Cudy CD‑GP1200 xPON Wi‑Fi 5 AX1200 Dual‑Mode Router
The Cudy CD‑GP1200 xPON Wi‑Fi 5 Router is a versatile dual‑mode solution supporting both GPON and EPON networks. Equipped with 4‑stream dual‑band Wi‑Fi 5, it delivers speeds of 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz, ensuring smooth connectivity for multiple devices.
With a SC/APC slot and 4 Gigabit Ethernet ports, the router provides flexible wired and wireless networking. It supports CWMP, OMCI, 4‑queue QoS, and Easy Mesh, making it ideal for ISPs and home users seeking reliable performance.
Compact at 173 × 123.8 × 33 mm and weighing just 288 g, the router consumes only 9.6W and offers a 20 km transmission distance. Powered by a 12V 1A adapter (included), it is designed for desktop or wall‑mount installation.
Technical Details:
Model / SKU: CD‑GP1200
Wi‑Fi Standard: Wi‑Fi 5 (dual‑band, 4‑stream)
Data Rates:
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
GPON: 2.488 Gbps downstream / 1.244 Gbps upstream
EPON: 1.25 Gbps downstream / upstream
Ports: 1 × SC/APC slot, 4 × Gigabit Ethernet
Antenna Gain: 2 × 5 dBi, 360° beam‑width
Power Consumption: Max 9.6W
Transmission Distance: Up to 20 km
Buttons: Power, Reset, WPS, Wi‑Fi On/Off
Operating System: Cudy OS
Operating Temperature: 0°C to 40°C
Dimensions: 173 × 123.8 × 33 mm
Weight: 288 g
Mounting: Desktop or wall‑mount
Power Input: 12V 1A (PSU included)
Features: CWMP, OMCI, QoS (4 queues), Easy Mesh
