Ubiquiti Wave‑Pro 60GHz/5GHz Radio
Brand: Ubiquiti
Product Code: WAVE‑PRO
Description: Ubiquiti UISP 60GHz/5GHz Wave Professional Radio
Product Overview
The Ubiquiti Wave‑Pro is a high‑capacity 60GHz radio system with a 5GHz backup radio, designed for professional long‑range wireless deployments. Featuring an integrated high‑gain antenna, 2 × 2.5Gbps Ethernet ports, 1 × 10Gbps SFP+ uplink, and integrated GPS, it delivers true duplex gigabit performance for PtP links up to 15km. In PtMP mode, it can operate as a CPE when paired with the Wave‑AP (up to 8km) or Wave‑APM (up to 6km), achieving a total throughput of up to 5.4Gbps. The unit includes a Bluetooth management radio for easy setup via the UISP platform, plus a precision alignment tool for reliable antenna positioning.
Key Features
High‑capacity 60GHz radio with 5GHz backup
True duplex gigabit PtP links up to 15km
PtMP mode: CPE with Wave‑AP (8km) or Wave‑APM (6km)
Aggregate throughput up to 5.4Gbps
Integrated GPS and precision mount bracket
Built‑in Bluetooth management radio for easy setup
2 × 2.5Gbps Ethernet ports + 1 × 10Gbps SFP+ uplink
Antenna gain: 60GHz 46dBi; 5GHz 22dBi
Beamwidth: 60GHz 1.3°; 5GHz 8°
Max power consumption: 26W
Operating temperature: –40°C to 60°C
Dimensions: Ø424.4 × 166.2 mm
Net weight: 4kg
Gross shipping weight: 5.0–5.5 kg (including packaging)
Note: Firmware v3.2.0 or later required for PtP links
Technical Specifications
Feature Details
Product Code WAVE‑PRO
Antenna Gain 60GHz: 46dBi; 5GHz: 22dBi
Beamwidth 60GHz: 1.3°; 5GHz: 8°
Data Rate 60GHz: up to 5.4Gbps; 5GHz: 800Mbps
Ethernet Ports 2 × 10/100/1000/2500
SFP+ Port 1 × 10Gbps
Hardware Button Reset
Max Power Consumption 26W
Mounting Pole‑mount
Operating System airOS
Operating Temp –40°C to 60°C
PoE Input 44–54V or 22–27V Passive PoE
PoE Output None
Power Input 48V 0.65A Gigabit PoE Injector (included)
Dimensions Ø424.4 × 166.2 mm
Net Weight 4kg
Gross Shipping Weight 5.0–5.5 kg
What’s Included
1 × Ubiquiti Wave‑Pro Radio
1 × 48V 0.65A Gigabit PoE Injector
Precision alignment tool
Pole‑mounting kit
User documentation
