4K 60Hz, 2K 144Hz
1× Upstream PD USB-C Male (5 Gbps)
2× USB-A 3.2 Gen 1 (5 Gbps)
1× USB-C 3.2 Gen 1 (5 Gbps)
1× TF Slot, 1× SDXC Slot
1× USB-C Receiving 100W PD
64 g (2.26 oz.)
130×32×11 mm (5.12×1.26×0.43")
PC/Mac/iPad/iPhone/Android/Nintendo

Cudy's CD-FS1010PG is an 8 Port Fast Ethernet switch with 8x 802.3af/at PoE ports and 2x Gigabit Uplink ports. The switch offers a 115W PoE budget, up to 32W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-8 while Extender mode increases the transmission distance on ports 1-8 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when in VLAN or Extender Mode. If an error is detected on the device, the switch immediately restarts the port.

Specifications

Ethernet Ports: 8x 10/100; 2x 10/100/1000
Hardware Button: VLAN; Extender; Default
Max. Power Consumption: 5W
Mounting: Desktop or Wall-Mount
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: 802.3af/at PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100-240V
Dimensions: 220 x 150 x 40mm
Weight: 800g

Cudy's CD-GS108D features 8x Gigabit Ethernet Ports and supports non-blocking switching architecture and MAC address auto-learning and auto-aging.

Specifications

Ethernet Ports: 8x 10/100/1000
Hardware Button: None
Max. Power Consumption: 2.3W
Mounting: Desktop
Operating System: None
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 5V 1A Power Supply (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 5V
Dimensions: 143 x 72.7 x 26.9 mm
Weight: 215g

WAN Router Specs
Wireless Data Rates 2.4GHz (802.11n/g/b, MIMO 300Mbps) 5GHz (802.11ac/an/a, MIMO 867Mbps) LTE FDD: Max 300Mbps (DL)/50Mbps (UL) LTE TDD: Max 226Mbps (DL)/48Mbps (UL) 42 Mbps (DL)/11.5 Mbps (UL) WCDMA: Max 384Kbps (DL)/Max 384Kbps (UL)
Wireless Security 1 x WPS Button
Wired Interfaces 4 x GbE RJ45: 1 GbE WAN/LAN + 3 GbE LAN 2 x SIM Slots (Nano)

WAN Router Specs
Wireless Standards IEEE 802.11ac /n/g/a/b
Wireless Data Rates 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mpbs
Wireless Security WPA-PSK/WPA2-PSK, OPEN
Wired Interfaces 1 10/100Mbps self-adaptive LAN

WAN Router Specs
Wireless Standards 5 GHz - IEEE 802.11ac/n/a, 2.4 GHz - IEEE 802.11n/b/g
Wireless Data Rates 867Mbps (5 GHz), 300Mbps (2.4 GHz)
Wireless Security WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Wired Interfaces 1 × 1000/100/10 Mbps WAN Port, 4 × 1000/100/10 Mbps LAN Ports

Cudy AC1200 Wi-Fi VPN Travel Router (CD-TR1200)


The Cudy TR1200 AC1200 Dual Band Wi-Fi 5 Mini VPN Router is a compact and versatile networking solution designed for both home and travel use. With dual-band Wi-Fi speeds of up to 1167 Mbps, it ensures fast and reliable connections for multiple devices. Equipped with advanced features like MU-MIMO technology, beamforming, and mesh support, the TR1200 offers seamless coverage and efficient performance. Its robust security protocols, including WPA3 and DNS over TLS, safeguard your network, while the inclusion of various VPN protocols ensures secure remote access. The router's compact design, coupled with USB-C power input and multiple operation modes, makes it an ideal choice for users seeking flexibility and high performance in a portable package.

Cudy AC1300 High Gain USB Wi-Fi Adapter (WU1300S)
Product Code: CD-U1300
WAN Router Specs
Wireless Standards IEEE 802.11ac,IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Data Rates 11b: 1/2/5.5/11Mbps 11g: 6/9/12/18/24/36/48/54Mbps 11n: 400Mbps 11ac: 867Mbps
Wireless Security WPS,64/128bit WEP,WPA/WPA2,WPA-PSK/WPA2-PSK(TKIP/AES)
Wired Interfaces USB3.0 Hi-Speed connector

Cudy AC1300 High Gain USB Wi-Fi Adapter

The WU1400 is a AC1200 wireless dual band USB Adapter with a 5dBi high gain antenna for better signal reception and sensitivity. Selectable dual-band connections for lag-free HD video streaming and gaming, with speeds up to 400Mbps on the 2.4GHz frequency and up to 867Mbps on the 5GHz frequency. The WU1400 is compatible with a wide variety of operating systems, such as Windows Vista / Windows 7 / Windows 8 / Windows 8.1 / Windows 10, mac OS and Linux.
Specifications Antenna Gain: 5dBi (External)
Beam-width: 360°
Data Rate: 2.4GHz: 400Mbps 5.8GHz: 867Mbps
Frequency: 2.4Ghz & 5.8GHz
Operating Temperature: 0 - 40°
System Requirement: Windows Vista/7/8/8.1/10; mac OS; Linux

Dimensions: 190 x 90 x 40mm
Weight: 29g

AX3000 Gigabit Dual Band Wi-Fi 6 Router. Faster, Stronger, More Stable Wi-Fi than ever.
Super-Fast AX3000 Wi-Fi 6
1.3 GHz Dual-Core Cortex-A53 CPU
4× 10/100/1000Mbps Ethernet Ports
160 MHz Channel Width
DL/UL OFDMA and DL/UL MU-MIMO
Wireguard/OpenVPN/L2TP/PPTP VPN Server and Client
Cudy Mesh
IPv4/IPv6
TR069/TR098/TR181/TR111

Cudy's CD-CS700 is a USB-C docking station featuring 2x HDMI and 2x Display Ports, 2x 10Gbps USB-C 14W ports, 4x 10Gbps USB-A 5W ports, a 3.5mm Audio Jack and a Gigabit Ethernet Port. The unit also includes a 150W power adapter to support 100W upstream charging.

Specifications

Upstream Port: 1x USB-C
Video Output: 2x HDMI; 2x Display Port
Video Output Resolution: 5K @ 60Hz or 2x 4K @ 60Hz
USB Ports: 2x USB-C ; 4x USB-A
Audio & Mic: 1x 3.5mm Combo Jack
Ethernet Ports: 1x 10/100/1000
Power Input: 20V 7.5A Power Supply (Included)
Input Voltage: 20V 7.5A
Max Charging Output: 100W (Powered by Included Adapter)
Max Idle Power Consumption: 5W
Dimensions: 210 x 85 x 15.5 mm
Weight: 350g

Cudy's CD-WR1200 is a dual-band WiFi 5 wireless router featuring 5x Fast Ethernet ports, 4x 5dBi high gain antennas and an aggregate data rate of up to 1167Mbps. The router features a built in firewall and VPN client, IPv6 compatibility and is easily deployed using WPS.

*Note: Easily manage your Cudy devices on site (Local App Management Only) using the mobile app. No Cudy Mesh support. VPN client mode only.

Specifications

Antenna Gain: 4x 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 5x 10/100
Hardware Button: Reset ; WPS
Max. Power Consumption: 9W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None
Dimensions: 221 x 134.6 x 27.9 mm

Cudy's CD-WR1300 is a dual-band 802.11ac (WiFi 5) wireless router featuring 5x Gigabit Ethernet ports and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, DNS over TLS (DoT), and various VPN server or client protocols as well as TR-069. It also supports OpenWRT, a popular open-sourced firmware, which allows access to more features and customisation. Access the OpenWRT firmware for this router here.

*Note: Easily manage this device on site or remotely using the mobile app.

Specifications

Antenna Gain: 4x5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset ; WPS
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None
Dimensions: 250 x 240 x 40mm
Weight: 375g

Cudy's CD-M12002 is a 2 pack, dual band 802.11ac (WiFi 5) mesh system featuring 2x Fast Ethernet Ports, integrated antennas and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, seamless roaming and multiple VPN Client options including PPTP, L2TP, OpenVPN, WireGuard, IPSec and Zerotier.

*Note: Easily manage this device on site or remotely using the mobile app.
Antenna Gain: 2x 4dBi Internal Antennas
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100 (Per Mesh Point)
Hardware Button: Reset ; Pair
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None

Dimensions: 150 x 150 x 110mm
Weight: 405g

Cudy's CD-M12003 is a 3 pack, dual band 802.11ac (WiFi 5) mesh system featuring 2x Fast Ethernet Ports, integrated antennas and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, seamless roaming and multiple VPN Client options including PPTP, L2TP, OpenVPN, WireGuard, IPSec and Zerotier.

*Note: Easily manage this device on site or remotely using the mobile app.
Antenna Gain: 2x 4dBi Internal Antennas
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100 (Per Mesh Point)
Hardware Button: Reset ; Pair
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None

Dimensions: 150 x 150 x 110 mm
Weight: 900g

Cudy's CD-M12001 is a dual band 802.11ac (WiFi 5) mesh router featuring 2x Fast Ethernet Ports, integrated antennas and an aggregate data rate of up to 1167Mbps. The router supports Cudy's whole home mesh system, seamless roaming and multiple VPN Client options including PPTP, L2TP, OpenVPN, WireGuard, IPSec and Zerotier.

*Note: Easily manage this device on site or remotely using the mobile app.

Specifications

Antenna Gain: 2x 4dBi Internal Antennas
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset ; Pair
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 12V 1A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V 1A
USB Ports: None

Cudy's CD-RE1200 is a dual band 802.11ac (WiFi 5) range extender featuring 1x Fast Ethernet Ports, 2x 5dBi high gain antennas and an aggregate data rate of up to 1167Mbps. The range extender supports Cudy's whole home mesh system and can operate in both range extender and access point mode.

Specifications

Antenna Gain: 2x 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset ; Pair
Max. Power Consumption: 10w
Mounting: Plug Point
Operating System: Cudy
Operating Temperature: 0° to 40°
PoE Input: None
PoE Output: None
Power Input: 2 Pin 5A
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 110V-240V
USB Ports: None
Dimensions: 130 x 80 x 100mm
Weight: 310g

Cudy's CD-AP1300O is an IP65 outdoor dual-band WiFi 5 (802.11ac) Access Point. The unit features detachable 5dBi antennas, a Gigabit Ethernet port and an aggregate wireless data rate of up to 1167Mbps. The unit accepts a wide voltage range of 24V-57V and includes mounting kits for both wall and pole mount. This Access Point supports multiple VPN options including PPTP, L2TP, OpenVPN, Wire Guard, IPSec and Zero Tier. It also features support for Cudy's whole home mesh system. When used with either the CD-WR1300, CD-WR3000, CD-M1300, CD-M1800 or CD-M30001 as the main router running the latest firmware, the AP can be easily adopted onto the existing network.

Specifications

Antenna Gain: 2x 5dBi Detachable Antennas
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset ; WPS
Max. Power Consumption: 10W
Mounting: Wall or Pole-Mount
Operating System: Cudy
Operating Temperature: -20 to 60°
PoE Input: 24-57V
PoE Output: None
Power Input: 48V 0.3A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24-57V
USB Ports: None
Dimensions: 240 × 100 × 53.7 mm

Cudy's CD-U1400 is a dual band 802.11ac (Wi-Fi 5) wireless USB adapter featuring a 5dBI external antenna and an aggregate data rate of up to 1267Mbps.

Specifications

Antenna Gain: 5dBi (External)
Beam-width: 360°
Data Rate: 2.4GHz: 400Mbps 5.8GHz: 867Mbps
Frequency: 2.4Ghz & 5.8GHz
Operating Temperature: 0 - 40°
System Requirement: Windows Vista/7/8/8.1/10; mac OS; Linux
Dimensions: 190 x 90 x 40mm
Weight: 29g
