HiLook 5 Port Gigabit Unmanaged Desktop Switch | DS-3E0505D-E

The HiLook 5-port, unmanaged, Gigabit desktop switch is designed for small-scale IP surveillance networks or networking applications.
The plug-and-play design simplifies installation without any configuration requirements, and its compact size minimizes the space required.


General
Dimensions (W × H × D)92.80 mm × 65.80 mm × 22.80 mm (3.65'' × 2.60'' × 0.90'')
ShellABS
Net Weight0.03 kg (0.07 lb)
Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity10%~90% RH non-condensing
Storage Temperature–40 °C to 70 °C (–40 °F to 158 °F)
Storage Humidity5%~90% RH non-condensing
Power Supply5 V DC, 0.6 A

Network Parameters
Ports5
Port Type10/100/1000 Mbps RJ45 ports
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab
Forwarding ModeStore-and-forward switching
MAC Address Table2 K
Switching Capacity10 Gbps
Packet Forwarding Rate7.44 Mpps
