Reyee RG-EST350 V2 5GHz Wireless Bridge Dual-Stream 802.11ac, 5KM Range, 867Mbps, IP54 Outdoor Rated SKU: RG-EST350-V2
The Reyee RG-EST350 V2 Wireless Bridge is a high-performance outdoor solution designed for long-range, real-time data transmission. Operating on 5GHz dual-stream 802.11ac (Wi-Fi 5 Wave2), it delivers speeds up to 867Mbps and supports MU-MIMO 2×2 for efficient multi-device communication.
With a 15dBi directional antenna, it can transmit data up to 5KM, making it ideal for surveillance, remote access, and point-to-point networking. The bridge supports up to 45 × 2MP cameras at 3KM and 20 × 2MP cameras at 5KM, ensuring robust throughput for high-density deployments.
Installation is simplified with automatic long-distance pairing, eliminating complex alignment procedures. Rated IP54 weatherproof and built to operate in extreme temperatures from -30°C to 65°C, it’s engineered for reliable outdoor performance. Remote monitoring and maintenance are made easy via Ruijie Cloud, offering intuitive statistics and control.
Key Features
🌐 5GHz Dual-Stream Wi-Fi 5 (802.11ac Wave2) – Fast and stable wireless transmission
📡 15dBi Directional Antenna – Optimized for long-range point-to-point links
🚀 Up to 867Mbps Speed – High bandwidth for real-time data and video
🔄 Automatic Long-Distance Pairing – No complex alignment required
🛡️ IP54 Weatherproof Rating – Built for outdoor environments
❄️ Wide Operating Temperature – -30°C to 65°C for extreme conditions
📷 Supports 45 × 2MP Cameras @ 3KM / 20 @ 5KM – Ideal for surveillance networks
📊 Ruijie Cloud Monitoring – Remote management and performance stats
🔌 2 × Gigabit Ethernet Ports – Seamless wired integration
🕒 3-Year Manufacturer Warranty – Long-term reliability
Technical Specifications
Feature Details
Product Code RG-EST350-V2
Wireless Standard Wi-Fi 5 (IEEE 802.11ac Wave2)
Frequency Band 5GHz
Wi-Fi Speed Up to 867Mbps
Antenna Gain 15dBi Directional
MIMO 2×2 MU-MIMO
Transmission Range Up to 5KM
Wireless Power ≤400mW (26dBm, adjustable)
Ethernet Ports 2 × 10/100/1000Base-T
Operating Temperature -30°C to 65°C
Weatherproof Rating IP54
Certifications CE, RoHS
Environment Outdoor
Warranty 3 Years Limited Manufacturer Warranty
What’s Included
1 × Reyee RG-EST350 V2 Wireless Bridge
1 × Mounting Kit
1 × Quick Start Guide
